Ryobi YN301PL Quick setup guide

RYOBI
3 GallOn aIR COmpRessOR
mOdel nO. Yn301pl
RepaIR sheet

2
RYOBI 3 GallOn aIR cOmpRessOR − mODel nO. Yn301pl
FIGuRe a
15
16
11
18
20
86
90
17
13
14
6
87
55
89
2
1
78
5
54
47
7
4
3
48
12
52
20
19
21
23
22
91
92
86
83
84
85
36
34
32
33
37
29
24
81
69
31
30
40
38
41
51
42
80
77 76
53
44
39
25
28 27 26
35
45
46
47
3
5
49
2
1
50
69 58 59
60
70
69
57 62
7
78 79
75
74
73
82
71
See Figure B
68
88
67
66 63
64
65
66
56
57
72
61
43
52
54
55
10
9
See Figure B

3
RYOBI 3 GallOn aIR cOmpRessOR − mODel nO. Yn301pl
1 079027004110 Wheel Cover.............................................................2
2 079027004109 C-Clip (D12)..............................................................2
3 079027002002 Wheel........................................................................2
4 079027004106 Bolt ...........................................................................9
5 079027004209 Washer (D12) ............................................................2
6 079026002907 Tank Drain Label.......................................................1
7 079027004105 Screw .......................................................................4
8 079027004102 Rear Rubber Feet .....................................................2
9 079026002003 Bungee Clip..............................................................2
10 079027004112 Bungee Strip.............................................................1
11 079027004113 Buckle.......................................................................2
12 079026002915 Point Label (D) ..........................................................1
13 079027004114 Screw .....................................................................11
14 079026002001 Left Housing .............................................................1
15 079027004118 Tube Liner.................................................................9
16 079027004919 Nail Storage Label (A)...............................................1
17 079027004187 Lower Left Rubber Feet............................................1
18 079027004188 Upper Left Rubber Feet ...........................................1
19 079027004149 Drain Valve................................................................1
20 079027004137 Screw (M6 x 15 mm) ................................................4
21 079027004116 Tank (3 gallon)...........................................................1
22 079027004117 Pressure Switch (100-135 PSI).................................1
23 079027004132 Joint Valve ................................................................1
24 079027004190 Upper Right Rubber Feet .........................................1
25 079027004175 Power Switch ...........................................................1
26 079026002914 Point Label (C)..........................................................1
27 079026002913 Point Label (B) ..........................................................1
28 079026002912 Point Label (A) ..........................................................1
The model number will be found on a label attached to air tank. Always mention the model number in all correspondence regarding your 3 GallOn aIR
COmpRessOR or when ordering replacement parts.
29 079027004119 Clip ........................................................................... 6
30 079027004121 Accessory Cover ......................................................1
31 079027004122 Spring .......................................................................1
32 079027004123 Screw .......................................................................1
33 079026002004 Lid Latch...................................................................1
34 079027004125 Lock Nut (M3)........................................................... 1
35 079027004120 Top Housing .............................................................1
36 079027004911 Warning Label (English) ............................................ 1
37 079027004917 Maximum Weight Label............................................1
38 079026002911 Quick Start Label......................................................1
39 079027004913 Pressure Warning Label ...........................................1
40 079027004126 Bolt ...........................................................................1
41 079026002005 Handle ......................................................................1
42 079027004131 Hex Nut (M5) ............................................................1
43 079027004915 Data Label ................................................................1
44 079026002006 Right Housing...........................................................1
45 079027004920 Nail Storage Label (B)............................................... 1
46 079026002900 Hot Surface Label (English/Spanish)........................1
47 079027004103 Screw .......................................................................4
48 079026002916 Point Label (E) ..........................................................1
49 079026002902 Cord Wrap Warning Label (Spanish) ........................1
50 079027004151 Power Cord ..............................................................1
51 079027004150 Bend Relief ...............................................................1
52 079027004104 Front Rubber Feet ....................................................2
53 079027004152 Pressing Line Plate...................................................1
54 079027004101 Axle...........................................................................2
55 079027004100 Screw .......................................................................6
56 079027004154 Quick Connector (1/4 in.) .........................................1
FIGuRe a paRts lIst
KeY paRt
nO. numBeR desCRIptIOn QtY.
KeY paRt
nO. numBeR desCRIptIOn QtY.

