Rollplay FLEX PEDAL DRIFTER Assembly instructions

Made in China.
Styles and colors may vary . Do not return to store. Call 1-888-982-9309 for assistance and
rreplacement parts.
Owner’s Manual and Assembly Instructions
Model #: WP2028
Read and understand the entire manual before assembly and operation.
The vehicle must be assembled by an adult who has read and understands the instructions.
IMPORTANT:
Save this manual with your sales receipt.
25701671 06/21

Phone: [phone]
Thank you for purchasing this Rollplay vehicle. We hope the rider enjoys
it for miles to come. Please read this instruction guide carefully before
assembling and operating the vehicle.
Keep your sales receipt and register your product at www.rollplay.com.
Please contact Rollplay Customer Service with any questions.
Specifications:
AGE:
MAX WEIGHT:
PRODUCT SIZE: 70.1 x 53 x 53.3 cm (27.5 x 20.8 x 21 in.)
2½ and up
25 kg (55 lb)
Please have your model number and serial number ready before calling.
Please have proof of purchase.
Introduction
Email: [e-mail]
Web: www.rollplay.com
Hours: 8 AM - 5 PM EST, Monday - Friday

DO NOT RETURN YOUR PRODUCT TO THE STORE.
CONTACT ROLLPLAY WITH QUESTIONS.
IMPORTANT!
E-mail Customer Service if you need assistance or replacement parts.
Please have your model number and serial number ready before calling.
Please provide proof of purchase. Keep your sales receipt and register your
product at www.rollplay.com, as we require proof of purchase.
[email protected]
Read this entire manual prior to
assembly to ensure safe operation
of the vehicle.

4Table of Contents
Safety ........................................................
Parts ..........................................................
...................................................
.......................................................
Front Wheel Assembly .............................
Nose Cover Assembly..............................
..................................
..................................
Propeller Assembly
Assembling the Seat
Folding
Unfolding
Seat Adjustment........................................
Storage Compartment..............................
General Care .............................................
Customer Service .....................................
Warranty ...................................................
Product Registration ...............................
5
7
8
9
10
11
12
13
14
15
16
17
18
19

5
Safety
WARNING: SAFETY RIDING RULES
The user must follow all safety rules and guidelines or serious
injury or death may occur.
ALWAYS use common sense and safe practices when using the vehicle. The user
must be at least 2½ years old and weigh no more than 25 kg (55 lbs).
This product contains small parts that are for adult assembly only. Keep small
children away when assembling. Remove and dispose of all protective material
and plastic bags before assembly.
Only sit on the seat of the vehicle.
Do not allow more than one rider.
Do not overload the vehicle. Do not remove the weight restriction decals.
Do not tow the vehicle with another vehicle or similar device.
Keep body parts, such as hands, legs and hair, and clothing away from moving
parts. Moving parts can cause serious injury.
ALWAYS wear shoes while using the vehicle.
NEVER operate near roadways or motor vehicles.
Do not operate near drop-offs, such as steps, steep inclines or hills. Operate on
relatively level ground.
Do not operate near water, swimming pools or other bodies of water.
Do not operate near loose dirt, mud, sand or fine gravel.
Do not operate in dangerous weather conditions such as rain or snow.
Make sure that the child's feet are on the pedals before pushing the vehicle.
NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is in
the vehicle. Direct adult supervision is REQUIRED.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Always use the vehicle in a safe, secure environment with adult supervision.•
Do not operate outside at night.•

6Safety
(Continued)
• Before use, the rider must understand how to control the vehicle and safety issues.
• It is the responsibility of the adult to educate the child and to determine if the child
is capable of understanding the vehicle controls.
• An adult must ALWAYS directly supervise the use of this vehicle.
• NEVER leave a child unsupervised on the vehicle.
WARNING: ADULT SUPERVISION
REQUIRED

Parts
1
5
3
4
2
7
6
8
10
10
11 12
13 14
9
1. Manual
2. Handlebar
3. Seat
4. Nose cover
5. Propeller (x2)
6. Storage compartment
7. Frame
8. Wheel assembly
9. Foot pedal
10 Front wheel (L/R)
11. M6x15 Screw (x2)
12. M5x21Screw (x2)
13. Washer (x2)
14. Nut (x2)
7
Hardware pack
• Phillips screwdriver
Not Included:

