Ryobi OHT1850 User manual

CORDLESS HEDGETRIMMER
OPERATOR’S MANUAL
OHT1850
BATTERIES AND CHARGERS SOLD SEPARATELY
090905002-02.indd 1090905002-02.indd 1 5/12/08 10:51:42 AM5/12/08 10:51:42 AM

Important!
It is essential that you read the instructions in this manual before
mounting and operating this machine.
Subject to technical modifications.
090905002-02.indd 2090905002-02.indd 2 5/12/08 10:51:45 AM5/12/08 10:51:45 AM

Fig. 2
Fig. 1
Fig. 3
B
A
AC
D
E
F
I
B
H
G
A
D
B
Fig. 4 Fig. 5
C
090905002-02.indd 3090905002-02.indd 3 5/12/08 10:51:45 AM5/12/08 10:51:45 AM

Fig. 8
Fig. 6 Fig. 7
Fig. 9
AB
Fig. 10
A
AB
C
D
E
H
I
F
A
BG
090905002-02.indd 4090905002-02.indd 4 5/12/08 10:51:50 AM5/12/08 10:51:50 AM

Page 1
ENGLISH
WARNING:
ThetoolsshouldbeoperatedwiththeONE+battery
pack.
When using battery operated tools basic safety
precaution should always be followed to
reduce
the risk of fire, leaking batteries and personal
injury, including the following.
Read the operation manual and follow all
warnings and safety instructions.
Wear eye protection and ear protection.
Do not use this machine in wet weather
conditions!
Wear protective clothing and boots
Wear non-slip, heavy duty gloves.
Keep all bystanders at least 15m away.
GENERAL POWERTOOL SAFETY WARNINGS
WARNING:
Readallsafetywarningsandallinstructions.Failure
to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
■Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
■Keepworkareacleanand welllit. Clutteredordark areas
invite accidents.
■Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
■Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
■Avoid body contact with earthed or grounded surfaces,
such as pipes,radiators, ranges and refrigerators.There
isanincreasedriskofelectricshockifyourbodyisearthed
or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
fromheat,oil,sharpedgesormovingparts. Damagedor
entangled cords increase the risk of electric shock.
■Whenoperating apowertool outdoors,useanextension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
■Ifoperatingapowertoolinadamplocationisunavoidable,
usearesidualcurrentdevice(RCD)protectedsupply.Use
of an RCD reduces the risk of electric shock.
NOTE: The term “residual current device (RCD)” may be
replacedbytheterm“groundfaultcircuitinterrupter(GFCI)”
or “earth leakage circuit breaker (ELCB)”.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use common
sensewhenoperatingapowertool.Donotuseapowertool
whileyouaretiredorundertheinfluenceofdrugs,alcohol
or medication. A moment of inattention while operating
power tools may result in serious personal injury.
■Use personal protective equipment. Always wear eye
protection.Protectiveequipmentsuchasdustmask,non-
skidsafety shoes,hardhat,orhearingprotectionusedfor
appropriate conditions will reduce personal injuries.
■Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and/
or battery pack,picking up or carrying the tool. Carrying
power tools with your finger on the switch or energizing
power tools that have the switch on invites accidents.
■Remove any adjusting key or wrench before turning the
powertoolon.Awrenchorakeyleftattachedtoarotating
part of the power tool may result in personal injury.
■Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
■Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
RULES FOR SAFE OPERATION
090905002-02.indd 1090905002-02.indd 1 5/12/08 10:51:56 AM5/12/08 10:51:56 AM

