Preface
For optimum performance, Saferoads Ironman Hybrid Barrier must be designed, installed and maintained as per this
manual. Please thoroughly review and understand this manual before using the Ironman Hybrid Barrier.
Local requirements may also impose restrictions. Please refer to local governing body for further information.
If more information is required, please contact Saferoads:
Websites: www.saferoads.com.au
Australia: 1800 060 672
International: [phone]
Email: [email protected]
Introduction
Saferoads Ironman Hybrid Barrier provides several unique advantages over traditional portable concrete barriers,
Pinned Steel Barriers or other styles of portable safety barriers:
 Crash tested to –
o MASH TL-2, 70km/h – 2,270kg Pickup @ 25 degrees
o NCHRP 350 TL-3, 100km/h – 2,000kg Pickup @ 25 degrees
 Safe, consistent and reliable redirection
 Maintenance free
 Durable
 Energy-absorbing with low deflection.
 Quick and easy deployment and retrieval.
 No anchoring required along LON
 Economical to transport.
 Easily repaired after design impacts.
 May be re-used without repair after TL-2 70km/h or less impacts, pending inspection of impacted units.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 3
Applications
Saferoads Ironman Hybrid Barrier functions as an unanchored longitudinal barrier to prevent errant vehicles from
penetrating, vaulting, or under-riding. Traffic is kept from entering the work area or from hitting exposed objects or
excavations. The Ironman Hybrid Barrier provides positive protection for roadside workers.
Impacting vehicles are redirected at a shallow angle in the vicinity of the impact area, thereby reducing the potential
for dangerous secondary impacts. The Ironman Hybrid Barrier absorbs impact energy and cushions vehicular impacts
while significantly reducing the risk to occupants of the impacting vehicle.
The Ironman Hybrid Barrier can be used in many applications. Some examples are:
 General road maintenance performed by road authorities, contractors, local municipalities etc.
 Road construction
 Lane closures
 Toll plazas
 Road resurfacing
 Excavation or culvert protection
 Detours
 Bridge repairs
 Median or roadside installations
The Ironman Hybrid Barrier can be used on concrete, asphalt and spray sealed surfaces.
Limitations
The Ironman Hybrid Barrier has been fully tested and evaluated as per the recommendations of the Manual for
Assessing Safety Hardware (MASH 2016).
The Ironman Hybrid Barrier is capable of decelerating and redirecting an errant vehicle up to 2,270 kg at speeds up to
70 km/h and angles of 25 degrees (MASH Test Level 2).
To ensure adequate performance in the event of an impact, the Ironman Hybrid Barrier must be deployed and
maintained in accordance with the manufacturer's instructions and local authority guidelines.
Impacts that exceed the design capabilities described in this manual (vehicle weight, speed and impact angle) may not
result in acceptable crash performance as described in MASH relative to structural adequacy, occupant risk and vehicle
trajectory factors.
Higher than reported deflections can be expected outside the Length of Need (LON) section.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 4
Testing
The Ironman Hybrid Barrier has been successfully crash tested to MASH 2016 Test Level 2 (TL-2) as a redirecting
longitudinal safety barrier for vehicle weight up to 2,270kg at speeds up to 70 km/h.
Whilst no longer approved at 100km/h, the Ironman Hybrid Barrier has been crash tested to the superseded Standard
NCHRP 350, TL-3 - 2,000kg vehicle, 100km/h at 25 degrees. This test shows the extra capacity of the system, this impact
has 80% more energy than the MASH TL-2 test and the deflection was 1.9m, only 28% more than the MASH TL-2
Deflection.
Barrier Segments
An Ironman Hybrid Barrier installation is constructed from a series of individual barrier segments. Each segment is
constructed from steel with four concrete inserts attached to the underside of the barrier. The dimensions of each
segment are:
Installed length 4.15m
Segment Width 546mm
Segment Height 813mm
Weight 925kg
The ends of each section are constructed with knuckles that interlock with those of other segments. The end knuckles
are vertically aligned to accept a steel connecting pin. The pin securely joins the sections for maximum impact
performance. The sections can swivel at the pin for easy positioning around work areas.
Limiting deflection spacers are to be installed to reduce the deflection and movement in the joints, they may only be
omitted where a tighter radius deployment is required.
The Ironman Hybrid Barrier is constructed in a unique shape. The sloping ribbed side walls interact with an impacting
vehicle in a way that resists penetration, vaulting, and under-riding. Each section contains four concrete ballast blocks
that are contained between the bottom rub rails providing weight and stability to reduce the deflection of the
freestanding Barrier.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 5
Barrier segments feature a central integrated lifting point. Barriers can be safely lifted from the centre lifting point.
The Ironman Hybrid Barrier is designed to accept a barrier stacked on top for storage and freighting purposes. The
segments interlock, so timber bearers between the barriers are not required. Saferoads recommends stacking the
Ironman Hybrid Barriers no more than two high.
Caution should be used when freighting so that the lower level is strapped down and secured before loading the
second level.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 6
Minimum Deployment
Ironman Hybrid Safety Barrier installations require a minimum deployment length of 57.5mm, 11no. Hybrid Barriers
plus 2 TL-2 SLED end treatments, to safely contain and redirect at MASH TL-2.
Length of Need
Saferoads Ironman Hybrid Barrier installations utilise SLED TL-2 end treatments to ensure occupant safety in the event
of an impact to the end of a barrier installation.
The Length of Need begins at the joint between the 4
th
and 5
th
Hybrid Barrier, 22.5m downstream from the nose of
the SLED. The End Length of Need is 22.5m Upstream from the downstream end of the System.
Crash testing revealed that a 2,270kg Dodge Ram was successfully redirected when impacting the plastic modules of
the Upstream SLED at 70km/h on a 20° angle. The deflection of the system was 3.5m, whilst the system will redirect
vehicles from the first steel barrier, to rely on the 1.49m deflection the BLON starts at the end of the 4
th
Barrier.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 7
Deployment Diagram

