Ronix RA-CT64 User manual

CONCRETE NAILER
RA-CT64

USER MANUAL 1
SPECIFICATIONS OF NAILER
.NAME OF PARTS
Body
Driver
Guide
Cantact
Arm Magazine
Cap
Exhaust
Cover
Grip
Air plug
Magazine
End Cap
Click
lever
Trigger
Model RA-CT64
Dimensions (LxHxW) 13" x 12-1/5" x 4-1/2"
330mmx310mmx115mm
Weight 2/93 kg
Operating Pressure 60-100 psi(4-7 kgf/cm2)
Nail Capacity 80 Nails
Nail Specication 14 Gauge concrete nail,shank dia:2.2mm

CONCRETE NAILER
2
FASTENER SPECIFICATIONS
SAFETY INSTRUCTIONS
DANGER!
1) Be sure to put goggles on before operation
Since a fastener red wrongly through careless handling can spring out or
you are always exposed to danger that can be caused by dust and extraneous
substances dispersed by exhausted air, you must always wear goggles for
operation. Goggles should meet requirements of ANSI Z89.1-1997 and
be able to protect both the front and the sides. An employer has responsibility
for having workers and all the other persons wear protective equipment in a
workshop.
2) Put on hearing protective equipment in certain working environment.

USER MANUAL 3
In working environment exposed to loudness which may result in hearing loss,
an employer (management) must provide hearing protection equipment to a
user and others in the workshop and a worker must wear it if necessary.
3) Never use any power source but compressed air.
As this tool is designed and manufactured to operate using air pressure
that is generated by an air compressor authorized by a safety certica-
tionauthority,you can not use any kind of gas combustible gases such as
oxygen and acetylene except this. Otherwise, it may not only cause
mechanical trouble but also malfunction or explosion, resulting in iniction of
fatal injury on a user or those around him or her.
4) Use it within the optimum range of air pressure.
This tool is designed to operate within a range of pressure between 58
psi and 100 psi (or between 4 bar and 7 bar). Connect this tool to a pres-
sure controllable device so that you can work under xed pressure. When
operating this tool, never use it under pressure of 120psi (8bar) and over.
This tool can not connected to the pressure higher than 120 psi(or 8 bar) ,
or will damage the parts.
5) Don’t use it near inammables (combustibles).
Never operate this tool near inammables (such as thinner and gasoline).
Combustible gas from such materials can be sucked into a compressor and
compressed together with air, possibly resulting in explosion.
6) Be careful not to aim or re it toward yourself or any other person in
any case.
You should be careful not to aim it toward yourself or any other person
in any case whether the tool is loaded with fasteners or not. Then, even
if malfunction or undesired ring occurs, you can minimize damage
caused by the red fasteners. Otherwise, it may result in serious injury.
7) Never touch the trigger except when this tool operates for work.
Never touch the trigger except when air is connected to this tool, which
operates for work. It is especially very dangerous to change the position or
move around during operation with your nger xed on the trigger, and you
may not do any similar action. Otherwise, possible carelessness may result
in iniction of serious injury on a user or those around him or her.

CONCRETE NAILER
4
WARNING!
8) Connect a proper connector to this tool correctly.
The connector for this tool should never have pressure kept when air
supply is cut off. If an improper part is applied, then the tool can operate
due to pressure left within it even after the airline is disconnected possibly
resulting in injury.
9) Disconnect the air line and empty the fasteners out of the container in
case that the tool is not used.
Be sure to cut off air supply and empty the fastener container when the
work is completed or when you move to another workshop, maintain,
disassemble, or repair this tool, or clear jam. Make sure that the airline
is disconnected in loading the container with fasteners again.
CAUTION
10) Make sure that each fastener is locked tightly.
The tool can be damaged if you use it with each fastener loosened, or
screws or bolts assembled wrongly. Make sure that all screws and bolts
are assembled correctly and tightly before using the tool.
11) Never let a worker remove or manipulate a safety device, or recompose
the tool at his or her discretion.
If you remove a safety device, or manipulate or recompose the tool at
will, it can cause a drop in performance and breakdown of the tool and
result in injury due to mechanical trouble and malfunction.
12) Be sure to disconnect the air line and empty fasteners out of the
container if the tool is not used.
You must disconnect the air line and empty the fastener container when
the work is completed or suspended, when you go out of a workshop,
when you move or transfer the tool, or on other occasions.
13) Stick the muzzle correctly to the target plane for drive a fastener.
If correct drive a fastener is not implemented on the target plane, the
red fastener can spring out, possibly resulting in injury.
14) You are prohibited from using the tool for other purposes than drive
a fastener and from throwing or dropping it.

