Sachtler 75/2 D HD User manual

www.sachtler.com
EN
Part No. S2034-0001
ENG 75/2 D HD Tripod
ENG 75/2 D HD
Tripod
DE

Copyright © 2014
All rights reserved.
Original Instructions: English
All rights reserved throughout the world. No part of this document may be stored in a retrieval system,
transmitted, copied or reproduced in any way, including, but not limited to, photocopy, photograph,
magnetic or other record without the prior agreement and permission in writing of the Vitec Group plc.
Disclaimer
The information contained in this manual is believed to be correct at the time of printing. Vitec Videocom
Ltd reserves the right to make changes to the information or specifications without obligation to notify any
person of such revision or changes. Changes will be incorporated in new versions of the publication.
We are making every effort to ensure that our manuals are updated on a regular basis to reflect changes
toproductspecificationsandfeatures. Should this manual not containinformation on the core functionality
of your product, please let us know. You may be able to access the latest revision of this manual from our
website.
Vitec Videocom Ltd reserves the right to make changes to product design and functionality without
notification.
Trademarks
All product trademarks and registered trademarks are the property of The Vitec Group Plc.
All other trademarks and registered trademarks are the property of their respective companies.
Published by:
Vitec Videocom Ltd
Supports Technical Publications Department
Western Way, Bury St Edmunds
Suffolk IP33 3TB
United Kingdom
Email: [email protected]

1
EN
Contents
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ENG 75/2 D HD Tripod. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Mid-level Spreader 75 HD (optional S2038-1000) . . . . . . . . . . . 4
Ground Spreader SP 75 (optional 7001) . . . . . . . . . . . . . . . . . . 4
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting up the Tripod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Attaching the mid-level spreader 75 HD. . . . . . . . . . . . . . . . . . . 7
Attaching the rubber feet 75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Attaching the ground spreader SP 75. . . . . . . . . . . . . . . . . . . . . 8
Setting up the mid-level spreader 75 HD . . . . . . . . . . . . . . . . . . 8
Setting up the ground spreader SP 75 . . . . . . . . . . . . . . . . . . . . 9
Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Attaching the bungee cord hook. . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Adjusting the leg clamps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ENG 75/2 D HD Tripod (S2034-0001) . . . . . . . . . . . . . . . . . . . 13
Mid-level Spreader 75 HD (optional S2038-1000) . . . . . . . . . . 13
Ground Spreader SP 75 (optional 7001) . . . . . . . . . . . . . . . . . 13
General Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

2
EN
Safety
Importantinformation on thesafe installationand operation ofthis
product. Read this information before operating the product. For
your personal safety, read these instructions. Do not operate the
product if you do not understand how to use it safely. Save these
instructions for future reference.
Warning Symbols Used in these Instructions
Safety cautions are included in these instructions. These safety
instructions must be followed to avoid possible personal injury and
avoid possible damage to the product.
Health and Safety
Intended Use
The ENG 75/2 D HD tripod is a two-stage aluminium tripod with fast
action clamps for easy setup. The optional mid-level spreader 75 HD
features a fast-action clamp with a profile allowing the tripod to be set
to two predefined footprints. The optional ground spreader SP 75 can
be adjusted to suit other footprints as required by the shooting
environment.
WARNING! Risk of personal injury or injury to others. All
personnel must be fully trained and adhere to correct manual
handling techniques and Healthy & Safety regulations. It is
the responsibility of the local organisation to enforce safe
working practices at all times.
WARNING! Do not exceed the maximum payload.
WARNING! Tripod spike feet can be dangerous, take care
handling.
WARNING! Finger entrapment. Avoid trapping fingers
when collapsing and extending the tripod.
WARNING! Trip hazard. Set the tripod footprint to suit the
shooting environment.
WARNING! Toppling hazard. Do not leave unattended.
Keep out of reach of children.
CAUTION! Do not over tighten the tripod leg locks. When in
use always lock the tripod leg clamps to prevent the tripod
collapsing.
CAUTION! Hold the camera securely when (a) mounting or
dismounting from the fluid head (b) making adjustments to
the tripod height or footprint.
CAUTION! Do not place your foot or heavy weight onto the
spreader.
CAUTION! Always remove the camera before transporting.
Clean regularly using a soft cloth and mild detergent.
Dry the product after use in wet conditions.

