Nomenclature TS 3270
Spare parts TS 3270
TOASTERS
TS 1270 / TS 3270
Congratulations for the acquisition of this upmarket appliance made in France. You
chose an appliance which alloys the est technical qualities with a ig user-
friendliness. We wish you the iggest contentment
1. SECURITY INSTRUCTIONS
Please respect these instructions scrupulously to avoid any risk of fire, electric shock,
scald or other wounds and damage. During the use of this appliance, fundamental
circumspection of security must always e noticed, such as:
- Take into account the instructions and keep it systematically with the appli-
ance.
- Install the appliance always in instructions respect. A 10 cm distance minimum
with the partition or the wall is necessary.
- Protect the appliance from direct light of the sun, frost and humidity.
- Never leave the appliance within the reach of children or disa led persons
without surveillance.
- Never move the appliance when it is working or when the surfaces of cooking
are still hot.
- Check that the appliance is definitely off efore connecting it up or disconnect-
ing it.
- Do not touch the hot surfaces of the appliance. The temperature of the hot sur-
faces can e very important when the appliance is working. Always use handles
and control kno s.
- Do not use the appliance for other functions than determined use.
- Do not leave the electrical cord in contact of hot surfaces.
- The appliance should not e used close to com usti le materials.
- During use, look after not to o struct hearings of aeration of the appliance
- To avoid any electric shock, never plunge the appliance, the cord or plug in
water or quite other liquid.
- If the cord is harmed, it must e replaced y the producer, his after sale ser-
vice or persons of similar skills to avoid any risk.
- Entrust repairs only to a skilled person.
- Use only spare parts of origin.
- At the end of cooking, efore cleaning the appliance, do not forget to discon-
nect it.
3

2. CONTENTS OF CARDBOARD PACKAGING
Device: A toaster with protecting grids
Accessories: - One tray
- One cooking grid with handles
- One cooking grid with deflector (TS 3270 only)
- The present note
See exploded views for TS 1270 / TS 3270 at the end of the document.
3. CONFORMITY OF USE
Use the appliance only to cook, reheat, glaze, rown, toast in quantity your croque
-monsieur, pizzas, quiches, cheese/meat puffs.with no preheating, smokes or
odours
4. WAY OF FUNCTIONING
Unique in the world, these salamanders toasters with 1 or 2 levels and 2 or 3 quartz
tu es lines ena le to defrost, rown, glaze, grill or toast every kind of dishes.
For fast service, the top part of the salamander (TS 3270) is closed and fitted with a
tray with handles.
According to the dimension of the machine, you can cook instantly at core with no
smoke and odour thanks to the rays of the infrared quartz tu es from 200 to 400
toasts per hour.
Preheat is not necessary as the temperature rise is very fast, less than 30 sec.
To turn on the toaster, just action the commutator (n°1 on picture) on the desired po-
sition (from 2 to 4), turn on the timer (n°4 on picture) according the desired cooking
time. The orange pilot light (n°2 on picture) ignites. Your machine is working
The selection of the cooking zone is made through the commutator
Never use the toaster without its tray (n°5 on picture)
4 11

10
Nomenclature TS 1270
Spare parts TS 1270
Commutator Orange pilot light
On/off pilot light Timer
Tray
5. FUNCTIONING / MANIPULATION
a Installation / assembly:
- Unpack carefully the device of its packaging.
- Place it on a plane and heatproof surface.
- Never place the device near a wall or near a partition makes of com usti le ma-
terials even if it is very well isolated.
- A distance of minimum 10 cm with the partition or the wall is necessary.
- Remove the protective films
b First starting:
During the first use, warm your machine up outside to evacuate residual smokes of
manufacturing oil from the metallic parts. This may emit a slight smell for a few mo-
ments.
First cleaning
Clean the device efore the first use. (See 6. Cleaning)
5
1
3
12
4
4
3
2
5
5

