Rotem DRM-3000 User manual

DRM-3000 Multi-Probe Area Meter
Operating Manual
Ver. 1.11

DRM-3000

DRM-3000
The publication, translation or reproduction, either partly or wholly, of this
document are not allowed without our written consent
Under no circumstances can the detectors be connected or disconnected
when the Unit is under power.
Considering local regulation in force: person and equipment protection
against electric shocks, Rotem Industries Ltd. recalls that ANY WORK
ON A POWERED EQUIPMENT SHALL MANDATORILY BE
PERFORMED BY QUALIFIED AND AUTHORIZED PERSONNEL.
Ionizing radiation of the sources used is dangerous for the worker
whenever the protective measures are not strictly applied.
Although our equipment items are built in compliance with the most
severe safety standards, the ionizing radiation source represents a
danger when the worker is not qualified or not warned.
ANY HANDLING OF RADIOACTIVE SOURCES SHALL MANDATORILY
BE
PERFORMED BY QUALIFIED ANO AUTHORIZED PERSONNEL.
Consequently, all precautions shall be taken to prevent any non-
authorized or non-qualified person from using this equipment,
endangering others and themselves.
Prior to any handling, those qualified and authorized to use this
equipment shall get information on the protective measures set forth by
the national standards in force.
Abandon or destruction of equipment containing a radioactive source is
FORBIDDEN. If no longer required, the user must inform Rotem
Industries who will arrange to take the source back (according to the
contract) and establish a certificate stating that the source has been taken
back. In the event that the source is lost or stolen, the user must inform
the appropriate authorities soon as possible
Directive 2002196/EC of the European parliament and of the council of
January 2003 on waste electrical and electronic equipment (WEEE). At
the end of the product's useful life, please dispose of it at appropriate
collection points provided in your country

DRM-3000
Revisions Log
Revision Date Origin and designation of modification Modified pages
1.00 05/05/2019
Added:
1. Replacing SD card
2. Updating the Firmware
25 and 28
1.01 17/06/2019
Added:
1. Cal Due: Display command
2. Display Graph option
3. Display Average option
4. Calibration option
1.02 18/07/2019
Added:
1. 8.4 Setting up the Meter
2. IP Cam instructions
1.03 15/08/2019 6.3.1 Changed Power Input Specs
1.04 03/09/2019
Added calibration position of DRM-
3000
for internal detector
Updated screens
1.05 10/10/2019 Updated Section 7 Updating the DRM-
3000 28 to 33
1.06 04/11/2019 Added Icon and explanation of the
average function 20, 23 and 26
1.07 05/03/2020 Updated screenshots
Simplified Connection Instructions
1.08 19/04/2020
Added background color explanation
Added Alarm Confirmation Procedure
Added Latching explanation
19 and 29
1.09 07/05/2020 Added Operating System Details 8
1.10 06/07/2021 Solenoid activation upon power up 15
1.11 29/11/2021
Replaced Pictures showing new ext.
detector numbering
Replaced calibration certificate (Sv/h)
10, 11
49

DRM-3000
Table of contents
1 Introduction ........................................................................................................................ 7
1.1 General ............................................................................................................................... 7
1.2 Field of use ......................................................................................................................... 7
1.3 DRM-3000 main advantages .............................................................................................. 8
2 Technical Specifications ................................................................................................... 8
2.1 Operating System Details ................................................................................................... 8
3 Supported Detectors ......................................................................................................... 9
4 Description ....................................................................................................................... 10
4.1 Physical presentation ........................................................................................................ 10
4.2 Connector View ................................................................................................................ 10
5 Mounting the DRM-3000 .................................................................................................. 11
5.1 Wall Mounting ................................................................................................................... 11
5.2 Table Top Mounting .......................................................................................................... 11
6 Operation .......................................................................................................................... 12
6.1 Detectors .......................................................................................................................... 12
6.1.1 Connecting the Detectors .................................................................................... 12
6.2 Response Times for the GM Tubes .................................................................................. 13
4.1.1 Automatic Range Switching for the DRM-3000 .................................................... 13
6.3 Power ............................................................................................................................... 14
6.3.1 Power Consumption ............................................................................................ 15
6.4 The Aux Connector ........................................................................................................... 15
6.5 The LAN connector ........................................................................................................... 17
6.5.1 The IP address .................................................................................................... 17
6.6 Installing the WRM2 Transmitter ....................................................................................... 18
6.6.1 WRM2 Radio Transmitter Characteristics ............................................................ 18
6.6.2 Configuring the WRM2 Module ............................................................................ 18
6.6.3 Inserting the WRM2 Module................................................................................. 18
6.7 Pushbuttons, Icons and Menus ......................................................................................... 19
6.7.1 Background Colors .............................................................................................. 19
6.7.2 Confirming an Alarm ............................................................................................ 19
6.7.3 Pushbuttons ......................................................................................................... 20
6.7.4 Icons .................................................................................................................... 21
6.7.5 Menus .................................................................................................................. 21
7 Communication ................................................................................................................ 30
7.1 Protocol ............................................................................................................................ 30
7.2 Communication Protocol ................................................................................................... 30
8 Updating the firmware of the DRM-3000 ........................................................................ 32
8.1 Updating the CPS Firmware ............................................................................................. 32
8.2 Updating the CPU Firmware ............................................................................................. 35
8.3 Replacing the Firmware SD card ...................................................................................... 37

