Ryobi RHT36 User manual

TAILLE-HAIES SANS FIL MANUEL D’UTILISATION 1
CORDLESS HEDGE TRIMMER USER’S MANUAL 10
AKKU-HECKENSCHERE BEDIENUNGSANLEITUNG 18
CORTASETOS INALÁMBRICO MANUAL DE UTILIZACIÓN 26
TAGLIASIEPI A BATTERIA MANUALE D’USO 35
CORTA-SEBES SEM FIO MANUAL DE UTILIZAÇÃO 44
ACCU HEGGENSCHAAR GEBRUIKERSHANDLEIDING 53
SLADDLÖS HÄCKKLIPPARE INSTRUKTIONSBOK 62
%$77(5,'5(9(1+ä..(./,33(5 BRUGERVEJLEDNING 70
OPPLADBAR HEKKSAKS BRUKSANVISNING 78
JOHDOTON PENSASLEIKKURI KÄYTTÄJÄN KÄSIKIRJA 86
SÖVÉNYVÁGÓ, VEZETÉK NÉLKÜLI HASZNÁLATI ÚTMUTATÓ 94
$.808/È72529e1ģä.<1$ä,9é3/27 NÁVOD K OBSLUZE 103
Äääìåìãüíéêçõâ äìëíéêÖá êìäéÇéÑëíÇé èé ùäëèãìÄíÄñàà 112
APARAT DE TUNS GARD VIU CU ACUMULATOR MANUAL DE UTILIZARE 120
$.808/$7252:(12ĩ<&('2ĩ<:23à27Ï: 32'5ĉ&=1,.2%6à8*, 128
%5(=ä,ý1,2%5(=29$/1,.ä,9(0(-( UPORABNIŠKI PRIROýNIK 137
%(ä,=$ä,9,&8 .25,61,ý.,35,58ý1,. 
JUHTMEVABA ELEKTRILINE HEKITRIMMER KASUTAJAJUHEND 152
$.808/,$725,1,6*<9$7925Ơ6*(1Ơ789$6 NAUDOJIMO VADOVAS 160
%(=9$'$.5Nj0*5,(=,6 /,(727Ɩ-$52.$6*5Ɩ0$7$ 
$.808/È72529e12ä1,&(1$ä,9é3/27 1È92'1$328ä,7,( 
ÅÖáÜàóÖç ïêÄëíéêÖá êöäéÇéÑëíÇé áÄ ìèéíêÖÅÄ 186
RHT36
FR
EN
DE
ES
IT
PT
NL
SV
DA
NO
FI
HU
CS
RU
RO
PL
SL
HR
ET
LT
LV
SK
BG
Important!
It is essential that you read the instructions in this manual before mounting
and operating this machine.

ȼɚɠɧɨ Ɉɬɢɡɤɥɸɱɢɬɟɥɧɚɜɚɠɧɨɫɬɟɞɚɩɪɨɱɟɬɟɬɟɢɧɫɬɪɭɤɰɢɢɬɟɜɬɨɜɚɪɴɤɨɜɨɞɫɬɜɨɩɪɟɞɢɞɚɛɨɪɚɜɢɬɟɫ
ɬɚɡɢɦɚɲɢɧɚ
6XEMHFWWRWHFKQLFDOPRGLILFDWLRQV6RXVUpVHUYHGHPRGLILFDWLRQVWHFKQLTXHV7HFKQLVFKHbQGHUXQJHQYRUEHKDOWHQ
%DMRUHVHUYDGHPRGLILFDFLRQHVWpFQLFDV&RQULVHUYDGLHYHQWXDOLPRGLILFKHWHFQLFKH7HFKQLVFKHZLM]LJLQJHQYRRUEHKRXGHQ
&RPUHVHUYDGHPRGLILFDo}HVWpFQLFDV0HGIRUEHKROGIRUWHNQLVNHQGULQJHU0HGI|UEHKnOOI|UWHNQLVNDlQGULQJDU
7HNQLVHWPXXWRNVHWYDUDWDDQ0HGIRUEHKROGRPWHNQLVNHHQGULQJHUɦɨɝɭɬɛɵɬɶɜɧɟɫɟɧɵɬɟɯɧɢɱɟɫɤɢɟɢɡɦɟɧɟɧɢɹ
=]DVWU]HĪHQLHPPRG\ILNDFMLWHFKQLF]Q\FK=PČQ\WHFKQLFNêFK~GDMĤY\KUD]HQ\$PĦV]DNLPyGRVtWiVMRJiWIHQQWDUWMXN
6XEUH]HUYDPRGLILFDĠLLORUWHKQLFH3DWXUDPWLHVƯEDVPDLQƯWWHKQLVNRVUDNVWXUOLHOXPXV
3DVLOLHNDQWWHLVĊGDU\WLWHFKQLQLXVSDNHLWLPXV7HKQLOLVHGPXXGDWXVHGY}LPDOLNXG3RGORQRWHKQLsNLPSURPMHQDPD
7HKQLþQHVSUHPHPEHGRSXãþHQH3UiYRQDWHFKQLFNp]PHQ\MHY\KUDGHQpɉɨɞɥɟɠɢɧɚɬɟɯɧɢɱɟɫɤɢɦɨɞɢɮɢɤɚɰɢɢ
VL

