COMPLICITY 300M
Owner’s Manual
Adjustable Bed Base
ROTEC INTERNATIONAL
123, RUE DE L'ÉGLISE, BAIE-DU-FÈVRE
QUEBEC, CANADA J0G 1A
All Rights Reserved Rev 3.0 09/2021

CONTENTS
Safety & Warranty Warning 1
Parts List 2
Base Installation Guide 3
Electronics Quick Reference Guide 5
Remote Controls Pairing 6
Backlight Remote Control Guide 6
Device in Case of Power Failure 8
APP Control Guide (iPhone & Tablet) 8
Troubleshooting 9
Warranty 10
Read BEFORE using this product
IMPORTANT SAFETY INSTRUCTIONS
When using electric equipment, basic precautions should
always be followed, including the following:
DANGER –To reduce the risk of electric shock
Always unplug this adjustable bed base (base) from the
electrical outlet before cleaning or servicing.
WARNING –To reduce the risk of burns, fire,
electricshock,or injury:
1. Unplug from outlet before putting on or taking off
parts.
2. Close supervision is necessary when this base is
used by, or near children, invalids, or disabled
persons.
3. Use this base only for its intended use as
described in these instructions. Do not use
attachments not recommended by the manufacturer.
4. Never operate this base if it has a damaged cord
or plug, if it is not working properly, if it has been
dropped or damaged, or dropped in water. Return the
base to a service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Do not use this base outdoors.
7. Do not use this base near explosives.
8. Using the base with oxygen administering
equipment other than the nasal masked type creates
a possible fire hazard.
9. Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.
10. To disconnect, turn all controls to the off position,
then remove plug from outlet.
11. Use caution when there are liquids in or around the
base to ensure no spilling occurs. In case of spillage,
stand in a dry, clean area of the floor and unplug the
base immediately. Clean up the spill and allow the
area around base to dry thoroughly before using the
electric controls again. Do not eat or drink hot liquids
while operating the base.
12. Do not allow any person or pet under the base at
any time.
13. During base operation, make sure body is well
positioned within the confines of the base. Do not
place extremities over the sides of the bed when
operating base functions.
14. Only for household and similar use.
15. Never operate the base with the ventilation openings
blocked.Keep theventilationopeningsfreeoflint,hair,
and the like.
16. Never drop or insert any object into any opening.
SAVE THESE INSTRUCTIONS
WEIGHT LIMITS
Weight Restrictions: The recommended weight limit
on this baseis750pounds. Thebasewillstructurally
support this weight, provided it is evenly distributed
acrossthebase. The power base is not designed to
support or lift the total weight in the head or foot
sections alone. Exceeding this weight restriction
could damage the base and/or cause injury and will
void the warranty.
WARRANTY WARNINGS
Anyopeningortamperingwiththecontrolbox,motors,
or hand controls (with the exception of the battery
compartment if equipped) will result in a void of the
warranty.
PRODUCT RATING
The motors are notdesignedtooperate continuously
formore than2minutesina 20 minute-time period or
approximately 10% duty cycle. Attempting to
circumvent or exceed this rating will shorten the life
expectancyofthe baseandmayvoid the warranty.
OPERATING INFORMATION
1. After base assembly is completed, operate remote
control to ensure proper functions.
2. Keep moving parts free of obstruction during bed
operation (including sheets, clothing, tubing, wiring,
and products using electric power cords).
3. Do not place entire weight on head or foot sections
of the bed, during repositioning and entering or
exiting bed.
HOSPITAL DISCLAIMER
This base is NOT designed for hospital use and is
NOTdesigned tomeet hospital standards.
FCC COMPLIANCE
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevice may
notcauseharmfulinterference; (2)thisdevicemustacceptanyinterferencereceived,includinginterferencethat may cause
undesiredoperation.
TocomplywiththeFCCRFexposurerequirements,nochangetotheantennaorthe deviceispermitted.Anychangeto the
antennaorthedevicecouldresultinthedeviceexceedingtheRFexposurerequirement andvoiduser’s rightto operate the
device.
FREQUENCY: 2.4 GHz
1

