User Manual
VS80 Camera
Probes
For use with the VS80 High Performance
Videoscope

Introduction
The probes covered in this manual are designed for use with the
VS80 High Performance Videoscope. The probes are controlled by
the touch-screen icons and control buttons on the VS80.
The VS80 user manual and additional translations of this probe
manual are available from the support site (see the Support
section).
Please update the VS80 firmware before use, as explained in the
VS80 manual. This will ensure optimal functionality and full compat-
ibility with your camera probe.
Probe Descriptions
The probes are described in the following sections, see the Specifi-
cations and Safety sections for additional information.
The VS80 offers many useful and convenient features including
capturing still images and video, changing camera views, connect-
ing with smart devices, and controlling worklights. Please refer to
the VS80 user manual for complete information.
VS80C55-1RM General Purpose Camera Probe
The general purpose camera probe head is 5.5 mm in diameter
and its probe length is 3.3 ft (1 m). The camera resolution is 640 *
480.
1. VS80 connector
2. Probe
3. Probe head
4. Front view of camera lens and worklights
#NAS100105; r. AB/83753/84877; en-US 1

VS80CHD–55-1RM HD Camera Probe
The HD camera probe head is 5.5 mm in diameter and its probe
length is 3.3 ft (1 m). The camera resolution is 1280 * 720.
1. VS80 connector
2. Probe
3. Probe head
4. HD camera lens and worklights
VS80C2-49-1RM Dual HD Camera Probe
The dual HD camera probe head is 4.9 mm in diameter and its
probe length is 3.3 ft (1 m). The camera resolution is 1280 * 720.
1. VS80 connector
2. Probe
3. Side view camera and worklights
4. Forward view camera
VS80CIR—21 Thermal IR Camera Probe
The VS80CIR-21 offers a Lepton 3.5 IR camera with a 3.3 ft (1 m)
probe. The VS80 displays the camera image and the temperature
of targeted surfaces and offers s selectable display palette, a tem-
perature alarm, and other features.
1. VS80 connector
2. Probe
3. Orientation mark. This represents the top of the image
4. IR camera lens
#NAS100105; r. AB/83753/84877; en-US 2

Connecting the Probe
The steps below explain how to safely connect the probe to the
VS80 monitor. Always turn the VS80 power off before replacing the
probe.
1. Align the white dot on the probe connector with the white dot on
the monitor connector.
2. Plug the probe into the monitor unit, ensuring proper alignment
and full insertion.
3. Tighten the collar nut to secure the connection. Do not
overtighten.
Safety
Safety Note
Please read and understand all safety cautions before use.
CAUTION
Do not insert the probe into flammable liquid or gas.
This product is designed for industrial use only. It is not intended for use in hu-
man or other biological inspection.
CAUTION
To clean the probe, wipe with a soft cloth dampened with a mild detergent and
clean water. Do not use abrasives, corrosives (alcohol), or solvents to clean
the probe. Use a high quality lens cleaning fluid and a lint-free swab to clean
the camera and worklight lenses.
Do not disassemble the product, damage to the product and electrical shock
may occur.
Avoid direct sun exposure. Store in a cool, dry, and well-ventilated area.
#NAS100105; r. AB/83753/84877; en-US 3

The probe contains sensitive circuitry that controls
the optics and electronics of the camera. Do not
strike the probe or allow it to impact objects
forcefully.
For digital probes ONLY, immerse probes only in
approved liquids (see the Specifications section).
This does NOT apply to the IR Camera (VS80CIR-
21). The IR Camera probe must NOT be immersed
in liquid.
Specifications
Digital Camera Specifications
Camera resolution 1280 (H) * 720 (V) for VS80C2–49–1RM and
VS80CHD-55–1RM
640 (H) * 480 (V) for VS80C55–1RM
Frame rate 30 frames per second (fps), approximately
Probe Diameter 5.5 mm for VS80CHD-55–1RM and VS80C55–
1RM
4.9 mm for VS80C2–49–1RM
Field of View 90°
Depth of Field 0.4 to 4.0 in (10 to 100 mm)
Probe tip length 0.78 in (20 mm) for VS80CHD-55–1RM and
VS80C55–1RM
0.84 in (21.3 mm) for VS80C2–49–1RM
Probe length 3.3 ft (1 m)
Side-view camera VS80C2–49–1RM only
LED Worklights Worklights are controlled from the VS80
Four forward and two side worklights on
VS80CHD-55–1RM and VS80C55–1RM
Five forward and one side worklight on VS80C2–
49–1RM
Operating temperature 32 to 140℉(0 to 60℃)
#NAS100105; r. AB/83753/84877; en-US 4

Storage temperature –4 to 140℉(-20 to 60℃)
Relative Humidity 10 to 95 % non-condensing
Approved liquids for digi-
tal camera probes
Approved for use in brake and transmission fluid,
diesel fuel, unleaded gasoline, engine oil, and
CPC hydraulic fluid (46AWS). This does NOT ap-
ply to the IR camera probe VS80CIR-21
Ingress rating Probe tip and body: IP 67 (IEC 60529)
Protected from submersion in water up to 3.3 ft (1
m) for 30 minutes maximum. In use: rain,
splashes, and accidental submersion
IR Camera Specifications
IR Camera type Thermal Lepton 3.5
Resolution 160 (H) * 120 (V)
Frame rate 8.7 Hz
Probe diameter 0.4 in (10.4 mm) probe
0.7 in (19 mm) camera
Probe tip length 1 in (25 mm)
Field of View (FOV) 71°
Operating temperature 32 to 122℉(0 to 50℃)
Storage temperature –4 to 140℉(-20 to 60℃)
Shock 25 g (IEC 60068-2-29)
Vibration 2 g (IEC 60068-2-6)
Drop-proof 6.6 ft (2 m)
Water-proof Probe tip and body: IP 67 (IEC 60529)
Protected from submersion in water up to 3.3 ft (1
m) for 30 minutes maximum. In use: rain,
splashes, and accidental submersion
#NAS100105; r. AB/83753/84877; en-US 5

Warranty and Support
Three-Year Limited Warranty
This product is protected by FLIR’s 3-Year Limited Warranty. Visit
www.flir.com/testwarranty to read the 3-Year Limited Warranty
document.
CUSTOMER SUPPORT
Customer Support Telephone List https://support.flir.com/contact
Repair, Calibration, and Technical Support https://support.flir.com
