RR Mechatronics RPI User manual

Instructions for Use
RPI
MRN-184-EN Version 6 (05-01-2022)

Contents
- Document history overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1 - Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1 - - About this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 - - Used symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 - - Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.4 - - Disclaimer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2 - Intended use RPI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3 - Installation procedures and requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1 - - Feed water requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 - Principles of operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5 - Performance characteristics and specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5.1 - - Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.2 - - User level description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.3 - - Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.4 - - Output performance characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.5 - - Waste. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.6 - - Identification and Labelling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 - Standard operation procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.1 - - Check before starting up after inactive period. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 - - Normal operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.3 - - Cubitainer Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.4 - - Replacement of the cubitainers and RPI-Check bottle. . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.4.1 - - Placement of a new cubitainer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.4.2 - - Concentrated reagent lot switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
6.4.3 - - Placement of a new RPI-Check bottle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.5 - - Checks during operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7 - Calibration procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.1 - - Control cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8 - User interface and software menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Contents
MRN-184-EN Version 6 (05-01-2022) 3

8.1 - - User Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
8.2 - - Access levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.3 - - Operator level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.4 - - Supervisor level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.5 - - Technician level. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.6 - - Home screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.7 - - Manual screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.7.1 - - Manual Control cycle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.7.2 - - Replace cubitainer function and adding users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.7.3 - - Manual insert cubitainer ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
8.7.4 - - Manual insert RPI-Check ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.8 - - Information screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
8.8.1 - - Retrieve performance data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.8.2 - - Instrument state. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
8.8.3 - - Instrument information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
8.9 - - Maintenance screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
8.9.1 - - WPU maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
8.9.2 - - RPI maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
8.10 - - Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
9 - Operational precautions, limitations and hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
9.1 - - Avoidance of infection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
10 - Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
10.1 - - No water. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
10.2 - - Concentrated reagent information is not recognized. . . . . . . . . . . . . . . . . . . . . . . . . . . 69
10.3 - - Reagent errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
10.4 - - Control cycle does not start or fails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
11 - Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
11.1 - - Maintenance items & Maintenance schedule RPI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
11.2 - - Removing and replacing cover panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
11.3 - - Replacing the Vent filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
11.4 - - Replacing peristaltic pump tubes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
11.5 - - Replacing Pickup tubes/End point filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
11.6 - - Maintenance WPU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
11.7 - - Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
11.7.1 - - Cleaning of the drawers and casing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
11.8 - - Replacing main fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Contents
4MRN-184-EN Version 6 (05-01-2022)

12 - Error list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
13 - System temporarily out of use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
14 - Decommissioning and disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
15 - Glossary of Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
- Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Contents
MRN-184-EN Version 6 (05-01-2022) 5

Manufacturer: RR Mechatronics Manufacturing B.V.
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.rrmechatronics.com
Postal address:
P.O. Box 225
1620 AE Hoorn
The Netherlands
Office address:
De Corantijn 13
1689 AN Zwaag
The Netherlands
© Copyright RR Mechatronics Manufacturing B.V.
All rights reserved.
Subject to changes without prior notice.
Issued by the Support Department of RR Mechatronics
Contents
6MRN-184-EN Version 6 (05-01-2022)

Document history overview
MRN-184-EN
Issue No Date Revised Section(s) Changes Authorised
6 jan. 2021 Disclaimer
Safety
Modification claim
Exposure limits / USB-port use
HSR
5 dec.2021 Calibration procedures
Decommissioning
Metrology traceability addition
Decommissioning only by FSE remark
HSR
4 nov. 2021 All General update including software
version 2.14 and changes due to
wording intended use of RPI-Check
HSR
3 jun. 2021 All General update and changed chapter
sequence according FDA regulations
HSR
2 jan. 2021 All General update HSR
1 oct. 2020 All General update HSR
Document history overview
MRN-184-EN Version 6 (05-01-2022) 7

