Ryobi P2000 User manual

Su recortadoras de hilo ha sido diseñada y fabricada de conformidad
con las estrictas normas para brindar fiabilidad, facilidad de uso
y seguridad para el operador. Con el debido cuidado, le brindará
muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones,
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
ACCEPTS ALL ONE+ BATTERY PACKS
BATTERIES AND CHARGERS SOLD SEPARATELY
COMPATIBLE AVEC TOUS LE BATTERIES ONE+
BATTERIES ET CHARGEUR VENDUS SÉPARÉMENT
ACEPTA TODOS LOS PAQUETES DE BATERÍAS ONE+
LAS BATERÍAS Y EL CARGADOR SE VENDEN POR SEPARADO
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
18 VOLT STRING TRIMMER
18 V TONDEUSE À FOUET
18 V RECORTADORA DE HILO
P2000
Le taille-bordures à ligne a été conçue et fabriquée conformément
à nos strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation. Correctement entretenue, elle vous donnera des années
de fonctionnement robuste et sans problème.
AVERTISSEMENT : Pour réduire les risques de
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Merci de votre achat.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
SAVE THIS MANUAL FOR FUTURE REFERENCE
Your trimmer has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.

2 — English
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
Important Safety Instructions ........................................................................................................................................3-4
Instructions importantes concernant la securite / Instrucciones de seguidad importantes
Symbols.........................................................................................................................................................................5-6
Symboles / Símbolos
Features............................................................................................................................................................................ 7
Caractéristiques / Características
Assembly .......................................................................................................................................................................... 8
Assemblage / Armado
Operation.....................................................................................................................................................................9-12
Utilisation / Funcionamiento
Maintenance..............................................................................................................................................................13-14
Entretien / Mantenimiento
Troubleshooting.............................................................................................................................................................. 15
Dépannage / Corrección de problemas
Warranty ......................................................................................................................................................................... 16
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.

3 — English
WARNING!
When using electric gardening appliances, basic safety
precautions should always be followed to reduce the risk
of fire, electric shock and personal injury.
READ ALL INSTRUCTIONS
For safe operation, read and understand all instructions
before using this product. Follow all safety instructions.
Failure to follow all safety instructions listed below, can
result in serious personal injury.
Do not allow children or untrained individuals to use this
unit.
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
Wear eye protection which is marked to comply with ANSI
Z87.1 when operating this product.
Use Safety Glasses – Always wear safety glasses with
side shields. Everyday glasses have only impact resistant
lenses. They are NOT safety glasses. Following this rule
will reduce the risk of eye injury.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Dress Properly – Use of rubber gloves and substantial
footwear is recommended when working outdoors.
Wear heavy, long pants, boots, and gloves. Do not wear
loose fitting clothing, short pants, or go barefoot. Do not
wear jewelry of any kind.
Secure long hair above shoulder level to prevent entan-
glement in moving parts.
Keep children away - Keep all bystanders, children, and
pets at least 50 ft. away.
Stay alert - Do not operate this unit when you are tired, ill,
or under the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Keep all parts of your body away from any moving
part.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the
dust or fumes.
Avoid body contact with grounded surfaces such as pipes,
radiators, ranges, and refrigerators. There is an increased
risk of electric shock if your body is grounded.
Avoid Dangerous Environments - Don’t expose power
tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
IMPORTANT SAFETY INSTRUCTIONS
Use Right Appliance - Do not force tool. Use the correct
tool for your application. The correct tool will do the job
better and safer at the rate for which it is designed.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and improve
your footing on slippery surfaces.
Do not overreach. Keep firm footing and balance.
Overreaching can result in loss of balance.
Avoid accidental starting. Be sure switch is in the locked
or off position before inserting battery pack. Carrying tools
with your finger on the switch or inserting the battery pack
into a tool with the switch on invites accidents.
Do not use tool if switch trigger does not turn it on or off.
Any tool that cannot be controlled with the switch trigger
is dangerous and must be repaired.
Disconnect battery pack from the appliance before
storing, servicing, changing accessories such as cutting
line. Such preventive safety measures reduce the risk of
starting the tool accidentally.
Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.
Maintain appliance with care - Replace string head if
cracked, chipped, or damaged in any way. Be sure the
string head is properly installed and securely fastened.
Failure to do so can cause serious injury.
Check for damaged parts. Before further use of the tool,
any part that is damaged should be carefully checked
to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting,
and any other conditions that may affect its operation. A
guard or other part that is damaged should be properly
repaired or replaced by an authorized service dealer.
Make sure all guards, straps, deflectors and handles are
properly and securely attached.
Use only the manufacturer’s replacement string in the
cutting head. Do not use any other cutting attachment,
for example, metal wire, rope, or the like. To install any
other brand of cutting head to this string trimmer can
result in serious personal injury.
Never operate unit without the grass deflector in place
and in good condition.

