Roland LEF-300 Use and care manual

Master Guide
Chapter 1
FullyUtilizing the Machine..................3
Chapter 2
Maintenance............................................41
Chapter 3
Appendix...................................................73

Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be
sure to read through this manual completely and store it in a safe location.
• Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.
• The contents of this manual and the specications of this product are subject to change without notice.
• The manual and the product have been prepared and tested as much as possible. If you nd any
misprints or errors, please inform Roland DG Corp.
• Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage that may occur
through use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage that may occur with
respect to any article made using this product.
This product uses GNU General Public License (GPL)/GNU Lesser General Public License (LGPL) software.
You have the right to acquire, modify, and distribute the source code for this GPL/LGPL software. You
can obtain the GPL/LGPL source code used in this product by downloading it from the Roland DG Corp.
website. See the following URL for details on the basic method for acquiring the source code.
URL: http://www.rolanddg.com/gpl/
Roland DG Corporation has licensed the MMP technology from the TPL Group.
This system (including the housing and safety device) is a Class 1 laser product.
Complies with IEC 60825-1 Edition 2.0 (2007-03).
Complies with FDA performance standards for laser products except for deviations pursuant to Laser
notice No.50 dated June 24, 2007.
Caution - Use of controls or adjustments or performance of procedures other than those specied
herein may result in radiation exposure.

1
Contents � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �1
Chapter 1 FullyUtilizing the Machine 3
Important Points to Check before Printing � � � � � �4
Three Important Points (Measures for UV
Reected Light and Ink Mist). . . . . . . . . . . . . . . . . .4
Saving Frequently Used Media Sizes (Preset
Function)� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �6
Saving the Current Media Setup with a
Dierent Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Load a Preset and Print . . . . . . . . . . . . . . . . . . . . . . .7
Make Fine Adjustments of Preset Settings
and Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Performing Advanced Setup of the Media� � � � � � � 9
Media Suction Function Setting. . . . . . . . . . . . . . .9
Setting the Height of the Media Manually . . . . .9
Expanding the Distance between the Media
and the Print Heads . . . . . . . . . . . . . . . . . . . . . . . . .11
Setting the Print Area for Each Setup of
Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Changing the Print Area . . . . . . . . . . . . . . . . . . . . .13
Setting the Print Area Using the Lower
Right of the Media as the Base Position. . . . . . .14
Check the Print Area . . . . . . . . . . . . . . . . . . . . . . . . .19
Optimizing the Printing Quality � � � � � � � � � � � � � � �20
Correcting for Misalignment in Bidirectional
Printing (Simple) . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Correcting for Misalignment in Bidirectional
Printing More Precisely (Detailed) . . . . . . . . . . . .21
Preventing Soiling and Dot Drop-Out by
Cleaning during Printing. . . . . . . . . . . . . . . . . . . . .24
Reducing Print Quality Degradation from
Ink Mist (Ink Spatter). . . . . . . . . . . . . . . . . . . . . . . . .25
Re-Curing Ink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Fully Utilizing Convenient Functions � � � � � � � � � � �27
Continuing Printing Even If Media Comes
into Contact with the Head Gap Sensor . . . . . .27
Continuously Outputting Print Data. . . . . . . . . .28
Reducing Output Time. . . . . . . . . . . . . . . . . . . . . . .30
Conguring the Machine's Settings � � � � � � � � � � � �31
Setting the Menu Language and the Units
of Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Setting the Activation Interval for Sleep
Mode (Power-saving Feature) . . . . . . . . . . . . . . . .32
Deactivating the Sleep Mode (Power-saving
Feature) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Returning All Settings to Their Factory
Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Determining What Happens When Ink Runs
Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Viewing Information about the System of
This Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Turning O the Status Light. . . . . . . . . . . . . . . . . .37
Connecting External Devices � � � � � � � � � � � � � � � � � �38
Connecting the Signal Tower. . . . . . . . . . . . . . . . .38
Using Expansion Terminal B to Connect an
External Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Chapter 2 Maintenance 41
About Maintenance� � � � � � � � � � � � � � � � � � � � � � � � � � �42
Instructions for Maintenance . . . . . . . . . . . . . . . .42
Automatic Maintenance Function and Notes .42
Alarm Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Maintenance Required before and after
Printing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �43
Maintenance Required before Printing . . . . . . .43
Maintenance Required after Printing . . . . . . . . .43
Periodic Maintenance � � � � � � � � � � � � � � � � � � � � � � � � �44
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Disposing of Discharged Fluid . . . . . . . . . . . . . . .46
When Normal Cleaning Is Not Eective� � � � � � � � �49
Medium and Powerful Cleaning. . . . . . . . . . . . . .49
Maintenance That Must Be Performed Once a
Month or More � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �52
Manual Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Checking for Remaining Ink and Replacing
Ink Cartridges � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �57
Checking for Remaining Ink. . . . . . . . . . . . . . . . . .57
How to Replace Ink Cartridges . . . . . . . . . . . . . . .58
When the White Ink Concentration Is Low � � � � � �60
Restoring the White Ink Concentration . . . . . . .60
When Dot Drop-Out Cannot Be Cleared Up for
White Ink, Gloss Ink, or Primer � � � � � � � � � � � � � � � � �61
Cleaning All Print Heads . . . . . . . . . . . . . . . . . . . . .63
Replacing Consumable Parts � � � � � � � � � � � � � � � � � �66
Replacing the Wipers . . . . . . . . . . . . . . . . . . . . . . . .66
Replacing the Filter . . . . . . . . . . . . . . . . . . . . . . . . . .69
When Moving the Unit � � � � � � � � � � � � � � � � � � � � � � � �73
Procedure from Preparing to Move to
Reinstallation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Contents