Connection of the device
- Check that the tension and the frequency of the electricity network suit to the values
indicated on the descriptive plate.
- Check that neither the cord nor the plug are damaged. If necessary, it has to e
replaced y the manufacturer, its after sale service or any qualified person to avoid
any risk.
- Make sure that every control kno is positioned on 0.
- Unwind completely the electric power ca le and connect it in a plug connected with
the earth.
- The device is connected.
NB: in case of connection of the device in a plug without earth protection or directly
on the electricity network, confide its connection to a qualified person .
c Use of device :
Elements of command and display
Putting on
Turn on the commutator (n°1 on picture) on the wished position.
Turn on the timer control kno (n°4 on picture) on the wished cooking time
The orange pilot light (n°2 on picture) ignites. The machine is on.
You can use your toaster in continuous y turning the timer on left side from position
0. Caution : do not forget to turn off your pizza oven after use.
Temperature setting
Set the power desired y positioning the commutator (n°1 on picture) to the wished
position.
Command/Display Function
Commutator 4 positions (n° 1 on pic-
ture) :
Position 1
Position 2: Toaster/salamander
Position 3: Pizza oven
Position 4
Stop
Bottom and middle quartz tu es on
Top and middle quartz tu es on
All the tu es warm
Orange pilot light (n°2 on picture) Machine is on
Timer 15 min (n°4 on picture) Cooking time
Green pilot light (n°3 on picture) On/off
6
The dispositions which follow are not exclusive of the profit of the legal guarantee
planned y articles 1641 and following ones of the Civil code relative to the defects
and the latent defects.
Exclusion clauses of the guarantee
Bad installation and bad maintenance, in particular if they do not respect cur-
rent regulations or instructions appearing in this user guide.
Cannot enefit from the guarantee the repairs required as a result of false opera-
tions, of inappropriate use, of carelessness or of excess loads of the device, as well
as those resulting from variations of the power supply, over tension or from defective
installations.
The damage due to shocks, ad weather is not flatware y the guarantee. The mate-
rial travels at the risks of the user; in case of delivery y carrier, the consignee has to
have reservations towards the carrier efore any delivery of the device.
The guarantee comes to an end in case of intervention, of repair, of modification y
no qualified persons, or of use in inappropriate purposes.
9

Wires colours correspondence Phase 1 Brown
Phase 2 Black
Phase 3 Grey
Neutral Blue
Earth Yellow-Green
8. NORMS AND LEGALS DISPOSALS
The device is conform to :
IEC/EN 60335-1
IEC/EN 60335-2-48
EN 55014-1 + 55014-2
EN 61000-3-2 + 61000-3-3
9. ELIMINATION OF THE ELECTRIC AND ELECTRONIC WASTE
The device respects the directives:
2002/96/CE (DEEE) N°34270064800021
2002/95/CE (ROHS)
2006/95 CE
2004/108 CE
Reach rule
Never put the device among household waste.
The device must e put down in a centre of recycling for the electric equipments.
The materials of the device are indeed reusa le. By eliminating correctly the electric
and electronic wastes, the recycling and quite other shape of re-use of worn equip-
ments, you participate in a significant way in the environmental protection.
For any information a out the collection of electric and electronic waste, please con-
tact your distri utor.
10. GUARANTEE
Conditions of guarantee
The guarantee applica le to any device is the commercial guarantee of the distri utor
or the retailer. Please contact the store where you ought your device to know the
precise conditions.
The guarantee grants no right for damages.
8
Stopping the appliance
Set the timer (n°4 on picture) on 0
Set the commutator (n°1 on picture) on 0: the appliance is no longer functioning.
Disconnect the power ca le.
Clean the appliance. (see 6. Cleaning)
d Breakdown / repair:
In case of reakdown or of damaged part, please call your after-sales service and
confide any technical operation to qualified person.
When you contact the after-sales service of your distri utor or your store, give him
the complete reference of your device (commercial name, type and serial num er).
This information appears on the visi le descriptive plate ehind the device.
6. CLEANING AND MAINTENANCE
- Disconnect the device.
- Let cool completely the device efore any technical intervention or cleaning.
- Never clean the quartz tu es when they are hot
- Avoid touching quartz tu es with your fingers ut use a cloth moistened with spirit.
- Clean regularly the external walls of your device with warm water and wash liquid:
avoid the a rasive towelling. Rinse your device with a wet sponge.
- Never clean the device under a water jet, the infiltrations would risk to damage it in
a irrepara le way.
- Never immerse the device, the cord or the plug in the water or quite other liquid to
avoid any electric shock.
- During a prolonged non-use, we recommend you strongly to keep the device
shielded from the humidity.
7. TECHNICAL SPECIFICATIONS
7
Models TS 3270
Outside dimensions 640x380x475 mm
Weight 18.5 Kg
Power 4000 W
No uartz tube 9
Current 17.4 A
Voltage 380-440 V 3 N
TS 1270
640x380x330 mm
15 Kg
2700 W
6
11 A
220-240 V
