Ryobi RHT3620G User manual

RBC36X26E
RBC36X26E
ORIGINAL INSTRUCTIONS
Cordless Hedge
Trimmer
RHT3620G
RHT3600G

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your cordless hedge trimmer.
INTENDED USE
The cordless hedge trimmer is only intended for use
outdoors. For safety reasons the product must be
adequately controlled by using two-handed operation.
The product is designed for home or domestic use. It is
intended to cut and trim hedges, shrubs, and similar
vegetation.
It should be used in dry, well-illuminated conditions.
It is not intended to cut grass, trees, or branches. It should
not be used for any other purpose than hedge trimming.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, fire, and/or serious injury.
Save all warnings and instruction for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injury.
■Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power in
unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
■Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s

2
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
■Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
■Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
■Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
■Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or
risk of injury.
■Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130°C may cause explosion.
■Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk
of fire.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
■Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
HEDGE TRIMMER SAFETY WARNINGS
■Keep all parts of the body away from the cutter
blade. Do not remove the cut material or hold the
material to be cut when blades are moving. Make
sure the switch is off when clearing jammed
materials. A moment of inattention while operating the
hedge trimmer may result in serious personal injury.
■Carry the hedge trimmer by the handle with cutter
blade stopped. When transporting or storing the
hedge trimmer always fit the cutting device cover.
Proper handling of the hedge trimmer reduces possible
personal injury from the cutter blades.
■Hold the power tool by insulated gripping surfaces
only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
ADDITIONAL SAFETY WARNINGS
■Some regions have regulations that restrict the use of
the product. Check with your local authority for advice.
Read all instructions.
■Clear the work area before each use. Remove all
objects, such as cords, lights, wires, or strings which
can be thrown or become entangled in the cutting
means.
■Check the hedge for foreign objects, such as wire
fences.
■Exercise additional caution when using the product
near posts, buildings, or other immovable objects.
■Beware of thrown objects. Keep all bystanders,
children, and pets at least 15 m away from work area.
Stop the product if anyone enters the area.
■Do not allow children or untrained individuals to use the
product.
■Do not operate the product in poor lighting. The
operator requires a clear view of the work area to
identify potential hazards.
■Ensure that all handles and guards are fitted when using
the hedge trimmer. Never attempt to use an incomplete
hedge trimmer or one fitted with anunauthorised
modification.
■Ensure before each use that all controls and safety
devices function correctly. Do not use the product if the
“off” switch does not stop the motor.
■Inspect the product before each use. Check for loose
fasteners, etc. Make sure all guards and handles are
properly and securely attached. Replace any damaged
parts before use. Check for battery pack leaks.
■Do not modify the product in any way.
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of
falling objects, wear appropriate head protection.
■Wear heavy, long trousers, boots, and gloves. Do not
wear loose fitting clothing, short trousers, jewellery of
any kind, or use with bare feet.
■Secure long hair so it is above shoulder level to prevent
entanglement in moving parts.
■Use of hearing protection reduces the ability to hear
warnings (shouts or alarms). The operator must pay
extra attention to what is going on in the working area.
■Operating similar tools nearby increases both the risk
of hearing injury and the potential for other persons to
enter your working area.
■Do not use the product while tired, ill, or under the

3
influence of alcohol, drugs, or medication.
■Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance and can
result in serious injury.
■Keep all parts of your body away from any moving part.
■Before starting the product, make sure the cutting
blades will not come in contact with anything.
■While operating the hedge trimmer, always hold it firmly
with both hands by the two handles. Ensure that the
operating position is safe and secure. The manufacturer
does not recommend the use of steps or ladders. If
higher trimming is required, use an extended-reach
tool.
■Blades are sharp. When handling the blade assembly,
wear non-slip, heavy-duty protective gloves. Do not
place your hand or fingers between blades or in any
position where they could get pinched or cut. Never
touch the blade nor service the product unless the
battery pack is removed.
■Turn off the product and remove the battery pack. Make
sure that all moving parts have come to a complete
stop:
●before adjusting the working position of the cutting
means
●before servicing
●before clearing a blockage
●before checking, cleaning, or working on the
product.
●before changing accessories
●before leaving the product unattended
●after striking a foreign object
●before performing maintenance
●whenever the product starts to vibrate abnormally
■Do not force the product through heavy shrubbery. This
can cause the blades to bind and slow down. If the
blades slow down, reduce the pace.
■Do not attempt to cut stems or twigs that are larger than
25.4 mm thick, or obviously too large to feed into the
cutting blade. Use a non-powered hand saw or pruning
saw to trim large stems.
■Do not operate the product with damaged or excessively
worn-out blades.
WARNING
If the product is dropped, suffers heavy impact, or begins
to vibrate abnormally, immediately stop the product and
inspect for damage or identify the cause of the vibration.
Any damage should be properly repaired or replaced by
an authorised service centre.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
TRANSPORTATION AND STORAGE
■Stop the product, remove the battery pack, and allow
both to cool down before storing or transporting.
■Clean all foreign material from the product. Store it in a
cool, dry, and well-ventilated place that is inaccessible
to children. For extra safety, store the battery pack
separately from the hedge trimmer. Keep away from
corrosive agents such as garden chemicals and de-
icing salts. Do not store the product outdoors.
■Cover the blade with the blade protector before storing
the product, or during transportation.
■For transportation, secure the product against
movement or falling to prevent injury to persons or
damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can cause
possible injury, can contribute to poor performance, and
may void your warranty.
WARNING
Servicing requires extreme care and knowledge
and should be performed only by a qualied service
technician. For service, have the product serviced by an
authorised service centre only. When servicing, use only
original replacement parts.
■Remove the battery pack before adjusting, maintaining,
or cleaning the product.
■You may make adjustments or repairs described in
this manual. For other repairs, contact an authorised

