RRS MTX User manual

GUARANTEE
ALL REALLY RIGHT STUFF BRAND PRODUCTS ARE
GUARANTEED TO THE ORIGINAL PURCHASER TO BE FREE
OF DEFECTS IN MATERIALS OR WORKMANSHIP FOR FIVE
(5) YEARS FROM THE DATE OF PURCHASE. PRODUCTS
WILL BE REPAIRED OR REPLACED AT OUR OPTION.
® , ™, © 1990-2017 Really Right Stuff, Inc. All rights reserved.
SPECIFICATIONS:
Weight of Driver Handle with primary Bit Holder & Bits installed ......................................3.4oz / 95g
Weight of secondary Bit Holders & Bits............................................................................ 1.3oz / 38g
Length of Driver Handle................................................................................................4.9” / 124mm
Total number of Bits included ....................................................................................................... 22
Number of Hex Keys included................................................................................ one stubby 3/16”
Replacement Bits / Hex Key..................................................................................................... $1 / $8
Bits are sourced from Taiwan. All other components are sourced from the US. Bits and hex key
made from steel with corrosion resistant coating. Hex socket driver accepts standard 3/16” bits.
Driver Handle
Bit Holders
Bits
(22 included)
Hex Key
(1 included)
Stow in Versa TVC 3/2 Quick-Column
Remove hook from
bottom of Quick-Column.
1
Screw MTX shaft
into hook.
2
Replace hook;
stow & go!
3
Hex Key Storage
Tuck stubby end in place then
push down.
Snap Out, Snap In
Tilt bit at an angle to
remove from
holder.
Hex Key Removal
Rotate hex key out then
tilt to remove.
MTX MULTI-TOOL
1146 Farmhouse Lane, San Luis Obispo, CA 93401 USA
1-805-528-6321 | 1-888-777-5557
www.ReallyRightStu.com
GUARANTEE
ALL REALLY RIGHT STUFF BRAND PRODUCTS ARE
GUARANTEED TO THE ORIGINAL PURCHASER TO BE FREE
OF DEFECTS IN MATERIALS OR WORKMANSHIP FOR FIVE
(5) YEARS FROM THE DATE OF PURCHASE. PRODUCTS
WILL BE REPAIRED OR REPLACED AT OUR OPTION.
® , ™, © 1990-2017 Really Right Stuff, Inc. All rights reserved.
SPECIFICATIONS:
Weight of Driver Handle with primary Bit Holder & Bits installed ......................................3.4oz / 95g
Weight of secondary Bit Holders & Bits............................................................................ 1.3oz / 38g
Length of Driver Handle................................................................................................4.9” / 124mm
Total number of Bits included ....................................................................................................... 22
Number of Hex Keys included................................................................................ one stubby 3/16”
Replacement Bits / Hex Key..................................................................................................... $1 / $8
Bits are sourced from Taiwan. All other components are sourced from the US. Bits and hex key
made from steel with corrosion resistant coating. Hex socket driver accepts standard 3/16” bits.
Driver Handle
Bit Holders
Bits
(22 included)
Hex Key
(1 included)
Stow in Versa TVC 3/2 Quick-Column
Remove hook from
bottom of Quick-Column.
1
Screw MTX shaft
into hook.
2
Replace hook;
stow & go!
3
Hex Key Storage
Tuck stubby end in place then
push down.
Snap Out, Snap In
Tilt bit at an angle to
remove from
holder.
Hex Key Removal
Rotate hex key out then
tilt to remove.
MTX MULTI-TOOL
1146 Farmhouse Lane, San Luis Obispo, CA 93401 USA
1-805-528-6321 | 1-888-777-5557
www.ReallyRightStu.com

KEY FEATURES LIST OF INCLUDED BITS / RRS HARDWARE
HEX TIPS
0.05 inch screws included with LCF-10P
1/16 inch legacy BH-55 panning base screws
5/64 inch leveling bases
3/32 inch legacy safety stop screws
7/64 inch general purpose
1/8 inch Versa SureGrip™ apex screws, tripod
platform set screws
9/64 inch general purpose
5/32 inch plates with ¼”-20 screws, screws for
clamps, TQC-14 leg angle tension screws
3/16 inch Versa 3/2 leg angle tension screws
7/32 inch plates with ⅜”- 16 screws, Versa 4 leg
angle tension screws
2mm general purpose
2.5mm safety stop screws
3mm most Lens Collar Foot (LCF) screws,
M5 flathead screws
JIS/CROSS TIPS
#00 common camera & lens screws
#0 common camera & lens screws
#1 common camera & lens screws
FLAT TIPS
#1 general purpose
#2 general purpose
TORX/STAR TIPS
T10 general purpose
T15 general purpose
T20 general purpose
T25 general purpose
Stainless steel shaft
threaded industry-
standard ⅜”-16.
Driver handle comes with
bit holder loaded with 10
of the most commonly
used RRS tips and stubby
3/16” hex key.
Hex socket driver
accepts standard
3/16” bits; magnetic
driver keeps RRS
steel bits securely
in place.
Driver handle is nicely
textured for grip and
comfortably fits the hand.
Each bit (not shown
to scale) is stamped
with the tip size.
To access stored bits, fully
unscrew butt-cap and slide
out bit holder. In use, keep
butt-cap tightly screwed to
maintain waterproof seal.
Anodized butt-cap socket threaded
industry-standard ⅜”-16.
KEY FEATURES LIST OF INCLUDED BITS / RRS HARDWARE
HEX TIPS
0.05 inch screws included with LCF-10P
1/16 inch legacy BH-55 panning base screws
5/64 inch leveling bases
3/32 inch legacy safety stop screws
7/64 inch general purpose
1/8 inch Versa SureGrip™ apex screws, tripod
platform set screws
9/64 inch general purpose
5/32 inch plates with ¼”-20 screws, screws for
clamps, TQC-14 leg angle tension screws
3/16 inch Versa 3/2 leg angle tension screws
7/32 inch plates with ⅜”- 16 screws, Versa 4 leg
angle tension screws
2mm general purpose
2.5mm safety stop screws
3mm most Lens Collar Foot (LCF) screws,
M5 flathead screws
JIS/CROSS TIPS
#00 common camera & lens screws
#0 common camera & lens screws
#1 common camera & lens screws
FLAT TIPS
#1 general purpose
#2 general purpose
TORX/STAR TIPS
T10 general purpose
T15 general purpose
T20 general purpose
T25 general purpose
Stainless steel shaft
threaded industry-
standard ⅜”-16.
Driver handle comes with
bit holder loaded with 10
of the most commonly
used RRS tips and stubby
3/16” hex key.
Hex socket driver
accepts standard
3/16” bits; magnetic
driver keeps RRS
steel bits securely
in place.
Driver handle is nicely
textured for grip and
comfortably fits the hand.
Each bit (not shown
to scale) is stamped
with the tip size.
To access stored bits, fully
unscrew butt-cap and slide
out bit holder. In use, keep
butt-cap tightly screwed to
maintain waterproof seal.
Anodized butt-cap socket threaded
industry-standard ⅜”-16.
Two secondary
bit holders come
loaded with 12
more tips.
Two secondary
bit holders come
loaded with 12
more tips.