Contents
2
Chapter 3 Appendix 75
Menu List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �76
Main Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Function Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Language and Unit Menu. . . . . . . . . . . . . . . . . . . .79
Read This Section Whenever You Face a
Problem (FAQ) � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �80
Printer Does Not Run . . . . . . . . . . . . . . . . . . . . . . . .80
Attractive Printing Is Impossible. . . . . . . . . . . . . .82
The Print Heads Do Not Move. . . . . . . . . . . . . . . .84
Handling Messages and Error Messages� � � � � � � �85
A Message Appears. . . . . . . . . . . . . . . . . . . . . . . . . .85
An Error Message Appears . . . . . . . . . . . . . . . . . . .87
Main Specications � � � � � � � � � � � � � � � � � � � � � � � � � � �89
Dimensional Drawings. . . . . . . . . . . . . . . . . . . . . . .89
Locations of the Power Rating and Serial
Number Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Specications and Diagrams for the
External Expansion Terminal . . . . . . . . . . . . . . . . .90
Specication Table . . . . . . . . . . . . . . . . . . . . . . . . . .93
Company names and product names are trademarks or registered trademarks of their respective holders.
http://www.rolanddg.com/
Copyright © 2015-2016 Roland DG Corporation

3
Important Points to Check before Printing ......4
Three Important Points (Measures for UV
Reected Light and Ink Mist)..................4
Saving Frequently Used Media Sizes (Preset
Function)......................................6
Saving the Current Media Setup with a
Dierent Name ...............................6
Load a Preset and Print .......................7
Make Fine Adjustments of Preset Settings
and Print .....................................8
Performing Advanced Setup of the Media.......9
Media Suction Function Setting...............9
Setting the Height of the Media Manually .....9
Expanding the Distance between the Media
and the Print Heads ........................ 11
Setting the Print Area for Each Setup of
Media ...................................... 12
Changing the Print Area .................... 13
Setting the Print Area Using the Lower Right
of the Media as the Base Position ........... 14
Check the Print Area ........................ 19
Optimizing the Printing Quality .............. 20
Correcting for Misalignment in Bidirectional
Printing (Simple) ........................... 20
Correcting for Misalignment in Bidirectional
Printing More Precisely (Detailed) ........... 21
Preventing Soiling and Dot Drop-Out by
Cleaning during Printing.................... 24
Reducing Print Quality Degradation from
Ink Mist (Ink Spatter)........................ 25
Re-Curing Ink .............................. 26
Fully Utilizing Convenient Functions .......... 27
Continuing Printing Even If Media Comes
into Contact with the Head Gap Sensor ..... 27
Continuously Outputting Print Data......... 28
Reducing Output Time...................... 30
Conguring the Machine's Settings ........... 31
Setting the Menu Language and the Units
of Measurement............................ 31
Setting the Activation Interval for Sleep
Mode (Power-saving Feature) ............... 32
Deactivating the Sleep Mode (Power-saving
Feature) .................................... 33
Returning All Settings to Their Factory
Default Values .............................. 34
Determining What Happens When Ink Runs
Out ........................................ 35
Viewing Information about the System of
This Machine ............................... 36
Turning O the Status Light................. 37
