SABINE NAVIGATOR - SERIAL PROTOCOLS User manual

Sabine, Inc. • 13301 NW US Highway 441 • Alachua, Florida 32615-8544 USA
[phone] • [phone] • Fax [phone] • www.Sabine.com
E-mail: [e-mail]
Sabine Navigator Communication Protocol (October 19, 2007)
This document applies to the following Sabine Navigator Models:
NAV240, NAV360, NAV480, NAV4802, NAV8802.
General structure of communication packets:
<0x01><R/W><SRC><COMMAND HEADER><VALUE>…<0x1F><CHKSUM><0x02>
1 1 1 4 1 1 1 1<=sizesinreadable asciibytes
<R/W> - Read = 4 (ascii 0x24), Write = 5 (ascii 0x25)
<SRC> - Device number which sent packet: <0x7f> => PC
The <COMMAND HEADER> is used to identify the types of value following the header. The value of the header indicates
the number of readable ascii bytes in the value that follows.
NAME CODE Comment
Command Header <0x03 to 0x07>; 0x03 = 4 bytes … 0x07 = 8 bytes How many bytes follow for the command
name (usually 4)
Device Header <0x08> 1 byte
I/O Header <0x09> 1 byte
Channel Header <0x0A> 1 byte
Aux Header <0x0B> 1 byte
Column Header <0x0C> 1 byte Always set to 0
Data Header <0x10 to 0x18>; 0x10 = 1 byte … 0x18 = 8 bytes # of bytes that follow
<VALUE> must always follow the <HEADER>.
Command Value Command ID in ASCII character (see table below)
Device Value Device # where this command is sent to
I/O Value 0x20 for Input, 0x21 for Output
Channel Value Channel #, zero-based
Aux Value For extra information such as EQ Num, FBX Num ,etc
Column Value Reserved for later use
Data Value The actual value to change for the command targeted

Page 2 of 6
There is no limit in the number of <HEADER><VALUE> combo as long as the whole block (from 0x01 to 0x02) is less than
256 readable ASCII bytes. When a <HEADER><VALUE> is received, the corresponding new parameters are stored in the
memory. However, it is not processed until a <0x1F> is received.
Format used for data values is readable ASCII (96 values for each character) unless specified otherwise.
Data Value ASCII representation
0 0x20
: :
95 0x7F
In other words, to send a data value of 0, send 0x20. To send a data value of 1, send 0x21, etc.
Checksum calculation:
1. Add up all of the bytes from the first (0x01) to the last byte before the check sum.
2. AND this result with 0xFF
3. Take the modulus this result with a base of 0x60 (hex 60 or decimal 96)
4. Add 0x20 to this value to get the ASCII representation
5. Use the hex value of this result for the check sum
Checksum Example (in Hexadecimal)
The string below mutes output 3. 0x53 is the checksum.
<01><25><7F><03><4D><55><54><30><08><20><09><21><0A><22><0B><20><0C><20><10><21> <1F><53><02>
1. Adding up all the bytes from 0x01 to 0x1F, the raw hex checksum is 0x2F3.
2. AND 0x2F3 with 0xFF: 0x2F3 AND 0xFF = 0xF3
3. Now take the modulus base 0x60: 0xF3 MOD 0x60 = 0x33.
4. Add 0x20 to 0x33 for the ASCII representation: 0x20+0x33=0x53. So the checksum is 0x53.
Another Example:
To set the gain to 0dB on input 1, device 1, the string would be (in HEX):
<1><25><7F><3><4C><56><4C><30><8><20><9><20><A><20><B><20><C><20><11><21><60><1F><69><2>
1is the start byte
25 means a write command follows
7F means the command came from the PC
3means the commmand that follows is 4 bytes long
4C 56 4C 30 is ASCII for "LVL0", the signal level (gain) command code

Page 3 of 6
8 20 means the command is addresed to device 0
9 20 means the command is addressed to the inputs
A 20 means the command is addressed to channel 1
B 20 means the aux value is 0 (unused for signal gain, but still required in the command string)
C 20 means the column value is 0 (unused for signal gain, but still required in the command string)
11 is the data header and means that 2 data bytes follow
21 60 is the value: 160.
1F is the execute byte
69 is the checksum
2is the end byte
For the data value:
160 is the 0db value for gain. The range of values is 0 to 220, corresponding to gain values of -40db to +15 db in 0.25 dB
steps.
The data values are encoded as ASCII values and have a maximum value of 96, so the gain value of 160 requires 2 bytes to
represent it. It is calculated like this:
Take 160 and divide by 96: the remainder is 64, so the MS byte is 1 and the LS byte is 64. Convert the values to ASCII
representations by adding 0x20 and the result is (in hex) 21 60
For the checksum:
1. Adding up all the bytes from 0x01 to 0x1F, the raw hex checksum is 0x349.
2. AND 0x349 with 0xFF: 0x349 AND 0xFF = 0x49
3. Now take the modulus base 0x60: 0xF3 MOD 0x49 = 0x49.
4. Add 0x20 to 0x33 for the ASCII representation: 0x20+0x49=0x69. So the checksum is 0x69.
Another Example (in Hexadecimal):
This string will mute input 2 of Device 1 (zero-based):
<01><25><7F><03><4D><55><54><30><08><20><09><21><0A><22><0B><20><0C><20><08><20>
<09><20><0A><21><0B><20><0C><20><10><21><1F><CS><02>
The mute will be turned on as specified by <10><21>. Notice that the mute of Output 3 of Device 1 is not affected because
there is no <1F> right after it, so the target of the MUT0 is overridden by the second target
Another Example (in Hexadecimal):
This mutes output 3 of Device 1 and also input 2 of Device 1
<01><25><7F><03><4D><55><54><30><10><21><08><20><09><21><0A><22><0B><20><0C><20>
<1F><08><20><09><20><0A><21><0B><20><0C><20><1F><CS><02>

