СОКОВЫЖИМАЛКА
JUICE EXTRACTOR
RDE-1501

4
ENGLISH
JUICE EXTRACTOR RDE-1501
Electric juice extractor is intended for making fruit or vege-
table juice.
DESCRIPTION
1. Pusher
2. Feeding chute
3. Lid
4. Grating filter
5. Juice collector
6. Juice draining spout
7. Locks
8. Motor unit
9. Operation mode switch (I-0-II)
10. Pulp compartment
11. Juice cup
SAFETY MEASURES
Before using the unit, read this instruction manual carefully
and keep it for future reference.
Use the unit for intended purposes only, as specified in
this manual. Mishandling the unit can lead to its break-
age and cause harm to the user or damage to his/her
property.
• To avoid injuries do not remove the juice extractor
lid during operation and when the unit is plugged in
as well.
• The juice extractor is equipped with an automatic safety
device which protects the motor from overheating damage
while working at maximum capacity. This protection auto-
matically switches the juice extractor off when the motor
overheats. Should this occur, unplug the juice extractor
and wait for the motor to cool down.
• Before using the unit for the first time, make sure that
the voltage in your mains corresponds to unit operating
voltage.
• Place the juice extractor on a dry, flat and steady sur-
face only.
• Before using the unit for the first time, wash all removable
parts that will contact processed foods thoroughly.
• Be cautious when holding the grating filter in your hands,
as the disc grating surface is very sharp.
• Check the grating filter before every use of the juice
extractor. If you find any mechanical damage, stop using
the unit and immediately replace the grating filter.
• Use the supplied removable parts only.
• Do not use the unit outdoors.
• Do not place the unit and the power cord near hot sur-
faces, heat sources or sharp edges of furniture.
• Before using the unit, make sure that all parts are set
properly.
• You can use the juice extractor only if the juice extractor lid
is fixed with the lock.
• Never push products into the feeding chute with your fin-
gers or other objects during operation. For this purpose
use the pusher only.
• Do not bring your face close to the open feeding chute
while the unit is operating, fruit/vegetable pieces can be
flung out of the feeding chute and cause harm to the user.
• Never use the juice extractor without installed pulp con-
tainer.
• The unit is not intended for chopping or mixing of prod-
ucts.
• Do not disassemble the slow juicer if its power plug is con-
nected to the mains socket.
• Do not touch the power plug with wet hands.
• Open the lock only after the unit is switched off and the
grating filter has stopped rotating.
• If some moisture or juice drops appear on the juice
extractor housing, switch it off, unplug it and wipe the
housing with dry cloth.
• After operation switch the unit off and pull the power plug
out of the mains socket.
• Do not allow children to touch the unit and the power cord
during operation.
• Do not leave children unattended to avoid them using the
unit as a toy.
• This unit is not intended for usage by children.
• During operation and breaks between operation cycles,
the unit should be placed out of reach of children.
• The unit is not intended to be used by people with phys-
ical, sensory or mental disabilities (including children) or
by persons lacking experience or knowledge if they are
not under supervision of a person who is responsible for
their safety or if they are not instructed by this person on
the usage of the unit.
• For children safety reasons do not leave polyethylene bags
used as a packaging unattended.
Attention! Do not allow children to play with polyethylene
bags or packaging film. Danger of suffocation!
• Check the power cord and plug periodically.
• Do not use the juice extractor if the power cord is dam-
aged. If the power cord is damaged, it should be replaced
by the manufacturer, service or similar qualified personnel
to avoid danger.
• Do not attempt to repair the unit. Do not disassemble the
unit by yourself, if any malfunction is detected or after it
was dropped, unplug the unit and apply to any authorized

5
ENGLISH
service center from the contact address list given in the
warranty certificate and on the website www.rondell.ru.
• Transport the unit in the original package only.
