Roller Grill RG 5 Technical manual

G03316
INSTRUCTIONS FOR USE AND INSTALLATION
ROLLER GRILLS
RG 5 / RG 7 / RG 9 / RG 11
Made in France
Made in FranceMade in France
Made in France
September 2014

21

20
Nomenclature RG 11
Spare parts RG 11
ROLLER GRILLS
RG 5 / RG 7 / RG 9 / RG 11
Congratulations for the acquisition of this upmarket appliance made in France You
chose an appliance which alloys the best technical qualities with a big user-friendliness
We wish you the biggest contentment
1. SECURITY INSTRUCTIONS
Please respect these instructions scrupulously to avoid any risk of fire, electric shock,
scald or other wounds and damage During the use of this appliance, fundamental cir-
cumspection of security must always be noticed, such as:
- Take into account the instructions to be systematically kept with the appliance
- Install the appliance always in instructions respect A 10 cm distance minimum
with the partition or the wall is necessary
- Protect the appliance from direct light of the sun, frost and humidity
- Never leave the appliance within the reach of children or disabled persons with-
out surveillance
- Never move the appliance when it is working or when the surfaces of cooking
are still hot
- Check that the appliance is definitely off before connecting it up or disconnecting
it
- Do not touch the hot surfaces of the appliance The temperature of the hot sur-
faces can be very important when the appliance is working Always use handles
and control knobs
- Do not use the appliance for other functions than determined use
- Do not leave the cord of electrical feeding in the contact of hot surfaces
- The appliance should not be used close to combustible materials
- During use, look after not to obstruct hearings of aeration of the appliance
- Never use metal utensils which could damage the coating of the cylinders
- Never operate the appliance without the sauce tray under the rollers
- To avoid any electric shock, never plunge the appliance, the cord or plug in wa-
ter or quite other liquid
- If the cord is harmed, it must be replaced by the producer, his after sale service
or persons of similar skills to avoid any risk
- Entrust compensations only to a skilled person
- Use only spare parts of origin
- At the end of cooking, before cleaning the appliance, do not forget to disconnect
it
3

2. CONTENTS OF CARDBOARD PACKAGING
Device: A roller grill
Accessories:- A sauce drip tray
- The present note
See exploded views for each roller grills at the end of the document
3. CONFORMITY OF USE
Use the device only to keep warm precooked sausages
4. WAY OF FUNCTIONING
These roller grills are available in four different versions Depending on the ver-
sions, you will be able to reheat up to 30 sausages For models RG 5 and RG 7,
you have one power control system enabling you to set the temperature of the
cylinders
Models RG 9 and RG 11 come with two independent power control systems,
which enable to have two independent heating areas The right knob controls the
front area and the left one is for the rear heating area
The running heating areas are indicated by the pilot lights
To turn on and off the appliance, there is a switch
To turn on the device, press the switch (n°3 on picture), just turn on the power con-
trol knob (n°2 on picture) on the wished position If you want a quick preheating, set it
on maximum position The orange pilot light ignites (n°1 on picture) during heating
When orange pilot light switches off, the device is ready for cooking
Pilot light Power control knob
On/off switch Sauce drip tray
4
21
4
3
12
34
19

18
Nomenclature RG 9
Spare parts RG 9
5. FUNCTIONING / MANIPULATION
a Installation / assembly:
- Unpack carefully the device of its packaging
- Place the roller grill on a plane and heatproof surface
- Never place the device near a wall or near a partition makes of combustible mate-
rials even if it is very well isolated
- A distance of minimum 10 cm with the partition or the wall is necessary
- remove the protective film from the sauce drip tray and install it under the cylin-
ders
b First starting:
Before the first use, clean the heating cylinders with water and some dishwashing
liquid The use of detergent is possible as long as it is not excessively aggres-
sive Then wipe with a cloth dipped in oil
Be sure to use only sausages designed for this type of use so that they maintain
their attractive look during heating
However, because sausages are never uniform, the parts in contact with the roll-
ers tend to brown faster than the remainder of the sausage
First cleaning
Clean the device before the first use (See 6 Cleaning)
Connection of the device
- Check that the tension and the frequency of the electricity network suit to the val-
ues indicated on the descriptive plate
- Make sure that every control knob is positioned on 0
- Check that neither the cord nor the plug are damaged
Unwind completely the electric power cable and connect it in a plug connected with
the earth
- The device is connected
NB: in case of connection of the device in a plug without earth protection or directly on
the electricity network, confide its connection to a qualified person
5

