Rosewill RSL-112 User manual

PIR Solar Spotlight/PIR Solaire Lumière
RSL-112
User Manual

PIR Solar Spotlight/PIR Solaire Lumière RSL-112 User Manual
1
2/ drill 4 holes on the wall based on the four
tubes in the battery back cover, insert the
bulged tubes in the holes, and fix the battery
back cover with screws.
3/ slip the solar light body up to down until the
hasp inside is connected, fix the body with
screws.
4/ adjust the angle of light head & PIR sensor
1·Solar light parts
2·Battery Charge
In normal condition, the batteries inside the solar light are fully charged. You can use the light directly. If
not, please fully charge the batteries before using: turn the switch “on” for sunny daytime and turn it
“off” when darkness comes. Repeating for 2 days (about 16 hours), the batteries would be fully
charged.
3·Solar Light Body Installation
1/loosethescrewsandremovethe
battery back cover from the light
solar light head ④battery back cover
①solar light body
③PIR sensor
⑦plug
⑤solar panel
⑥panel base
⑾screw
⑩socket ⑿on/off switch
⑧screw*6 ⑨bulged tube*6

PIR Solar Spotlight/PIR Solaire Lumière RSL-112 User Manual
2
*Avoid installation near
places where there would
be waving objects.
*Avoid installation near
objects that would release
hot air.
*Avoid installation near
places with strong
reflection.
*Avoid installation near
places already has strong
night light.
*Avoid installation in places
that easily waves.
*Avoid installation in places
where there would be eternal
movement with animals.
1/ Take the solar panel and panel base.
3/ Twist the solar panel on the panel base.
2/ Drill two holes on the wall based in the holes in
the panel base, then insert in the panel base, then
insert the bulged tubes into the holes. Finally fix
the panel base on the wall by screws.
Remarks For Installation
* Do not install the light where people can be easily to be hurt in case of drop.
* Install the light in horizontal level.
* Please do not install the light in following places.
4·Solar Panel Installation

PIR Solar Spotlight/PIR Solaire Lumière RSL-112 User Manual
3
1/ insert the wire plug into the socket on the
bottom of the solar light body.
2/ turn the switch “on” after completing
installation.
Please check the following data for the
sense range.
Remarks: This sense range will verify with
different environment, like temperature,
place, climate etc.
*Make sure the solar panel is installed where direct sunlight is sufficient.
Make sure the panel is
45°from the horizontal level.
This angle can be adjusted.
Be away from shadow of
trees or buildings.
Be away from place where
other night lights existing.
1/ LED can’t be replaced
2/ Battery replacement
* Turn the switch “off”
* See 3. Solar light body installation
* Replace the batteries with 3pcs 1.2V AA
900mAh Ni-MH rechargeable batteries
Remarks For Installation
WARNING: please regularly check the panel and light after installation, to avoid any
unpredictable fire or electronic shock!
5·Complete The Installation 6·PIR Sensor Sense Range
7·Replace the parts

PIR Solar Spotlight/PIR Solaire Lumière RSL-112 User Manual
4
8·Problem Solving
*Make sure the switch is “on”.
*Make sure the panel is not broken.
*Make sure the panel is installed in places free from shadow
*Make sure the panel is not polluted by dirt. If have, please clean it with water by soft cloth. Do not
use solvents. Take extreme care not to scratch the clear cover.
9·Safety Guide
*The solar light is waterproof on normal conditions, but please make sure it is not always exposed to
a lot of water, or installed in some moist places, like bathroom.
*Make sure hands are not wet when replacing the batteries.
*Make sure not to reconstruct the solar light by yourself, to avoid any possible malfunction, fire or
electronic shock.
*Make sure the solar light is not installed where the temperature is too high.
*Please notice that the Ni-MH batteries recharging capacity might decline under extreme low
temperature.
*The LED inside can not be replaced.
10·Technical Data
LED: Nichia 1pc 1watt power LED
Battery : 3pcs 900mAh Ni-MH batteries
Sensor : PIR sensor
Sense Range : about 6m*90°
Light duration per sense :30~40 seconds
Material : plastic
Wire length : about 5m
Thank you for purchasing a quality Rosewill Product.
Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
