Safety Vision SV-IR-THRM User manual
sv-ir-thrm
UsEr GUiDE
sv-ir-thrm user guide
Important Notices
Title: SV-IR-THRM User Guide
Document Version: 1
Revision: 0
Safety Vision attempts to provide information contained in this manual
based on the latest product information available at the time of
publication. However, because of Safety Vision’s policy of continual product
improvement, Safety Vision reserves the right to amend the information in
this document at any time without prior notice.
This material is confidential and the property of Safety Vision. It is shared with
your company for the sole purpose of helping you with the operation of the
described equipment.
Safety Vision makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Safety Vision shall not be liable for errors
contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this material.
Safety Vision expressly disclaims all responsibility and liability for the
installation, use, performance, maintenance, and support of third-party
products. Customers are advised to make their independent evaluation of
such products.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Safety Vision.
Safety Vision® is a registered trademark of Safety Vision, LLC. All other
products or name brands mentioned in this document are trademarks of
their respective owners. For more information about Safety Vision and its
products, go to www.safetyvision.com or call 800-880-8855.
sv-ir-thrm user guide 2
Overview
Using a high-precision temperature measurement sensor imported from Belgium, the
mini thermo detector measures the human body surface temperature without any
contact. When an abnormal body temperature is detected, an audible voice warning
will occur. This can be used as a stand-alone product or integrate with walk-through
metal detectors, doors, intelligent access control systems, and more.
Features
• No contact temperature measurement: The detector measures forehead
or hand temperatures and is accurate up to 3 inches away.
• Voice Alarm: After passing the detector an audible voice will state “Your
temperature is normal” for a normal body temperature or
“Please check again” for an abnormal body temperature.
• False Alarm Prevention: Using advanced STM technology the possibility
of false alarms is prevented.
• Easy to use: Just plug it in and it is ready to use.
sv-ir-thrm user guide
3
Components
1 Enter Button
Press the Enter button to conrm
selection.
2 Adjust Button
When inputting a numerical value,
press the Adjust button to change
the value of numerical input.
3 Select Button
When inputting a numerical value,
press the Select button to move a
space to the right.
4 Power Button (disabled)
When connected to a power source
the thermometer is always on.
5 Normal LED Indicator
LED activates when detected
temperature is within the
95° F - 98.6° F (35° C - 37° C) range
6 Power Input
7 Distance Sensor
8 Speaker
Verbal alarm when temperature is
normal (“normal temperature”) or
abnormal (“please check again”).
9 Temperature Display
10 Abnormal LED Indicator
LED activates when detected
temperature is out of the
95° F - 98.6° F (35° C - 37° C) range.
11 Infrared Sensor
sv-ir-thrm user guide 4
Operating the SV-IR-THRM
Start up
Connect the power supply, press the Power button, and wait for the display to show 0.
Shutdown
Press the Power button to turn o the system.
Display Version Number
Press the Select button twice and the version number will display, then press the
Select button to return to the main interface.
Check the Device ID
Press the Adjust button twice and the device ID will display, then press the Adjust
button to return to the main interface.
sv-ir-thrm user guide
5
Configuration
Temperature Conguration
Press the Enter button, press the Select button, then press the Adjust button and
enter the password 6100. Enter the password by pressing Enter,then alternating
between the Adjust button to change the numerical value of each space and the
Select button to move spaces.
For example, to input the password 6100:
1. Press the Select button once, then the Adjust button 7 times.
2. Next, press the Select button to move the next space, then the Adjust button 2
times.
3. Press the Select button to move to the next space and the Adjust button 1 time
to input 0.
4. Repeat this once more for the last 0 and press the Enter button.
Press the Enter button, press the Select button to enter the setting. After setting,
press the Enter button to return to the main interface.
Alarm temperature setting Ambient temperature
compensation settings
NOTE:
9860 means the alarm temperature is .
Factory setting value of alarm temperature is .
Factory setting value of ambient temperature is .
The temperature is displayed in .
sv-ir-thrm user guide 6
Voice Volume and Temperature
Press the Enter button, press the Select button, then press the Adjust button
and enter the password 6100. Press the Enter button again and the display will
show 0000.
Press the Enter button to display FFFF and then press the Adjust button until
you reach the desired volume. If you press the Select button again, you will
enter the reserved function. From here, press the Adjust button to change the
temperature unit. After the setting is completed, press the Enter button to
return to the main interface.
ID Number
Press the Enter button, press the Select button, then press the Adjust button and
enter the password 6100. Press the Enter button and 0000 will display. From here,
the ID number can be modified. Press the Enter button twice to save the ID number
and return to the main interface.
NOTE: You only need to set the ID number if you are adding the optional network
(LAN) function.
NOTE:
1is the voice volume, the range is 0-3: 0 is mute and 3 is the loudest.
1.0 is a reserved function.
0is Celsius °C, 1is Fahrenheit .
Voice volume Reserved function Temperature unit
sv-ir-thrm user guide
7
Restore Factory Settings
Press the Enter button, press the Select button, then press Adjust button to input
the password 6100. Press the Enter button to display FFFF, which indicates that the
system has been restored to the factory setting. Press the Enter button to return to
the main interface.
NOTE: The temperature unit and voice volume is not included in the factory reset
parameters.
Installation Guidelines
Install the device indoors, as wind and sunshine can interfere with the thermo
detection.
Thermo Detection Notes
1. The normal use environment temperature is 32° F ~ 86° F. If you are using when
temperature is approximately -14° F, the ambient temperature compensation
value needs to be increased by 5°, until the error between the measured
value and the forehead gun is within ± 0.3°. If multiple body temperature
measurements are abnormally low, you can also use this method to calibrate the
detector.
2. The best measurement distance is .393 ~ 3 inches.
3. The measurement time is 0.5 seconds. To avoid repetitive measurement, please
move forehead or hand away immediately after detection.
4. The measurement accuracy is ±0.3°.
sv-ir-thrm user guide 8
TEMPERATURE MEASUREMENT
SPEED
Less than 1 second
TEMPERATURE MEASUREMENT
ACCURACY
± 0.3°
TEMPERATURE MEASUREMENT
DISTANCE
<3in (<76.2mm)
POWER CONSUMPTION
Less than 8W
EXTERNAL POWER SUPPLY
120V AC converter
WORKING VOLTAGE
12V
WORKING TEMPERATURE
-14° F ~ 104° F (-10° C ~ 40° C)
OPERATING HUMIDITY
95%, non-condensing
DIMENSIONS W × H × D
4.34 × 6.45 × 1.3in (110.24 × 164 × 33mm)
(excluding bracket and power adapter)
WEIGHT
1.32lb (0.6kg)
CERTIFICATIONS
CE, FCC, ROHS
PART NUMBER
SV-IR-THRM
Appendix A: Specifications
Appendix B: Dimensions
sv-ir-thrm user guide
9
FCC Compliance Statement
This device has been tested and found to
comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when
the equipment is operated in a commercial
environment. This equipment generates, uses,
and can radiate radio frequency energy and,
if not installed and used in accordance with
the instruction manual, may cause harmful
interference in which case the user will be
required to correct the interference at is own
expense.
Any changes or modications in construction
of this device which are not expressly approved
by the party responsible for the compliance
could void the user’s authority to operate the
equipment.
Corporate Headquarters
6100 W. Sam Houston Pkwy. N.
Houston, TX 77041-5113
www.safetyvision.com
Main: 713.896.6600
Toll Free: 800.880.8855
Fax: 713.896.6640
Copyright © 2020 Safety Vision, LLC All Rights Reserved.