DRM-3000
9 RMVC accessible functions ............................................................................................ 38
9.1 Defining the IP connection ................................................................................................ 38
9.2 Real time Monitoring ......................................................................................................... 39
9.2.1 Connecting to the DRM-3000 ............................................................................... 39
9.3 Downloading the data ....................................................................................................... 39
9.4 Setting up the Meter ......................................................................................................... 40
10 Real time Calibrating ....................................................................................................... 42
10.1 Setup ................................................................................................................................ 44
10.1.1 Recommended Calibration Points ........................................................................ 45

Page | 7 DRM-3000 Operating Manual
1 Introduction
1.1 General
The Data Radiation Meter-3000, is a multiple detector based dose rate meter, capable of
supporting one internal gamma detector and three external detectors by using state-of-the-art
microprocessor-based technology and combined telemetry of the WRM2 900 MHz or 2.4 GHZ
FHSS radio. The DRM-3000 is designed for highly stable and accurate dose rate
measurements from different types of detectors.
The DRM-3000 is a lightweight and compact instrument with sophisticated software offering
special features and optimal performance for telemetry data.
The RMVC Software is used to configure (RMV) and calibrate (RMC) the DRM family of
detectors.
An automatic self-diagnostic procedure continuously checks both electronics and detectors
and reports any case of detector failure.
The DRM may be used in the following ways:
by connecting the meter to a PC
by connecting the meter to a DDC-16/AM-16 Area Meter (wired) or RS-485 cable
by using the internal WRM2 FHSS radio to transmit data
by using an internal or externally connected network adapter
The meter includes four electronic boards:
PCL R1010V4.0 CPU Board- responsible for managing the GUI
PCL R1011V4.0 CPS-MAIN Board – responsible for managing the external detectors
PCL R1020V2.0 CPS-STACK Board – responsible for providing the H.V. to AMP detectors if
required.
PCL R1021V1.0 DC2DC Board – responsible for providing 24VDC if required
PCL R1022 V1.0 Internal W.R Detector – If required
A built-in TCP/IP is the connection used for calibration and configuration. The WRM2 FHSS
radio is already included in the DRM-3000 package and a base station (ROTEMI P/N: WR2-
9001) is needed for reception of telemetry data.
1.2 Field of use
The DRM-3000 has been designed to be mounted in a strategic position providing up to four
radiation levels simultaneously thus providing the users, a comprehensive overview of the
radiological conditions in the work place. Each of the four sections can be programmed to
display the Dose Rate, Accumulated Dose and Detector Name. The background color of each
section reflects the relationship between the dose rate and threshold levels thus providing an
extra input for the user.
The radiation data is stored internally in each meter for a month and can also be exported to
an external Control Station in TCP/IP, POE, 485 or wireless modes.

