RSI SLANT User manual

USER GUIDE
SLANT
TABLE LEG

OV1010 | 3
Parts Diagram 4
42", 36", 29" Legs 4
Safety Information 5
Assembly Instructions 6-7
TABLE OF CONTENTS
STANDARDS & CERTIFICATIONS
Meets 2014 BIFMA standards.
WARRANTY
Contact your sales representative for warranty information.

4 |
PARTS Qty/Package
1. Leg 1
2. Cover Panel 1
3. Glide Foot 1
4. Felt Pads 4
PARTS DIAGRAM
2
1
4
3

| 5
SAFETY
INFORMATION
IMPORTANT SAFETY INSTRUCTIONS Save these instructions.
INSTALL ONLY APPROVED WORK SURFACES
This table system does not include a work surface (desktop). Desktop dimensions for four-leg congurations
are not to exceed 60" diameter. If you are unsure if your preferred work surface meets specications, contact
customer service.
DO NOT OVERLOAD DESK
To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight
of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability
and cause table to tip over.
• Do not exceed maximum load (including weight of desktop) of 200 lb (91Kg)
• Do not sit or stand on table
USE CARE WHEN MOVING TABLE
• Remove all objects and mounted accessories from the table before moving
• Clear objects and equipment from table before rolling to reduce the risk of tipping over
SAFETY INFORMATION

6 |
ASSEMBLY
INSTRUCTIONS
FEED CORD THROUGH LEG
Route the cord into top and bottom hooks. Gather as much
length as desired in the space between the two hooks.
ATTACH FELT PADS TO TABS
Felt pads will eliminate any rattle that may occur where
cover is attached to leg. At top of leg, place pads into slots
and fold down to overlap. See Illustration B. Wrap pads
around each of the lower tabs on the cover.
ASSEMBLY INSTRUCTIONS
The assembly of the table frame to be made in accordance with this manual.
Changes to the table frame or improper use may affect the safety, function, and life of your product.
This manual applies to the following table legs: 29", 36" and 42".
1INSTALL LEG ASSEMBLY TO THE TABLE TOP
See Illustrations C–E to choose your preferred conguration.
Mark the locations of the pilot holes. Drill the pilot holes
to the size recommended by the table top manufacturer.
Install the screws through the mounting plate into the table
top. NOTE: The holes in the mounting plate are .13 in
INSTALL COVER PANEL TO LEG
Insert tabs on top of cover panel into corresponding slots of
leg. Slide cover panel downward so that bottom tabs insert
into corresponding slots at the bottom of the foot.
See Illustration A
2
3
4
ILLUSTRATION A
ILLUSTRATION B

| 7
ASSEMBLY INSTRUCTIONS
ROUND TOP CENTER CONFIGURATION SQUARE TOP CENTER CONFIGURATION
SQUARE TOP CORNER CONFIGURATION
42"
X: 8.75"
Y: 48" (minimum
table top size)
36"
X: 6.8125"
Y: 46" (minimum
table top size)
29"
X: 4.75"
Y: 40" (minimum
table top size)
42"
X: 8.75"
Y: 48" (minimum
table top size)
36"
X: 6.8125"
Y: 46" (minimum
table top size)
29"
X: 4.75"
Y: 40" (minimum
table top size)
42"
X: 11.5"
Y: 38" minimum
table top size
36"
X: 9.5"
Y: 36" minimum
table top size
29"
X: 7.375"
Y: 32" minimum
table top size MOUNTING PLATE
X Y
ILLUSTRATION C
X Y
ILLUSTRATION D
Y
X
ILLUSTRATION E
Maximum tabletop diameter is 60".
If you have any difculty assembling this unit, or need to
order replacement parts, please contact our Customer
Service department. Use the parts diagram on page 4
as a reference.
