Roller Grill SBC 40 F User manual

304180 en ma 2016-02 1/8
USER INSTRUCTIONS
REFRIGERATED SQUARE SALAD’BAR(*304.180)
You should read these user instructions carefully before using the appliance

304180 en ma 2016-02 2/8
REFRIGERATED SQUARE SALAD‘BAR
SBC 40 F
Congratulations for the acquisition of this upmarket appliance made in France. You
chose an appliance which alloys the best technical qualities with a big user-
friendliness. We wish you the biggest contentment
1. SECURITY INSTRUCTIONS
Please respect these instructions scrupulously to avoid any risk of fire, electric shock,
scald or other wounds and damage. During the use of this appliance, fundamental
circumspection of security must always be noticed, such as:
- Take into account the instructions to be systematically kept with the appli-
ance.
- Install the appliance always in instructions respect. A 10 cm distance mini-
mum with the partition or the wall is necessary.
- Protect the appliance from direct light of the sun, frost and humidity.
- Never leave the appliance within the reach of children or disabled persons
without surveillance.
- The machine has to be used only by qualified person.
- Never move the appliance when it is working.
- Check that the appliance is definitely off before connecting it up or discon-
necting it.
- Do not use the appliance for other functions than determined use.
- Do not leave the electrical cord in contact of hot surfaces.
- The appliance should not be used close to combustible materials.
- To avoid any electric shock, never plunge the cord or plug in water or quite
other liquid.
- If the cord is harmed, it must be replaced by the producer, its after sale ser-
vice or persons of similar skills to avoid any risk.
- Entrust repairs only to a skilled person.
- Use only spare parts of origin.
- Before cleaning the appliance, do not forget to disconnect it.

304180 en ma 2016-02 3/8
2. CONTENTS OF CARDBOARD PACKAGING
Device: a salad’bar
Accessories: - The present note
3. CONFORMITY OF USE
Use the salad’bar only to keep your cold meals (cold starters, shellfish, meat, des-
serts…) at a temperature between +2°C and +10°C during working and service
hours. Afterwards they will be stores in a conventional cool chamber.
4. WAY OF FUNCTIONING
This salad’bar keep the 4 x GN containers cold.
To turn on your salad’bar, press on the left switch (n°3 on picture): the electronic
thermostat (n°1 on picture) preset in factory is on. It flashes and then displays the
temperature.
Press on the right switch (n°2 on picture) to turn on the light (n°4 on picture). A 1/4
lock drain valve, in lower part, enable to drain water from the container ).
3
4
2
1

304180 en ma 2016-02 4/8
Electronic thermostat Lighting switch
On/off switch Led light
5. FUNCTIONING / MANIPULATION
a) Installation / assembly:
- Unpack carefully the appliance from its packaging
- Unload the salad’bar (see 11. Unloading of the salad’bar)
- Place the equipment on a stable and heatproof surface.
- Never place the device near a wall or near a partition makes of combustible ma-
terials even if it is very well isolated.
- A distance of 10 cm from the partition or the wall is considered enough.
- Remove the protective film from the appliance.
b) First starting:
First cleaning
Clean the device before the first use. (See 6 Cleaning)
Connection of the device
- Check that the tension and the frequency of the electricity network suit to the
values indicated on the descriptive plate.
- Check that neither the cord nor the plug are damaged
- Make sure that every control knob is positioned on 0.
- Unwind completely the electric power cable and connect it in a normalised plug
with the earth.
- The device is connected.
NB: in case of connection of the device in a plug without earth protection or directly
on the electricity network, confide its connection to a qualified person .
4
1 2
3

304180 en ma 2016-02 5/8
c) Use of device :
Elements of command and display
Starting
- Press on the switch (n°3 on picture), the machine is on. The preset electronic
thermostat flashes and displays the temperature.
- Wait until the salad’bar is at the right temperature
- Press on the second switch (n°2 on picture) to turn on light.
Temperature setting
The electronic thermostat is preset in factory. It can be adjusted if necessary.
To modify the temperature, press the "set" key for 5 seconds: the programmed
value is displayed and the LED flashes. Use the arrows to adjust your tempera-
ture and valid by pushing on set
Stopping the appliance
- Set each switch (n°2 and 3 on picture) on 0: the appliance is no longer function-
ing.
- Disconnect the power cable.
- Clean the appliance. (see 6. Cleaning)
d) Breakdown / repair:
In case of breakdown or of damaged part, please call your after-sales service and
confide any technical operation to qualified person.
When you contact the after-sales service of your distributor or your store, give him the
complete reference of your device (commercial name, type and serial number). This
information appears on the visible descriptive plate behind the device.
Command/Display Function
Electronic thermostat (n°1
on picture) Temperature setting
Switch 0/I (n°2 on picture) Light on / Light off
Switch 0/I (n°3 on picture) On/off