Page | 8 DRM-3000 Operating Manual
1.3 DRM-3000 main advantages
 Single Meter Supporting 4 detectors – More cost effective
 Large Color Display with color coded background– Radiological conditions are clearly
shown
 TCP/POE Data transmission and power supply – No need for external power sources
 Saves Data for a period of one month – Can be downloaded online or at a later stage
 Supports a wide range of external detectors
2 Technical Specifications
Casing:
High Impact Plastic (ABS-PC) with Aluminum back cover
Display:
7" HD Display background color according to dose rate
Power Source:
External DC Power, POE and Internal Battery (24 hours). Charging Time - 5 hrs.
I/O:
3 x External Detectors Serial (RS-485) or Digital pulse or Analog pulse
AUX connector D-Type 26 pin
RS
-
485 and 4
-
20 mA and
External Power 24V
and optional light tower and Dry contact
RJ-45 Ethernet Cable
10/100 BASE –TX PoE/IEEE 802.3 af/at compliant
Temperature Range:
Operation: -25oC to +55oC (-13oF to 131oF)
Humidity Range:
40% to 95% RH (non-condensing)
Alert indicators
Buzzer 85 dB at 30 cm
High Volume Buzzer 100 dB at 30 cm
Multicolored LED
Colors: White, Green, Yellow, Red, Purple,
Blue and Light Blue
Advanced Detector Bracket with 3 colored LED's and buzzer
Remote Light Tower (5 colors) showing Worst Case Scenario
Dimensions:
Meter: 25 cmW x 23 cmH x 7 cmD (10" x 9" x 2.75")
Weight:
1.75 Kg (3.9 lbs)
Internal Detector:
Optional
Detectors:
GM Tubes, ZP-1301 and ZP-1201 (or equivalent)
Measuring Range:
0.5 µSv/h to 10 Sv/h (50 µR/h - 1,000 R/h)
Sensitivity:
0.3 - 18 cps/mR/hr (137Cs)
Accuracy:
±10% of reading
Units:
mR and mR/hr or µSv and µSv/hr
Max Cable Length:
100 meters/yards from Instrument to Detector
2.1 Operating System Details
LINUX kernel release ver.
3.14.52
-
1.1.1 ga
Operating system
ARM CORTEX A7 32 bit Main Processor
SD 8 Gb
Storage
RTC: ds1307 Battery: BQ40Z50 OS supported drivers for external devices

Page | 9 DRM-3000 Operating Manual
3 Supported Detectors
The following detectors are supported by the DRM-3000. The maximum cable length between the
Meter and Detector is 100 yards.
Description
Measuring Range
Wide Range Gamma 0.5 µSv/h to 10 mSv/h
(50 µR/h to 1R/h)
High Range Gamma 1 µSv/h to 1 Sv/h
(0.1 mR/h to 100 R/h)
Low Range Gamma 0.5 µSv/h to 10 Sv/h
(50 µR/h to 1,000 R/h)
AMP-300 Gamma 1 mSv/h to 300 Sv/h
(100 mR/h to 30,000 R/h)
AMP-200 Gamma 10 mSv/h to 150 Sv/h
(1 R/h to 15,000 R/h)
AMP-100 Gamma 50 µSv/h to 10 Sv/h
(5 mR/h up to 1,000 R/h)
AMP-50 Gamma 0.1 µSv/h to 40 mSv/h
(10 µR/h to 4 R/h)
Ludlum 42-30
Neutron
0 to 100 mSv/h
(0 to 10,000 mrem/h)
Thermal to approx. 12 MeV
Berthold LB6411
Neutron
30 nSv/h to 100 mSv/h
(3 uR/h to 10,000 mrem/h)
Thermal to 20 MeV
Ludlum Prescila
Neutron Thermal to 100 MeV
IC-10 Ion Chamber 0.1 mR/h to 25 R/h
GM-10 Low Energy
Gamma 0 to 42,000 CPS
SFP-100 Alpha Beta
Frisker

Page | 10 DRM-3000 Operating Manual
4 Description
4.1 Physical presentation
4.2 Connector View
CPS Stack
Board
Detector CPU Board
Backup Battery Pack
(Optional)
Internal
Buzzer
Rear Cover
Internal Detector Board
(optional)
CPU Mainboard
7 inch HD Display
High Impact Plastic Casing
External Power
Plug
Touch Panel
High Volume Buzzer and Casing (Optional)
Multicolored LED
Logo Instrument
Logo Company
WRM
-
2 mounting pads

Page | 11 DRM-3000 Operating Manual
5 Mounting the DRM-3000
The DRM-3000 can be either wall mounted or connected to a tabletop bracket.
5.1 Wall Mounting
The DRM-3000 is supplied with a wall bracket and 4 Wall mounting screws. Attach the 4 screws to the
back cover of the Meter and attach the Wall bracket to the wall taking care that the key slots are facing
upwards . The DRM-3000 is attached to the bracket by placing the four screws over the key slots and
pushing down to secure.
5.2 Table Top Mounting
The four screws shown above can be used to secure the DRM-3000 to the Table top Bracket shown
here
Key slot direction