10
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Your hedge trimmer has been engineered and
manufactured to Ryobi’s high standard for dependability,
ease of operation, and operator safety. When properly
cared for, it will give you years of rugged, trouble-free
performance.
Thank you for buying a Ryobi product.
RULES FOR SAFE OPERATION
WARNING
5HDGDOOVDIHW\ZDUQLQJVDQGDOOLQVWUXFWLRQV )DLOXUH
to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
INTENDED USE
This hedge trimmer is intended for cutting and trimming
hedges and bushes in domestic use. It is not intended to
be used for cutting above shoulder level. The product is
not for no load use.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
ELECTRICAL SAFETY
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result
in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
gloves, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
Do not over-reach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
BATTERY TOOL USE AND CARE
Ensure the switch is in the off position before
inserting battery pack. Inserting the battery pack into
power tools that have the switch on invites accidents.

11
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may cause
burns or fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with plenty of soap and water. If liquid
contacts eyes, immediately seek medical help. Liquid
ejected from the battery may cause irritation or burns.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
HEDGE TRIMMER SAFETY WARNINGS
Keep all parts of the body away from the cutter blade.
Do not remove cut material or hold material to be
cut when blades are moving. Make sure the switch
is off when clearing jammed material.A moment of
inattention while operating the hedge trimmer may
result in serious personal injury.
Carry the hedge trimmer by the handle with the
cutter blade stopped. When transporting or storing
the hedge trimmer always fit the cutting device cover.
Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
Hold the power tool by insulated gripping surfaces
only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a "live" wire may
make exposed metal parts of the power tool "live" and
could give the operator an electric shock.
READ ALL INSTRUCTIONS BEFORE OPERATING
Read the instructions carefully. Be familiar with the
controls and proper use of the unit.
Do not operate this unit when tired, ill, or under the
influence of alcohol, drugs, or medication.
Inspect the unit before use. Replace damaged parts.
Check for battery pack leaks.
Make sure all fasteners and guards are in place and
secure. Replace cutting blades or any other parts
that are cracked, chipped, or damaged. Make sure
the cutting blade is properly installed and securely
IDVWHQHG)DLOXUHWRGRVRFDQUHVXOWLQSHUVRQDOLQMXU\
to the operator and bystanders, as well as damage to
the unit.
Use the right tool. Only use this hedge trimmer for the
purpose intended.
Do not use hedge trimmer if switch will not turn the
unit on or off. A unit that cannot be controlled with the
switch is dangerous and must be repaired.
Clear the area to be cut before each use. Remove all
objects such as cords, lights, wire, or string which can
become entangled in the cutting blade.
Clear the area of children, bystanders, and pets.
At a minimum, keep all children, bystanders and
pets outside a 15 m radius; there still may be a
risk to bystanders from thrown objects. If you are
approached, stop the unit immediately.
Do not operate power tools in explosive atmospheres,
such as in the presence of fl ammable liquids, gases
or dust. Power tools create sparks which may ignite
the dust or fumes.
To avoid the risk of electric shock, do not operate unit
in damp or wet locations.
Do not handle the unit with wet hands.
Do not allow children or untrained individuals to use
this hedge trimmer.
To reduce the risk of injury, always wear full eye
protection, footwear, goggles and clothing when using
this machine.
Wear a face or dust mask if the operation is dusty.
Dress properly. Do not wear loose clothing or
jewellery; they can be caught in moving parts. Use of
rubber gloves, substantial footwear and long trousers
is recommended when working outdoors.
To prevent hair from being drawn into nearby air
vents and becoming entangled in moving parts,
wear protective hair covering to contain long hair or
secure covered hair above shoulder level.
When transporting or storing the machine always fit
with blade cover.
Always be aware of your surroundings and stay alert
for possible hazards that you may not hear due to the
noise of the machine.
)RUPWKHKDELWRIFKHFNLQJWRVHHWKDWNH\VDQG
adjusting wrenches are removed from the tool before
turning it on.
Always ensure all the handles and guards are fitted
when using the tool.
Never attempt to use an incomplete machine or one
fitted whith an unauthorised modification.