Page 2
ENGLISH
RULES FOR SAFE OPERATION
■Ifdevicesareprovidedfortheconnectionofdustextraction
andcollectionfacilities,ensurethese areconnected and
properly used. Use of dust collection can reduce dust-
related hazards.
POWERTOOL USE AND CARE
■Do not force the power tool. Use the correct power tool
foryourapplication.Thecorrectpowertoolwill do the job
better and safer at the rate for which it was designed.
■Do not use the power tool if the switch does not turn it
on and off.Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
■Disconnect t he plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
■Storeidlepowertools outof thereach ofchildrenand do
notallowpersonsunfamiliarwith thepower toolorthese
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
■Maintainpowertools.Checkfor misalignmentor binding
ofmovingparts,breakageofpartsandanyothercondition
that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
■Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
■Use the power tool, accessories and tool bits etc. in
accordance with these instructions,taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
SERVICE
■Haveyourpowertoolservicedbyaqualifiedrepairperson
using only identical replacement parts. This will ensure
that the safety of the power tool is maintained.
HEDGETRIMMER SAFETY WARNINGS
■Keep all parts of the body away from the cutter blade.
Do not remove cut material or hold material to be cut
when blades are moving. Make sure the switch is off
whenclearingjammedmaterial.Amomentofinattention
while operating the hedge trimmer may result in serious
personal injury.
■Carry the hedge trimmer by the handle with the cutter
blade stopped. When transporting or storing the
hedge trimmer always fit the cutting device cover.
Properhandlingofthehedgetrimmerwillreducepossible
personal injury from the cutter blades.
■Keepcableawayfromcuttingarea.Duringoperationthe
cable may be hidden in shrubs and can be accidentally
cut by the blade.
ADDITION
■Advice to check the hedge for foreign objects, e.g. wire
fences
■Recommendation for the use of a residual current device
with a tripping current of 30mA or less.
■Instruction to hold the hedge trimmer properly, e.g. with
both hands if two handles are provided.
READ ALL INSTRUCTIONS BEFORE OPERATING
■Readtheinstructionscarefully.Befamiliarwiththecontrols
and proper use of the unit.
■Do not operate this unit when tired, ill, or under the
influence of alcohol, drugs, or medication.
■Inspect the unit before use. Replace damaged parts.
Check for battery pack leaks.
■Make sure all fasteners and guards are in place and
secure. Replace cutting blades or any other parts that
arecracked,chipped,ordamaged.Makesurethecutting
blade is properly installed and securely fastened. Failure
to do so can result in personal injury to the operator and
bystanders, as well as damage to the unit.
■Use the right tool. Only use this hedge trimmer for the
purpose intended.
■Do not use hedge trimmer if switch will not turn the unit
on or off. A unit that cannot be controlled with the switch
is dangerous and must be repaired.
■Clear the area to be cut before each use. Remove all
objects such as cords, lights, wire, or string which can
become entangled in the cutting blade.
■Clear the area of children, bystanders, and pets. At a
minimum,keepall children,bystanders andpetsoutside
a 15 m radius; there still may be a risk to bystanders
fromthrown objects.Bystandersshould beencouraged
to wear eye protection. If you are approached, stop the
unit immediately.
■Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
■To avoid the risk of electric shock, do not operate unit in
damp or wet locations.
■Do not handle the unit with wet hands.
■Do not allow children under the age of 15 or untrained
individuals to use this hedge trimmer.
■To reduce the risk of injury, always wear full eye
protection, footwear, goggles and clothing when using
this machine.
090905002-02.indd 2090905002-02.indd 2 5/12/08 10:51:56 AM5/12/08 10:51:56 AM