Page | 12 DRM-3000 Operating Manual
6 Operation
6.1 Detectors
Each DRM-3000 is capable of supporting one external instrument with a 4-20 mA Output. The
User can set the required Units of Measurement, High (20mA) Range and Low (4mA) Range in
the DRM-3000 using the RMVC software.
The DRM-3000 is also capable of supporting the full range of Rotem Detectors as well as
others like the Ludlum 42-30 Rem Ball Neutron detector, the Ludlum Prescila Neutron Detector
and the SFP-100 Alpha Beta detector from V.F.
Some detectors like the AMP series, which have a minimum amount of electronics in the
detector to preserve their “radiation hardness” need the H.V. to be supplied by the DRM-3000
and other detectors, like the Wide Range Gamma detector, which is a smart detector, are
capable of sending the radiation data to the DRM-3000 via serial data.
The DRM-3000 is designed to interface with all these different types of detectors but care
should to be taken when first connecting the detectors to the DRM-3000
6.1.1 Connecting the Detectors
The placement of detectors in their slots defines the position their data is displayed on the
Screen.
If more than one detector is connected to the DRM-3000 Meter, the Display will be divided
into all four segments and each segment will display according to the connector. For
example if an internal detector is installed and a detector is connected to the Detector 1
connector, then the two top segments will show data and the bottom two segments will stay
blank.

Page | 13 DRM-3000 Operating Manual
6.2 Response Times for the GM Tubes
Table 1
Response Time for Small Changes
Table 2
Fast Response Time
Radiation Field
Range [mR/h]
Response
Time
[sec.]
Radiation field
[mR/h] from
to/above
Response
Time
[sec.]
< 0.5 45 0.05 1.0  2
0.5 - 1.5 30 0.5 3.0  2
1.5 - 2.5 20 1.5 5.0  2
2.5 - 6 10 2.5 12  2
6 - 12 6 6 20  2
12 - 24 4 12 40  2
20 - 60 3 20 60  2
60 - 800 2 1 R/h 2 R/h  2
0.6 - 1.2 R/h 5 2 R/h 2.6 R/h  2
1.2
-
2 R/h
4
2
-
3 R/h
3
3
-
10 R/h
2
–
3
> 10 R/h  2
If the radiation field measured by the meter increases significantly, the response time will be
 2 sec. as seen in Table 2. In other cases the response time is according to Table 1.
For example:
For a radiation field increase from 2.5 mR/h to 12 mR/h, the response time will be  2 sec.
For radiation field fluctuations between 2.5 mR/h and 6 mR/h, the response time will be 10 sec.
4.1.1 Automatic Range Switching for the Wide Range Detector
Both the Internal and external detectors include two GM Tubes:
Low range - ZP-1201 (or equivalent), and high range ZP-1301 (or equivalent).
In a field of 0.01 mR/h to 1,500 mR/h both GM tubes are connected and the field is measured
by the low range GM tube. If the radiation field is higher than 1,500 mR/h, the low range
detector is disconnected, and the radiation field is measured by the high range GM tube.
The switching between the low and high range GM-Tube is performed at 1,500 mR/h when the
radiation field increases (low range detector is disconnected), and at 1,000 mR/h when the
radiation field decreases (low range detector is connected).

Page | 14 DRM-3000 Operating Manual
6.3 Power
The DRM-3000 Meter requires between 9VDC to 15VDC 1.5A to operate and is powered by
one of three options mentioned below:
1. AC Power through a power transformer connected to a cable (6.5ft) which connects
externally to the Power Connector shown below
The AC Power Adapter Features
Output; 12 VDC / 2 Amps
Universal Input Range 100~240Vac 50~60 Hz
Safety: UL/CUL/PSE/BSMI/RCM/GS
EMI: CE/FCC Class B: Conduction & Radiation Met.
Protection: OVP (Over Voltage Protection), SCP (Short Circuit Protection), OCP (Over
Current Protection)
2. POE (Power over Ethernet) which uses a standard configuration of 10/100BASE-TX PoE
which is IEEE802.3 af/at compliant.
3. Internal Battery which provides 24 hours operation at background radiation levels.
The DRM-3000 will draw power in the following priority: 1. AC Power, 2. POE and 3.
Internal Battery. This means that if all three are connected the Meter will use the AC Power
only and will not use the POE or internal battery.
The DRM-3000 will charge the internal battery only if connected directly to the AC Power.
The DRM-3000 will be capable of supplying 24VDC through the Auxiliary connector only if
connected directly to the AC Power and if the optional DC power board exists in the
Instrument.