12
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
The vibration level during actual use of the power tool
can differ from the declared total value depending on
the ways in which the tool is used.
It has been reported that vibrations from hand-held tools
may contribute toa condition calledRaynaud’sSyndrome
in certain individuals. Symptoms may include tingling,
QXPEQHVVDQGEODQFKLQJRIWKH¿QJHUVXVXDOO\DSSDUHQW
upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking and work practices
are all thought to contribute to the development of these
symptoms. It is presentlyunknown what, if any, vibrations
or extent of exposure may contribute to the condition.
There are measures that can be taken by the operator
to possibly reduce the effects of vibration:
 .HHS \RXU ERG\ ZDUP LQ FROG ZHDWKHU :KHQ
operating the unit wear gloves to keep the hands
and wrists warm. It is reported that cold weather is a
major factor contributing to Raynaud’s Syndrome.
  $IWHUHDFKSHULRGRIRSHUDWLRQH[HUFLVHWRLQFUHDVH
blood circulation.
  7DNHIUHTXHQWZRUNEUHDNV/LPLWWKHDPRXQWRI
exposure per day.
If you experience any of the symptoms of this
condition, immediately discontinue use and see your
physician about these symptoms.
WHILE OPERATING
Do not use trimmer without front handle in place.
Keep both hands on handles when unit is in use.
To avoid accidental starting, never carry your unit with
your finger on the trigger.
Stay alert and pay attention to what you are doing.
Use common sense when using this hedge trimmer.
Wear heavy, long pants, substantial footwear and well
fitting gloves. Do not wear short pants, sandals or
go barefoot.
Do not operate in poor lighting. Use the unit only in
daylight or good artificial light.
Do not overreach or stand on unstable support.
Keep good footing and balance at all times. Do not
use on ladder.
Do not force the hedge trimmer. It will do the job
better and with less likelihood of a risk of injury at the
rate for which it was designed.
Release the trigger, allow the motor to stop,
and remove the battery pack before performing
maintenance, repair, or making adjustments.
This hedge trimmer is to be used for cutting hedges,
bushes, and shrubs only. Do not use for any other
purpose.
Before starting the unit, make sure the cutting blades
will not come in contact with anything.
If the machine strike or become entangled with
foreign objects, stop the unit immediately, remove the
battery pack and check for damage. Do not operate
before repairing damage. Do not operate the unit with
loose or damaged parts.
Watch what you are doing. Use common sense.
Maintain hedge trimmer with care. Keep cutting edge
sharp and clean for best performance and to reduce
WKHULVNRILQMXU\)ROORZLQVWUXFWLRQVIRUOXEULFDWLQJ
and changing accessories. Keep handles dry, clean,
and free from oil and grease.
Check damaged parts. Before further use of the
hedge trimmer, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform it’s intended function.
Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and any
other condition that may affect it’s operation. A guard
or other part that is damaged should be properly
repaired or replaced by a Authorised Service Centre
unless indicated elsewhere in this manual.
Risk of cut. Keep hands away from blades. Do not
attempt to remove cut material or hold material to
be cut when blades are moving. Make sure battery
pack is removed and the trigger is released when
clearing jammed material from blades. Do not grasp
the exposed cutting blades or cutting edges when
picking up or holding the unit.
CAUTION
Blades continue to move for a short time after unit is
turned off.
Keep hands, face, and feet at a safe distance from
moving parts. Do not touch or try to stop the cutting
blades when they are moving.
Always stop the motor when cutting is delayed or
when walking from one cutting location to another.
Keep unit clean of hedge clippings and other
materials. They may become lodged in the cutting
blades.
Store the unit inside in a dry place, either locked up
or up high to prevent unauthorised use or damage.
Keep out of the reach of children or untrained
individuals.
Replace blade cover when unit is not in use.
Never douse or squirt the unit with water or any other
liquid. Keep handles dry, clean and free from debris.
Clean after each use, see Storage instructions.
Be sure to secure the unit while transporting.