Connecting External Devices ................. 38
Connecting the Signal Tower................ 38
Using Expansion Terminal B to Connect an
External Device............................. 39
Chapter 1
FullyUtilizing the
Machine

4 Chapter 1 FullyUtilizing the Machine
Three Important Points (Measures for UV Reected Light and Ink Mist)
On this machine, ink axed on the surface of the print heads might be cured by the reection of the UV-LED
lamp light and by ink mist (ink splashing during printing). If ink axed on the surface of the print heads is
cured, dot drop-outs may occur. Continued use of the product in this state may cause a failure that requires
the replacement of the print heads.
While daily cleaning is important to prevent dot drop-outs, there are also three important points to check
before printing. Be sure to check the three points given below.
1. You cannot use an object that easily reects light as the object to be printed on (the media).
Materials that are likely to reect the UV-LED lamp light, such as mirrors and stainless steel, promote the
curing of the surface of the print heads and therefore cannot be used as the object to be printed on (the
media).
2. Make the distance between the surface of the object to be printed on (the
media) and the print heads as short as possible.
As the distance between the surface of the object to be printed on (the media) and the print heads increases,
the likelihood of ink mist increases. When setting the height of the media manually, make the distance as
short as possible. When the height is automatically set, the distance is about 1 mm (39.4 mil).
""2. Setting the Height of the Media Automatically" (First Step Guide)
"“Setting the Height of the Media Manually” (p. 9)
About 1 mm (automatic setting)
Object to be printed on (media)
Print heads
Important Points to Check before Printing

Important Points to Check before Printing
5Chapter 1 FullyUtilizing the Machine
3. A jig might be required depending on the size and shape of the object to be
printed on (the media).
Depending on the size and shape of the object to be printed on (the media), the distance between the
object to be printed on (the media) and the print heads may increase, which will increase the likelihood of
ink mist occurring. In the direction of print heads movement, the object to be printed on (the media) or a jig
must be present in the area 40 mm (1.6 in.) to both the right and left of the portion (width) of the data to be
printed. In this situation, the dierence in height between the surfaces of the object to be printed on (the
media) and the jig must be less than 2 mm (78.7 mil).
""2. Setting the Height of the Media Automatically" (First Step Guide)
"“Setting the Height of the Media Manually” (p. 9)
"“Height Settings When the Print Surface is Uneven” (p. 10)
When a jig is required:
• The object to be printed on (the media) is not large enough to spread over the area 40 mm to both the right
and left of the portion (width) of the data to be printed.
• The variation in height of the surface of the object to be printed on (the media) is 2 mm or more.
Print heads
Object to be printed on (media)
40 mm or longer 40 mm or longer
Flat table
Jig
Data
Less than 2 mm in
height dierence from
the actual print surface
Print heads
Object to be printed on (media)
Flat table
Data
Jig
Less than 2 mm
from the highest
position
Jig
40 mm or longer 40 mm or longer
There are conditions for the height settings when the surface of the object to be printed on (the media) has a
height dierence. For more information, refer to“Height Settings When the Print Surface is Uneven” (p. 10).