4 — English
IMPORTANT SAFETY INSTRUCTIONS
Maintain a firm grip on both handles while trimming. Keep
string head below waist level. Never cut with the string
head located over 30 in. or more above the ground.
Store idle appliances - When not in use, string trimmer
should be stored indoors in a dry, locked place out of the
reach of children.
Never use blades or flailing devices. Unit is designed for
line trimmer use only. Use of any other accessories or
attachments will increase the risk of injury.
Inspect area to be cut. Remove objects (rocks, broken
glass, nails, wire, string, etc.) which can be thrown or
become entangled in cutting head.
Keep the air vents clean and free of debris to avoid
overheating the motor. Clean after each use.
Stop the unit and disconnect the power source when not
in use. Carry the unit with the motor stopped.
Store out of the reach of children.
Do not hang unit so that the switch trigger is
depressed.
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery
tool or when changing accessories. Following this rule will
reduce the risk of electric shock, fire, or serious personal
injury.
Do not charge battery tool in rain, or damp or wet location.
Following this rule will reduce the risk of electric shock.
Do not use battery-operated appliance in rain.
Remove or disconnect battery before servicing, cleaning
or removing material from the gardening appliance.
Use only the following type and size batteries:
Store idle appliances - When not in use, string trimmer should
be stored indoors in a dry, locked place out of the reach of
children.
Do not dispose of the batteries in a fire. The cell may
explode. Check with local codes for possible special
disposal instructions.
Do not open or mutilate the batteries. Released electrolyte
is corrosive and may cause damage to the eyes or skin.
It may be toxic if swallowed.
Do not place battery tools or their batteries near fire or
heat. This will reduce the risk of explosion and possibly
injury.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped or
received a sharp blow. A damaged battery is subject to
explosion. Properly dispose of a dropped or damaged
battery immediately.
Exercise care in handling batteries in order not to short the
battery with conducting materials such as rings, bracelets,
and keys. The battery or conductor may overheat and
cause burns.
For best results, your battery tool should be charged in
a location where the temperature is more than 50°F but
less than 100°F. To reduce the risk of serious personal
injury, do not store outside or in vehicles.
Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in contact
with your skin, wash immediately with soap and water,
then neutralize with lemon juice or vinegar. If liquid gets
into your eyes, flush them with clean water for at least
10 minutes, then seek immediate medical attention.
Following this rule will reduce the risk of serious personal
injury.
If the power supply cord is damaged, it must be replaced
only by the manufacturer or by an authorized service
center to avoid risk.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this power tool.
If you loan someone this power tool, loan them these
instructions also.
MODEL BATTERY PACK CHARGER (P113)
P2000
(P104 Li-ion)
130429001, 130429002
130155001
(P100 Ni-Cd)
130255004, 130224028
140501001
140501005
BATTERY PACK CHARGER (P110)
(P100 Ni-Cd)
130255004, 130224028
1423701, 140237021,
140237023

5 — English
SYMBOLS
Keep Bystanders Away
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Keep all bystanders at least 50 ft. away.
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
Read The Operator’s Manual
Safety Alert
SYMBOL NAME DESIGNATION/EXPLANATION
Voltage
Current
Frequency (cycles per second)
Power
Time
Type of current
Type or a characteristic of current
Double-insulated construction
Do not expose to rain or use in damp locations.
Precautions that involve your safety.
Wet Conditions Alert
Class II Construction
Direct Current
Alternating Current
min Minutes
WWatt
Hz Hertz
AAmperes
VVolts
Ricochet Thrown objects can ricochet and result in personal injury or
property damage.
Eye Protection
Always wear safety goggles or safety glasses with side shields and,
as necessary, a full face shield when operating this product.
No Blade Do not install or use any type of blade on a product displaying
this symbol.