13
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Keep these instructions. Refer to them often and use
them to instruct other users. If you loan someone this
unit, also loan them these instructions.
SERVICE
Service on unit must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified personnel could result in a risk of injury
to the user, or damage to the unit. It may also void
your warranty.
When servicing a unit, use only identical replacement
SDUWV)ROORZLQVWUXFWLRQLQWKH0DLQWHQDQFHVHFWLRQ
of this manual. Use of unauthorised parts or failure
to follow Maintenance Instructions may create a risk
of shock or serious injury to the user, or damage to
the unit. It may also void your warranty.
WARNING
If any parts are missing, do not operate unit until the
PLVVLQJSDUWVDUHUHSODFHG)DLOXUHWRGRVRFRXOG
result in possible serious personal injury.
SAVE THESE INSTRUCTIONS. REFER TO THEM
FREQUENTLY AND USE THEM TO INSTRUCT OTHERS
WHO MAY USE THIS UNIT. IF YOU LOAN SOMEONE
THIS UNIT, LOAN THEM THESE INSTRUCTIONS
ALSO.

14
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation
of these symbols will allow you to operate the tool better and safer.
SYMBOL DESIGNATION/EXPLANATION
Precautions that involve your safety.
Read the operation manual and follow all warnings and safety instructions.
Wear eye and hearing protection.
Thrown objects can ricochet and result in personal injury or property damage. Wear protective
clothing and boots.
Wear non-slip, heavy duty gloves.
50 ' 15 m
Keep all bystanders at least 15m away.
Do not expose to rain or in damp conditions.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SYMBOLS

15
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
15
SPECIFICATIONS
FEATURES
1. Blade cover
2. Blade
3. Hedgesweep™ debris sweeper
4. Guard
5. Sensor switch
)URQWKDQGOH
7. Battery pack
8. Trigger lock button
9. Trigger
10. Charger
11. Latch
12. Cutting blade
13. Blade guard
OPERATION
For complete charging instructions, refer to
the Operator’s Manuals for your Ryobi battery
pack and charger models.
NOTE: To avoid serious personal injury, always
remove the battery pack and keep hands clear of
the lock-out button when carrying or transporting
the tool.
INSTALL BATTERY PACK
Place the battery pack in the hedge trimmer.
Align raised rib on battery pack with groove in hedge
trimmer. See Figure 2.
Make sure the latch on the battery pack snaps in
place and that battery pack is secured in hedge
trimmer before beginning operation.
REMOVE BATTERY PACK
Locate the latch on the battery pack and depress to
release the battery pack from the hedge trimmer. See
Figure 2.
Remove battery pack from the hedge trimmer.
CAUTION
When placing battery pack in your hedge trimmer,
be sure raised rib on battery pack aligns with groove
in hedge trimmer and latch snaps in place properly.
Improper assembly of battery pack can cause damage
to internal components.
STARTING THE HEDGE TRIMMER
Remove the blade cover.
)RUDGGHGVDIHW\WKHUHLVDPLFURVZLWFKLQWKHIURQW
KDQGOH6HH)LJ:KHQRSHUDWLQJKROGWKHWULPPHU
with both hands, one hand to pull the trigger lock
button backward and squeeze the trigger, and the
other hand to squeeze the front handle.
Release the trigger lock button and continue to
squeeze the trigger for extended operation.
BLOCK RELEASE GEAR BOX
This hedge trimmer is equipped with a block
release gear box. If the blade jams, the blades will
automatically retract allowing the jam to be cleared
easily. Release the triggers, remove jammed material,
then squeeze trigger again to restart the hedge
trimmer. If the stem is too dense or too hard to be
trimmed, use a pruning saw to clear the stem.
STOPPING THE HEDGE TRIMMER
Release the trigger to stop the hedge trimmer.
Upon release of the trigger, the trigger lock button will
be automatically reset to the lock position.
Remove battery pack from the hedge trimmer.
OPERATING TIPS
Do not force the hedge trimmer through heavy
shrubbery. This can cause the blades to bind and
slow down. If the blades slow down, reduce the pace.
Product Specifications
Model RHT36
Voltage 36 volts
No load speed 1500 /min
Blade speed 3000 spm
Blade length 550 mm
Cutting capacity 20 mm
Measured sound
pressure level
Measured sound
power level
Vibration
Weight with
Battery pack
Battery pack BPL3626
Charger BCL3620
4.43 kg
LPA=81 dB(A), KPA=2.0 dB(A)
ah= 1.86 m/s2, K=1.5 m/s2
LWA=90 dB(A), KWA=2.0 dB(A)