Page 3
ENGLISH
RULES FOR SAFE OPERATION
■Wear a face or dust mask if the operation is dusty.
■Dress properly. Do not wear loose clothing or jewellery;
theycanbecaughtinmovingparts.Useofrubbergloves,
substantial footwearandlongtrousers is recommended
when working outdoors.
■To prevent hair from being drawn into nearby air vents
andbecomingentangledinmovingparts,wearprotective
hair covering to contain long hair or secure covered hair
above shoulder level.
■When transporting or storing the machine always fit with
blade cover.
■Always be aware of your surroundings and stay alert for
possible hazards that you may not hear due to the noise
of the machine.
■Formthehabitofcheckingtoseethatkeysandadjusting
wrenches are removed from the tool before turning it
on.
■Alwaysensure allthehandles and guardsarefittedwhen
using the tool.
■Neverattempttouseanincompletemachineoronefitted
with an unauthorised modification.
WHILE OPERATING
■Do not use trimmer without front handle in place. Keep
both hands on handles when unit is in use.
■To avoid accidental starting, never carry your unit with
your finger on the trigger.
■Stay alert and pay attention to what you are doing. Use
common sense when using this hedge trimmer.
■Wear heavy, long pants, substantial footwear and well
fitting gloves. Do not wear short pants, sandals or go
barefoot.
■Do not operate in poor lighting. Use the unit only in
daylight or good artificial light.
■Do not overreach or stand on unstable support. Keep
good footing and balance at all times. Do not use on
ladder.
■Do not force the hedge trimmer. It will do the job better
and with less likelihood of a risk of injury at the rate for
which it was designed.
■Release the trigger, allow the motor to stop, and remove
the battery pack before performing maintenance, repair,
or making adjustments.
■This hedge trimmer is to be used for cutting hedges,
bushes, and shrubs only. Do not use for any other
purpose.
■Beforestarting theunit,makesurethecuttingblades will
notcomeincontactwithanything.Ifyoustrikeorbecome
entangledwithforeignobjects,stoptheunitimmediately,
remove the battery pack and check for damage. Do not
operatebeforerepairingdamage.Donotoperatetheunit
with loose or damaged parts.
■Watch what you are doing. Use common sense.
■Maintain hedge trimmer with care. Keep cutting edge
sharp and clean for best performance and to reduce
the risk of injury. Follow instructions for lubricating and
changingaccessories.Keephandlesdry,clean,andfree
from oil and grease.
■Check damaged parts. Before further use of the hedge
trimmer, a guard or other part that is dam-aged should
be carefully checked to determine that it will operate
properly and perform it's intended function. Check
for alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other condition
that may affect it's operation. A guard or other part that
is damaged should be properly repaired or replaced by
aAuthorised Service Centreunlessindicatedelsewhere
in this manual.
■Riskofcut.Keephandsawayfromblades.Donotattempt
to remove cut material or hold material to be cut when
bladesaremoving. Makesurebattery packisremovedand
the trigger is released when clearing jammed material
fromblades. Do not grasp the exposedcuttingbladesor
cutting edges when picking up or holding the unit.
CAUTION:
Blades coast after unit is turned off.
■Keephands,face,andfeetatasafedistancefrommoving
parts.Donottouchortryto stopthecuttingbladeswhen
they are moving.
■Always stop the motor when cutting is delayed or when
walking from one cutting location to another.
■Keep unit clean of grass clippings and other materials.
They may become lodged in the cutting blades.
■Store the unit inside in a dry place, either locked up or up
high to prevent unauthorised use or damage. Keep out
of the reach of children or untrained individuals.
■Replace blade cover when unit is not in use.
■Never douse or squirt the unit with water or any other
liquid. Keep handles dry, clean and free from debris.
Clean after each use, see Storage instructions.
■Be sure to secure the unit while transporting.
■Keep these instructions. Refer to them often and use
them to instruct other users. If you loan someone this
unit, also loan them these instructions.
SERVICE
■Service on unit must be performed only by qualified
repair personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury to
the user, or damage to the unit. It may also void your
warranty.
090905002-02.indd 3090905002-02.indd 3 5/12/08 10:51:56 AM5/12/08 10:51:56 AM

Page 4
ENGLISH
RULES FOR SAFE OPERATION
■When servicing a unit, use only identical replacement
parts. Follow instruction in the Maintenance section
of this manual. Use of unauthorised parts or failure
to follow Maintenance Instructions may create a risk of
shock or serious injury to the user, or damage to the unit.
It may also void your warranty.
■When replacing the blade the whole blade assembly
should be changed.
BATTERYTOOL USE AND CARE
■Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
■Usepowertoolsonlywith specificallydesignatedbattery
packs. Use of any other battery packs may create a risk
of injury and fire.
■When battery pack is not in use, keep it away from other
metal abject like paper lips, coins, keys, nails, screws,
or other small metal objects that can make a connection
fromoneterminaltoanother.Shortingthebatteryterminals
together may cause burns or fire.
■Under abusive conditions, liquid may be ejected from
thebattery;avoidcontact.Ifcontactaccidentallyoccurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
■Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
WARNING:
If any parts are missing, do not operate unit until
the missing parts are replaced. Failure to do so
could result in possible serious personal injury.
SAVE THESE INSTRUCTIONS. REFER TO THEM
FREQUENTLY AND USE THEM TO INSTRUCT OTHERS
WHO MAY USE THIS UNIT. IF YOU LOAN SOMEONE THIS
UNIT, LOAN THEM THESE INSTRUCTIONS ALSO.
PRODUCT SPECIFICATIONS
Motor .........................................................................18V
No Load Speed............................................... 1200 min-1
Blade Length ...................................................... 457 mm
Cutting Capacity................................................... 10 mm
Weight With Battery Pack.......................................3,2 kg
Battery pack (not included) ……................ BPP-1817M /
...........................................BPP-1815M / BPP-1817MG /
............... ABP1801 /ABP1802 / BPL-1820 / BPL-1820G
Charger (not included) ………… ..................... BC-1800 /
.........................BC-1800M / BC-1815S / BC-1815SMG /
.................................ACR1800 / BCL-1800 / BCL-1800G
FEATURES
Fig. 1
A. BLADE COVER
B. GUARD
C. FRONT HANDLE
D. TRIGGER LOCK BUTTON
E. REAR HANDLE
F. BATTERY PACK (Not Included)
G. BLADE
H. SENSOR SWITCH
I. TRIGGER
Fig. 2
A. BATTERY PACK (Not Included)
B. LATCHES
Fig. 3
A. FRONT HANDLE
B. SENSOR SWITCH
C. TRIGGER LOCK BUTTON
D. TRIGGER
Fig. 6
A. BLADE COVER SCREWS
B. BLADE COVER
Fig. 7
A. BLADE SCREWS
B. BAR PLATE
C. RETAINING RING
D. WASHER
E. RETAINING PLATE
F. CUTTER BLADE ASSEMBLY
090905002-02.indd 4090905002-02.indd 4 5/12/08 10:51:57 AM5/12/08 10:51:57 AM