6 — English
SYMBOLS
SERVICE
Servicing requires extreme care and knowledge and should
be performed only by a qualified service technician. For
service we suggest you return the product to the nearest
AUTHORIZED SERVICE CENTER for repair. When
servicing, use only identical replacement parts.
WARNING:
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use this product. Call Ryobi
customer service for assistance.
WARNING:
SAVE THESE INSTRUCTIONS
The operation of any power tool can result in foreign objects being thrown into your eyes, which can
result in severe eye damage. Before beginning power tool operation, always wear safety goggles or
safety glasses with side shields and, when needed, a full face shield. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
CAUTION: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SYMBOL SIGNAL MEANING

7 — English
FEATURES
PRODUCT SPECIFICATIONS
Motor...................................................................... 18 V DC
Cutting Swath..............................................................12 in.
Line Size .................................................................0.065 in.
KNOW YOUR STRING TRIMMER
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
ADJUSTABLE FRONT HANDLE
The front handle assembly can be adjusted for ease of
operation and to help prevent loss of control.
EDGER GUIDE
The edger guide allows the string trimmer to perform as an
edger.
THREE-POSITION PIVOTING HEAD
The trimmer head can be adjusted with the pivot button.
GRASS DEFLECTOR
The trimmer includes a grass deflector that helps protect
from flying debris.
GripZone™OVERMOLD
GripZone™overmold provides added user comfort.
LOCK-OFF BUTTON
The lock-off button prevents accidental starting.
ROTATING REAR HANDLE
The rotating rear handle can be locked in two different
positions for ease of use when edging and trimming.
TELESCOPING BOOM
The string trimmer can be adjusted to different extension
points for ease of use.
EDGER
GUIDE
GRASS
DEFLECTOR
ADJUSTABLE
FRONT HANDLE
Fig. 1
SWITCH
TRIGGER
TOOLS NEEDED
PHILLIPS SCREWDRIVER
TELESCOPING
BOOM
LOCK-OFF
BUTTON
GripZone™
OVERMOLD
ROTATING REAR
HANDLE
PIVOTING
HEAD
Weight (without battery pack).....................................4.6 lb.
Replacement Spool Part Number ........................AC14RSL
Replacement Spool Cap Part Number.................. AC14HC

8 — English
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have carefully
inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-860-4050 for assistance.
PACKING LIST
String Trimmer
Grass Deflector Assembly with Screw
Front Handle Assembly
Operator’s Manual
WARNING:
If any parts are damaged or missing do not operate
this product until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible serious
personal injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
product when assembling parts.
Fig. 2
GRASS
DEFLECTOR SLIDE
OVER HEAD
AND
TURN
COUNTERCLOCKWISE
Fig. 3
SCREW
SCREW
HOLE
ATTACHING GRASS DEFLECTOR
See Figure 2 - 3.
WARNING:
The string cutting blade on the grass deflector is sharp.
Avoid contact with the blade. Failure to avoid contact can
result in serious personal injury.
 Remove supplied screw with a phillips screwdriver
from the trimmer head.
Fit the grass deflector into the slots on trimmer head.
Turn counterclockwise to lock grass deflector into
place.
Line up the screw hole in the grass deflector with the
center hole in the trimmer head.
Install supplied screw and tighten by turning clockwise
with a phillips screwdriver.