9V 9V
Parts List
Allelectronicsandcomponentsthatneedtobeinstalledareplacedinboxesunderthebaseor
attached
to the frame. Before discarding the packing materials, ensure that all the parts are accounted for.
Wireless Remote Power Supply AC Power Cord Mattress Retainer Bar Adjustable Legs Device in case of
Control 29V 2.0A Power Failure
Bluetooth Synchronisation Cord
Not Included
3 AAA batteries for 2 9V batteries for the device in case
each remote control of power failure
NOTE: To avoid damage to the base, always open the carton while the base is in the flat position.
Base Installation Guide
Two people are required to set up the base.
x2
x1
x1
x1
x6
x1
x3
Battery
9V 9V
3"+6"
x1
1.
x2
x1
x1
x1
x6
3"+6"
Remote Control Power Supply
(29V 2.0A)
AC Power Cord Mattress Retainer Bar Adjustable Legs
x1 x1 x1
Device in case of
Power Failure
Bluetooth
Open the box, take out all the packing components.
2.
Remove the base from the box. Make sure the floor is clean. Lay the base flat on the floor.
3.
Install legs and tighten byhand.
3
2
x1
Synchronisation Cord

Headboard
For efficiency, cost savings and safety reasons, Rotec recommends that users fix their headboard directly to the
wall (material not included).
Electronics Quick Reference Guide
+
DONE!
Wireless Remote Controls
3
4
5
Foot Motor
4.
Mattress Retainer Block
Carefully turn the base over soitis resting
on its legs.
5.
Slide the left side of the mattress retainer bar
into the bracket. Pull the retainer bar to the
opposite bracket and secure the right side.
6.
ConnecttheDCpowercordtothepowersupply,uncoiltheACpowercord
and then connect it to theAC power source.
AC Power Source
DC Power Cord
AC Power Cord
Power Supply
Connect the connectors as illustrated.
7.
Insert 3 AAA batteries (not included)
into each remote control.
LEFT
RIGHT
Left Head
Motor
Right Head Motor
USB Charger
Under-bed Lighting
Bluetooth
Left Side Massage
Right Side Massage
Power Supply
Y Cable
Y Cable
Y Cable
Left Head Right Head Foot
Motor Motor Motor
Control Box
(under the base)

Remote Controls Pairing
The remote controls that come in the box are already paired to their adjustable base. No further action is required.
If a remote control is not paired with the base, follow the steps below:
1. Unplug the base from the power source then turn it back
on, defaulting to remote pairing within 30 s.
2. Next, press and hold at the same time.
3. You will hear a beep from the buzzer and the backlight of
the remote control will flash twice, which means the
pairing is successful. Release the buttons.
Backlight Wireless Remote Control Guide
Adjustment
LEFT HEAD UP/DOWN BUTTONS DUAL HEAD UP/DOWN BUTTONS
Press and hold to lift or lower the Press and hold to lift or lower simultaneously the
LEFT HEAD section. independent heads.
RIGHT HEAD UP/DOWN BUTTONS FOOT UP/DOWN BUTTONS
Press and hold to lift or lower the HEAD Press and hold to lift or lower the FOOT section.
section.
One Touch Buttons
Press to memorize the desired position.
STEP 1: Operate the remote control to get your desired position.
STEP 2: Press and hold"M" formore than3 s until you hear abeep of the buzzer onthe control box; the
backlight of the remote control flashes twice, which means the memory position is saved.
Press to turn on the massage.
Press the button once to increase one intensity level. There are 3 intensity levels available. When it has
been in the 3rd level, press the button again and the massage will turn off. The massage motor will turn off
automatically after 30 min.
Pressto adjustthe basetotheprogrammedreclinedposition for optimumweightdistribution.
Press to adjust de base to the flat position.
Presstoturn on the under-bed lighting. The lightwillturn off if thebuttonis not pressed within 10 min.
Presstoadjustthebase tothepre-programmedanti-snorepositionthat letsyougeta restful night.
6
6
Memory
Right Head Lowering
Simultaneous Lifting of
Independant Heads
tête
Left Head Lowering
Flat
Foot Lifting
Simultaneous Lowering of
Independant Heads
Left Head Lifting
Right Head Lifting
Under-bed Lighting
Zero Gravity
Left Side Massage
Right Side Massage
Anti-
Snore
Anti-snore
Foot Lowering