Page | 15 DRM-3000 Operating Manual
6.3.1 Power Consumption
The Following table describes the consumption of the DRM-3000 when connected to an
external DC source of 15VDC with different connections
Condition Current
Consumption
Power
DRM-3000 without any detector 450 mA 5.4 W
As above w
ith Internal Detector
600
mA
7
.2
W
As above with 3 external detectors 950 mA 11.4 W
As above under alarm condition
970
mA
11
.64
W
With 3 external detectors and flow meter 1.2 A 14.4 W
6.4 The Aux Connector
The Aux Connector provides the following inputs and outputs as per the diagram below:
1. Flow Meter
Pin #10 – +24VDC OUT
Pin #11 – Flow Meter Input (4-20mA)
Pin #12 – 24V GND (Power to Flow Meter)
2. 1 x dry contact, N.O. or N.C. dry contact or 24VDC
For meters with CPS firmware version 1.19 and above, once powered up the DRM-3000 will
activate the solenoid to provide the connection shown below. This upgrade provides the user
with an indication on loss of power to the DRM-3000.
The internal solenoid provides a wide switching range from 10 µA 100 mV DC to 4A 250 VAC
but caution should be taken, especially selection of cables, when introducing more than 24VDC
from an external power source being controlled by the Meter.
Upon alarm condition pin #1 and pin #2 are disconnected and pin #2 and pin #4 are connected.
Simultaneously, depending on the selection of the two jumpers 24VDC will be fed to pin #6 (J4
closed) or the second set of contacts will act exactly like the first set of contacts; pin #5 and pin
#3 are disconnected and pin #6 and pin #3 are connected.

Page | 16 DRM-3000 Operating Manual
The DRM-3000 is capable of supplying autonomous 24VDC through the Auxiliary connector only
if connected directly to the AC Power and if the optional DC power board exists in the Instrument.
Additionally the routing of the 24V is defined by the placement of a jumper between pins J4
(behind J3).
If the Jumper is placed on J4 then 24 VDC will be supplied from Pin #5 continuously until an over
threshold condition occurs and then upon an over threshold condition 24 VDC will be supplied to
Pin #6 as long as the over threshold condition continues.
The DRM-3000 is also capable of supplying an external power source up to 10 µA 100 mV DC or
4A 250 VAC without being connected directly to the AC Power and without the DC power board.
3. RS-485 or RS-232 (two pins)
We have integrated a multiprotocol transceiver IC so that the user can select his preferable sort of
communication
RX – Pin #8
TX- Pin #9
4. Output for external light tower
Pins 13 to 22 are dedicated to powering and controlling our signal light unit. The Light Tower
receives power from Pin #21 (OUT) and Pin #22 (GND).
5. Connector Schematics
1
RELAY
NC11
2
RELAY
NC12/NO22
3
RELAY
NC22/NO12
4
RELAY
NO21
5
RELAY
NC21
6
RELAY
NO11
8
RS485
B/RS232_RX
9
RS485
A/RS232_TX
10
+24V
OUT (Power To Flow Meter)
11 Flow Meter Input (4-20mA)
12
24V
GND (Power To Flow Meter)
13 TWR CLEAR
14 TWR AMBER
15 TWR GREEN
16 TWR BLUE
17 TWR RED
18 TWR BZR1
21 TWR 24V OUT
22 TWR 24V GND