4
service centre.
■After each use, clean the product with a soft, dry cloth.
■After each use, clean the debris from the blades
with a stiff brush, and then carefully apply a rust
preventative lubricant before refitting the blade
protector. The manufacturer recommends you to use
a rust preventative lubricant spray to apply an even
distribution and reduce the risk of personal injury from
contact with the blades. For information about suitable
spray product, check with an authorised service centre.
■If needed, lubricate the blades lightly before use using
the above method.
■Check all nuts, bolts, and screws at frequent intervals
for proper tightness to ensure the product is in safe
working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service
centre.
RESIDUAL RISK
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and the
operator should pay special attention to avoid the following:
■injury caused by contact with the cutting means
–The blades cannot be guarded while cutting.
Contact with the blades can cause serious injury.
Keep the blade away from yourself and others.
Cover it with the blade protector whenever you are
not cutting.
■injury caused by vibration
–Always use the right tool for the job, use designated
handles and restrict working time and exposure.
■hearing damage caused by exposure to noise
–Wear hearing protection and limit exposure
RISK REDUCTION
It has been reported that vibrations from handheld tools
may contribute to a condition called Raynaud’s Syndrome.
Symptoms may include tingling, numbness, and blanching
of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet,
smoking, and work practices are all thought to contribute to
the development of these symptoms. There are measures
that can be taken by the operator to possibly reduce the
effects of vibration:
■Keep your body warm in cold weather. When operating
the product, wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your physician.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
WHAT’S IN THE BOX
RHT3626G / RHT3600G
■Hedge trimmer x1
■Operator’s manual x1
■HEDGESWEEP x1
■Blade cover x1
■Battery (sold separately for RHT3600G) x1
■Charger (sold separately for RHT3600G) x1
SYMBOLS ON THE PRODUCT
Safety alert
Please read the instructions carefully
before starting the product.
Beware of thrown or ying objects.
Keep all bystanders, especially children
and pets, at least 15m away from the
operating area.
Wear ear protection.
Wear eye protection.
Always hold the hedge trimmer with
both hands when operating.
Wear non-slip, heavy duty gloves.
To prevent serious injury, do not touch
cutting blades.
Do not expose to rain or damp condition.
Remove the battery before starting any
work on the product.
96 dB
86 dB
The guaranteed sound pressure level
is 86 dB.
The guaranteed sound power level
shown on this label is 96 dB.
Regulatory Compliance Mark (RCM).
The product meets applicable
regulatory requirements.

5
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
SYMBOLS IN THIS MANUAL
Parts or accessories sold separately
Note
Warning
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.

6
WHAT’S IN THE BOX
WHAT’S IN THE BOX
x 1
x 1
x 1
RHT3620G
x 1
x 1 x 1

7
WHAT’S IN THE BOX
x 1
x 1
x 1
RHT3600G
x 1

8
KNOW YOUR PRODUCT
1 2 3 4 5 6 7 8
10 91112
1. Blade
2. HEDGESWEEP debris sweeper
3. Guard
4. Operator presence switch
5. Front handle
6. Lock trigger for rotating handle
7. Trigger
8. Rear handle
9. Charger
10. Battery latch button
11. Battery pack
12. Blade protector

9
GETTING STARTED
1
2
1
2
1
3
2
4
Always wear safety goggles or safety glasses with side
shields when operating the product. Failure to do so could
result in objects being thrown into your eyes resulting
in possible serious injury. When handling the blade
assembly, wear non-slip, heavy-duty protective gloves.
Wear nonskid, protective footwear that will protect your
feet and improve your footing on slippery surfaces.
Slide the HEDGESWEEP over the blade. Remove the
blade protector from the blade.
Hold the hedge trimmer with both hands. Press the front
trigger with one hand, and squeeze the rear trigger with
the other hand.
NOTE: Both triggers need to be pressed for the duration
of the operation.
Install the battery pack in the product. Make sure that the
latches on each side of the battery pack snap in place and
that the battery pack is securely attached before using the
product.

