RYOBI
18 VOLT RIGHT ANGLE DRILL
MODEL NO. P240
REPAIR SHEET

RYOBI 18V RIGHT ANGLE DRILL – MODEL NUMBER P240
2
4
9
10
13 13
22
10 21
20
19
18
17
16
12
11
4
20
8
7
15
14
6
5
32
1
23
24

RYOBI 18V RIGHT ANGLE DRILL – MODEL NUMBER P240
3
Key Part
No. Number Description Qty.
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your Right Angle Drill or when ordering repair parts.
1 6612003 * SCREW (M5 X 18.5 mm) ....................................................1
2 690032015 CHUCK (3/8 in.) .................................................................1
3 220017041 GEAR BOX ASSEMBLY .....................................................1
4 200202334 HOUSING ASSEMBLY .......................................................1
5 6621202 * SCREW (M4 X 10 mm PAN HD.) ........................................2
6 6703001 SPRING WASHER ..............................................................2
7 230081002 MOTOR ASSEMBLY ..........................................................1
8 270018078 SWITCH ASSEMBLY ..........................................................1
9 6782106 BIT (DOUBLE ENDED PH#2, PH#3) ..................................1
10 6320601 BIT CLIP .............................................................................2
11 660204001 * SCREW (M3 X 10 mm PAN HD.) ........................................4
12 671510001 MOUNTING PLATE ............................................................1
13 200305001 SWIVEL FOOT ASSEMBLY ................................................1
14 512697001 FORWARD/REVERSE SELECTOR .....................................1
15 512698001 PADDLE SWITCH TRIGGER ..............................................1
16 671624001 SPRING ..............................................................................2
17 671522001 BALL PIN ............................................................................2
18 512699001 PIVOT HOLDER .................................................................1
19 671511001 MOUNTING BASE ..............................................................1
20 6620805 * SCREW (M4 X 16 mm) .......................................................9
21 6782405 BIT (DOUBLE ENDED 6 mm, 7 mm) ..................................1
22 200292003 LANYARD ..........................................................................1
23 940237058 DATA LABEL .......................................................................1
24 940203046 LOGO LABEL .....................................................................1
983000648 OPERATOR’S MANUAL
983000648R REPAIR SHEET (REV:01)
03-09-06

RYOBI 18V RIGHT ANGLE DRILL – MODEL NUMBER P240
4
MOTOR
RED LEAD
BLACK LEAD
WIRING DIAGRAM
BLACK LEAD
RED LEAD
SWITCH
ASSEMBLY
