DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
8.25”
10.75”
14.13”
17.13”
7.50”
Ceiling
Cut-Out
5.50”sq.
0.5” - 1.0”
A...Housing
Housing and plaster frame: 18 gauge CRS
with flat black powder coated internal
finish. Adjustable trimless mud-ring can
accommodate 1/2”, 5/8”, 3/4” & 1” ceiling
thickness.
B ...System Protection:
Thermal protection provided.
C ...Electrical
Integral j-box and electronic metal halide
ballast. 120V/277V input. Junction box
is U.L. listed for through branch wiring.
Includes five 1/2 trade size knockouts.
D...Lamp
MR16 metal halide lamp 20 or 39 watts.
GX10 TAL lamp socket included. Provides
360º rotation of trim and secures original
trim position after relamping.
E ...Mounting
Hanger Bars and Butterfly Brackets
included for residential and commercial
applications respectively. Perforated
flaps for secure drywall installation.
Ceiling Cut-Out: 5.50” sq.
QUIET CEILING
TRIMLESS
QCT903ICMH
Insulated Ceiling
AirTite
Metal Halide
Housing
for Square Trim
FOR METAL HALIDE MR16
20W or 39W
ORDERING INFORMATION
Housing
QCT903ICMH =
Quiet Ceiling
Insulated Ceiling Housing
AirTite for Square Trim
w/Integral Metal Halide Ballast
Voltage
120 =120 volts primary
277 =277 volts primary
Insulated ceiling AirTite housing for Quiet Ceiling square trimless fixtures.
Includes electronic metal halide ballast for use with 20W or 39W MR16
Metal Halide lamp.
For insulated ceiling applications. Rated for direct contact with insulation
material.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Lamp Wattage
20 =20 watts
39 =39 watts
QCT903ICMH
Ceiling mudding compound is applied
right to the edge of the fixture.
rev. 030108