9 — English
OPERATION
WARNING:
Do not allow familiarity with products to make you care-
less. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with side
shields when operating products. Failure to do so could
result in objects being thrown into your eyes, resulting in
possible serious injury.
WARNING:
Do not use any attachments or accessories not recom-
mended by the manufacturer of this product. The use of
attachments or accessories not recommended can result
in serious personal injury.
This product will accept Ryobi One+ 18 V lithium-ion
battery packs and Ryobi One+ 18 V nickel-cadmium battery
packs.
For complete charging instructions, refer to the Operator’s
Manual for the battery packs and chargers listed in the
General Safety Rules.
WARNING:
Battery products are always in operating condition.
Therefore, the ON/OFF switch should always be turned
OFF when not in use.
STARTING/STOPPING THE STRING TRIMMER
See Figure 4.

To start the string trimmer, push the lock-off button to
either the right or left side and pull the switch trigger.

To stop the string trimmer, release the switch trigger.
TO INSTALL BATTERY PACK
See Figure 5.
Insert the battery pack into the product as shown.
Make sure the latches on each side of the battery pack
snap into place and the battery pack is secured before
beginning operation.
TO REMOVE BATTERY PACK
See Figure 5.
Depress the latches on each side of the battery pack.
Remove the battery pack.
Fig. 4
Fig. 5
LATCHES
SWITCH
TRIGGER
LOCK-OFF
BUTTON

10 — English
TELESCOPING BOOM
See Figure 6.
The boom can be extended or shortened for ease of use.
Remove the battery pack.
Loosen the telescoping boom coupler by turning it coun-
terclockwise. Slide the boom to the desired position.
Tighten the coupler by turning clockwise. Make sure the
boom is securely tightened before reinstalling the battery
pack.
ADJUSTABLE FRONT HANDLE
See Figure 7.
The angle of the front handle can be adjusted 180°.
Remove the battery pack.
Set the trimmer on a flat surface and turn the knob coun-
terclockwise to loosen the handle.
For trimming, adjust the handle upward.
For edging, adjust the handle downward.
Turn the knob clockwise until the handle is securely
tightened before reinstalling the battery pack.
THREE-POSITION PIVOTING HEAD
See Figure 8.
The trimmer head can be adjusted to three different
positions.
Remove the battery pack.
Depress the pivot button and move the trimmer head up
or down to one of the three positions indicated by the
notches.
NOTE: Adjust the trimmer head to the first and second
notches for trimming and edging. Adjust to the third notch
for storage only.
Make sure the trimmer head is securely locked into place
before reinstalling the battery pack.
OPERATION
TELESCOPING
BOOM COUPLER
Fig. 6
Fig. 7
PIVOT
BUTTON
KNOB
NOTCH 3: STORAGE
POSITION ONLY
LOOSEN
TIGHTEN
BOOM
Fig. 8
NOTCHES 1 AND 2: TRIMMING
AND EDGING

11 — English
PROPER OPERATING
POSITION
OPERATING THE TRIMMER
See Figure 9.
Follow these tips when using the string trimmer:

Hold the trimmer with your right hand on the rear handle
and your left hand on the front handle.

Keep a firm grip with both hands while in operation.

Trimmer should be held at a comfortable position with the
rear handle about hip height.

Cut tall grass from the top down. This will prevent grass
from wrapping around the shaft housing and string head
which may cause damage from overheating.
If grass becomes wrapped around the string head:

Remove the battery pack from the trimmer.

Remove the grass.
WARNING:
Always hold the string trimmer away from the body
keeping clearance between the body and the string
trimmer. Any contact with the string trimmer cutting head
while operating can result in serious personal injury.
CUTTING TIPS
See Figure 10.
Keep the trimmer tilted toward the area being cut; this is
the best cutting area.
The string trimmer cuts when passing the unit from left
to right. This will avoid throwing debris at the operator.
Avoid cutting in the dangerous area shown in figure 10.
Use the tip of the string to do the cutting; do not force
string head into uncut grass.
Wire and picket fences cause extra string wear, even
breakage. Stone and brick walls, curbs, and wood may
wear string rapidly.
Avoid trees and shrubs. Tree bark, wood moldings, siding,
and fence posts can easily be damaged by the string.
OPERATION
DANGEROUS
CUTTING AREA
BEST CUTTING AREA
DIRECTION
OF
ROTATION
Fig. 10
Fig. 9