c Use of device :
Elements of command and display
Putting on
Press the switch on/off (n°3 on picture)
Turn on the power control knob (n°2 on picture) on the wished position: the or-
ange pilot light (n°1 on picture) ignites
For a quick preheating, set the power control knob on maximum position
Once orange pilot light (n°1 on picture) is off, the machine reached the wished
temperature
For a continuous heating, select position C on power control knob
Temperature setting
Set the temperature by positioning the power control knob (n°2 on picture) to the
desired temperature The orange pilot light (n°1 on picture) switches on if a high-
er level of temperature is required and switches off when the same is reached
During heating, do not reduce the power so as to avoid the sausages shrink-
ing and taking on a wrinkled look
Stopping the appliance
Set power control knob (n°2 on picture) and the switch (n°3 on picture) on 0: the
appliance is no longer functioning
Let the device cool
Disconnect the power cable
Clean the appliance (see 6 Cleaning)
d Breakdown / repair:
In case of breakdown or of damaged part, please call your after-sales service and
confide any technical operation to qualified person
When you contact the after-sales service of your distributor or your store, give him
the complete reference of your device (commercial name, type and serial number)
This information appears on the visible descriptive plate behind the device
Command/Display Function
Orange pilot light
(n°1 on picture)
Machine is heating (pilot light on)
Temperature reached (pilot light off)
On/off switch
(n°3on picture)
On/off
Power control knob (n°2
on picture)
Temperature setting
6
17

16
Nomenclature RG 7
Spare parts RG 7
6. CLEANING AND MAINTENANCE
Disconnect the device
- Let cool completely the device before any technical intervention or cleaning
- Only use non-abrasive products, clean regularly the external walls of your device
with warm water and wash liquid: avoid the abrasive towelling Rinse your device with
a wet sponge
- For better cleaning, perform it when the cylinders are still hot To do this, turn the
power control knob to position C and clean the cylinders with a damp cloth Wipe the
cylinders from the ends toward the center so as not to push grease into the Teflon
rings
- Never clean the device under a water jet, the infiltrations would risk to damage it in a
irreparable way
- Never immerse the device, the cord or the plug in the water or quite other liquid to
avoid any electric shock
- During a prolonged non-use, we recommend you strongly to keep the device shield-
ed from the humidity
7. TECHNICAL SPECIFICATIONS
Wires colours correspondence Phase Brown / Black / Grey
Neutral Blue
Earth Yellow-Green
Models RG 5 RG 7 RG 9 RG 11
Outside di-
mensions mm
550x320x245 550x320x245 550x460x245 550x460x245
Weight 12.5 Kg 14 Kg 18.5 Kg 20 Kg
Power 625 875 1125 1375
Nb elements 57911
Current 3 A 4 A 5 A 6 A
oltage 220-240 V ~ 220-240 V ~ 220-240 V ~ 220-240 V ~
Capacity
(sausages)
12 18 24 30
7

8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-48
EN 55014-1 + 55014-2
EN 61000-3-2 + 61000-3-3
9. ELIMINATION OF THE ELECTRIC AND ELECTRONIC WASTE
The device respects the directives:
2002/96/CE ( DEEE) N°34270064800021
2002/95/CE ( ROHS)
2066/95 CE
2004/108 CE
Reach rule
Never put the device among household waste
The device must be put down in a centre of recycling for the electric equipments
The materials of the device are indeed reusable By eliminating correctly the electric
and electronic wastes, the recycling and quite other shape of re-use of worn equip-
ments, you participate in a significant way in the environmental protection
For any information about the collection of electric and electronic waste, please con-
tact your distributor
10. GUARANTEE
Conditions of guarantee
The guarantee applicable to any device is the commercial guarantee of the distributor
or the retailer Please contact the store where you bought your device to know the
precise conditions
The guarantee grants no right for damages
The dispositions which follow are not exclusive of the profit of the legal guarantee
planned by articles 1641 and following ones of the Civil code relative to the defects
and the latent defects
8
15

Nomenclature RG 5
Spare parts RG 5
14
Rep Code Qty Désignation Spare part
1A09003 2Steatite Steatite
2B06029 10 Bague téflon Teflon ring
3A10002 1Serre cable Cord closer
4C03013 1Cordon avec prise Cord with plug
5B07006 1Chaine Chain
6B01005 5Tube + pignon Gear wheel
7D02037 5Résistance blindée Heating element
8A03064 1Moteur Motor
9A13003 4Pied Foot
10 A07025 1Interrupteur Switch
11 A04006 1Regulateur Regulator
12 A14078 1Bouton Knob
13 A08003 1Voyant orange Orange pilot light
14 27008SE 1Plat Tray
Exclusion clauses of the guarantee
Bad installation and bad maintenance, in particular if they do not respect cur-
rent regulations or instructions appearing in this user guide.
Cannot benefit from the guarantee the repairs required as a result of false opera-
tions, of inappropriate use, of carelessness or of excess loads of the device, as well
as those resulting from variations of the power supply, over tension or from defective
installations
The damage due to shocks, bad weather is not flatware by the guarantee The mate-
rial travels at the risks of the user; in case of delivery by carrier, the consignee has to
have reservations towards the carrier before any delivery of the device
The guarantee comes to an end in case of intervention, of repair, of modification by
no qualified persons, or of use in inappropriate purposes
9