1
Introduction
Read this manual, especially the standard operation procedure and Safety instructions , before using the
instrument.
1.1 - About this manual
This manual describes all necessary procedures and information required for the correct and successful use
of the RPI, covering normal operation, user maintenance and troubleshooting. When instrument is
mentioned, it is used for the complete instrument, the RPI including the AFS-24 unit.
This manual is applicable for the following RPI-models and concentrated reagents:
A0021587 RPI-ECO21 (120V), for DxH Concentrated ECO Diluent C67249 (Beckman-Coulter).
A0021595 RPI-ECO21 (230V), for DxH Concentrated ECO Diluent C67249 (Beckman-Coulter).
This manual does not describe specific service related issues, such as detailed technical information and
repair procedures.
The manual found with your RPI is important for proper usage and maintenance in compliance with the
manufacturer specifications.
Your RPI is delivered with these documents:
An " Instruction for Use " which describes all specifications, operations, user functions and user maintenance
of the RPI.
A " User manual AFS® 8, 16, 24 " which describes all specifications, operations, user functions and user
maintenance of the AFS-24 (WPU).
It may be necessary to reference these documents for maintenance or other procedures with the RPI. It is
recommended to store these documents in such way that they can be quickly located and where they will
not be damaged.
Updates of this manual and RPI software will be published on our website, distributors will be informed
about updates. Electronic versions of this manual and versions in available languages and future revisions
are available on:
https://support.rrmechatronics.com
1.2 - Used symbols
This ATTENTION symbol is used to refer to instructions in this manual that need to
be done carefully.
Introduction
8MRN-184-EN Version 6 (05-01-2022)

These symbols are used to indicate that proper safety equipment has to be used.
Protective glasses and gloves must be worn
This UV RADIATION sticker is used to refer to a position on or inside the water
system cabinet where exposure to UV light is possible
This ELECTRICAL GROUND sticker is used to refer to a position on the water system
Cabinet or inside where an electrical ground connection is made.
This DANGER sticker is used to refer to a position on the water system Cabinet or
inside of it that could be hazardous.
This symbol indicates useful information, not related to any specific danger.
1.3 - Installation
The instrument must be installed in a dry and dust-free location on a solid and stable surface.
Do not expose the instrument to excessive temperature fluctuation and direct sunlight.
Avoid shocks and vibrations. Ensure good ventilation and do not place the instrument directly in contact with
other equipment.
Leave >1m space in front of the instrument to be able to move the instrument forwards to perform
maintenance activities at the back side.
Avoid installation near devices causing interference e.g. radios, centrifuges, etc. Installation of the
instrument in places where chemicals are stored or gas develops is not permitted.
Introduction
MRN-184-EN Version 6 (05-01-2022) 9

1.4 - Disclaimer
Operate and maintain this instrument according to this manual and other instructions from the manufacturer.
Failures and defects as result of unspecified use will void the product warranty. Changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
The instrument is not equipped with backup- or control systems to prevent production of incorrect reagent
due to conditions such as:
▪ Uncalibrated measuring circuitry
▪ Instrument malfunction
▪ Poor quality of concentrated reagent
▪ Poor quality of feed water
The RPI (including WPU) is designed to stay connected to the main power supply and water
supply at all times.
The quality of RPI’s production has to be checked daily for use on the connected analyzers
according local quality specifications.
Do not disconnect the RPI(s) prior to completion of the shut-down cycle.
The manufacturer disclaims any liability for any direct, indirect, incidental, special or
consequential damages of any kind, arising from the use of incorrect prepared reagent.
Note:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
Introduction
10 MRN-184-EN Version 6 (05-01-2022)

2
Intended use RPI
The RPI is a general purpose instrument intended to dilute a concentrated reagent to a usable fluid for in
vitro laboratory testing.
Intended use RPI
MRN-184-EN Version 6 (05-01-2022) 11

3
Installation procedures and requirements
Users are not allowed to install and connect the instrument. The RPI must be unpacked, installed and
checked by a trained engineer prior to first operation.
Installation procedures and requirements are described in the Installation manual.
3.1 - Feed water requirements
The provided feed water quality will affect the performance of the RPI and is required to be within the
specifications mentioned below.
RR Mechatronics recommends that a Merck Millipore representative performs a water analysis prior to the
installation of the RPI to ensure your water supply meets the requirements.
This representative can also arrange for mitigations if laboratory water quality does not meet specifications.
Requirements:
Pressure: 1 – 6 bar
Flow rate: > 5 L/min at 2 bar
Type: Potable tap water
Temperature: 10 – 30 °C
Conductivity: 100 – 2000 μS/cm @ 25 °C
pH: 4- 10
Langelier Saturation Index (LSI): < 0.3
Free total chlorine: < 3 ppm
Installation procedures and requirements
12 MRN-184-EN Version 6 (05-01-2022)