12 — English
OPERATION
Fig. 13
Fig. 14
ADVANCING STRING
NOTE: The trimmer is equipped with an auto-feed head.
Bumping the head to try to advance the line will damage
the trimmer and void the warranty.
With the trimmer running, release the switch trigger.
Wait two seconds, and press the switch trigger.
NOTE: The string will extend approximately 1/4 in. with
each stop and start of the switch trigger until the string
reaches the length of the grass deflector cut-off blade.
Resume trimming.
ADVANCING THE STRING MANUALLY
See Figure 11.

Remove the battery pack.

Push the black button located on the string head while
pulling on string to manually advance the string
CUT-OFF BLADE
See Figure 12.
This trimmer is equipped with a cut-off blade on the grass
deflector. For best cutting, advance string until it is trimmed
to length by the cut-off blade. Advance string whenever you
hear the engine running faster than normal, or when trimming
efficiency diminishes. This will maintain best performance
and keep string long enough to advance properly.
ROTATING REAR HANDLE
See Figure 13.
The rotating rear handle is used in combination with the
edger guide.
Remove the battery pack.
Pull up on the edging coupler and turn handle end coun-
terclockwise until the edging coupler locks into place.
Release the edging coupler.
EDGING
See Figures 12 - 14.
Rotate the rear handle when using the edger guide for edging
sidewalks and walkways. To use the edger guide, flip down
from its stored position.
Always hold the string trimmer away from the body keeping
clearance between the body and the string trimmer. Any
contact with the string trimmer cutting head while operating
can result in serious personal injury.
Fig. 12
PULL
EDGING COUPLER
TO ROTATE
ROTATING REAR
HANDLE
EDGER GUIDE
CUT-OFF
BLADE
Fig. 11
BUTTON
STRING

13 — English
MAINTENANCE
BATTERY PACK REMOVAL AND PREPARATION
FOR RECYCLING
To preserve natural resources, please
rec ycl e or di spose of bat ter ies
properly.
This product uses nickel-cadmium and
lithium-ion batteries. Local, state or
federal laws may prohibit disposal of
batteries in ordinary trash.
Consult your local waste authority for
information regarding available recycling
and/or disposal options.
WARNING:
Upon removal, cover the battery pack’s terminals with
heavy-duty adhesive tape. Do not attempt to destroy or
disassemble battery pack or remove any of its compo-
nents. Lithium-ion and nickel-cadmium batteries must
be recycled or disposed of properly. Also, never touch
both terminals with metal objects and/or body parts as
short circuit may result. Keep away from children. Failure
to comply with these warnings could result in fire and/or
serious injury.
Li - Ion
BATTERIES
This product will accept Ryobi One+ 18 V lithium-ion battery
packs and Ryobi One+ 18 V nickel-cadmium battery packs.
Length of service from each charging will depend on the type
of work you are doing.
The batteries for this product have been designed to provide
maximum trouble-free life. However, like all batteries, they
will eventually wear out. Do not disassemble battery pack
and attempt to replace the batteries. Handling of these
batteries, especially when wearing rings and jewelry, could
result in a serious burn.
To obtain the longest possible battery life, we suggest the
following:
For lithium-ion batteries:
Remove the battery pack from the charger once it is fully
charged and ready for use.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below
80°F and away from moisture.
Store battery packs in a 30%-50% charged condition.
Every six months of storage, charge the pack as
normal.
For nickel-cadmium batteries:
Remove the battery pack from the charger once it is fully
charged and ready for use.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below
80°F.
Store battery packs in a “discharged” condition.
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear safety goggles or safety glasses with side
shields during power product operation or when blowing
dust. If operation is dusty, also wear a dust mask.
WARNING:
To avoid serious personal injury, always remove the
battery pack from the product when cleaning or
performing any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
injury.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts should
be replaced at an Authorized Service Center.