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 8
System Deflection & Working Width
A sufficient clear zone must be allocated between the Ironman Hybrid Safety Barrier and the work zone to allow for
deflection of the barrier during an impact. The Crash tested deflection for a TL-2 impact, 2,270kg Pickup at 70km/h at
25 degrees is 1.49m.
The Working width, which includes the Barrier width plus the Deflection is 2.04m
The table below shows the deflection and working width for impacts along the Length of Need (BLON). These results
are taken from MASH TL-2 compliant impacts using a 2270kg Dodge Ram pickup. Please note that actual deflections,
and therefore working widths, may vary from expected results due to site conditions.
LON
Speed 70km/h
Angle of Impact 25°
Deflection 1.49m
Working Width 2.04m
Site Considerations
While Saferoads Ironman Hybrid Barrier can be installed on most worksites, some obstacles must be avoided. Ironman
Hybrid Barriers should not be installed if there is:
 Curvature tighter than 78m radius
 Cross slope steeper than 5%
 Longitudinal slope steeper than 5%
 Crest sharper than 5%
 Ditch sharper than 5%
 Kerbs or similar obstacles restricting the deflection
For more information, please contact Saferoads or the relevant road authority.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 9
Barrier Deployment
Before beginning deployment, ensure there is adequate traffic management, and whenever possible personnel should
remain on the non-traffic side of the installation. Also ensure appropriate lifting equipment is used and operated by
competent personnel.
1. Beginning at the upstream end of the installation, unload the first barrier segment and place in the correct
position.
The Ironman Hybrid Barrier Deflection Limiting Spacer is designed to minimise the risk of hand injuries during
deployment. The following procedure is designed to prevent possible injury.
2. Working downstream of the first barrier segment, unload the second barrier segment, place the spacer on the
1
st
Barrier, it will sit on the Knuckles of the bulkhead.
SPACER PIN
3. Manoeuvring the next Barrier into position. Remain cautious of potential pinch and crush points when
lowering and connecting barriers.
4. Bring barrier segments together with care.
5. Insert the Connecting Pin
6. Repeat until all barrier segments are placed into the correct position and joined to adjacent barrier segments.
7. For installing the SLED end terminal refer to the SLED Manual

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 10
8. A SLED Transition Strap is required to attach a Standard SLED Transition Panel to the Ironman Hybrid Barrier.
See below, 3 bolts are to be removed at the quarter Bulkhead, use the Strap to mark and then drill the forth
hole (18mm dia.)
9. Attach the Strap with M16 x 50 Mushroom head Gal bolts
10. See below standard SLED Transition attachment to the Hybrid Barrier, 3 x M16 x 30 Hex Bolts attach the SLED
Trans Panel to the Hybrid Transition Strap.
To ensure compliance of the Ironman Hybrid Barrier, attachments such as anti-gawk screens, signs, flashing lamps
etc. must not be fitted to the barrier without written permission from Saferoads. Any unauthorized attachments
could affect impact performance.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 11
Maintenance and Repair
Each Ironman Hybrid Barrier segment is made up of twelve main components, all of which are fully replaceable as
designed to ensure a long service life.
The Ironman Hybrid Barrier is bolted together using standard guardrail bolts so any individual component can be easily
removed and replaced.
Barriers which show evidence of impact will require close inspection of concrete ballast blocks, all struts, braces and
supports showing particular attention to weld point integrity.
It is not recommended to self-repair any components as this could compromise the integrity of the barrier in regard
to its original design specification. Any damaged sections must be replaced with original modular sections supplied by
the manufacturer. Failure to do so will negate the manufacturer‘s guarantees in regard to the tested performance of
the Ironman Hybrid Barrier.

W www.saferoads.com.au
T 1800 060 672
E [email protected]
Australian Version
2.0
May 2021
Page 12
Safe Work Method Statement
Sign
Off
Residual
Risk
L L L L L L L L
Person
Responsible
Risk Before
Controls
M
H
M M
L L
M M
Controls Required
Ensure machinery and operators are
appropriately certified. Ensure all
equipment is in good, working and
tagged condition.
Ensure there are no hazards above the
area. If unsure arrange a spotter.
Ensure hazards are cleared from area,
and do not use lifting equipment in
adverse weather.
Where possible personnel should be
away from area. If personnel are
required body parts should be clear
when lowering and joining barrier
segments. Appropriate PPE should also
be worn.
Abide by worksite speed limits and
transport routes. Ensure nearby
personnel are wearing high-vis clothing.
Personnel should wear appropriate
clothing and foot wear for
environmental conditions.
Where required personnel should wear
appropriate hearing protection.
Where required personnel should wear
appropriate protective gear such as
helmets, boots and eye protection.
Hazard Identified
Lifting equipment failure
Contact with overhead
services
Contact with people or
property
Crushing under or
between segments
Collision with people or
property
Environmental hazards
Excess noise
Falling items or debris
Activity
Lifting
Ironman
Segments
Placing
Ironman
Segments
Arriving or
departing
worksite
Attending
worksite