Page 5
G. YOKES
H. CAMS
I. PINS
Fig. 9
A. CUTTER BLADE
B. GUARD
Fig. 10
A. BLADE COVER
ENGLISH
OPERATION
INSTALLINGTHE BATTERY PACK (NOT INCLUDED)
■Place the battery pack in the hedge trimmer. Align raised
rib on battery pack with groove in hedge trimmer. See
Figure 2.
■Make sure the latches on the battery pack snap in place
andthatbattery packissecuredin hedgetrimmerbefore
beginning operation.
REMOVINGTHE BATTERY PACK (NOT INCLUDED)
■Locatelatchesofbatterypackanddepresstoreleasethe
battery pack from the hedge trimmer. See Figure 2.
■Remove battery pack from the hedge trimmer.
CAUTION
Whenplacingbatterypackinyourhedgetrimmer,be
sureraised ribonbattery packalignswith groovein
hedge trimmer and latches snap in place properly.
Improper assembly of battery pack can cause
damage to internal components.
STARTINGTHE HEDGETRIMMER
■Remove the blade cover.
■For added safety, there is a sensor switch in the upper
handle. See Fig. 3 . When operating, hold the trimmer
with both hands, one hand to push the trigger lock
button forward, and the other hand to squeeze the front
handle.
■Release the trigger lock button and continue to squeeze
the trigger for extended operation.
STOPPINGTHE HEDGETRIMMER
■Release the trigger to stop the hedge trimmer.
FEATURES ■Upon release of the trigger, the trigger lock button will be
automatically reset to the lock position.
OPERATINGTIPS
■Donotforcethehedgetrimmerthroughheavyshrubbery.
This can cause the blades to bind and slow down. If the
blades slow down, reduce the pace.
■Do not try to cut stems or twigs that are larger than 10
mm thick, or those obviously too large to feed into the
cutting blade. Use a non-powered hand saw or pruning
saw to trim large stems.
■If desired, you can use a string to help cut your hedge
level.Decidehowhighyouwantthehedge.Then,stretch
a piece of string along the hedge at this height. Trim the
hedge just above this guide line of string. See Figure 4.
Trimtheside ofahedgeso thatitwillbe slightly narrower
atthetop.SeeFigure5.Moreofthehedgewillbeexposed
whenshapedthisway,anditwillbemoreuniform.Ifblades
do become jammed, stop the motor, allow the blades to
stop and remove the battery pack before attempting to
remove the obstruction.
■Wear gloves when trimming thorny or prickly growth.
Whentrimmingnewgrowth,useawidesweepingaction,
so that the stems are fed directly into the cutting blade.
Older growth will have thicker stems and will be trimmed
easiest by using a sawing movement.
DANGER
If blade jams on any electrical cord or line, DO
NOT TOUCH THE BLADE! IT CAN BECOME
ELECTRICALLY LIVE AND VERY DANGEROUS.
Continueto holdthehedgetrimmerbytheinsulated
rear handle or lay it down and away from you in
a safe manner. Disconnect the electrical service
to the damaged line or cord before attempting to
free the blade from the line or cord. Failure to heed
this warning will result in serious personal injury or
possible death.
WARNING
Clearthe areatobecutbeforeeachuse.Removeall
objects such as cords, lights, wire, or string which
can become entangled in the cutting blade and
create a risk of serious personal injury.
WARNING
Avoid using solvents when cleaning plastic parts.
Mostplasticsaresusceptibletodamagefromvarious
Typesofcommercialsolventsandmaybedamaged
by their use. Use a clean cloth to remove dirt, oil,
090905002-02.indd 5090905002-02.indd 5 5/12/08 10:51:57 AM5/12/08 10:51:57 AM