6 Chapter 1 FullyUtilizing the Machine
Saving Frequently Used Media Sizes (Preset Function)
You can save media settings in presets. If you save the settings of frequently used media, you can load them
instantly and shorten the time required for conguring settings.
Saving the Current Media Setup with a Dierent Name
The following settings congured in the media setup can be saved as a preset. You can save up to 40 dierent
presets.
• Height position of the media
• Print area (including the print-start location)
You can assign a name to each preset. Using media names for these presets may aid recognition.
Procedure
1. Set up the media (height position, print area), and then check that [SETUP] is lit.
2. Press [MENU].
3. Press [ ], then [ ].
PRESET
SAVE
4. Press [ ].
5. Press [ ] or [ ] to select one option from NAME1 to NAME40.
SAVE
NAME1
6. Press [ENTER].
The current "height position of the media" and "print area" settings are saved.
7. Press [ ] or [ ] to enter a character.
SET NAME
S
8. When you have selected the character you want to enter, press [ ].
The characters you can enter are "A" through "Z," "0" through "9," and the "-" character. You can enter up to
15 characters, including spaces.
SET NAME
SAMPLE

Saving Frequently Used Media Sizes (Preset Function)
7Chapter 1 FullyUtilizing the Machine
9. Press [ ] or [ ] to enter the next character.
Enter the following characters in the same way.
10. When you have nished entering text, press [ENTER].
11. Press [MENU], then [ ] to go back to the original screen.
Load a Preset and Print
Load the settings saved in a preset and perform printing.
NOTE
Be sure to hold the handle of the front cover and open and close it gently.
Procedure
1. Press [MENU].
2. Press [ ] twice.
LOAD
DEFAULT
3. Press [ ] or [ ] to select the name of the preset (settings) you want to load.
Select one of the 40 types of presets (when no names have been assigned, select from NAME1 to NAME40)
or DEFAULT (DEFAULT is the factory defaults for each setting).
4. Press [ENTER].
SETUP MEDIA
Media setup is canceled ([SETUP] turns o ).
5. Open the front cover, and then secure the media in place.
""1. Loading Media (Media Setup)" (First Step Guide)
6. Press [SETUP].
The loaded preset settings are displayed.
HEIGHT:000.0mm
7. Press [ENTER].
W:770mm L:330mm
H:100mm

Saving Frequently Used Media Sizes (Preset Function)
8 Chapter 1 FullyUtilizing the Machine
MEMO
Every time you set up the media, you can set the print area (base position and range). For details, refer to
“Setting the Print Area for Each Setup of Media”(p. 12).
8. Start printing.
Printing is performed with the loaded preset settings.
Make Fine Adjustments of Preset Settings and Print
You can change part of a preset and then perform printing.
For instance, you can change the print area only without changing the media height setting.
Procedure
1. Load a preset and x the position of the media by following steps 1 to 7 of“Load a Preset and Print” (p.
7).
2. If you want to change the height setting of the media, set the height of the media.
"Steps 2 to 5 of "2. Setting the Height of the Media Automatically" (First Step Guide)
"Steps 4 and 5 of “Setting the Height of the Media Manually” (p. 9)
3. If you want to change the print area, set the print area.
"“Changing the Print Area” (p. 13)
4. Start printing.