14 — English
MAINTENANCE
SPOOL REPLACEMENT
See Figure 15.
Use only round type .065 in. diameter monofilament string.
Use original manufacturer’s replacement string for best
performance.
Remove the battery pack.
Push in tabs on side of spool retainer.
Pull spool retainer up to remove.
Remove the old spool.
To install the new spool, make sure the string is captured
in the slot on the new spool. Make sure the end of the
string is extended approximately 6 in. beyond the slot.
Install the new spool so that the string and slot align with
the eyelet in the string head. Thread the string into the
eyelet.
Pull the string extending from the string head so the string
releases from the slot in the spool.
Reinstall the spool retainer by depressing tabs into slots
and pushing down until spool retainer clicks into place.
STRING REPLACEMENT
See Figures 15 - 16.
Remove the battery pack.
Remove the spool from the string head.
NOTE: Remove any old string remaining on the spool.
Cut a piece of string approximately 9 ft. (2.7 m) long. Use
only .065 in. (1.65 mm) diameter monofilament string.
Insert the string into the anchor hole in the upper part of
the spool. Wind the string around the upper part of the
spool clockwise, as shown by the arrows on the spool.
Place string in the slot on upper spool flange, leaving
about 6 in. (152 mm) extended beyond the slot. Do not
overfill. After winding the string, there should be at least
1/4 in. (6 mm) between the wound string and the outside
edge of the spool.
Replace the plastic retainer, spool, and the spool retainer.
Refer to Spool Replacement earlier in this manual.
STORING THE TRIMMER
Remove the battery pack from the string trimmer before
storing.
Clean all foreign material from the trimmer.
Store it in a place that is inaccessible to children.
Keep away from corrosive agents such as garden
chemicals and de-icing salts.
Fig. 15
SPOOL
RETAINER
EYELET
SPOOL
TABS
SLOTS
Fig. 16
HOLE
WIND CLOCKWISE
SPOOL
Replacement Spool Part Number ........................AC14RSL
Replacement Spool Cap Part Number.................. AC14HC

15 — English
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
String will not advance when using
the auto-feed head:
1. String is welded to itself.
2. Not enough string on spool.
3. String is worn too short.
4. String is tangled on spool.
1. Lubricate with silicone spray.
2. Install more string. Refer to String
Replacement earlier in this manual.
3. Pull string while pressing button.
4. Remove string from spool and rewind.
Refer to String Replacement earlier in this
manual.
Grass wraps around driveshaft
housing and string head
Cutting tall grass at ground
level.
Cut tall grass from the top down to prevent
wrapping.
Motor fails to start when switch
trigger is depressed.
Battery is not secure.
Battery is not charged.
To secure the battery pack, make sure the
latches on each side of the battery pack
snap into place.
Charge the battery pack according to the
instructions included with your model.
CALL
1-800-860-4050
www.ryobitools.com
CALL US FIRST
For any questions about operating or maintaining your product,
call the Ryobi®Help Line!
Your product has been fully tested prior to shipment to ensure
your complete satisfaction.