10
OVERVIEW
p.11
p.14 p.15
p.13
Operating the hedge trimmer Rotating the rear handle
Cleaning the hedge trimmer Storing the hedge trimmer

11
OPERATION
1
2
1
2
OPERATING THE HEDGE TRIMMER
CAUTION: Always use two hands to
operate the hedge trimmer, which is tted
with two handles.
WARNING: Keep hands away from the
blades at all times.
1. Slide the HEDGESWEEP over the
blade. Remove the blade protector from
the blade.
2. Install the battery pack in the product.
Make sure that the latches on each
side of the battery pack snap in place
and that the battery pack is securely
attached before using the product.

12
OPERATION
1
2
3
4
3. Press the front trigger with one hand, and
squeeze the rear trigger with the other
hand.
4. Use the hedge trimmer for cutting in a
slow, sweeping action from side to side.

13
OPERATION
2
1
90°90°
45°45°
2
1
1
2
3
ROTATING THE REAR HANDLE
1. Pull the handle rotation trigger. Turn the
handle to the right or to the left until it
clicks.
NOTE: The handle can be rotated 45˚ or 90˚
to the left or to the right.
2. Press the front trigger with one hand,
and squeeze the rear trigger with the
other hand.
3. Trim the side of a hedge from bottom to
top.

14
MAINTENANCE
2
1
1
2
3
4
CLEANING THE HEDGE TRIMMER
1. Remove the battery pack.
2. Slide the HEDGESWEEP off the blade.
3. After each use, clean the body and
handles of the product with a soft, dry
cloth and a brush. Clean the debris from
the blades with a stiff brush.
NOTE: Do not use water and soap to
clean the product.
4. Lubricate the blades lightly before and
after use.
NOTE: Always use warranty-approved
lubricants.
20190329v1

15
STORAGE
2
1
20190329v1
1
2
3
4
STORING THE HEDGE TRIMMER
NOTE: Clean all foreign materials from the
product before storing.
1. Remove the battery pack.
2. Cover the blade with the blade protector.
3. Slide the HEDGESWEEP over the
blade.
4. Store the product in a cool, dry, and
well-ventilated place that is inaccessible
to children and away from sources of
ignition.

PRODUCT SPECIFICATIONS
Cordless Hedge Trimmer
Model RHT3620G/RHT3600G
Rated voltage 36V d.c.
No-load speed 1600/min ±10%
Blade length 60 cm
Cutting capacity 25.4 mm
Vibration level (in accordance with EN 60745-1 and EN 60745-2-
15)
Vibration total value <2.5 m/s2
Front handle 2.1 m/s2
Rear handle 1.7 m/s2
Uncertainty of measurement 1.5 m/s2
Noise emission level (in accordance with EN 60745-1 and EN
60745-2-15)
A-weighted sound pressure level 82.5 dB(A)
Uncertainty of measurement 3 dB
A-weighted sound power level 93.5 dB(A)
Uncertainty of measurement 1.6 dB
Weight without Battery pack 2.96 kg
BATTERY AND CHARGER
Model RHT3620G RHT3600G
Battery pack BPL3620D not included
Weight 1.38 kg
Charger
BCL3617S not included
Weight 0.83 kg
Compatible
battery pack
BPL3626, BPL3626D, BPL3626D2, BPL3640,
BPL3640D, BPL3650, BPL3650D, BPL3650D2,
BPL3620D
Compatible
charger
BCL3620, BCL3620S, BCL3650F,
BCL3617S, BCL3617U
VIBRATION LEVEL
WARNING
The declared vibration value has been measured with a
standard test method and may be used to compare one
tool with another.
The declared vibration value may be used in a
preliminary assessment of exposure.
The vibration emission during actual use of power tool
can differ from the declared total value depending on the
ways in which the tool is used.
Identify safety measures to protect yourself based on an
estimation of exposure in the actual conditions of use,
taking account of all parts of the operating cycle such
as the times when the tool is switched off and when it is
running idle in addition to the trigger time.

Imported by:
RYOBI is a trademark of Ryobi Limited,
and is used under license.
HEDGESWEEP is a trademark of Techtronic Outdoor
Products Technology Limited.
961476017-01
Techtronic Industries (Australia) Pty. Ltd.
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries New Zealand Ltd.
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
