Rosewill RC-20003 User manual

1
Thank you for purchasing a Rosewill PCI Express Card.
Please read the instruction manual before use and retain for future reference.
RC-20003
INTRODUCTION
1.1 Features
• Supports 2 x USB 3.2 Gen 2 ports
• Supports PCIe 3.0 x2
• Compliant with PCI Express Base 3.0 Specication
• Compliant with USB 3.2 Specication Revision 1.0
• Up to USB 3.2 Gen 2 10 Gbps Bandwidth Performance with Low Latency
• Compatible with USB 3.2, USB 3.1, USB 3.0 and USB 2.0 devices
• Supports Multiple INs
• Compliant with UASP Revision 1.0
• Max. current output 3A per port
• 15-pin SATA Power connector
1.2 System Requirements
• Windows 8.x/10 (32/64-bit); Windows Server 2012
• Mac OS X 10.10 or later
• Linux 3.5 or later
• One available PCI Express x4, x8 or x16 slots
1.3 Package Contents
• 1 x PCIe USB 3.2 Gen 2 Host Adapter
• 1 x Quick Installation Guide
• 1 x Low Prole Bracket

GETTING STARTED
2.1 Hardware Installation
1. Turn off the power to your computer.
2. Unplug the power cord and remove your computer’s cover.
3. Remove the slot bracket from an available PCI Express slot (x4 x8, or
x16) .
4. To install the card, carefully align the card’s bus connector with the
selected PCIe slot on the motherboard. Push the board down rmly.
5. Replace the slot bracket’s holding screw to secure the card.
6. Secure the computer cover and reconnect the power cord.
2.2 Driver Installation
1. Drivers are embedded into Windows 8.x/10 and macOS; the drivers can
be installed automatically.
RC-20003_A
Technical Support Information [email protected] 1-800-575-9885
Please register your product at www.rosewill.com for complete warranty information and support for your product.
