RSA Lighting QCT-2275BK User manual

Type: Project:
RSA LIGHTING 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2004 RSA Lighting All Rights Reserved • Specifications subject to change without notice. QC29
4” Lensed Wallwasher Square Trimless Fixture
w/ Integral Linear Spread Lens
Insulated Ceiling Housing - 7.5” Height
12V Bi-Pin Base MR16 Lamp 50 Watts Max.
17.50"
14.13"
7.50"
9.88"
MDL
Item # Description Finish Voltage / Wattage
QCT-2275WH / QCT-903-IC
QCT-2275BK / QCT-903-IC
QCT-2275S / QCT-903-IC
QCT-2275SS / QCT-903-IC
QCT-2275PM / QCT-903-IC
Quiet Ceiling Series Lensed Wallwasher Square Trimless Fixture
with Insulated Ceiling Housing w/ Magnetic Transformer White
Black
Silver
Stainless Steel
Primer
12V / 50W Max.
Hanger Bars extend from
14.00” to 25.25” max.
Mudding Ring adjusts in
plaster frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
DESCRIPTION:
Recessed trimless fixture for wallwash
applications. Exclusive adjustable mud
ring accommodates various ceiling thick-
nesses. Exclusive adjustable mud ring
accommodates 1/2”, 5/8”, 3/4” & 1” ceilings.
ELECTRICAL:
120V input, 12V output. Junction box is
U.L. listed for through branch wiring.
CONSTRUCTION:
Housing and plaster frame: 18 gauge CRS
Trim ring, j-box and hanger assemblies:
16 gauge CRS.
SYSTEM PROTECTION:
Thermal protection provided to guard
against overheating and misuse of insu-
lation over and around fixture.
• WASHES VERTICAL SURFACE WITH EVENLY
DIFFUSED LIGHT
• DESIGNED TO BE INSTALLED WITHIN 18” -
24” OF VERTICAL SURFACE
Magnetic
Transformer
Perforated flap for
secure drywall
installation
Mud Ring adjusts in plaster
frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
STATE OF WASHINGTON AIRTIGHT APPROVED
Ceiling mudding compound
is applied right to the edge
of the fixture.
Mudding Compound
c QCT-2275WH c QCT-2275BK
c QCT-2275S c QCT-2275SS
c QCT-2275PM
w/ QCT-903-IC Housing
INCLUDES LINEAR
SPREAD LENS
Steel Safety
Cable
4.00"
SQ.
2.00" SQ.
Ball
Detent
Retainers
For 277 volt transformer add “277” to end of item #.
For Chicago Plenum add “CP” to end of item #.
REV 062904