16
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
16
Do not try to cut stems or twigs that are larger than
20 mm thick, or those obviously too large to feed into
the cutting blade. Use a non-powered hand saw or
pruning saw to trim large stems.

If desired, you can use a string to help cut your hedge
level. Decide how high you want the hedge. Then,
stretch a piece of string along the hedge at this height.
Trim the hedge just above this guide line of string.
6HH)LJXUH7ULPWKHVLGHRIDKHGJHVRWKDWLWZLOOEH
VOLJKWO\QDUURZHUDWWKHWRS6HH)LJXUH0RUHRIWKH
hedge will be exposed when shaped this way, and it will
be more uniform. If blades do become jammed, stop the
motor, allow the blades to stop and remove the battery
pack before attempting to remove the obstruction.
 Wear gloves when trimming thorny or prickly growth.
When trimming new growth, use a wide sweeping
action, so that the stems are fed directly into the
cutting blade. Older growth will have thicker stems and
will be trimmed easiest by using a sawing movement.
DANGER
If blade jams on any electrical cord or line,
DO NOT TOUCH THE BLADE! IT CAN BECOME
ELECTRICALLY LIVE AND VERY DANGEROUS.
Continue to hold the hedge trimmer by the insulated
rear handle or lay it down and away from you in a
safe manner. Disconnect the electrical service to the
damaged line or cord before attempting to free the
EODGHIURPWKHOLQHRUFRUG)DLOXUHWRKHHGWKLVZDUQLQJ
will result in serious personal injury or possible death.
WARNING
Clear the area to be cut before each use.
Re-move all objects such as cords, lights, wire, or
string which can become entangled in the cutting blade
and create a risk of serious personal injury.
WARNING
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various Types
of commercial solvents and may be damaged by their
use. Use a clean cloth to remove dirt, oil, grease, etc.
When servicing use only identical Ryobi replacement
parts. Use of any other parts can create a hazard or
cause product damage.
CAUTION
Do not at any time let brake fluids, gasoline,
petroleum based products, penetrating oils,
etc., come in contact with plastic parts. They
contain chemicals that may damage, weaken, or
destroy plastics.
USING THE HEDGESWEEP™ DEBRIS SWEEPER
WARNING
Make sure that you disconnect the hedge trimmer from
the power supply before attaching or removing the
HedgeSweep™ debris sweeper.
To avoid clippings and other debris falling back into the
hedge while cutting you can use the HedgeSweep™
debris sweeper to sweep the cuttings off the hedge. You
can attach the HedgeSweep™ debris sweeper by sliding
LWRQWRWKHUDLODVVKRZQLQ)LJXUH7KHVORSHGHQGRILW
should be facing the motor housing of the hedge trimmer.
To remove HedgeSweep™ just pull it towards the open
end of the blade.
MAINTENANCE AND REPAIR
BLADE MAINTENANCE – HEDGE TRIMMER
WARNING
Battery units do not have to be plugged into an
electrical outlet; therefore, they are always in operating
condition. To prevent serious personal injury, always
remove the battery and take extra precautions and
care when performing maintenance, service or for
changing the cutting blade.
WARNING
To prevent serious personal injury, remove the battery
pack before servicing, cleaning, or removing material
from the unit.
BLADE CARE
Lubricate the cutting blades after each use.
Periodically inspect the blades for damage and wear.
Always use the manufacturer's specified replacement
blades.
TO LUBRICATE BLADE
See figure 6
Remove battery pack from hedge trimmer.
)RUHDVLHURSHUDWLRQDQGORQJHUEODGHOLIHOXEULFDWHWKH
hedge trimmer blade before and after each use. Before
lubricating, remove the battery pack and lay hedge
trimmer on a flat surface. Apply light weight machine
RLODORQJWKHHGJHRIWKHWRSEODGH6HH)LJXUH
Occasionally, you should oil your hedge trimmer during
prolonged use. Before oiling, stop hedge trimmer,
remove battery pack, then oil. You then can resume
trimming. Do not oil while hedge trimmer is running.

