ASSEMBLY MANUAL

Model professionally assembled and finished by Mike Wherry

Contents include: All plastic pieces to complete

model, metal axles and pictorial instructions

describing assembly. Paint and glue not included.

SKILL

NIVEAU

NIVEL

round2models.com collectormodel.com

P958-200

Assembly:

Carefully study and understand the

entire instruction sheet. Compare the parts in the box

to the instruction sheet to be sure you have received

all the parts required. Carefully remove parts from

trees. If subassemblies and components are painted

do so before any parts are attached. Use only cement

and paint made for styrene plastic.

Painting:

Painting is optional and is not required

to complete kit.

Wash parts thoroughly with mild soap

and water. Parting lines, glue joints, and sharp edges

should be sanded or filled with filler putty designed for

plastic. Apply a "primer" coat and allow to dry. Check

parts for imperfections and repeat the procedure if

necessary. Remove any lint or dust. Apply paint

evenly, in several thin coats rather than one heavy

coat. Allow each coat to thoroughly dry before the next

is applied. Each coat should be carefully “wet

sanded” using slightly damp No. 1200 sandpaper. Be

careful not to remove any detail while sanding.

Lightest colors should be painted first. Use frosted

tape to mask off areas not to be painted. Remove tape

after paint is dry to the touch. Use a very fine brush to

touch up edges.

DECALS:

See back of decal sheet for proper

application.

ECTO-1 INFORMATION

WHAT COULD BE MORE APPROPRIATE FOR CHASING

GHOSTS THAN A BLOCK-LONG ‘59 CADILLAC

AMBULANCE, SPECTACULARLY OUTFITTED WITH

ECTOPLASMIC SURVEILLANCE, DETECTION AND STORAGE

EQUIPMENT FOR THE ETHERIAL BOGIES? PLUS, ENOUGH

FLASHING LIGHTS TO LIGHT UP A SMALL TOWN?

WHY, NOTHING ELSE EVEN COMES CLOSE - IT IS THE

PERFECT VEHICLE FOR THIS SPOOKY JOB. WHETHER IT’S

SLIME IN YOUR REFRIGERATOR OR DANCING FURNITURE

OR REAL GHOSTS IN YOUR TV, THE ECTO-1 IS ALWAYS

ON CALL. AND WHO ARE YOU GONNA CALL?

GHOSTBUSTERS, THAT’S WHO! THEY BELIEVE YOU.

DECAL / STICKER

NEW YORK

SCREWS

REAR BUMPER

& TAILLIGHTS

ASSEMBLED ROOF RACK

BODY

FRONT

WINDOWS

FRONT BUMPER,

GRILLE &

HEADLIGHTS

REAR

WINDOWS

ELECTRICAL

CONDUIT

LADDER

Final Assembly of the ECTO 1.

Snap the Front windows #9 and the Rear windows #10 into the Body #11. Install the Front bumper, grille & headlights #40 to the front of the Body #11. Install the Rear

bumper, grille & headlights #39 to the rear of the Body #11. Place the Interior assembly #8 into the Body #11 and fasten the Chassis assembly #1 into the Body #11

using the four Screws provided. Snap the Ladder #37 and the Electrical conduit #38 to the right side of the Body #11 and the Roof rack #12.

DECAL / STICKER

NEW YORK

DECAL / STICKER

1/25 SCALE MODEL KIT

ECTO-1WITH

SLIMER

International Hobbycraft (UK) Ltd.

10 Temple Back

Bristol BS1 6FL England

Round 2, LLC.

4073 Meghan Beeler Court

South Bend, IN 46628

DECAL / STICKER

DECAL

DECAL / STICKER

STEP 3

FRONT TIRE

WHITE SIDE

WALL INSERT

FRONT

WHEEL

METAL AXLE

FRONT WHEEL

FRONT TIRE

WHITE SIDE

WALL INSERT

REAR WHEEL

REAR TIRE

WHITE SIDE

WALL INSERT

CHASSIS

METAL AXLE

REAR WHEEL

WHITE SIDE

WALL INSERT

REAR TIRE

INTERIOR

STEERING

WHEEL

SHIFT SELECTOR

& TURN SIGNAL

DASHBOARD

25,26

SIREN

HALVES

WHIP

ANTENNA

FRONT

BULKHEAD

PARABOLIC

ANTENNA COVER

WEATHER

RADAR DOME

RADAR &

ANTENNA MAST

CLEAR COVER

AIR TANK

RIGHT

TAIL FIN

AIR TANK

ROOF RACK

DRIVER’S SPOTLIGHT

& MIRROR

BODY

LIGHT

LEFT TAIL FIN

DUCT

LIGHT BAR

23,24

EQUIPMENT STORAGE

TUBE HALVES

SPOT

LIGHT

ELECTRON

CANNON

ANTENNA

BASE

CANNON

MOUNT

ELECTRON

CANNON

PYLON

DECAL / STICKER

X2 or Red

DECAL / STICKER

X2 or Red

LIGHT BAR

CLEAR COVER

Assemble the body of the ECTO 1.

Snap the Air tanks #13 & #14 to the left side of the Roof rack #12 – Snap the Front bulkhead #22 in place in the Roof rack #12. Install the Weather radar dome #16

on the Radar and antenna mast #15 and snap the assembled Mast to the left rear corner of the Roof rack #12. Install the clear Parabolic antenna cover #18 to the Antenna

base #17 – Snap the assembled Parabolic antenna to the rear of the Roof rack #12. Snap the Electron cannon mount #19 into the Cannon #20 – Snap the assembled

Cannon into the Electron cannon pylon #21 – Snap the pylon in place on the floor of the Roof rack #12. Snap the Equipment storage tube halves #23 & #24 together –

Then snap the assembled Tube to the right side of the Roof rack #12. Assemble the Siren parts #25 & #26 – Then snap the Siren and Spotlight #27 in place at the Front

of the Roof rack #12.

Install the Left tail fin #31 & Right tail fin #32 onto the Body #11. If you wish to add the Red Body-Side Stickers to your Model kit – DO SO NOW. Install the Ducts #33

& #34 to the left side and roof of the Body #11. Snap the assembled Roof rack #12 in place on the roof of the car Body #11. Snap the Clear covers #29 onto the Light

bars #28 – Snap the two assembled Light bars in place on the roof of the Body #11. Install four Lights #30 – Two to the front, and two to the rear of the roof. Install the

driver’s Spotlight & mirror #35 to the driver’s side door – Then attach the Whip antenna #36 to the top of the right front fender.

Assemble the chassis & the interior of the ECTO 1.

Assemble the White side wall inserts #3 onto the Wheels #2 – Snap these assemblies into the Tires #4. Press the assembled Wheels and Tires onto the Metal axles after

inserting the Axles into the holes in the Chassis #1.

Push the Steering wheel #7 through the Shift selector & Turn signal #6 – Then install the Steering column assembly in the Dashboard #5 – Snap the assembled

Dashboard into the Interior #8.

DECAL

AC POWER

EFC RT980 SSLPAUHF

INPUT

AC POWER

EFC RT980 SSLPAUHF

INPUT

DECAL

CANNOTREADTHIS

ORFINDANEXAMPLE

CANNOTREADTHIS