304180 en ma 2016-02 6/8
6. CLEANING AND MAINTENANCE
- Disconnect the device.
- Clean regularly the metallic parts after each use by using only use non-abrasive
products, warm water and wash liquid: avoid the abrasive towelling. Rinse your
device with a wet sponge and dry it with a soft cloth.
- Never clean the device under a water jet, the infiltrations would risk to damage it
in a irreparable way.
- Never immerse the cord or the plug in the water or quite other liquid to avoid any
electric shock.
- Never use abrasive product or vinegar; it could damage the container in irremedi-
able way.
7. TECHNICAL SPECIFICATIONS
Wires colours correspondence Phase Brown / Black / Grey
Neutral Blue
Earth Yellow-Green
8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-89
EN 55014-1 + 55014-2
EN 61000-3-2 + 61000-3-3
Model SBC 40 F
Dimensions 1435x1435x1540 mm
Weight 120 Kg
Power 450 W
Gas R 134 A
Temperature +2° à +10° C
Current 2.5 A
Voltage 220-240 V ~
Colours Wenge/Light oak/Mahogany

304180 en ma 2016-02 7/8
9. ELIMINATION OF THE ELECTRIC AND ELECTRONIC WASTE
The device respects the directives:
2002/96/CE (DEEE) N°34270064800021
2002/95/CE (ROHS)
2066/95 CE
2004/108 CE
Reach rule
Never put the device among household waste.
The device must be put down in a centre of recycling for the electric equipments.
The materials of the device are indeed reusable. By eliminating correctly the electric
and electronic wastes, the recycling and quite other shape of re-use of worn equip-
ments, you participate in a significant way in the environmental protection.
For any information about the collection of electric and electronic waste, please contact
your distributor.
10. GUARANTEE
Conditions of guarantee
The guarantee applicable to any device is the commercial guarantee of the distributor
or the retailer. Please contact the store where you bought your device to know the pre-
cise conditions.
The guarantee grants no right for damages.
The dispositions which follow are not exclusive of the profit of the legal guarantee
planned by articles 1641 and following ones of the Civil code relative to the defects and
the latent defects.
Exclusion clauses of the guarantee
Bad installation and bad maintenance, in particular if they do not respect current
regulations or instructions appearing in this user guide.
Cannot benefit from the guarantee the repairs required as a result of false operations,
of inappropriate use, of carelessness or of excess loads of the device, as well as those
resulting from variations of the power supply, over tension or from defective installa-
tions.

304180 en ma 2016-02 8/8
The damage due to shocks, bad weather is not flatware by the guarantee. The mate-
rial travels at the risks of the user; in case of delivery by carrier, the consignee has to
have reservations towards the carrier before any delivery of the device.
The guarantee comes to an end in case of intervention, of repair, of modification by
no qualified persons, or of use in inappropriate purposes.
11. UNLOADING OF THE SALAD’BAR
It is necessary to do this operation with at least two persons.
1. Unpack the salad’bar with care. Remove all the protective films located around the
pallet
2. Remove the 4 unloading planks placed under the salad’bar (picture A)
3. Place one of the four unloading planks under one of the castor. Push it until the
first slat of the pallet (see red circles in pictures B and C)
Picture A
Unloading planks
Picture B Picture C

304180 en ma 2016-02 9/8
4. Slide a second unloading plank (picture D) in front of the first one. VERY IMPORTANT:
Make sure that the second plank is well stacked on the first one (picture E)
5. Repeat the steps 3 and 4 on the other side.
6. Make the salad’bar slide on the unloading planks (pictures F and G)
7. Your salad’bar is now unloaded. You just have to put it into operation
Picture E
Picture D
Picture F Picture G
Picture H
