MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
Form#5320,Rev.RTP,08‐09‐12
















KITCONTENTS








ITEM#QTYDESCRIPTION
11PASM,HARN,PAS,CAM,RCA,DC
21PASM,HARN,PAS,VIDEO,OUTPU
T

31PASM,HARN,PAS,MAIN,ACC+/‐,OBD2
41PASM,MOD,PAS
51CANEXTENSIONHARNESS
1
2
3
4
5


MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
2
BEFOREBEGINNINGINSTALLATION

1. Readandunderstandtheentiremanual.

2. ValidatePASkitcontents.

3. PASmustbeinstalledwiththeprescribedcameraintheprescribedlocation.

4. CameraSystemmustbeinstalledandfunctionalbeforeinstallingPASInordertosavetimeintroubleshooting.

















RostraPASpartnumber250‐8883hasbeen
designedtoworkdirectlywiththe250‐
8137/250‐8115CAMERAASSYONLY!This
productmustbeinstalledasperthis
instructioninorderforittofunctionas
desi
g
ned,testedandadvertised.


MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
3
























RemovePassengersidekickpanelto
gainaccesstoCanJunction/wires.
(greenw/white+/green‐)
ConnectRedwirefromCanExtension
Harnesstogreenw/whitestripewire.
ConnectBlackWirefromCan
ExtensionHarnesstogreenwire.

Locatefusepanel
underneathdriver‐side
dash.
ConnectRedDC+
harnessleadtoBlack
withYellowStripe(+)
atgrayconnectorof
fusepaneland
ConnectBlackDC‐
harnessleadtoBrown
VehicleGroundWire.


MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
4
THEBENEFITSOFTHEREARSIGHTPARKASSISTSYSTEM(PAS)

1. DrivingTrajectory–ThePASusesthesteeringanglesensorfromthevehicletocreateagraphofthevehicle’s
backingtrajectory.ThesystemtakestheguessworkoutofwherethevehiclewillendupwhenBacking‐Up.

2. SizeMatters–Havingenoughroomtoparkisalwaysaquestion.Knowingthespaceislargeenoughandwhere
thevehiclewillendupreducesstressandanxietyoverbackingupwhetherbackingintoperpendicularor
parallelparkingplaces.

3. Blindspotsdooccurandsocautionmustalwaysbeusedwhendrivinginreverse.Notethattherearviewand
sideviewmirrorsmustbeobservedandalsothefrontofthevehiclewhenusingthisproduct.Thisisnotan
auto‐parkproductandismeanttoonlyassistthedriverinparkingthevehicle.



MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
5
REVERSEPARKINGwiththeREARSIGHTParkAssistSystem(PAS)
























MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
6
PARALLELPARKINGWITHTHEREARSIGHTParkAssistSystem(PAS)


























YES I
T
WILL!
WILLITFIT?


MERCEDESSPRINTER‐  PARKASSISTSYSTEM/CAMERAKIT2010‐2012
PARTNUMBER:250‐8883
7
TROUBLESHOOTING
1. GreenLightonMirrorisFlashing:
a. VerifythatOBDIIConnectorfromPASsystemispluggedintoOBDIIconnectoronvehicle.
b. VerifyVideofromPASmoduletoMirrorisconnected.
c. WithTruckinReverseGearverifyVoltageinthecenterofDCConnectorcomingfromthePASmodule
hasareadingof10‐16+VDCmeasuredtoground.
d. VerifyconnectiontoAccessoryPoweronRedWireofPASmodulemeasures10‐16+VDCmeasuredto
ground.
2. Directionalarrowdoesnotcorrelatetosteeringwheelposition:
a. Cameradirectionmayneedtobeadjustedtocalibratepositiontoarrow.