9Chapter 1 FullyUtilizing the Machine
Performing Advanced Setup of the Media
Media Suction Function Setting
The at table suctions the media to make it hard to move and easy to load.
Procedure
1. Press [PAUSE/VACUUM].
The suction function turns on (or o ).
The Suction Function Cannot Be Changed In the Following Situations
• During setup processing
• When the MENU/FUNCTION menu is displayed
• During printing (when printing is paused or is being canceled)
• When an error is displayed
CAUTION!
The suction function cannot be used to hold in place curled or thick media. Secure the media in place using
a substance such as commercially available tape axed directly to the at table.
Setting the Height of the Media Manually
Manually set the height of the media for printing.
Although the manual setting takes a little longer than the automatic setting because you need to visually set
the height, it is suitable when you do not want the head gap sensor to come in contact with the media and
when you want to set the distance between the heads and the media.
* If the print surface is uneven, there is a limit to the area of unevenness.
"“Height Settings When the Print Surface is Uneven” (p. 10)
NOTE
Be sure to hold the handle of the front cover and open and close it gently.
Procedure
1. Secure the media in place on the at table.
""1. Loading Media (Media Setup)" (First Step Guide)
2. Close the front cover.
SETUP MEDIA
3. Press [SETUP].
[SETUP] starts to ash.

Performing Advanced Setup of the Media
10 Chapter 1 FullyUtilizing the Machine
4. Press [ ], [ ], [UP], or [DOWN] to move the at table.
Move the head gap sensor as close as possible to the print surface.
This step can be performed with the front cover open.
NOTE
Set the height of the table in a way that the highest position of the media (print surface) will not come into
contact with the head gap sensor.
When the screen shown in the gure appears
AUTO DETECTION
Press [ENTER] on this screen to start the automatic detection of the height. During automatic detection,
the head gap sensor comes into contact with the media.
If you do not want to perform automatic detection, press [ ] to return to the original screen.
5. If the front cover is open, close it.
6. When the location is set, press [ENTER].
7. Perform the procedure in “Correcting for Misalignment in Bidirectional Printing (Simple)” (p. 20).
Height Settings When the Print Surface is Uneven
This machine can also print on uneven surfaces. However, note the following points regarding the height
setting.
Head gap sensor
Get as close as you possibly can.
Media
HEIGHT:000.0mm

Performing Advanced Setup of the Media
11Chapter 1 FullyUtilizing the Machine
The gap between the "highest position of the media" and the "lowest position
of the print surface" should be 2 mm (78.7 mil) or less (as a general guide).
The print quality at the lower position degrades as the height gap widens.
Max. 2 mm (as a
general guide)
Highest position of
the media
Lowest position of
the print surface Media
Printing on a surface that is perpendicular to the print heads is not possible.
Printing on this surface is not possible.
Print heads
Media
Expanding the Distance between the Media and the Print Heads
When you set the height of the media automatically (First Step Guide), the distance between the media and
the print heads is set to 1.0 mm (39.4 mil) with which optimum printing is performed. However, if the height
(thickness) of the media on which printing is performed varies or when the media is lifted or warped during
printing, the media might come into contact with the print heads.
You can expand the distance in advance considering the change of the height (thickness) of the media.
NOTE
• If the distance is expanded too much, the print quality may be deteriorated and the nozzles of the print
heads may be clogged. Congure the settings so that the distance between the highest position of the
media and the lowest position of the print surface is 2 mm or less (p. 11).
• This setting is enabled when the height of the media is set automatically.
""2. Setting the Height of the Media Automatically" (First Step Guide)
Procedure
1. Press [MENU].

Performing Advanced Setup of the Media
12 Chapter 1 FullyUtilizing the Machine
2. Press [ ] twice to display the screen shown below.
MENU
SUB MENU
3. Press [ ].
4. Press [ ] several times to display the screen shown below.
SUB MENU
AUTO DOWN
5. Press [ ].
AUTO DOWN
0.0mm 1.5mm
6. Press [ ] or [ ] to set the distance between the media and the print heads.
You can adjust the distance in increments of 0.1 mm (3.9 mil).
AUTO DOWN Distance between the media and the print heads
0.0 mm (Default settings) to 2.0 mm (0.0 to 78.7 mil) 1.0 mm to 3.0 mm (39.4 to 118.1 mil)
7. Press [ENTER].
8. Press [MENU], then [ ] to go back to the original screen.
9. Perform the procedure in “Correcting for Misalignment in Bidirectional Printing (Simple)” (p. 20).
Setting the Print Area for Each Setup of Media
Usually, when you set up the media, the print area and the base position from the previous setup are set.You
can change them every time you set up the media.
Procedure
1. Press [MENU].
2. Press [ ] twice to display the screen shown below.
MENU
SUB MENU
3. Press [ ] twice.
SET AT SETUP
ENABLE DISABLE