Page 6
ENGLISH
grease,etc.WhenservicinguseonlyidenticalRyobi
replacementparts.Useofanyotherpartscancreate
a hazard or cause product damage.
CAUTION
Donotatanytimeletbrakefluids,gasoline,petroleum
based products, penetrating oils, etc., come in
contact with plastic parts. They contain chemicals
that may damage, weaken, or destroy plastics.
MAINTENANCE AND REPAIR
REPLACING BLADES
WARNING
Blades are sharp. When handling blade assembly,
do not place your hand or fingers between blades
or in any position where they could get pinched or
cut.NEVERtouchbladesorserviceunitwithbattery
pack installed.
REMOVINGTHE BLADE (Fig. 6 & 7)
■Remove battery pack from hedge trimmer.
■Place hedge trimmer upside down on a workbench and
remove four (4) blade cover screws.
■Remove blade cover. See Figure 6.
■Remove bar plate from the two pins. See Figure 7.
■Remove retaining ring, washer and retaining plate. See
Figure 7.
■Align the cams.
NOTE: The yokes can not be lifted unless it clears the lip
of the cams.
■Remove the four (4) blade screws.
■Each blade has an oval yoke attached at one end. Slide
the blades into position so the yokes align. Remove the
blade from the housing.
INSTALLINGTHE BLADE (Fig. 6 & 7)
■Align the cams.
■Place new blade on housing and align yokes to drop into
place.Rotatethebladesothatitdropspastthelowercam.
NOTE: When properly aligned, the blade assembly
fits in recessed slot in motor housing.
■Re-Install the four (4) blade screws and tighten
securely.
OPERATION ■Re-Install retaining plate, washer and retaining ring.
■Re-Install the bar plate over the two pins.
■Install the blade cover using the 4 blade cover screws.
Tighten securely.
WARNING
Make sure bottom plate is replaced before inserting
the battery pack, and starting the hedge trimmer.
Failure to do so will expose internal parts, which
couldcauseanaccidentorelectricalshock,resulting
in serious injury.
NOTE: If binding occurs after replacing the blade assembly,
repeat the steps under Removing the Blade and Installing
the Blade.
BLADE MAINTENANCE – HEDGETRIMMER
WARNING
Battery units do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. To prevent serious personal
injury, always remove the battery and take extra
precautionsandcarewhenperformingmaintenance,
service or for changing the cutting blade.
WARNING
Topreventseriouspersonalinjury,removethebattery
packbeforeservicing,cleaning,orremovingmaterial
from the unit.
BLADE CARE
■Lubricate the cutting blades after each use.
■Periodically inspect the blades for damage and wear.
■Always use the manufacturer's specified replacement
blades.
TO LUBRICATE BLADE
■Remove battery pack from hedge trimmer.
■For easier operation and longer blade life, lubricate the
hedge trimmer blade before and after each use. Before
lubricating,removethebatterypackandlayhedgetrimmer
onaflatsurface. Apply lightweightmachine oil alongthe
edge of the top blade. See Figure 8.
■Occasionally, you should oil your hedge trimmer during
use. Before oiling, stop hedge trimmer, remove battery
pack, then oil. You then can resume trimming. Do not oil
while hedge trimmer is running.
090905002-02.indd 6090905002-02.indd 6 5/12/08 10:51:58 AM5/12/08 10:51:58 AM