4
Principles of operation
The RPI (Reagent Production Instrument) is an automated reagent preparation instrument. It produces a
ready-to-use reagent out of a concentrated reagent and lab water to a predetermined target conductivity.
The instrument is a single unit, housing all necessary parts inside a closed frame. The frame is covered with
easily removable, coated, sheet metal panels. The instrument is operated with a user interface with multi-
authority levels.
All external connectors are situated on the rear side of the instrument, including the ON/OFF switch.
All user serviceable and replaceable parts are accessible through the doors, drawers and panels.
The RPI and its modules are shown here. The WPU (Water Purifying Unit) is shown here (See
AFS manual for details).
1. Top concentrate cubitainer
2. Bottom concentrate cubitainer
3. Power indicator
4. USB connection
5. RPI Check
6. Touchscreen with Graphical User Interface
7. WPU (Water Purifying Unit, AFS® 24)
8. Sight glass for display WPU
Principles of operation
MRN-184-EN Version 6 (05-01-2022) 13

5
Performance characteristics and specifications
Performance characteristics and specifications
14 MRN-184-EN Version 6 (05-01-2022)

5.1 - Technical specifications
Instrument model Model name
RPI-ECO21
Catalogue number (REF)
A0021587 120V
A0021595 230V
Dilution method Electrical Conductivity and Temperature measurement (EC-T)
Concentration window Upon request (indication 15 - 25x)
Temperature compensation
method
Reagent specific conductivity-temperature curve
Reconstitution accuracy < 1% (1SD)
Conductivity production range Upon request (indication 10 -20 mS/cm @25˚C)
Production capacity ~20 L/hr peak (for 3 hours)
<17 L/hr continuous (excluding lot-change and service)
Number of concentrate
cubitainers
2 x 10L, hot swappable
Result monitoring method RPI-Check
Intended use The RPI is a general purpose instrument intended to dilute a
concentrated reagent to a usable fluid for in vitro laboratory
testing.
Traceability
Concentrated reagent
cubitainers
Near Field Communication (NFC)
RPI-Check NFC
User interaction 4 access levels [to be entered in the Graphical User
Interface(GUI)]
Internal Water Production Unit
Water Purification Unit (WPU) Merck Millipore AFS® 24
Feed Water quality
requirements
See specification from AFS® 24 manual for details
Feed water temperature 10 - 30°C
Performance characteristics and specifications
MRN-184-EN Version 6 (05-01-2022) 15

Input water connection 1x John Guest PM Acetal fitting 8 mm
Produced water quality Clinical laboratory reagent water, conductivity ≥ 1MΩ/cm
Installation requirement Installation by Merck-Millipore Field Installation Engineer is
required
Waste
RPI Waste connection 1x John Guest PM Acetal fitting 10mm (OD)
AFS-24 Waste connection 1x John Guest PM Acetal fitting 6 mm (OD)
Concentrate cubitainers
Cubitainer positions 2
Cubitainer orientation Upright
Cubitainer volume 10L
Maximum Cubitainer
dimensions
H 245 x W 245 x D 245 mm
Cubitainer detection &
identification
NFC
Location RFID at cubitainer Rear
Concentrate pick-up tube To be determined with customer
Monitoring process:
Monitoring method Control cycle using RPI-Check
RPI-Check temperature Acclimated to environment temperature (>24 hours)
Frequency ≥1x per 24 hrs
Control process start Manual start and time scheduled
Internal reagent storage:
Storage volume 10 liters
Storage temperature Displayed in GUI and monitored (not controlled)
Performance characteristics and specifications
16 MRN-184-EN Version 6 (05-01-2022)

