ROOMS TO GO HNCL 9650-LS User manual

1
Manufactured for Rooms To Go
HNCL
LIST OF PARTS
NO Description Item QTY
A
B
C
1
1
D
1
4
E
LAF Backrest
RAF Backrest
Wood Leg
9650-LS LOVESEAT SKU#14296506,14296518,14297015
LOVESEAT
Lvst Body
B
C
Legs and hardwares located in the zip pocket
A
12
Cross-head Bolt
M8 x 30mm Thread
TOOLS REQUIRED:SCREWDRIVER (Not Included)

1
Manufactured for Rooms To Go
HNCL
9650-SF SOFA SKU#14197013,14196504,14196516
SOFA
LIST OF PARTS
NO Description Item QTY
A
B
C
1
1
D
1
1
1
E
Sofa
Body
4
G
Middle Support Leg
F
LAF Backrest
Middle Backrest
RAF Backrest
Wood Leg
Legs and hardwares are located in the zip pocket
B
C
D
A
12
TOOLS REQUIRED:SCREWDRIVER (Not Included)
Cross-head Bolt
M8 x 30mm Thread

ASSEMBLY INSTRUCTION
Step 2
Attach the backrests B,C,D to back frame by zippers.
2
Zipper
A
Step1
Take off the legs
E,F and hardware G from the zip pocket at the bottom of the sofa. Align
wood legs E
to
the pre-drilled holes,insert bolts,then use screwdriver to tight the legs. Insert
the bolt of the middle support legs F in the pre-drilled holes at the central then turn the leg
clockwise until the leg are tightened.
F
X3
G
E
B
C
D

ASSEMBLY INSTRUCTION
2
Step 2
Attach the backrests B,C
to back frame by zippers.
Zipper
A
Step1
Take off the legs
D and hardware E from the zip pocket at the bottom of the furniture.
Align wood legs
D
to
the pre-drilled holes,insert washers and bolts,then use screwdriver to
tight the legs.
D
X3
E
B
C