16 — English
LIMITED WARRANTY STATEMENT
Techtronic Industries North America, Inc., warrants to the
original retail purchaser that this RYOBI®brand outdoor
product is free from defect in material and workmanship
and agrees to repair or replace, at Techtronic Industries
North America, Inc.’s, discretion, any defective product
free of charge within these time periods from the date of
purchase.
Two years if the product is used for personal, family or
household use;
90 days, if used for any other purpose, such as
commercial or rental.
This warranty extends to the original retail purchaser
only and commences on the date of the original retail
purchase.
Any part of this product found in the reasonable judgment
of Techtronic Industries North America, Inc. to be defective
in material or workmanship will be repaired or replaced
without charge for parts and labor by an authorized service
center for RYOBI®brand outdoor products (Authorized
Ryobi Service Center).
The product, including any defective part, must be returned
to an authorized Ryobi service center within the warranty
period. The expense of delivering the product to the service
center for warranty work and the expense of returning it
back to the owner after repair or replacement will be paid
by the owner. Techtronic Industries North America, Inc.’s,
responsibility in respect to claims is limited to making the
required repairs or replacements and no claim of breach of
warranty shall be cause for cancellation or rescission of the
contract of sale of any RYOBI®brand outdoor product. Proof
of purchase will be required by the dealer to substantiate
any warranty claim. All warranty work must be performed
by an authorized service dealer.
This warranty is limited to ninety (90) days from the date
of original retail purchase for any RYOBI®brand outdoor
product that is used for rental or commercial purposes, or
any other income-producing purpose.
This warranty does not cover any product that has been
subject to misuse, neglect, negligence, or accident, or that
has been operated in any way contrary to the operating
instructions as specified in this operator’s manual. This
warranty does not apply to any damage to the product that
is the result of improper maintenance or to any product
that has been altered or modified. The warranty does not
extend to repairs made necessary by normal wear or by the
use of parts or accessories which are either incompatible
with the RYOBI®brand outdoor product or adversely affect
its operation, performance, or durability. In addition, this
warranty does not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting
Lines, Inner Reels, Starter Pulleys, Starter Ropes, Drive
Belts, Tines, Felt Washers, Hitch Pins, Mulching Blades,
Blower Fans, Blower and Vacuum Tubes, Vacuum Bag
and Straps, Guide Bars, Saw Chains
Techtronic Industries North America, Inc., reserves the
right to change or improve the design of any RYOBI®brand
outdoor product without assuming any obligation to modify
any product previously manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED IN
THEIR ENTIRETY AFTER THE EXPIRATION OF THE
APPROPRIATE TWO-YEAR, ONE-YEAR, OR NINETY-
DAY WARRANTY PERIOD. TECHTRONIC INDUSTRIES
NORTH AMERICA, INC.’S, OBLIGATION UNDER THIS
WARRANTY IS STRICTLY AND EXCLUSIVELY LIMITED TO
THE REPAIR OR REPLACEMENT OF DEFECTIVE PARTS
AND TECHTRONIC INDUSTRIES NORTH AMERICA,
INC., DOES NOT ASSUME OR AUTHORIZE ANYONE
TO ASSUME FOR THEM ANY OTHER OBLIGATION.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU. TECHTRONIC
INDUSTRIES NORTH AMERICA, INC., ASSUMES NO
RESPONSIBILITY FOR INCIDENTAL, CONSEQUENTIAL,
OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO, EXPENSE OF RETURNING THE PRODUCT TO AN
AUTHORIZED RYOBI SERVICE CENTER AND EXPENSE
OF DELIVERING IT BACK TO THE OWNER, MECHANIC’S
TRAVEL TIME, TELEPHONE OR TELEGRAM CHARGES,
RENTAL OF A LIKE PRODUCT DURING THE TIME
WARRANTY SERVICE IS BEING PERFORMED, TRAVEL,
LOSS OR DAMAGE TO PERSONAL PROPERTY, LOSS
OF REVENUE, LOSS OF USE OF THE PRODUCT,
LOSS OF TIME, OR INCONVENIENCE. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all RYOBI®brand outdoor products
manufactured byorfor TechtronicIndustriesNorth America,
Inc., and sold in the United States and Canada.
To locate your nearest Authorized Ryobi Service Center,
dial 1-800-860-4050.
WARRANTY

