RSA Lighting Adjustable Slot Apeture Trim ACT-1685BK User manual

Type: Project:
RSA LIGHTING 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2004 RSA Lighting All Rights Reserved • Specifications subject to change without notice. AC1
HOT AIMING lamp
adjustment with a regular
phillips screwdriver
5” Adjustable Slot Apeture Trim
w/ Hot Aiming Adjustability
New Construction Housing - 4.75” Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
13.25"
8.22"
4.63"
7.25"
For 277 volt transformer add “277” to end of item #.
Item # Description Finish Voltage / Wattage
ACT-1685WH / ACT-950
ACT-1685BK / ACT-950
ACT-1685S / ACT-950
ACT-1685SS / ACT-950
ACT-1685PM / ACT-950
Accurus Series Adjustable Slot Aperture Trim with
New Construction Housing w/ Magnetic Transformer White Black
Silver
Stainless Steel
Primer
12V / 75W Max.
Hanger Bars extend from
14” to 25.25” max.
Housing adjusts in
plaster frame to accommodate
various ceiling thicknesses.
Butterfly Brackets
for commercial
installations
5.00" Dia.
1.34"
1.75"
DESCRIPTION:
Recessed slot aperture Trim. 360orota-
tional adjustability and 45o(0overtical to
45otilt) angle adjust with angle locking
mechanism in trim. Housing accommo-
dates various ceiling thicknesses.
ELECTRICAL:
120V input, 12V output. Junction box is
U.L. listed for through branch wiring.
Internal rotation
ring with locking
adjustment.
Provides 360º
rotation and
secures original
trim position after
relamping or
maintenance.
Angle Indicators
Lamp holder can accept
up to three (3) optical
accessories
Steel Safety
Cable
CONSTRUCTION:
Housing and plaster frame: 18 gauge CRS
Trim ring, j-box and hanger assemblies:
16 gauge CRS.
SYSTEM PROTECTION:
Thermal protection provided to guard
against overheating and misuse of insu-
lation over and around fixture. Vent holes
in housing provide cooler operation.
Magnetic
Transformer
Perforated flap for secure
drywall installation
c ACT-1685WH c ACT-1685BK
c ACT-1685S c ACT-1685SS
c ACT-1685PM
w/ ACT-950 Housing
Trim detail shows fixture trim
below the ceiling line.
45º locking rack & pinion angle
adjustment mechanism
w/ Hot Aiming feature
REV 062904
