Page 1 of 3 RTS20 12-10-10
Service Level
Ryobi Technologies, Inc.
Anderson, South Carolina 29625
SERVICE INFORMATION
Product: Ryobi Table Saw
Identification: Model RTS20
Condition: A design improvement was made changing certain parts of the bevel
locking lever assembly.
Remedy: When model RTS20 is in for any repair service, inspect the saw for updated
bevel locking lever parts. Updated parts can be easily identified by a compression
spring located on the locking lever screw. If parts are original and have not been
changed, order and replace parts as indicated. (see Fig 1, 2, and 3)
Old part: New part:
Wave Washer, no longer needed Spring, #089037008208
Bevel Bushing (without step) Bevel Bushing, part #089037008209
Pad, part #089037008040 Pad, part #089037008040 (thicker)
Outer washer, no longer needed
Mandatory Service
Information

Page 2 of 3 RTS20 12-10-10
Fig 1: new design with spring and step down
bevel bushing
Fig 2: old design with outer washer, bevel bushing, and wave washer

Page 3 of 3 RTS20 12-10-10
Fig 3: Bevel lock lever with new pad
Note: when replacing the above parts, it is also recommended to replace the nut
(part 089037008039) at the end of the bevel lock lever screw shown in Fig 1.
Submit warranty claim using………………………RTS20 12-10-10
Warranty claim compensation……………………...Use Ryobi Labor Chart
For Technical assistance contact Ryobi Technical Support at 1-800-525-2579