• Keep the unit out of reach of children and disabled persons.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY. ITS
COMMERCIAL USAGE AND USAGE IN PRODUCTION AREAS
AND WORK SPACES IS PROHIBITED.
BEFORE THE FIRST USE
After unit transportation or storage at low temperature
keep it for at least three hours at room temperature
before switching on.
• Unpack the juice extractor.
Disassemble and clean the juice extractor before
usage:
• Remove the pusher (1) from the lid (3) feeding chute (2).
• Lower the locks (7) and remove the lid (3).
• Remove the grating filter (4) holding it by the juice col-
lector (5).
• Wash thoroughly and dry all the removable parts (1, 3, 4, 5,
11) that will contact products.
Note: Be cautious when holding the grating filter (4) in your
hands, as the disc grating surface is very sharp.
MAKING JUICE
Before the first plugging in make sure that the operating volt-
age of the unit corresponds to the voltage of your mains.
Fruit and vegetables meant for processing must be fresh.
Before juice extracting wash fruit/vegetables, remove inedi-
ble parts from vegetables or fruit, such as stems, hard peel or
stones, for example, of cherry or peach, cut them into pieces
easily fitting into the feeding chute (2).
• Place the motor unit (8) on a dry, flat and steady surface.
• Before the unit assembling make sure that the operation
mode switch (9) is set to the position «0», and the plug is
not inserted into the mains socket.
• Set the juice collector (5) on the motor unit (8).
• Install the grating filter (4) into the juice collector (5).
ATTENTION!
Do not use the juice extractor if you find mechanical damages
of the grating filter (4).
• Install the lid (3) on the juice collector (5) and fix it with
the locks (7).
• Set the juice cup (11) under the juice draining spout (6).
• Insert the power plug into the mains socket.
• Switch the juice extractor on by setting the switch (9) to
the position «I» (low speed) or to position «II» (high speed).
Notes:
Low speed «I» is intended for extracting juice from soft
vegetables/fruits, such as tomatoes, ripe pears, strawber-
ries, oranges, plums, grapes, pumpkins, onions, cucum-
bers etc.
High speed «II» is intended for extracting juice from hard
vegetables/fruits, such as artichoke, carrot, apples, capsi-
cum, beet, potatoes, pineapples, vegetable marrows, celery,
spinach, dill, leek etc.
ATTENTION!
To avoid the grating filter (4) stopping and motor rotor
jamming during the processing of viscous or quite hard
food it is recommended to use the high speed operation
mode «II» of the juice extractor.
• The unit will be switched on only if all the removable parts
are installed properly, and the lid (3) is fixed with the
locks (7).
• Feed fruit/vegetable pieces into the lid (3) feeding chute
(2) only when the grating filter (4) is rotating.
• Gradually put vegetables or fruits cut beforehand into
the lid (3) feeding chute (2) and push them gently with
the pusher (1). Do not press on the pusher (1) too hard
as it can lead to decrease of juice amount as well as
stop the grating filter (4) rotation. The slower is the
fruit and vegetables processing, the higher is the juice
extraction rate.
• Do not put your fingers or any other foreign objects into the
lid (3) feeding chute (2).
• During operation, check the grating filter (4) periodically
for obstruction of the mesh with pulp, if necessary wash
the grating filter (4); before removing the grating filter (4),
switch the juice extractor off and unplug it.
• Control the pulp compartment (10) filling, if the compart-
ment (10) is filled up, switch the juice extractor off, unplug
it and remove the pulp.
ATTENTION!
The juice extractor is equipped with an automatic safety
device which protects the motor from overheating dam-
age while working at maximum capacity. This protec-
tion automatically switches the juice extractor off when
the motor overheats. Should this occur, unplug the juice
extractor and wait for the motor to cool down.
After processing of 500 g hard and fibrous fruits and
vegetables (citrus plants, pineapples, apples, carrots
etc.) disassemble and clean the unit. Non-compliance
with the requirement can cause the grating mesh block-
age and will complicate the unit cleaning.