Performing Advanced Setup of the Media
13Chapter 1 FullyUtilizing the Machine
4. Press [ ] or [ ] to select a value.
SET AT SETUP Explanation
DISABLE
(Default setting)
Setup is performed using the print area of the previous setup.
The factory default print area is the full area (770 × 330 mm [30.3 × 13 in.]).
This setting is suitable when you always perform printing on media of a xed size.
ENABLE
Set the print area (base position, width, and length of the print area) every time you set
up the media.
Select this value when the media shape changes for each printing operation.
5. Press [ENTER].
6. Press [MENU], then [ ] to go back to the original screen.
Changing the Print Area
In the factory defaults, the base position (home position) of the print area is at the right front of the at table
and the print area is the full area (770 × 330 mm [30.3 × 13 in.]).
The base position of the print area should be changed according to the shape of the media.
You can reduce the print time if you narrow (limit) the print area.
Determining the Base Position of the Print Area (Home Position)
Determine the home position used as the base to set the print area.
1. Press [MENU].
2. Press [ ] twice to display the screen shown below.
MENU
SUB MENU
3. Press [ ].
4. Press [ ] to display the screen shown below.
SUB MENU
SET BASE POS.
5. Press [ ].
SET BASE POS.
LOWER R LOWER R

Performing Advanced Setup of the Media
14 Chapter 1 FullyUtilizing the Machine
6. Press [ ] or [ ] to select the base position.
SET BASE POS. Print Object
LOWER R
Set the base position (home position) at the front right of the print area. This method is appropriate
when the print site is level and you can clearly specify the print area.
“Setting the Print Area Using the Lower Right of the Media as the Base Position”(p. 14)
CENTER
Set the base position at the center of the media. This method is appropriate when clear specication of
the print area is dicult or when the print site is curved or uneven.
“Setting the Print Area Using the Center of the Media as the Base Position” (p. 16)
7. Press [ENTER].
MEMO
Every time you set up the media, you can set the print area (base position and range). For details, refer to
“Setting the Print Area for Each Setup of Media”(p. 12).
8. Press [MENU], then [ ] to go back to the original screen.
Setting the Print Area Using the Lower Right of the Media as the Base Position
This is the print area setting method when the print site is level and you can clearly specify the print area.
MEMO
Print area setup can be performed with the front cover open. However, if the front cover is left open for
approximately 40 seconds, the print heads automatically return to the home position. The previous menu
is displayed, so repeat the operations.
NOTE
Be sure to hold the handle of the front cover and open and close it gently.
Procedure
1. Set “SET AT SETUP” (p. 13) to "ENABLE."
2. Set “SET BASE POS.” (p. 14) to "LOWER R."
3. Set up the media.
""STEP 2: Loading Media and Setting the Height" (First Step Guide)
4. Press [ ], [ ], [ ], or [ ] when the following screen appears.
SCAN: 000.0mm
FEED: 000.0mm
The at table moves to the rear, the print heads move to above the at table, and the laser pointer turns on.

Performing Advanced Setup of the Media
15Chapter 1 FullyUtilizing the Machine
5. Press [ ], [ ], [ ], or [ ] to move the laser pointer until it points to a position to the right foreground of
the print area.
6. Press [ENTER].
The print heads return to the home position.
WIDTH: 000.0mm
LENGTH:000.0mm
MEMO
When the media comes into contact with the head gap sensor, the screen shown below appears and the
setup is canceled. Perform operations again from "2. Setting the Height of the Media Automatically" (First
Step Guide) or “Media Suction Function Setting”(p. 9).
CHECK TABLE
HEIGHT
7. Press [ ], [ ], [ ], or [ ].
The at table moves to the front and the print heads move to the left side of the at table.
8. Press [ ], [ ], [ ], or [ ] to move the laser pointer until it points to a position to the inner left of the print area.
Right foreground of the print area
Inner left of the print area

