Russound TPM-1 User manual

TPM-1
Instruction Manual
Option Switch
Off On Audio Output Volume Control Audio Input Power On Power 16VAC
Telephone Paging Module
TPM-1 manual 3/15/00 9:47 AM Page 1

INTRODUCTION
The TPM-1 Telephone Paging Module is an accessory of the DTI-1 Doorbell
Telephone Interface. It can be used to page through a Russound whole house audio
distribution system with paging input (such as the PR-4Z) or to a paging amplifier.
Paging is as simple as picking up the telephone. These instructions assume that you
have already installed or are currently installing a DTI-1 with either a Russound whole
house audio system or a paging system.
CONNECTIONS
NOTE: If you are using the Paging Module to connect to the a Russound Whole
House Audio System, you must first enable +12V trigger output by placing the
Option Switch in the On position (right).
1. Connect the Audio In of the TPM-1 to the TeleDoorBell 2 connection located on
the front of the DTI-1 via the included RJ11 Modular Wire.
2. Connect the Trigger Output +12V to the Trigger Input on the Russound paging
input.
3. Connect the Trigger Output Ground to the Ground Input on the Russound pag-
ing input.
NOTE: If you are installing the TPM-1 to an previously existing DTI-1 system it
will be necessary to disconnect the RJ11 connector from the Remote Trigger con-
nection on the DTI system and reattach them to the corresponding screw con-
nections on the TPM-1.
Telephone
Ring On/Off Remote Trigger Tele- DoorBell Telephone Line (In & Out) Power Plug 16VAC
21
RJ11 Modular Wire
(supplied with TPM-1)
To Audio In of
amplifier
paging system
16V AC
OUTPUT
Option Switch
Off On Audio Output Volume Control Audio Input Power On Power 16VAC
DTI-1 front
TPM-1 front
2
TPM-1 manual 3/15/00 9:47 AM Page 2

4. Connect the White, Black, Red, Green, Yellow, Blue to an RJ11 plug. Plug the
RJ11 connector into the Remote Trigger connection on the DTI-1.
5a. Connecting To A Russound Whole House Audio System
Connect the –Audio of the TPM-1 to the Ground connection of the Russound
paging input and the +Audio of the TPM-1 to the Signal connection of the
Russound paging input.
5b. Connecting To A Paging Amplifier
Connect the Audio OUT of the TPM-1 to the Audio IN of the paging amplifier
via a single RCA to RCA cable.
6. Plug in the 16VAC power transformer.
PAGE 1
V G S T
AD 4 PAG
D2 D1
V G
Telephone
Ring On/Off Remote Trigger Tele- DoorBell Telephone Line (In & Out) Power Plug 16VAC
21
WHITE
BLACK
RED GREEN
YELLOW
BLUE
BLACK
RELAY 1
Pressing doorbell automatically
activates this relay
BLACK
RED
RED
GREEN
YELLOW
Russound Paging Interface
Device Contact B (Option Off)
Trigger Output Ground (Option On)
DoorBell Contact B
DoorBell Contact A
Device Contact A (Option Off)
Trigger Output +12V (Option On)
+Audio
–Audio
DTI-1 front
TPM-1 rear
3
TPM-1 manual 3/15/00 9:47 AM Page 3

OPERATION
To page the master power switch of the PR-4Z and the AP-48 amplifier must be ON.
the TDI must be connected as described in the DTI-1 instruction. To page, pick up the
handset and press *# **9 make your announcement. There is a rest delay that
will discontinue the page after 30 seconds. To end the page simply hang up the tele-
phone. To adjust the page volume adjust the volume setting located on the front of
the TPM-1.
WARRANTY
The Russound TPM-1 is fully guaranteed for One (1) year from the date of purchase
against all defects in materials and workmanship. During this period Russound will
replace any defective parts and correct any defect in workmanship without charge for
either parts or labor. For this warranty to apply, the unit must be installed and used
according to its written instructions. If service is necessary, it must be performed by
Russound. The unit must be returned to Russound at the owner’s expense and with
prior written permission. Accidental damage and shipping damage are not considered
defects under the terms of the warranty. Russound assumes no responsibility for
defects resulting from abuse or servicing performed by an agency or person not
specifically authorized in writing by Russound. Damage to or destruction of compo-
nents due to improper use voids the warranty. In these cases the repair will be made
at the owner’s expense. To return for repairs, the unit must be shipped to Russound at
the owner’s expense, along with a note explaining the nature of the service required.
Be sure to pack in a corrugated container with at least 3 inches of resilient material to
protect the unit from damage in transit.