USER MANUAL 5
The resultant shock can cause damage to main parts or malfunction,
possibly resulting in injury.
15) Never drive a fastener on hard or thin objects, an edge of the target
surface or a fastener crown already driven.
Otherwise, the fastener fails to be driven in but springs out, thus inicting
an injury on a worker or those around him or her.
16) Conduct operations in an upright and safe position all the time.
Long-time work in an unstable and wrong position may put excessive
stress on the body, possibly resulting in an injury.
17) When the temperature falls below zero, it is important to note that
you should keep the tool warm in a safe and convenient way.
If you fail to do this, make the tool get warm according to the following
procedure.
Control air pressure in the range of 40psi to 70psi.
Remove all the fasteners loaded in the tool.
Connect the airline to the tool and try mock drive a fastener.
- Keep pressure low enough to operate the tool in a proper way.
- Operate it slowly to let the actuator get warm.
- Piston operation helps bumper and O-ring maintain the original elasticity.
APPLICATIONS
ST Nail
Trusses Building
Wood to Concrete
Finish Construction
Crate & Box Assembly
Cabinet Framing
-

CONCRETE NAILER
6
INSTRUCTIONS FOR OPERATION
.BE SURE TO READ THE SAFETY INSTRUCTION BEFORE USING
THIS TOOL.
.PREPARATIONS
1) Be sure to put on personal protective equipments for example, goggles,
earplugs, safety cap before using this tool.
2) Be sure to use an air compressor authorized by the safety certication
authority as a pressure source for operating this tool within the optimum
range of pressure (58~100psi).
3) Make sure that this tool has no trouble about the safety device, the
trigger, fasteners such as bolts, and so on.
4) Inject three or four drops of oil used exclusively for a tool into the air
plug before using this tool. (Do this regularly once a day if possible.)
5) Check the airline and the air connector for damage and don’t use
longer airline than necessary (over 17ft).
PRELIMINARY CHECKUP
1) To give a checkup to the tool, adjust the operating pressure to
58 psi (4 bar) before air connection.
2) Keep pressure low as far as it may cause no trouble in operation
within the optimum range of pressure according to hardness of the
working plane and length of fasteners.
LOADING NAILS
WARNING!
Turn the muzzle downward and never pull the trigger in loading or unloading
nails.
1) Pull the magazine backward with the click lever pressed.

USER MANUAL 7
2) Load nails from the side of the magazine.
3) Keep pushing the magazine until it is xed in the click lever.
UNLOADING NAILS
1) Pull the magazine backward with the click lever pressed.
2) Unload nails from the side of magazine.
3) Keep pushing the magazine until it is xed in the click lever.
MAINTENANCE AND INSPECTION
Be sure to read the safety instruction before inspecting or maintaining
this tool.
WARNING!
Be sure to disconnect the air line before clearing jam, or repairing or
inspecting the tool.
- Implement single/contact re operation and turn the trigger lock with
the ngertip switch pressed

CONCRETE NAILER
8
1) Single re operation
- Be sure to use only Single re operation when this tool is red on
concrete surface.
For operation on a precise position by one re, put the ngertip
switch toward the single re form ( ) and pull the trigger with the
contact teeth pressed against the target position for nailing.
2) Contact re operation
For successive res, put the ngertip switch toward the contact re
form ( ) and keep the contact teeth pressed against the target
position for nailing with the trigger pulled.
.CLEARING A JAM
If jam occurs during the nailing process, clear it according to the
following procedure.
1) Disconnect the air line from the tool.