Performing Advanced Setup of the Media
16 Chapter 1 FullyUtilizing the Machine
MEMO
For a test print, set "WIDTH" to 80 mm (3.2 in.) or more and "LENGTH" to 70 mm (2.8 in.) or more. An error
will occur and test prints cannot be performed if the area is smaller than this.
9. Press [ENTER].
10. If the front cover is open, close it.
The print area is specied. The print heads return to the home position.
Make sure the "W" (width), "L" (length), and "H" (height) values on the menu screen are as intended.
W:770mm L:330mm
H:100mm
MEMO
If you want to use the print area specied here for the next printing operation, switch “SET AT SETUP” (p.
13) to "DISABLE." With this setting, you can set up the media without setting the print area and base
position.
Setting the Print Area Using the Center of the Media as the Base Position
This is the print area setting method that is appropriate when printing on media for which it is dicult to
clearly specify the print area or when the print site is curved or uneven.
MEMO
Print area setup can be performed with the front cover open. However, if the front cover is left open for
approximately 40 seconds, the print heads automatically return to the home position. The previous menu
is displayed, so repeat the operations.
NOTE
Be sure to hold the handle of the front cover and open and close it gently.
Procedure
1. Set “SET AT SETUP” (p. 13) to "ENABLE."
2. Set “SET BASE POS.” (p. 14) to "CENTER."
3. Set up the media.
""STEP 2: Loading Media and Setting the Height" (First Step Guide)
4. Press [ ], [ ], [ ], or [ ] when the following screen appears.
SCAN: 000.0mm
FEED: 000.0mm
The at table moves to the rear, the print heads move to above the at table, and the laser pointer turns on.

Performing Advanced Setup of the Media
17Chapter 1 FullyUtilizing the Machine
5. Press [ ], [ ], [ ], or [ ] to move the laser pointer until it points to the center position of the area you
want to print.
6. Press [ENTER].
The print heads return to the home position.
WIDTH: 000.0mm
LENGTH:000.0mm
MEMO
When the media comes into contact with the head gap sensor, the screen shown in the gure appears and
the setup is canceled. Perform operations again from "2. Setting the Height of the Media Automatically"
(First Step Guide) or “Media Suction Function Setting”(p. 9).
CHECK TABLE
HEIGHT
7. Press [ ] or [ ] to enter the length of the area you want to print.
8. Press [ ] or [ ] to enter the width of the area you want to print.
MEMO
For a test print, set "WIDTH" to 80 mm (3.2 in.) or more and "LENGTH" to 70 mm (2.8 in.) or more. An error
will occur and test prints cannot be performed if the area is smaller than this.
9. If the front cover is open, close it.
10. Press [ENTER].
The print area is specied. The print heads return to the home position.
Make sure the "W" (width), "L" (length), and "H" (height) values on the menu screen are as intended.
W:770mm L:330mm
H:100mm

Performing Advanced Setup of the Media
18 Chapter 1 FullyUtilizing the Machine
MEMO
If you want to use the print area specied here for the next printing operation, switch “SET AT SETUP” (p.
13) to "DISABLE." With this setting, you can set up the media without setting the print area and base
position.
Specifying the minimum print area enables print time reductions
Set "FULL WIDTH S" to "PRTAREA" to narrow the width in which the print heads move, which reduces
the print time.
"“Reducing Output Time” (p. 30)
Example of good settings Example of bad settings
The blank area in
the print area is
minimized.
The print area
has a lot of
unnecessary
blank areas.
This function is eective when the print area or output data has a small width.
When the laser pointer is dicult to see
Depending on the material used on the media, such as transparent media and high-gloss media with
dark color used on the print surface, the laser pointer may be dicult to see. In such cases, the laser
pointer may become more visible by placing masking tape on the print surface or on the back.
