RVS RVS-128 User manual

Advanced Blind Spot Sensor System
RVS-128
Instruction Manual
VEHICLE SAFETY -
IT'S ALL WE DO.
TM

Rear View Safety Reverse With Condence ™
2 3
ItemList....................................02
TechnicalSpecication..............................03
Wiring Diagram...............................03-04
WireConnectionDiagram.......................... . 04
InstallationGuide.. ............................05-07
AlertConditions.................................07
Alert Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
SafetyInformation........................ . . . . . 09
Warranty........................... . . . . . 10
Disclaimer........................... . . . . . 11
TheRVSDierence......................... . . . . . 12
TABLE OF CONTENTS
TECHNICAL SPECIFICATION
Radar Sensor
2PCS
Sensor Extension Cable
2PCS
GPS Antenna
1PCS
LED Extension Cable
3PCS
LED Indicator
2PCS
Buzzer
1PCS
Main Unit
1PCS
Main Harness
1PCS
3M Velcro
4PCS
Item List
Technical Specication
Wiring Diagram
Tools for installation: insulation tape,
multi-meter, screwdriver, cleaning cloth, tape.
Operating frequency
Transmit power
Detection range
Detection ability
24.0 ----24.25GHZ
15dbm
40 degree (Horizontal )
5 targets can be detected at the same time
Speed range 0.35mph---137mph
Speed accuracy < 0.35mph
Direction of movement
Speed Restriction
Detection range
Approached or overtaken by vehicles
Truck : 1ft-82ft
Car: 1ft-50ft
Motorcycle:1ft-33ft
Pedestrian:1ft-23ft
Operating voltage
cables waterproof
9---35V
Radars: IP 67 / Cables: waterproof
Working current
Working temperature
< 200mA
-40℃~ + 85℃
1.The GPS Antenna when connected activates
notications over 20mph (Example LED + Speaker)
2.If No GPS signal is detected or satellites not found,
the system will give notications at any speed.
LED
Buzzer
LED
R-SENSOR
L-SENSOR
M ain Unit

Rear View Safety Reverse With Condence ™
4 5
LED
LED
R-SENSOR
L-SENSOR
M ain Unit
LED
LED
R-SENSOR
L-SENSOR
M ain Unit
WIRE CONNECTION DIAGRAM
INSTALLATION GUIDE
Buzzer
Buzzer
Wire Connection Diagram
Installation Guide
Step 1. Sensor Installation
Installation requirements: sensors should be mounted to the front corner of the
vehicle, Using screws to x the sensor on the front of the vehicle.
Step 2. Installation of the left/right turn signal
Using the voltage Multi-meter, locate the left
and right turn signal trigger wires behind the
tail lamp. Once veried, connect the left and
right signal wires of the RVS-128 wire harness
to the correct signal wires.
Please note.
Letters R and L on the rub-
ber gasket, stands for right
sensor and left sensor.
SCREW
SENSOR HOUSING
RUBBER GASKET
L - Left Sensor
R - Right Sensor

Rear View Safety Reverse With Condence ™
6 7
ALERT CONDITIONS
Illumination of the LED indicator on the control box:
1.The LED comes on solid when the system is rst powered up;
2.The LED blinks slowly while the GPS module is connected to the satellite;
3.The LED blinks quickly while sensing moving objects approaching in the blind spot
(same frequency as to the alarm LED indicators & the buzzer);
4.The LED maintains the last blinking status after the alerts have ended
(the last blinking status of alarming is o / on randomly)
Step 3. LED Indicator Installation
Place the LED indicators where it is visible for the driver. Ideally on the A-pillar
or in eld view side mirrors.
Step 4. Buzzer Location
While installing the speaker, make sure it is not obstructed by any panels inside
the vehicle.
Step 6. Man Box Location
While installing the main box, use tape to mount it on the cab
1. When the vehicle is on, the system
would start detecting objects in the
blind spot area in the lane next to
and behind the vehicle, up to 82
feet.
2. When vehicles are approaching
and their speed is faster than our
own speed.
L - Left LED R - Right LED
Buzzer
Step 5.Tuck the wires neatly to hide and prevent wire pinch.
NOTE!
Alert Conditions
INSTALLATION GUIDE

Rear View Safety Reverse With Condence ™
8 9
TROUBLESHOOTING
A. Blind detection on right side:
1. R-LED indicator will be activated when there is an object approaching to the
right side blind area of your vehicle (see Fig.16).
2. If the right turn signal of your vehicle is triggered at the same time, the R-LED
indicator will be blinking and the buzzer will be beeping as well (with the same
frequency).
B. Blind detection on left side:
1. L-LED indicator will be activated when there is an object approaching to the
left side blind area of your vehicle (see Fig.16).
2. If the left turn signal of your vehicle is triggered at the same time, the L-LED
indicator will be blinking and the buzzer will be beeping as well (with the same
frequency).
C.The LED and buzzer will standby (no activity) if there is no object approaching
to the blind area of your vehicle.
D. During reversing, the R & L LED will be blinking according to the approaching
object detection of each side.
INSTALLATION GUIDE
Alert Characteristics Troubleshooting
Issue Reason Solution
LED light does not
work
Opposite LED
indicator
Buzzer does not work
Unit does not work
after GPS is connected
Sensors or GPS does
not work
Incorrect connection or pins not
making contact
LED light is broken
Microwave sensor or LED
indicators are plugged in to the
opposite connector
Defective buzzer speaker
Sensors or GPS module are
covered by the metal bumper or
other metal
Sensors or GPS module are
covered by the metal bumper or
other metal
Blind spot system does not
trigger the sensors if the speed is
less than 20mph
Find the best location where the
GPS antenna cannot be blocked
by any metal
Replace buzzer
Wrong connection or pins not
making contact
Check the harness and make sure
connection is correct
Make sure RED is driver side and
YELLOW is passenger side.
Replace LED light
Check the harness and make sure
connection is correct
8

Rear View Safety Reverse With Condence ™
10 11
If you have questions about this product, contact:
Rear View Safety
1797 Atlantic Avenue
Brooklyn, NY 11233
Tel: [phone]