3
EN
Components
ENG 75/2 D HD Tripod
.No. Description
1Upper leg clamp lever
2Bungee cord hook
3Safety sleeve
4Rubber feet 75 x 3 (optional)
5Double-spiked foot
6Lower leg clamp lever
7Mid-level spreader 75 HD (optional)
8Ground spreader SP (optional)

4
EN
Components
Mid-level Spreader 75 HD (optional S2038-1000) Ground Spreader SP 75 (optional 7001)
No. Description
1HIGH/LOW profile knob
2Pull up ring
3Spreader lock
4Spreader attachment hook
5Red attach/release button
6Spreader arm
No. Description
1Spreader lock
2Pull up ring
3Spreader foot
4Spreader arm

5
EN
Assembly
Setting up the Tripod 6. Detach the bungee cord hook to release the legs.
7. Holding the tripod upright, open out the legs and set the footprint
of the tripod to suit the shooting environment.
CAUTION! Use the spreader to ensure the tripod legs are
spread sufficiently, so that the Centre of Gravity of the tilted
payload remains within the footprint of the tripod. Use the
tie-down hook on the tripod for additional stability.
Notes
1. The following procedure refers to a two-stage tripod
fitted with a mid-level spreader (if necessary, refer to
Attaching the mid-level spreader 75 HD on page 7).
2. ALWAYS use the spreaders to increase the rigidity of
the tripod.
3. At the fullest extension of the spreader and with all legs
fully retracted, the tripod can be used at its lowest
operating height. Although the tripod can be set up
lower than this without the spreader, it is NOT
recommended as the tripod geometry becomes
unstable.
4. Do not use spikes on hard ground or delicate surfaces.
5. The tie-down hook can be used either to hang a
backpack on for additional stability or as a storage point
for items.

6
EN
Assembly
8. Extend the upper stage by lifting the clamp levers and adjusting
the height of the tripod as required. When complete, push down
the clamp levers, until they snap into the ‘locked’ position.
9. Adjust the operating height by flipping down the leg clamp levers
on the lower stage and pulling the tripod up to the desired height.
When complete, push up the lower stage clamp levers, until they
snap into the ‘locked’ position.

7
EN
Assembly
Attaching the mid-level spreader 75 HD
1. Hold each spreader arm between thumb and forefinger, then using
the other hand squeeze the red attachment button.
2. Align the spreader hook with the tripod leg from underneath and
release the red attach/release button to lock the spreader arm in
place.
Attaching the rubber feet 75
1. Place the rubber foot between the spikes. Check the markings on
the foot for orientation. The ‘INSIDE’ marking must be turned
towards the centre of the tripod.
2. Push down firmly on the leg, put your fingers through the larger
loop, and pull the rubber pull-loop over the latching nose.
CAUTION! Ensure that the red attach/release button is fully
out after attaching the spreader to the tripod. Failure to
attach the spreader correctly could cause damage to the
equipment.

8
EN
Assembly
Attaching the ground spreader SP 75
1. Place the ground spreader on the floor and open out the legs.
Place the spikes of the tripod between the foot moulding on the
ground spreader.
2. Push down firmly on the leg, put your fingers through the larger
loop, and pull the rubber pull-loop over the latching nose.
Setting up the mid-level spreader 75 HD
1. Pull up the ring in the centre of the spreader. Adjust the profile
setting to either HIGH (45°) or LOW (flat) and arrest the tripod legs
in position.

9
EN
Assembly
2. If required, unlock the spreader locks to allow the spreader arms
to extend as necessary. Tighten the spreader locks.
Setting up the ground spreader SP 75
1. Unlock the spreader locks to allow the spreader arms to extend.
Adjust the tripod footprint, as required. Tighten the spreader locks.

10
EN
Transportation
Attaching the bungee cord hook
The bungee cord hook is used to secure the tripod legs together when
in transit and is housed underneath the base of an upper leg. When the
tripod is collapsed, the bungee cord hook can be stretched around the
upper legs and clipped onto the leg assembly.