Reagent delivery port details:
Number of output ports 4
Output port outer diameter John Guest PM Acetal 6 mm (OD)
End point filtration 0.22 µm
Expected priming vacuum ~ 33 kPa (250 mmHg) by analyzer
User interface
Human machine interface Full color touch screen
Display specifications 154x90mm (7"), 1024x600 resolution, 85˚ viewing angle
User access levels Operator / Lab manager / Lab technician / Field Service Engineer
(FSE)
Languages English, Dutch, French, Italian, German, Spanish
Intended use:
Use environment In-Vitro Diagnostic laboratories
Intended operators Trained IVD lab personnel
Cubitainer switching
Intra lot cubitainer switching Uninterrupted production
Lot-to-lot cubitainer switching When storage is empty, prime with new lot.
Analyzers background cycles recommended.
Operational
Maximum ready to use
reagent storage time
To be determined by customer
Mobility 4 wheels
Sanitation
Reconstitution rinse cycle Timer initiated, once every 24 hrs.
Rinse medium Clinical laboratory reagent water, resistivity≥ 1MΩ/cm
Performance characteristics and specifications
MRN-184-EN Version 6 (05-01-2022) 17

Deep cleanse cycle Yearly maintenance+ incidentally
Deep cleanse medium Chloride cleaning tablet
Exterior sanitation Common lab practice
Maintenance
Preventive maintenance calls
per year
1, by qualified field service engineer
Consumables replacement
frequency
RPI: Every 3 months, WPU: Every 3 months
Consumables RPI-Check / Progard / Q-gard / end point filters / peristaltic
pump tubing and pickup tubes
Electrical requirements
Mains voltage 120 or 230V (± 10%), 50-60 Hz (± 3%)
Fuse EU (230V) 2x 3.15A T (Slow blow) Hollyland 31-50T-032H or equivalent
according IEC 60127 (250V, temp range -55°C to + 125°C)
Fuse USA (120V) 2x 6.3 A T (Slow blow)Hollyland 31-50T-063H or equivalent
according IEC 60127 (250V, temp range -55°C to + 125°C)
Power consumption 600 VA
Protection class IP 20
Overvoltage category II
Pollution degree 2
External connections
RS232 Serial connection RJ11
Ethernet connection TCP/IP
External light (24V)(option) 24V, < 2A
USB 2.0
Environment
Performance characteristics and specifications
18 MRN-184-EN Version 6 (05-01-2022)

Environment
Sound level Less than 62 dBA
Environment temperature 5-40 °C
Operating temperature 15.5 – 32 °C
Relative humidity 35-75% non-condensing
Operational altitude 0 – 2000 m AMSL
Indoor/outdoor use Indoor use
Total dimensions
Instrument size L 775 x W 620 x H 750 mm
Empty weight 107 kg, including WPU
Chemical compatibility
Wetted surface materials PFA / HDPE / PP / PPS (40%GFR) / LLDPE / EPDM / AlO /
ANSI-316 / Pyrex 3.3/ POM / Pt / Tygon
Data storage
Storage medium Onboard memory & data export storage (USB) (4 GB)
Stored data Batch production information and reagent traceability information
Data on Cubitainer NFC tag Reagent type, dilution target, origin, production date, lot number,
ID, shelf life, remaining volume
Compliance
Classification EU IVD Class A
Classification USA Class 1, 510 (k) Exempt
Compliant to EU harmonized standards relevant to IVD Medical devices/
cMETus certified
Used materials ROHS 2011/65/EU and 2015/863/EU
Performance characteristics and specifications
MRN-184-EN Version 6 (05-01-2022) 19

5.2 - User level description
The software has four access levels from basic functionality for the operator up to full access for the Field
Service Engineer.
The four levels are:
1.
Operator:
▪ Basic functionality
2.
Supervisor:
▪ Basic functionality
▪ Retrieve performance data
▪ Environmental settings
3.
Technician:
▪ all previous
▪ Basic maintenance
4.
Field Service Engineer:
(these functions are not described in this manual)
▪ all previous
▪ Replace failing / damaged modules
▪ Perform yearly maintenance/Shutdown procedure
Performance characteristics and specifications
20 MRN-184-EN Version 6 (05-01-2022)
