RSi Smartcanopy SMART TRAY MULTI User manual

FITMENT INSTRUCTIONS
RSI SMART TRAY - MULTI
LIKE SHARE FOLLOW
PLEASE READ FITMENT INSTRUCTIONS CAREFULLY
BEFORE INSTALLATION.

1
M12 X 40 SET SCREWS
DESCRIPTION QTY EXAMPLE
4
M12 NYLOC NUTS 4
MOUNTING RUBBER PADS / WIRE HARNESS 6 / 2
FITMENT KIT CONTENT (HARDWARE)
HARDWARE
FITMENT KIT CONTENTS
M12 X 30 FENDER WASHERS 8
CATEGORY TOOLS EXAMPLE
TOOLS
Socket Wrench & Accessories
Flat Spanners
REQUIRED TOOLS
Allen Keys
NO. 19 Socket
Socket Wrench
NO. 19 FLAT
FULL SET
Torque Wrench
RSI SMART TRAY
DESCRIPTION QTY EXAMPLE
1
FITMENT KIT CONTENTS (COMPONENTS)
VEHICLE ORIENTATION:
DOCUMENT REVISION 4.

2
PLEASE ADHERE TO BELOW TO PREVENT DAMAGE TO VEHICLE AND RSI SMART TRAY DURING FITMENT
WARNING
!
1. ONL Y USE THE RECOMMENDED TOOLS AS INDICATED IN THE FITMENT INSTRUCTION ABOVE
2. ONL Y USE THE HARDW ARE PROVIDED IN THE FITMENT KIT OUTLINED ON THE PAGE BEFORE
3. HANDLE ALL RSI SMART TRAY FITMENT COMPONENTS WITH CARE UPON UNPACKING.
4. IT IS RECOMMENDED THAT A LIFT HOIST MUST BE USED TO LIFT THE RSI SMART TRAY.
5. NEVER USE ACETONE ON PAINTWORK
STEP
ONE
1. REMOVE THE LOADBIN OF THE VEHICLE.
2. ENSURE ALL HARDWARE AND COMPONENTS ARE ACCOUNTED FOR.
3. USE CAUTION WHEN WORKING TO AVOID ANY UNNECESSARY FORMS OF DAMAGE.
4. PLACE ALL COMPONENTS ON A PROTECTIVE SURFACE TO AVOID DAMAGE.
STEP
TWO
1. REMOVE ANY WIRES FROM THE BOLTING POSITIONS WHERE THE CHASSIS RAILS WILL BE MOUNTED.
2. RE USE THE FRONT TWO SCREWS THAT HELD THE LOADBIN IN PLACE.
3. PLEASE SEE IMAGE DEPICTED BELOW TO VIEW THE 6 MOUNTING PONTS.
MOUNTING POITIONS.
MOUNTING POITIONS.
MOUNTING POITIONS.
MOUNTING POITIONS.
FITMENT OF THE RSI SMART TRAY TO VEHICLE

3
STEP
THREE
1. PLACE THE RUBBER MOUNTING PADS, ON TOP OF THE MOUNTING POSITIONS.
2. PLACE THE 20MM SPACER PLATES ON TOP OF THE RUBBER MOUNTING PADS ON THE TWO REAR
MOUNTING PADS.
3. PLEASE SEE IMAGE BELOW.
REAR MOUNTING POSITION.
PLACE TWO RUBBER INSERTION PADS.
REAR MOUNTING POSITION.
PLACE TWO RUBBER INSERTION PADS.
NO INSERTION RUBBER.
INSERTION RUBBER IN PLACE
FITMENT OF THE RSI SMART TRAY TO VEHICLE

4
STEP
FOUR
1. LIFT THE RSI SMART TRAY AND PLACE IN POSITION TO PREPARE FOR THE NEXT STEP.
2. A LIFTING HOIST IS RECOMMENDED WHEN LIFTING THE RSI SMART TRAY.
3. USE CAUTION WHEN LIFTING AND WORKING WITH THE RSI SMART TRAY.
HOOK THE STRAPS IN THE SAME POSITION ON THE OPPOSITE HAND SIDE.
STEP
FIVE 1. ONCE THE RSI SMART TRAY IS POSITIONED CORRECTLY AND THE MOUNTING POINTS LINE UP PROCEED
TO BOLT IT DOWN USING THE HARDWARE DEPICTED BELOW.
M10 X 40 SET SCREW.
M10 X 30 FENDER WASHER.
M10 NYLOC NUT.
BOLTING POSITIONS(USE SUPPLIED HARDWARE).
BOLTING POSITIONS(USE SUPPLIED HARDWARE).
BOLTING POSITIONS(USE FACTORY HARDWARE).
FITMENT OF THE RSI SMART TRAY TO VEHICLE

5
STEP
SIX
1. PLEASE ENSURE THAT THE FUEL FILLER CAP IS POSITIONED THROUGH THE CUT OUT ON THE RAILS
OF THE RSI SMART TRAY.
2. PLEASE MAKE SURE THERE ARE NO KINKS OR BENDS IN THE FUEL FILLER PIPE, AS THIS WILL BE A
PROBLEM WHEN FILLING UP WITH FUEL.
3. THE FUEL FILLER CAP WILL NOT BE BOLTED TO ANYTHING.
ENSURE THAT THE FUEL FILLER PIPE IS FREE OF ANY KINKS OR BENDS, PUSH
THROUGH CUT OUT ON MOUNTING RAILS ON THE RSI SMART TRAY.
FITMENT OF THE RSI SMART TRAY TO VEHICLE

6
FITMENT OF THE RSI SMART TRAY TO VEHICLE
STEP
SEVEN
1. ONCE THE RSI SMART TRAY HAS BEEN SECURELY BOLTED DOWN, PLUG THE TAIL LIGHTS INTO THE
MAIN VEHICLE POWER SUPPLY USING THE WIRING HARNESS.
2. TEST ALL LIGHTS AND IMMEDIATELY REPORT A PROBLEM.
RSISMARTCANOPY SMARTCANOPY
DBN 031 700 5925 CPT 021 981 2301
JHB 011 974 0370
THANK YOU FOR PURCHASING A RSI SMART TRAY.
SHOULD YOU HAVE ANY ENQUIRIES ABOUT THE FITMENT, FEEL FREE TO CONTACT US
PLUG CORRESPONDING PLUG INTO THE MAIN POWER LINE.
PLUG CORRESPONDING PLUG INTO THE CIRCUIT BOX.
PLUG CORRESPONDING PLUG INTO THE MAIN POWER LINE.