11
EN
Maintenance
General
The tripod is robustly made to high engineering standards and little
attention is required to maintain serviceability except for regular
cleaning. Repairs and any adjustments beyond those described in this
manual should be carried out by qualified persons only. Contact
Sachtler headquarters, your local Sachtler office or representative.
Routine checks
During use, check the following:
• Check tripod for signs of wear or damage. Replace as necessary.
Cleaning
During normal use the only cleaning required is a periodic wipe-down
with a lint-free cloth. Any dirt that accumulates during storage or
periods of non-use may be removed with a vacuum cleaner. Particular
attention should be paid to the bowl base of the tripod.
However, use out-of-doors under adverse conditions will require
special attention. Salt spray should be washed off with fresh water at
the earliest opportunity. Sand and dirt acts as an abrasive and should
be removed using a semi-stiff brush or vacuum cleaner.
Routine checks
During normal use, check the following regularly:
• Check the effectiveness of the leg clamps (refer to ‘Checking the
effectiveness of the leg clamps’ below) and adjust if necessary
(refer to Adjusting the leg clamps on page 12).
• Check the effectiveness of the locking bolts. The bolts should
move freely and retract fully and the spreader hook should be
easily removable.
• Check the effectiveness of the spreader locks. The spreader arms
must be able to extend and retract smoothly. Check the spreader
lock allows sufficient tightening.
No further routine maintenance is required.
Checking the effectiveness of the leg clamps
To check the effectiveness of each leg clamp, proceed as follows:
• Extend all three tripod legs fully and apply the clamp levers.
• Position each leg in turn vertically on a set of weighing scales.
• Gradually add a load to the leg, until either or both clamps begin to
slip. Note the reading on the scales at which this occurs.
• A reading of less than 66 lbs (30 kg) will necessitate adjustment
(refer to Adjusting the leg clamps below for instructions).
CAUTION! Do NOT use solvent-based or oil-based
cleaners, abrasives or wire brushes to remove
accumulations of dirt as these will damage the protective
surfaces. Use mild, detergent-based cleaners only.

12
EN
Maintenance
Adjusting the leg clamps
Shouldthe legclampsbecomeineffective,theymay requireadjustment
(refer to Checking the effectiveness of the leg clamps on page 11).
To adjust the leg clamp mechanism proceed as follows:
Set the clamp lever to the ‘unlocked’ or horizontal position.
Using a 3 mm Allen key, tighten the four screws incrementally by
approximately 15 degrees.
Test the effectiveness of the clamp and repeat the process, until 66 lbs
(30 kg) is achieved. Check that the clamp lever can be applied easily.
CAUTION! Do NOT over-adjust the clamp lever mechanism
to support more than 66 lbs (30 kg) as this will cause
damage to the tripod.

13
EN
Technical Specification
ENG 75/2 D HD Tripod (S2034-0001) Mid-level Spreader 75 HD (optional S2038-1000)
Ground Spreader SP 75 (optional 7001)
Technical specifications are subject to change without notice.
Bowl
75 mm
Max Payload
35 kg (77 lbs)
Weight
3.1 kg (6.8 lbs)
With Ground Spreader SP 75
44 cm (17.3 in.) to 155 cm (61.0 in.)
With Mid-level Spreader 75 HD
56 cm (22.1 in.) to 155 cm (57.9 in.)
Transport Length
69 cm (27.2 in.)
Operating Temperature
-40°C to 60°C (-40°F to 140°F)
Material
Aluminium
Weight
0.49 kg (1 lb)
Transport Length
24.6 cm (9.6in.)
Build-up Radius - Flat
23.1 cm (23.2 in.) to 38.3 cm (61.4 in.)
Build-up Radius - 45 Degrees
11.8 cm (23.2 in.) to 19.1 cm (61.4 in.)
Weight
0.6 kg (1.3 lbs)
Transport Length
36 cm (14 in.)
Build-up Radius
33 cm (13 in.) to 58 cm (22.8 in.)
Max Payload
40 kg (88 lbs)

14
EN
General Notices
Declaration of Conformity
Vitec Videocom Limited declares that this product has been
manufactured in accordance with BS EN ISO 9001:2008 and is in
compliance with the essential requirements and other relevant
provisions of the Machinery Directive 2006/42/EC. A copy of the
Declaration of Conformity is available upon request.
Warranty
The warranty expires if:
(a) The product was operated improperly or not in line with the
specified technical data.
(b) The product housing was opened by unauthorized
personnel.
Sachtler reserve the right to make changes to product design and
performance as technology advances.
Please register your product for an extended warranty period at
www.sachtler.com
Should the product become defective, contact your local
Sachtler service centre. To find your local service centre visit
www.sachtler.com

15
DE
Inhalt
Sicherheit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Bestimmungsgemäße Verwendung . . . . . . . . . . . . . . . . . . . . . . . 16
Komponenten . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Stativ ENG 75/2 D HD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mittelspinne 75 HD (optional S2038-1000). . . . . . . . . . . . . . . . 18
Bodenspinne SP 75 (optional 7001). . . . . . . . . . . . . . . . . . . . . 18
Montage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Aufstellen des Stativs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Anbringen der Mittelspinne 75 HD . . . . . . . . . . . . . . . . . . . . . . 21
Anbringen der Gummifüße 75 . . . . . . . . . . . . . . . . . . . . . . . . . 21
Anbringen der Bodenspinne SP 75 . . . . . . . . . . . . . . . . . . . . . 22
Einrichten der Mittelspinne 75 HD . . . . . . . . . . . . . . . . . . . . . . 22
Einrichten der Bodenspinne SP 75. . . . . . . . . . . . . . . . . . . . . . 23
Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Anbringen des Gummizughakens. . . . . . . . . . . . . . . . . . . . . . . 24
Pflege und Wartung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Allgemeines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Reinigung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Anpassen der Beinklemmen. . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Technische Daten. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Stativ ENG 75/2 D HD (S2034-0001) . . . . . . . . . . . . . . . . . . . . 27
Mittelspinne 75 HD (optional S2038-1000). . . . . . . . . . . . . . . . 27
Bodenspinne SP 75 (optional 7001). . . . . . . . . . . . . . . . . . . . . 27
Allgemeine Hinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Konformitätserklärung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Gewährleistung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