Page 7
MAINTENANCE AND REPAIR
ENGLISH
SHARPENING BLADE
■Allow the blades of hedge trimmer to come to a stop in
the position shown in Figure 9. This will allow clearance
for the file between cutter teeth and guard teeth.
■Remove battery pack from hedge trimmer.
■Clamp blade assembly in a vice and file the exposed
cutting surface of each blade tooth with an 203 mm (8
inch) smooth round file, 6.4 mm (1/4 inch) or 5.6 mm
(7/32 inch) diameter. Be sure to retain the original angle
of tooth when filing.
■Removethe hedgetrimmer fromthevice,replacebattery
packandrestartthehedgetrimmer.Allowthebladesofthe
hedgetrimmertocometoastopsothattheunsharpened
edges of the cutter blade teeth are exposed.
■Removebatterypack fromhedgetrimmerand repeatthe
sharpening procedure as described above.
HEDGETRIMMER LUBRICATION
All of the bearings in this tool are lubricated with a sufficient
amount of high-grade lubricant for the life of the unit under
normal operating procedures.
Therefore, no further lubrication is required.
WARNING
Donotattempttomodifythisunitorcreateormount
anyaccessorynotspecificallyrecommendedinthis
manual for use with this hedge trimmer. Any such
alterationormodificationismisuseandcouldresultin
a hazardous condition leading to possible serious
personal injury.
WARNING
Examinehedgetrimmerfrequentlytoassureallparts
are unbroken and securely attached. Make sure
all screws and fasteners are securely tightened to
prevent the risk of serious personal injury.
CLEANINGTHE HEDGETRIMMER
■Remove the battery pack.
WARNING
Topreventseriouspersonalinjury,removethebattery
packbeforeservicing,cleaning,orremovingmaterial
from the unit.
■Clean the unit using a damp cloth with a mild
detergent.
■Do not use any strong detergents on the plastic housing
or the handle. They can be damaged by certain aromatic
oils such as pine and lemon, and by solvents such as
kerosene.
■Moisturecancauseashockhazard.Wipeoffanymoisture
with a soft dry cloth.
■Use a small brush or the air discharge of a small vacuum
cleaner brush to clean the air vents on the battery pack
housing and motor housing.
■Keep the air vents free of obstructions.
STORINGTHE HEDGETRIMMER
■Cleanthehedgetrimmerthoroughlybeforestoring.Store
the hedge trimmer in a dry, well-ventilated place that is
inaccessibletochildren.Keepawayfromcorrosiveagents
such as garden chemicals and de-icing salts.
■Alwaysplacebladecoveroncuttingbladesbeforestoring.
See Figure 10.
■Storeandchargeyourbatteriesinacoolarea.Temperatures
above or below normal room temperature will shorten
battery pack life.
■Never store batteries in a discharged condition. Wait for
battery pack to cool and charge immediately.
■All batteries gradually lose their charge. The higher the
temperature, the quicker they lose their charge. If you
store your unit for long periods of time without using it,
recharge the batteries every month or two. This practice
will prolong battery pack life.
DISPOSAL
Wasteelectricalproductsshouldnotbedisposedoftogether
with household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
090905002-02.indd 7090905002-02.indd 7 5/12/08 10:51:59 AM5/12/08 10:51:59 AM

Page 8
LIMITED WARRANTY
TTI warrants this outdoor product to be free of defects in material or workmanship for 24 months from the date of purchase
by the original purchaser, subject to the limitations below. Please keep your invoice as proof of date of purchase.
This warranty is only applicable where the product is used for personal and non-commercial purposes. Thiswarranty
does not cover damage or liability caused by / due to misuse, abuse, accidental or intentional acts by user, improper
handling, unreasonable use, negligence, failure by end user to follow operating procedures outlined in the user’s manual,
attemptedrepair bynon-qualifiedprofessional,unauthorized repair,modification, oruseofaccessoriesand/orattachments
not specifically recommended by authorized party.
This warranty does not cover belts, brushes, bags, bulbs or any part which ordinary wear and tear results in required
replacement during warranty period. Unless specifically provided under applicable law, this warranty does not cover
transportation cost or consumable items such as fuses.
This limited warranty is void if the product’s original identification (trade mark, serial number, etc.) markings have been
defaced, altered or removed or if product is not purchased from an authorized reseller or if product is sold AS IS and / or
WITH ALL FAULTS.
Subject to all applicable local regulations, the provisions of this limited warranty are in lieu of any other written warranty,
whetherexpressorimplied,writtenororal,includinganywarrantyofMERCHANTABILITYORFITNESSFORAPARTICULAR
PURPOSE.INNOEVENTSHALLWEBELIABLEFORSPECIAL,INCIDENTAL,CONSEQUENTIALORINCIDENTALDAMAGES.
OUR MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
This warranty is valid only in the European Union, Australia and New Zealand. Outside these areas, please contact
your authorized Ryobi dealer to determine if another warranty applies.
18V
Sound pressure level: LpA=71dB(A), KpA=3 dB(A)
Sound power level: LwA=91dB(A), KwA=3 dB(A)
Weighted root mean square acceleration value: 1.0m/s2, K=1.5 m/s2
Date of Issuance
Issued by
DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is in conformity with the following standards or
standardized documents.
98/37/EC, 89/336/EEC, 2000/14/EC GUARANTEE
DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is in conformity with the following standards or standardized
documents.
98/37/EC, 89/336/EEC, 2000/14/EC GUARANTEE
Technical documents are kept by Homelite Far East Co., Ltd. 24/F, 388 Castle Peak Road, Tsuen Wan, Hong Kong.
090905002-02.indd 8090905002-02.indd 8 5/12/08 10:52:00 AM5/12/08 10:52:00 AM