17 — English
NOTES/NOTES/NOTAS

18 — English
NOTES/NOTES/NOTAS

19 — English
NOTES/NOTES/NOTAS

20 — English
987000-180
07-01-08 (REV:05)
WARNING:
Theengineexhaustfrom this product
contains chemicals known to the
State of California to cause cancer,
birth defects, or other reproductive
harm.
CALIFORNIA PROPOSITION 65
TECHTRONIC INDUSTRIES NORTH AMERICA, INC.
1428 Pearman Dairy Road, Anderson, SC 29625 USA
1-800-860-4050 • www.ryobitools.com
Ryobi®is a registered trademark of Ryobi
Limited used under license.
Ryobi®est une marque déposée de Ryobi
Limited utilisée sous licence.
Ryobi®es una marca comercial registrada
de Ryobi Limited y es empleada mediante
autorización.
• PARTS AND SERVICE
Prior to requesting service or purchasing replacement parts, please obtain your model
and serial number from the product data plate.
• MODEL NO. ______________________SERIAL NO. __________________________
• HOW TO OBTAIN REPLACEMENT PARTS:
Replacement parts can be purchased online at www.ryobitools.com or by calling
1-800-860-4050. Replacement parts can also be obtained at one of our Authorized
Service Centers.
• HOW TO LOCATE AN AUTHORIZED SERVICE CENTER:
Authorized Service Centers can be located online at www.ryobitools.com or by call-
ing 1-800-860-4050.
• HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT:
To obtain Customer or Technical Support please contact us at 1-800-860-4050.
• PIÈCES ET SERVICE
Avant de faire la demande de service ou l’achat de pièces de remplacement, veuillez
obtenir le numéro de série du modèle à partir de la plaque de données du produit.
• NUMÉRO DE MODÈLE ____________NUMÉRO DE SÉRIE___________________
• COMMENT OBTENIR LES PIÈCES DE REMPLACEMENT :
Les pièces de remplacement peuvent être achetées en ligne sur le site
www.ryobitools.com ou par téléphone au 1-800-860-4050. Les pièces de remplacement
peuvent être obtenues à un de nos centres de service autorisés.
• COMMENT TROUVER UN CENTRE DE SERVICE AUTORISÉ :
Les centres de service autorisés peuvent être localisés en ligne au www.ryobitools.
com ou en téléphonant au 1-800-860-4050.
• COMMENT OBTENIR DE L’AIDE EN CONTACTANT LE SERVICE À LA
CLIENTÈLE :
Pour contacter le service à la clientèle pour une question technique ou pour tout autre
renseignement, veuillez nous téléphoner au 1-800-860-4050.
• PIEZAS DE REPUESTO Y SERVICIO
Antes de solicitar servicio técnico o comprar piezas de repuesto, obtenga su modelo
y número de serie de la placa de datos del producto.
• NÚMERO DE MODELO ____________NÚMERO DE SERIE___________________
• CÓMO OBTENER PIEZAS DE REPUESTO:
Las piezas de repuesto se pueden comprar en nuestro sitio en la red mundial, en la
dirección www.ryobitools.com o llamando al 1-800-860-4050. Las piezas de repuesto
también se pueden obtener en uno de nuestros Centros de Servicio Autorizados.
• CÓMO LOCALIZAR UN CENTRO DE SERVICIO AUTORIZADO:
Puede encontrar los Centros de Servicio Autorizados visitando nuestro sitio en la red
mundial, en la dirección www.ryobitools.com or by calling 1-800-860-4050.
• CÓMO OBTENER SERVICIO O ASISTENCIA TÉCNICA AL CONSUMIDOR:
Para obtener Servicio o Asistencia Técnica al Consumidor, sírvase comunicarse con
nosotros llamando al 1-800-860-4050.
OPERATOR’S MANUAL
MANUEL D’UTILISATION / MANUAL DEL OPERADOR
18 VOLT STRING TRIMMER
18 V TONDEUSE À FOUET
18 V RECORTADORA DE HILO
P2000
AVERTISSEMENT :
Les gaz d’échappement de ce produit
contiennent des produits chimiques
identifiésparl’étatdeCaliforniecomme
causes de cancer, de malformations
congénitales et d’autres troubles de
l’appareil reproducteur.
PROPOSITION 65 DE L’ÉTAT DE
CALIFORNIE
ADVERTENCIA:
Las emanaciones provenientes del
escape del motor de este producto
contienen sustancias químicas
reconocidasporelestadode California
como causantes de cáncer, defectos
congénitos y otras afecciones del
aparato reproductor.
CALIFORNIA-PROPUESTA DELEY
NÚM. 65
