Safavieh SFV2113 User manual

2 X
8 X
HW1
A
* Do not tighten bolts until completely assembled.
Model# SFV2113
CARE AND MAINTENCE
Wipe clean with a soft, dry cloth. The seat board can be cleaned with a mild
cleaner. Test the cleaning method on a hidden area before using them over the
entire area.
NOTICE
* This item may require periodic tightening.
* This item should be assembled on a soft surface to prevent scratching the finished
product during assembly.
* Please make sure that you have all parts indicated before you begin assembly of
this item.
Part List and Hardware List
Product Dimensions:58"W*18"D*27"H
HW2 Hex Socket Bolt 5/16"-18 x 2-1/4''
M4
WARNING
PIECE DESCRIPTION PICTURE QUANTITY
DRAWER
LEG
B
1 X
4 X
HW3
Allen Key Weight Capacity : 25 lbs on top of the product
25 lbs on shelf
Warning : Do not stand on the product
Warning : Do not over torque bolts.
1
2
3
45
Anti-Tip Hardware
HW4
HW5
1 X
4 X
2 X
160mm
5/32"*20mm
Handle
Phillips Bolt
C O U T U R E

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time:20 minutes.
Tools Required for Assembly : Allen key (included) & Phillips head screwdriver (not included)
HW2
HW4
B
4
Wall
1
2
3
4
5
12
3
4
5
HW5
HW5
A
Step 3
Straighten up the assembled
product.Following the installation
instructions of anti-tipping (HW5) to
fix the product in the wall by 2
straps. Assembly is completed.
Step 2
Attach 4*Legs (B) in the
corresponding position on the
underneath of Drawer (A) by
using Allen key (HW4) to lock
with 8*Hex Socket Bolt (HW2),
As picture.
Step 1
Open the sliding door, installed the
2*Handles (HW1) on the inside of
2*Sliding Doors respectively by
using a Phillips head screwdriver
(not included) to lock with 4*Phillips
Bolt (HW3).
P.S. How to remove and install the
drawer knob, please see another
assembly instruction.
Philips head screwdriver not included
A
HW1
HW3
HW3
321
Notice :
SET OF HANDLES, 4*LEGS and
HARDWARE BAG AT THE
BOTTOM OF THIS PRODUCT.
