RSA Lighting QCM514RMMH User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
12.00”
9.48”
5.20”
12.00”
Up to 1-3/8”
Ceiling
Cut-Out
7.10” dia.
A...Housing
Constructed of 18 gauge CRS with flat
black powder coated internal finish.
Adjustable trimless mesh plate and
swing-out retaining brackets can
accommodate up to 1-3/8” ceiling
thickness.
B ...System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
Vent holes in housing provide cooler
operation.
C ...Electrical
Integral j-box and metal halide ballast.
120V input. Junction box is U.L. listed for
through branch wiring. Includes four 1/2
trade size knockouts.
D...Lamp
CMH MR16 20W or ES16 BriteSpot 39W
(not included). GX10 twist-lock lamp socket.
E ...Mounting
Housing is secured with three
adjustable swing-out retaining brackets.
Adjustment is made from countersunk
phillips screws in the mesh plate.
Perforated mesh plate may be secured
to drywall and/or joists (by others) for
additional support.
Ceiling Cut-Out: 7.10” dia. MINI
QUIET CEILING
TRIMLESS
QCM514RMMH
Remodel Housing
for Square Trim
FOR CMH MR16 20W
or ES16 BriteSpot 39W
ORDERING INFORMATION
Housing
QCM514RMMH =
Mini Quiet Ceiling
Remodel Housing
for Square Trim
w/ Integral Ballast
Remodel housing for Mini Quiet Ceiling small aperture square trimless
fixtures. (QCM5101, QCM5102, QCM5103, QCM5104).
For non-I.C. remodel applications. Fixture is installed after the ceiling.
Insulation must be kept 3” from all sides and at least 1” above the
housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
QCM514RMMH
Ceiling mudding compound is applied
right to the edge of the fixture.
Voltage
120 =120 volts primary
277 =277 volts primary*
* Consult factory for 277V ballast availability.
Metal Halide Ballast
20 =CMH MR16 20W
39 =ES16 BriteSpot 39W
rev. 091806