7
Front Wheel Assembly
R
L
R
R
A.Insert the plugins marked with "L" and "R" on the front wheel assembly into the
front forks L/R.
B.Align the hole position according to the picture, then tighten and attach it with
M5X21 screw using a Phillips screwdriver (not included).
8
A B

Nose Cover Assembly
A.Insert the hooks marked with arrows on the inside of the nose cover into the
slots with arrows on the front as shown in the figure.
B.Hold the nose cover and rotate it clockwise until it locks into place.
9
A B

Propeller Assembly
Insert the shaft on the propeller into the holes as shown. Firmly push in until a
click is heard.
10

Assembling the Seat
Put the M6X15 screws ①through the seat and seat base holes, add washers ②
and lock with nut ③ as shown in the figure above.
1
2
3
11

Folding
1
2
3
As shown in the figure above, press the folding button ①and pull the folding
lever ②outward with one hand, then lift the seat up ③with other hand to fold the
vehicle. Folded vehicle will look like the figure above to the right.
12

Unfolding
2
As shown in the figure above, pull the folding lever ①out and then rotate it in the
direction of arrow ②until a "click" is heard. After unfolding completely, the vehicle will
look like the figure above to the right.
1
13

Seat Adjustment
Loosen the side screw of the seat adjustment plate with a Phillips screwdriver (not
included) as shown in figure A. The seat can now be moved forwards and
backwards. After adjusting the position, tighten the side screw of the seat
adjustment plate (figure B) to hold the seat in the new position.
14
A B

Open the lid of the storage compartment according to the direction of the arrow as
shown in the figure above.
Storage Compartment 15

• Regularly inspect all vehicle parts to ensure they are in good working
condition.
Remove any damaged parts and immediately contact Customer Service
for replacement parts. See Customer Service on Page 17 for more
information.
DO NOT operate the vehicle if there are any damaged parts.
Carefully clean the vehicle with a damp cloth and mild soap.
Store the vehicle indoors or use a tarp to cover it. Keep away from
stoves, heaters, or other sources of heat.
•
•
•
•
General care
16

17
Customer Service
If your product requires replacement parts, please contact Rollplay
Customer Service.
Hours: 8 AM - 5 PM EST, Monday - Friday
Phone: [phone]
Email: [email protected]
Web: www.rollplay.com
WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales
receipt or register your product at www.rollplay.com.
Do not return your product to the store.
Contact Rollplay with questions.

This warranty does not cover, and is not intended to exclude any liability on the
part of Rollplay, whether under this warranty or implied by law for any indirect
or consequential damages for breach of warranty. Some states may not allow the
exclusion or limitation so this limitation may not apply to you.
18 Warranty
• One-year limited warranty from the date of purchase with proof of purchase
from a Rollplay certified retailer. This one-year limited warranty covers
the ride-on vehicle against defects in materials and workmanship to the original
purchaser. Proof of purchase receipt from a Rollplay certified retailer
is required.
• This warranty covers normal use and does not cover the Rollplay vehicle
if deemed damaged by unreasonable use, modification, neglect, accident,
abuse, misuse, improper service or other causes not arising out of defects in
materials or workmanship. Evidence of any attempt at customer repair will void
this warranty.
•
Should you need service or assistance with your vehicle during the warranty period:
• Please do not return vehicle to the store.
• Consult the troubleshooting guide in this manual and online at www.rollplay.com
• Call Rollplay Customer Service at 1-888-982-9309
may vary from state to state.
Note: This warranty gives you specific legal rights. You may also have other rights that
Please save your original sales receipt.

19
Product Registration
Fill out the form below and mail it to:
Rollplay
Attn: ParentLink
1801 Commerce Dr.
Piqua, OH 45356
www.rollplay.com
We will use the information pr ovided only for your warranty. We will not sell,
rent or share your personal information.
First Name: Last Name: Title:
Address:
City: State: Zip Code:
Email: Phone:
Date of Purchase:
The following product information is on the cover of the owner’s manual.
Product Name: Model Number:
Serial Number: Retailer Place of Purchase:
Product Registration
Questions or comments? Contact us at www.rollplay.com or 1-888-982-9309