USER MANUAL 9
2) Unload nails left in the magazine.
3) Open the guide cover B.
4) Use a long nose to remove a nail caught in.
CAUTION
- After clearing jam, make sure that the product has no trouble before using it.
- If jam or other factors damage main parts, it can prevent normal operation.
- If any trouble occurs, stop using the tool and ask a nearby A/S center
or a distributor for A/S.
INSPECTING THE MAGAZINE
1) Disconnect the air line from the tool.
2) Inspect if the inside of the magazine is cleared or damaged. (Dust or
alien substances such as pieces of wood in the operation body of the
pusher within the magazine can prevent smooth operation.)
STORING
1)When not in use for an extended period, apply a thin coat of the lubricant
to the steel parts to avoid rust.
2) Do not store the tool in a cold weather environment. Keep the tool in
a warm area.
3) When not in use, the tool should be stored in a warm and dry place.
4) Keep out of reach of children.
5) All quality tools will eventually require servicing or replacement of
parts because of wear from the normal use.
OPERATOR TROUBLESHOOTING (REFERENCE)
.SUPPLEMENT TO THE OPERATING INSTRUCTION
According to the European Norm EN 792-13 the regulation is valid from
01.01.2001 that all fastener driving tools with contact actuation must be

CONCRETE NAILER
10
marked with the symbol “Do not use on scaffoldings, ladders” and they
shall not be used for specic application for example:
- When changing one driving location to another involves the use of
scaffoldings, stairs, ladders or ladder alike constructions e.g. roof laths.
- Closing boxes or crates.
- Fitting transportation safety systems e.g. on vehicles and wagons.
SERVICE AND REPAIRS (A/S REQUEST)
WARNING!
- It is important to note that users or distributors who want to have this tool
repaired must get A/S from A/S personnel trained in RONIX SERVICE.
- Use only parts supplied or authorized by RONIX SERVICE for repair.
MAINTENANCE CHART & OPERATOR TROUBLESHOOTING
1) Maintenance Chart
Practice Reason Method
Drain air line lter
daily
Prevent accumulation of
moisture and dirt.
Open manual petcock.
Keep lubricator lled. Keep the tool lubricated Fill with RONIX SER-
VICE pneumatic tool
lubricant.
Clean magazine and
feeder mechanism.
Prevent a jam & Dry re. Blow clean daily.
Lubricate the Tool
after nailing.
Extend the tool life. Supply 3~4 drops of
lubricant into the tool.
Drain air compressor. Keep the tool operated
properly.
Open petcock on air
compressor tank.

USER MANUAL 11
2) Operator Troubleshooting
Problem Check Method Correction
Tool operates, but no
nail is driven.
Check air pressure. Reduce air pressure.
(58~100psi)
Check for a jam. Clean a jam. (Refer to
4-1)
Check for proper nail. Use only recommended
nails.
Tool operates, but no
nail is driven.
Check air line & Plug Check for air line connection
and damage to tting
part (Change it in case
of damage)
Check for abnormality in
head valve
Change O-ring in case
of damage
Check air pressure. Reduce air pressure.
(58~100psi)
Check position Piston
set
Readjust.
- Supply of lubricant into
the tool.
Driver blade worn or
damaged?
Part change (Contact
RONIX SERVICE or
Distributor)
Piston O-ring worn or
damaged?
-
Check air pressure. Reduce air pressure.
(58~100psi)
Check air pressure. Reduce air pressure.
(58~100psi)
Check for proper nail. Use only recommended
nails.
- Supply of lubricant into
the tool.
Piston O-ring cut or
heavily worn?
Part change. (Contact
RONIX SERVICE or
Distributor)
Check air pressure. Reduce air pressure.
(58~100psi)
Check inside diameter of
air hose.
Use larger air hose.