Page 9
RYOBI TECHNOLOGIES (UK) LIMITED.
Medina House, Fieldhouse Lane, Marlow,
Buckinghamshire, SL7 1TB,
UNITED KINGDOM
Tel: + 44 (0) 1628 894400
Fax: + 44 (0) 1628 894401
Technical Helpline: [phone]
RYOBI TECHNOLOGIES SAS
Immeuble Le Grand Roissy
Z.A. du Gué - 35 rue de Guivry
77990 LE MESNIL AMELOT FRANCE
Phone: + 33 (0)1 60 94 69 70
Fax: + 33 (0)1 60 94 69 79
RYOBI BELGIUM
Avenue des Pâquerettes, 55
Zoning artisanal - bâtiment 5
B - 1410 Waterloo
BELGIQUE
Tel : + 32 (0) 2 357 81 40
Fax : + 32 (0) 2 357 81 49
RYOBI ITALIA
Via Vincenzo Borelli, 13
I - 41100 Modena
ITALIA
Tel : + 39 (0) 59 23 84 08
Fax : + 39 (0) 59 24 69 60
RYOBI IBÉRICA
Avenidad de la Industria 52
28820 Coslada - Madrid
ESPANA
Tel : + 34 (0) 91 627 93 26
Fax : + 34 (0) 91 627 93 29
TECHTRONIC INDUSTRIES (ASIA) CO. LTD.
24/F, CDW Building,
388 Castle Peak Road,
Tsuen Wan, Hong Kong.
Tel : + 852 2402 6888
RYOBI TECHNOLOGIES GMBH
Itterpark 4
D-40724 Hilden
DEUTSCHLAND
Tel: + 49 (0) 2103 2958-0
Fax: + 49 (0) 2103 2958-29
RYOBI TECHNOLOGIES GMBH
Vertriebsbüro Österreich
Schinitzgasse 13
A-8605 Kapfenberg
Tel.: + 43 (0) 3862 23590-0
Fax: + 43 (0) 3862 23590-25
TECHTRONIC INDUSTRIES AUSTRALIA PTY LIMITED.
Building B, Rosehill Industrial Estate,
3 Shirley Street,
Rosehill NSW 2142
AUSTRALIA
Tel: [phone] or 1300 361 505
Fax: [phone]
TECHTRONIC INDUSTRIES (NZ) LIMITED.
27 Clemow Drive, Mt Wellington
PO Box 12-806, Penrose, Auckland
NEW ZEALAND
Tel: + 64 (0) 9 573 0230 Free Call: [phone]
Fax: + 64 (0) 9 573 0231
A&M MIDDLE EAST FZCO
P.O.Box 61254
Jedel Ali, Dubai,
UNITED ARAB EMIRATES
Tel.: + 971 4 8861399
Fax: + 971 4 8861400
Machine: CORDLESS HEDGE TRIMMER Type: OHT1850
Name/Title: Andrew Eyre
Vice President, Engineering
Signature:
Name of company:
Homelite Far East Co., Ltd.
Address:
24/F, CDW Building,
388 Castle Peak Road,
Tsuen Wan, Hong Kong.
090905002-02.indd 9090905002-02.indd 9 5/12/08 10:52:00 AM5/12/08 10:52:00 AM
