Safety Vision SV-IR-TEMP User manual
sv-ir-tEMP
UsEr GUiDE
sv-ir-temp user guide
Important Notices
Title: SV-IR-TEMP User Guide
Document Version: 1
Revision: 0
Safety Vision attempts to provide information contained in this manual
based on the latest product information available at the time of
publication. However, because of Safety Vision’s policy of continual product
improvement, Safety Vision reserves the right to amend the information in
this document at any time without prior notice.
This material is confidential and the property of Safety Vision. It is shared
with your company for the sole purpose of helping you with the operation
of the described equipment.
Safety Vision makes no warranty of any kind with regard to this material,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Safety Vision shall not be liable for errors
contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this material.
Safety Vision expressly disclaims all responsibility and liability for the
installation, use, performance, maintenance, and support of third-party
products. Customers are advised to make their independent evaluation of
such products.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Safety Vision.
Safety Vision® is a registered trademark of Safety Vision, LLC. All other
products or name brands mentioned in this document are trademarks of
their respective owners. For more information about Safety Vision and its
products, go to www.safetyvision.com or call 800-880-8855.
sv-ir-temp user guide
1
Features 2
Components 3
Display 4
Alerts 6
Operation 9
Settings
Temperature Display Units 10
Modes 10
Alarm Temperature Setting 10
Volume 11
Backlight 11
Language 11
Output Signal 12
Additional Information 12
Appendix A: Specications 13
Appendix B: Dimensions 13
FCC Compliance Statement 14
Contents
sv-ir-temp user guide 2
Features
No contact temperature measurement: The SV-IR-TEMP measures
forehead or hand temperatures and is accurate up to 11.8 inches away.
Voice Alarm: After passing the detector an audible voice will state
“normal temperature” for a normal body temperature or
“please retest” for an abnormal body temperature.
Easy to use: Just put in four (4) AA batteries and it is ready to use.
sv-ir-temp user guide
3
Components
Speaker
• Verbal alert when temperature is
normal (“normal temperature”) or
abnormal (“please retest”).
• The SV-IR-TEMP uses four (4) AA
batteries.
USB-PS
sv-ir-temp user guide 4
Display
Count Mode: Count the number of people and objects pass by the
thermometer (1-9999).
Body Mode: Measure body temperature (default).
Surface Mode: Measure the surface temperature of an object.
Expression: Displays a J(normal temperature) or L(abnormal temperature)
USB Connection Status
Volume
Remaining Power
: Temperature value or count value
Celsius or Fahrenheit
sv-ir-temp user guide
5
An Mindicates the current historical record
number; F indicates the setting item number.
Displays “History Temp” or “Environment Temp”
Indicates that thermometer is calibrated.
Displays the environment temperature.
(Displaycont.)
sv-ir-temp user guide 6
Alerts
Standby: the backlight is turned o and the temperature remains displayed.
Insufficient Power: the icon ashes and displays that the battery is empty.
sv-ir-temp user guide
7
(Alertscont.)
Normal Temperature: flashing green LEDs on both sides.
Abnormal Temperature: flashing red LEDs on both sides and backlight turns red.
sv-ir-temp user guide 8
(Alertscont.)
Lo (in Body Mode):temperature is out of range and lower than 95° F and backlight
turns red.
Hi (in Body Mode):temperature is out of range and higher than 107.6° F and
backlight turns red.
sv-ir-temp user guide
9
Operation
Temperature Measurement: Stand 1.97” - 11.8” in front of the temperature sensor.
Historical Temperature Query: Press the left and right buttons to query the historical
temperature, Mrepresents the current historical temperature. The SV-IR-TEMP
currently supports up to 99 historical temperatures.
sv-ir-temp user guide 10
Settings
1Temperature Display Units
Press the SET button once to F1. Press the
left and right buttons to switch between
Celsius (°C) and Fahrenheit (°F).
Note: Default is Fahrenheit.
2Modes
Press the SET button until F2 appears.
Press the left and right buttons to
changes modes.
Note: Default is Body Mode.
3Alarm Temperature Setting
Press the SET button until F3 appears.
Press the left and right buttons to switch
the alarm temperature between
98.6° F ~ 100.4° F.
Note: Default is 100.4°F
Note: The alarm value is only available
in Body Mode, there is no alarm
temperature in the Surface or Count
modes.
sv-ir-temp user guide
11
(Settingscont.)
4Volume
Press the SET button until F4 appears.
Press the left and right buttons to adjust
the volume. The more parentheses in
front of the speaker icon, the greater the
volume. The volume is muted when the
speaker icon disappears.
5Backlight
Press the SET button until F5 appears.
Press the left and right buttons to turn the
backlight on or o
ON: the backlight is on
OFF: the backlight is o
6Language
Press the SET button until F6 appears.
The voice broadcast language, English
(EN), is displayed.
Note: default is English.
sv-ir-temp user guide 12
(Settingscont.)
7Output Signal
Press the SET button until F7 appears.
Press the left and right buttons to switch
the output signal type.
S1: switch mode
S2: pulse mode
Additional Information
When changing the operating environment, the device must be left to stand for
more than 30 minutes.
Avoid direct sunlight when using outdoors.
Keep away from the air conditioner, fans, etc.
sv-ir-temp user guide
13
SV-IR-TEMP
SPEED
Less than 1 second
± 0.2° (place in the operating environment for 30
minutes before use)
1.97 ~ 11.8 in (50 ~ 300 mm)
5V DC, 500mA
30 seconds automatic standby during
non-working times
0° F ~ 122° F (0° C ~ 50° C)
-14° F ~ 104° F (-10° C ~ 40° C)
4.92 × 6.65 × 5.43 in (125 × 169 × 138 mm)
CE, FCC, ROHS
Appendix A: Specifications
Appendix B: Dimensions
sv-ir-temp user guide 14
FCC Compliance Statement
This device has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference in which case the
user will be required to correct the interference at is own expense.
Any changes or modications in construction of this device which are
not expressly approved by the party responsible for the compliance
could void the user’s authority to operate the equipment.
Corporate Headquarters
6100 W. Sam Houston Pkwy. N.
Houston, TX 77041-5113
www.safetyvision.com
Main: 713.896.6600
Toll Free: 800.880.8855
Fax: 713.896.6640
Copyright © 2020 Safety Vision, LLC All Rights Reserved.