4
RYOBI 3 GallOn aIR cOmpRessOR − mODel nO. Yn301pl
The model number will be found on a label attached to air tank. Always mention the model number in all correspondence regarding your 3 GallOn aIR
COmpRessOR or when ordering replacement parts.
FIGuRe a paRts lIst
KeY paRt
nO. numBeR desCRIptIOn QtY.
KeY paRt
nO. numBeR desCRIptIOn QtY.
57 079027004181 Screw .......................................................................4
58 079027004177 Lock Washer (D12) ...................................................1
59 079027004178 Bolt (M5 x 10 mm) .................................................... 1
60 079026002905 Regulator Knob Label...............................................1
61 079026002008 Regulator Knob ........................................................1
62 079026002904 Pressure Warning Hang Tag (Spanish) ..................... 1
63 079027004182 Lead Assembly.........................................................1
64 079027004183 Lead Assembly.........................................................1
65 079027004184 Connector Cap.........................................................1
66 079027004207 Lock Washer (D4) .....................................................3
67 079027004185 Screw .......................................................................3
68 079027004098 Lead..........................................................................1
69 079027004179 Clamp (D14)..............................................................4
70 079027004180 Rubber Hose ............................................................1
71 079027004145 Tube..........................................................................1
72 079027004146 Bracket .....................................................................1
73 079027004144 Loop (D8)..................................................................1
74 079027004143 Hex Nut (M12) ..........................................................1
75 079027004148 Bolt ...........................................................................4
76 079027004153 Screw .......................................................................2
77 079027004128 Screw .......................................................................1
78 079027004140 Screw .......................................................................2
79 079027004139 Metal Bracket ...........................................................1
80 079027004129 Metal “L” Bracket .....................................................1
81 079027004189 Lower Right Rubber Feet .........................................1
82 079027004133 Rubber Hose (D8).....................................................1
83 079027004136 Hex Bolt (M6 x 20 mm).............................................3
84 079027004135 Washer (D6) ..............................................................3
85 079027004134 Isolator......................................................................3
86 079027004138 Lock Washer (D6) .....................................................2
87 079026002007 Hose Compartment..................................................1
88 079027004099 Vent Guide................................................................1
89 079026002910 Logo Label................................................................1
90 079027004142 Connector.................................................................1
91 079027004115 Pressure Relief Valve (150 PSI).................................1
92 079027004208 Washer (D5) ..............................................................2
nOt shOWn:
079027004714 Accessory Kit
(Incl. Accessory Bag through Rubber Nozzle)..........1
079027004191 Accessory Bag .........................................................1
079027004192 Pencil Tire Guage .....................................................1
079027004193 Teflon Tape ...............................................................1
079027004194 Tire Chuck Head.......................................................1
079027004195 Blow Gun..................................................................1
079027004196 Safety Nozzle............................................................1
079027004197 Plug (1/4 in. Male Npt Male) .....................................1
079027004198 Plug (1/4 in. Female Npt Female) .............................1
079027004199 Inflation Nozzle .........................................................1
079027004200 Quick Connect..........................................................1
079027004201 Rubber Nozzle..........................................................1
079027004202 Coil Hose w/male 1/4 in. Npt Thread .......................1
987000773 Accessory Flyer (YN801CFK Combo) ...................... 1
987000771 Operator’s Manual ....................................................1
987000772 Accessories Manual (YN301PL, 079027004719) ..... 1
4-26-10
(REV:02)

5
RYOBI 3 GallOn aIR cOmpRessOR − mODel nO. Yn301pl
3
38
31
33
5
7
32
21
2
1
1
4
24
23
26
22
35
34
27
28
29
30
36
37
25
19
20
18
16
17
9
10
11
13
14
12
15
6
8
FIGuRe B

6
RYOBI 3 GallOn aIR cOmpRessOR − mODel nO. Yn301pl
The model number will be found on a label attached to air tank. Always mention the model number in all correspondence regarding your 3 GallOn aIR
COmpRessOR or when ordering replacement parts.
FIGuRe B paRts lIst
KeY paRt
nO. numBeR desCRIptIOn QtY.
KeY paRt
nO. numBeR desCRIptIOn QtY.
1 079027004064 Brush Assembly........................................................2
2 079027004711 Motor Pump Housing Assembly...............................1
3 079027004174 Elbow Connector......................................................1
4 079027004171 Pressure Regulator Manifold ....................................1
5 079027004172 Straight Connector ...................................................1
6 079027004715 Gasket Kit (Incl. Key Nos. 8, 10, 14).........................1
7 079027004170 Plug...........................................................................1
8 079027004071 Gasket ......................................................................3
9 079027004072 Cylinder ....................................................................1
10 079027004073 O-Ring ......................................................................1
11 079027004074 Rivet..........................................................................1
12 079027004075 Reed Valve................................................................1
13 079027004076 Muffler.......................................................................1
14 079027004077 Seal Ring ..................................................................1
15 079027004096 Spring Plate ..............................................................1
16 079027004082 Elbow Connector......................................................1
17 079027004080 Washer (D6) ..............................................................4
18 079027004081 Hex Bolt (M6)............................................................4
19 079027004079 Washer (D6) ..............................................................4
20 079027004078 Cylinder Cover..........................................................1
21 079027004713 Manifold Assembly (Incl. Key Nos. 3-5, 7, 22-38) ....1
22 079027004717 Regulator Assembly (Incl. Key Nos. 27–35)..............1
23 079027004169 Pressure Gauge (1.5 in.) ...........................................1
24 079027004168 Seal Ring ..................................................................1
25 079027004167 Bellow Spring ...........................................................1
26 079027004166 Rubber Cushion........................................................1
27 079027004205 Piston Seal Ring .......................................................1
28 079027004204 Piston........................................................................1
29 079027004160 Lock Nut (M5) ...........................................................1
30 079027004158 Double Thread Nut ...................................................1
31 079027004157 Double Thread Bolt...................................................1
32 079027004203 Regulator Knob.........................................................1
33 079027004156 Copper Washer.........................................................1
34 079027004159 Washer (D9.5 x D5)...................................................1
35 079027004161 Spring .......................................................................1
36 079027004164 Hex Nut.....................................................................1
37 079027004206 Seal Ring (D11 x t1.6) ...............................................1
38 079027004173 Pressure Gauge (2 in.) ..............................................1