16
DE
Sicherheit
Wichtige Informationen zur sicheren Montage und Verwendung
dieses Produkts. Lesen Sie diese Informationen, bevor Sie das
Produkt verwenden. Lesen Sie diese Anweisungen zu Ihrer
persönlichen Sicherheit. Das Produkt nicht verwenden, wenn Sie
nicht wissen, wie man es sicher verwendet. Diese Anweisungen
zum späteren Nachschlagen aufbewahren.
In diesen Anweisungen verwendete Warnsymbole
Diese Anweisungen enthalten Sicherheitswarnungen. Diese
Sicherheitswarnungen müssen befolgt werden, um mögliche
persönliche Verletzungen und mögliche Schäden am Produkt zu
vermeiden.
Gesundheit und Sicherheit
Bestimmungsgemäße Verwendung
Das Stativ ENG 75/2 D HD ist ein zweistufiges Aluminiumstativ mit
Schnellverschlussklemmen zur einfachen Aufstellung. Die optionale
Mittelspinne 75 HD verfügt über Schnellverschlussklemmen mit Profil,
wodurch das Stativ auf zwei vordefinierte Einsatzradien eingestellt
werden kann. Die optionale Bodenspinne SP 75 kann auf andere
Einsatzradien eingestellt werden, je nach Drehumgebung.
ACHTUNG! Gefahr von persönlicher Verletzung oder
Verletzung Dritter. Sämtliches Personal muss vollständig
geschult sein und die korrekten manuellen
Bedienungstechniken sowie die Gesundheits- und
Sicherheitsvorschriften befolgen. Das jeweilige
Unternehmen vor Ort ist für die Durchsetzung sicherer
Arbeitsverfahren zu allen Zeiten verantwortlich.
ACHTUNG! Maximale Traglast nicht überschreiten.
ACHTUNG! Die spitzen Stativbeine können gefährlich sein,
vorsichtig damit umgehen.
ACHTUNG! Fingereinklemmungsgefahr. Beim
Zusammenschieben und Ausziehen des Stativs auf Finger
achten.
ACHTUNG! Stolpergefahr. Einsatzradius des Stativs
entsprechend der Drehumgebung einstellen.
ACHTUNG! Sturzgefahr. Nicht unbeaufsichtigt lassen.
Außer Reichweite von Kindern halten.
VORSICHT! Beinverriegelungen des Stativs nicht übermäßig
fest anziehen. Bei Verwendung stets die Beinklemmen des
Stativs sperren, damit das Stativ nicht einklappt.
VORSICHT! Kamera bei (a) Anbringen oder Abnehmen vom
Fluidkopf (b) Ändern der Stativhöhe oder des Stativ-
Einsatzradius stets sicher festhalten.
VORSICHT! Nicht den Fuß oder schwere Gewichte auf die
Spinne stellen.
VORSICHT! Vor dem Transport stets die Kamera entfernen.
Regelmäßig mit weichem Tuch und mildem Reinigungsmittel
auf Laugenbasis säubern.
Das Produkt nach Verwendung unter nassen Bedingungen
trocknen.

17
DE
Komponenten
Stativ ENG 75/2 D HD
.Nr. Beschreibung
1Oberer Klemmhebel
2Gummizughaken
3Sicherheitshülle
4Gummifüße 75 x 3 (optional)
5Doppel-Spike-Fuß
6Unterer Klemmhebel
7Mittelspinne 75 HD (optional)
8Bodenspinne SP (optional)

18
DE
Komponenten
Mittelspinne 75 HD (optional S2038-1000) Bodenspinne SP 75 (optional 7001)
Nr. Beschreibung
1Drehknopf Profil HOCH/NIEDRIG
2Zugring
3Spinnensicherung
4Spinnenmontagehaken
5Roter Knopf zum Anbringen/Abnehmen
6Spinnenarm
Nr. Beschreibung
1Spinnensicherung
2Zugring
3Spinnenfuß
4Spinnenarm