Page 4 of 6
This example actually puts the DATA before the TARGET. When the first <1F> is received, Output 3 of Device 1 will be
muted, when the second <1F> is received, Input 2 of Device 1 will be muted as well.
NORMAL COMMAND ID
Meter MTR0
Comp. Gain Reduct. Meter CME0
Mute MUT0
Signal Level LVL0
Signal Polarity POL0
Signal Delay (100ms@48k) DLY0
Signal Delay (90ms@48k) DLY1
Signal Delay (200ms@48k) DLY2
Signal Delay (80ms@48k) DLY3
EQ Type EQT0
EQ Frequency EQF0
EQ Bandwidth EQB0
EQ Level EQL0
Crossover Type XRT0
Crossover Frequency XRF0
Crossover Slope XRS0
Compressor Threshold CMT0
Compressor Attack CMA0
Compressor Release CMR0
Compressor Ratio CMX0
Bypass Delay BPDY
Bypass EQ BPEQ
Bypass Compressor BPCP
Bypass Crossover BPXR
Mixer MIXA
Channel Name CHN0
SYSTEM COMMAND ID
Down Sync %SD0
Up Sync %SU0
Lock Password %LP0
Lock Key %LK0
Channel In Number %nI0
Channel Out Number %nO0
Company %NC0
Sampling Frequency %nS0
Product Name %NP0
Version %NV0
Device Name %ND0
Device Number %nD0
Program Number %Pn0
Program Name %PN0
Program Recall %PR0
Program Store %PS0
Program Download %PD0
Program Upload %PU0
RESET %RS0
FBX COMMAND ID
FBX Type FTYP
FBX Level FLVL
FBX Frequency FFRQ
FBX Bandwidth FBNW
FBX Global Lock FLCK
FBX Global Bypass FBYP
FBX Global Mdepth FMDP
FBX Global Width FWID
FBX Global Sensitivity FSEN

Page 5 of 6
FBX Global Persistence FPER
FBX Global Threshold FTHS
FBX Setup FSET
FBX Reset Dynamic FRST
Program Download
1. PC sends Download ON command (%PD0 with data = TRUE)
2. PC starts sending each parameter (just like downsync) for program #30
3. PC sends Program Store command (%PS0 with data = 29)
4. PC receives Program Store command (%PS0 with data = 29) as acknowledgement
5. Repeats step 2 to 4 for the rest of the program in descending order
6. PC sends Download OFF command (%PD0 with data = FALSE)
Program Upload
1. PC sends Upload ON command (%PU0 with data = TRUE)
2. PC sends Program Recall command (%PR0 with data = 29)
3. PC receives Program Recall command (%PR0 with data = 29) as acknowledgement
4. PC sends Upsync command (%SU0) to receive data for program #30
** Upsync will always send system parameter such as Channel #, Password, etc. Simply ignore them and take the
main data part **
5. Repeats step 2 to 4 for the rest of the program in descending order
6. PC sends Upload OFF command (%PU0 with data = FALSE), the firmware will automatically reload the data in
memory (program #31) upon completion
Downsync (Reset All)
1. PC sends Downsync ON command (%SD0 with data = TRUE)
2. PC starts sending a parameter to the firmware
3. PC receives Meter (%MTR0), repeat step 2 for another parameter. When all parameters are sent, goto next step.
4. PC sends Downsync OFF command (%SD0 with data = FALSE)
5. PC receives Downsync OFF command as acknowledgement (%SD0 with data = FALSE)
Password, Program Name, Device Name
Each character of the string is sent along with the Aux header/value. The value of the character is based on the character
code map. For example, a password for “ABCD” would be packed like this:
<01><57><7F><03><25><4C><50><30><08><20><0B><20><10><21><1F><0B><21><10><22><0B>
<22><10><23><0B><23><10><24><CS><02>

Page 6 of 6
CHARACTER CODE MAP
_ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789abcdefghijklmnopqrstuvwxyz-<>?,./~!@#$%^&*()=+';:
Security Lock
Similar to Password, the menu that is to be locked is identified by the Aux header/value. The data will specify LOCK (true)
or UNLOCK (false).
0 - INPUT SIG
1 - INPUT EQ
2 - INPUT FBX
3 - INPUT FBX-GLOBAL
4 - INPUT FBX-SETUP
5 - INPUT LIMIT
6 - INPUT NAME
7 - INPUT BYPASS
8 - OUTPUT SIG
9 - OUTPUT EQ
10 - OUTPUT XOVER
11 - OUTPUT LIMIT
12 - OUTPUT SOURCE
13 - OUTPUT NAME
14 - OUTPUT BYPASS
15 - PROGRAM RECALL
16 - SYSTEM
17 - MUTE