Page | 17 DRM-3000 Operating Manual
6.5 The LAN connector
The external LAN Connector can be used to connect the DRM-3000 to the Ethernet to interface with
a web based software or the LAN connector can be used to connect the DRM-3000 directly to a
computer for the purpose of setting up the instrument, downloading data or uploading new firmware.
To create a clean Ethernet or POE installation, we offer a back cover of the DRM-3000 with a hole
for the Ethernet cable. This way the DRM-300 can be mounted flush to the wall.
6.5.1 The IP address
Each DRM-3000 is provided with a unique MAC address which can be used along with DHCP to set
a static IP. There are two connection options: network connection via DHCP or direct connection to
a PC. In a network connection the Switch is responsible for providing a dynamic IP address and can
be configured to provide a fixed IP address according to the MAC address of each DRM-3000. In a
direct connection the network adapter provides an Automatic Private IP Addressing (APIPA) to the
DRM-3000 each time they are connected and after a period of up to 30 seconds. The range of IP
addresses is 169.254.X.X
Click on the Confirm Button to display the Main Menu
Click on the Up or Down Button to navigate to the required command [METER DETAILS]
Click on the Confirm Button and the Sub-Menu will appear:

Page | 18 DRM-3000 Operating Manual
6.6 Installing the WRM2 Transmitter
6.6.1 WRM2 Radio Transmitter Characteristics
1. 10.25” L x 4.28” D x 4.88 W
2. Transmit power output 100 mW (900 MHz), 50 mW (2.4 GHz), 3.5 mW (868 MHz)
3. Receiver sensitivity -110 dBm (900 MHz) and –105 dBm (2.4 GHz)
4. 868 MHz, 900 MHz or 2.4 GHz spread spectrum hopper (FHSS)
5. Range for the 900 MHz unit 1500’ indoors-industrial environment, 2 miles outdoors RF line-
of-sight with standard dipole antenna, up to 20 miles with high gain directional antenna
6. Range for the 2.4 GHz unit 600’ (200 m) indoors, 1.5 miles outdoors with RF line-of-sight w/
dipole antenna, up to 10 miles (16 km) with high gain antenna
7. Over the air data stream at 19,200 BAUD
8. Addressable from 0 to 65,000
9. FCC approved, IC Certified, 2.4 GHz and 868 MHz are CE marked
10. Programmable transmission intervals from 1 sec to 16 sec.
6.6.2 Configuring the WRM2 Module
The WRM2 Transmitter should be configured to the following parameters in order to enable it
to be compatible to the DRM-3000
6.6.3 Inserting the WRM2 Module
1. Under no circumstances can the WRM-2 transmitter be connected or disconnected to its
mounting pads while the Unit is under power.
2. Open the rear cover of the Meter and insert the WRM-2 transmitter onto its mounting pads.
3. Close the rear cover
4. Activate the WRM2 from the Q-SETUP screen or from the RMVC Software program.

Page | 19 DRM-3000 Operating Manual
6.7 Pushbuttons, Icons and Menus
6.7.1 Background Colors
The DRM-3000 provides a number of background colors on the display to help users
identify the radiological conditions and reasons for the audible alarms.
Each of the four display segments shows its own individual color, while the external LED
shows the color reflecting the worst case scenario as follows:
Green from background to first threshold
Yellow from first threshold to second threshold
Red from second threshold upwards or User Threshold (Alarm).
Blue Shows a Lost Contact condition between detector and Meter
6.7.2 Confirming an Alarm (TBD)
Clicking on any of the buttons on the Control Panel resets the Alert condition, silences the
buzzer and deactivates the solenoid. The background color remains either yellow or red as
long as the dose rate exceeds any of the thresholds.
The DRM-3000 provides both an audible and visible alarm when the following occurs:
Over threshold condition: There are two internal thresholds for dose rate. The background
color will change from green to yellow if the first dose rate threshold is breached and from
yellow to red if the second dose rate threshold is breached.
User Alarm threshold condition: This internal threshold is set via the RMVC software or
WebiSmarts Software and activates an audible alarm, changes the background color to red
and activates the internal solenoid: Clicking on any of the buttons confirms this alarm and
mutes the audible alarm.
Lost Contact condition between detector and Meter
Detector Fail condition

Page | 20 DRM-3000 Operating Manual
6.7.3 Pushbuttons
6.7.3.1 Powering Up the Meter
Before powering up the Meter, make sure all the external detectors are connected, during
the powering up routine, the Meter will automatically identify all connected detectors.
Press, with a short press on the On/Off Button, the Display will flash and the Meter will
begin the Power Up Routine.
6.7.3.1.1 Power Up Routine
Screen Flashes once
Penguin shown top left hand corner
Open embedded loading
Desktop followed by
Startup Screen
Upper Led flashes green and buzzer sounds and after a few seconds the Display
shows the Radiation Data.
The Startup Screen