17
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
SHARPENING BLADE
See figure 7
Allow the blades of the hedge trimmer to come to a
VWRSLQWKHSRVLWLRQVKRZQLQ)LJXUH7KLVZLOODOORZ
clearance for the file between cutter teeth and guard
teeth.
Remove battery pack from hedge trimmer.
Clamp blade assembly in a vice and file the exposed
cutting surface of each blade tooth with an 203 mm
(8 inch) smooth round file, 6.4 mm (1/4 inch) or 5.6
mm (7/32 inch) diameter. Be sure to retain the original
angle of tooth when filing.
Remove the hedge trimmer from the vice, replace
battery pack and restart the hedge trimmer. Allow the
blades of the hedge trimmer to come to a stop so that
the unsharpened edges of the cutter blade teeth are
exposed.
Remove battery pack from hedge trimmer and repeat
the sharpening procedure as described above.
HEDGE TRIMMER LUBRICATION
All of the bearings in this tool are lubricated with a
VXI¿FLHQWDPRXQWRIKLJKJUDGHOXEULFDQWIRUWKHOLIHRIWKH
unit under normal operating procedures. Therefore, no
further lubrication is required.
WARNING
Do not attempt to modify this unit or create or mount
any accessory not specifically recommended in this
manual for use with this hedge trimmer. Any such
alteration or modification is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING
Examine hedge trimmer frequently to assure all parts
are unbroken and securely attached. Make sure all
screws and fasteners are securely tightened to prevent
the risk of serious personal injury.
CLEANING THE HEDGE TRIMMER
WARNING
To prevent serious personal injury, remove the battery
pack before servicing, cleaning, or removing material
from the unit.
Remove the battery pack.
Clean the unit using a damp cloth with a mild detergent.
Do not use any strong detergents on the plastic
housing or the handle. They can be damaged by
certain aromatic oils such as pine and lemon, and by
solvents such as kerosene.
Moisture can cause a shock hazard. Wipe off any
moisture with a soft dry cloth.
Use a small brush or the air discharge of a small
vacuum cleaner brush to clean the air vents on the
battery pack housing and motor housing.
Keep the air vents free of obstructions.
STORING THE HEDGE TRIMMER
See figure 8
Clean the hedge trimmer thoroughly before storing.
Store the hedge trimmer in a dry, well-ventilated
place that is inaccessible to children. Keep away from
corrosive agents such as garden chemicals and de-
icing salts.
Always place blade cover on cutting blades before
VWRULQJ6HH)LJXUH
Store and charge your batteries in a cool area.
Temperatures above or below normal room
temperature will shorten battery pack life.
Store the battery pack where the temperature is below
27°C, and away from moisture.
Never store batteries in a discharged condition. Wait
for battery pack to cool and fully charge immediately.
All batteries gradually lose their charge. The higher the
temperature, the quicker they lose their charge. If you
store your unit for long periods of time without using
it, recharge the batteries every month or two. This
practice will prolong battery pack life.
DISPOSAL
Waste electrical products should not be
disposed of together with household waste.
Please recycle where facilities exist. Check
with your local authority or retailer for recycling
advice.
