Safran MorphoAccess SIGMA Series Instruction manual

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
MorphoAccess®SIGMA Series
Quick User Guide
All descriptions illustrations, and specifications in this brochure should be considered approximate and may relate to optional equipment or feature

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
1
Table of Contents
2014_0000000530-V6
Color
Step
Content
One
Overview
Two
Wiring
Three
Communication
Four
ACP or SDAC
Five
Administration
Six
Software
Seven
Enrollment

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
2
MorphoAccess® SIGMA Overview
The MorphoAccess®SIGMA terminal has a
simple and ergonomic man-machine interface
designed for access control and Time &
Attendance, with fingerprint recognition,
contactless card authentication and PIN
authentication options.
USB port (for
configuration and
settings with a
USB mass
storage key)
Step one : overview
USB host port
WR* product
comes with a
sensor protection
cap (not displayed
here)
Optional Wi-Fi™
USB adaptor
(plugged at the back
of the terminal)
5“ WVGA
touchscreen LCD
Optical biometrical sensor
VGA Camera
Speaker
Microphone
HID® iCLASS™ 13,56MHz (SIGMA … ICLASS)
Or MIFARE™DESFire ™13,56MHz (SIGMA .. MULTI)
Or HID® Prox ® 125kHz (SIGMA .. PROX)
Optional Contactless Card reader.
Specific logo on cover when available
Status LED
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
3
QTY
ITEM
1
MorphoAccess
® SIGMA terminal
1
Micro SD card installed
in the terminal
1
Wall Mount Plate
1
Battery
1
POE module
1
ProtectionAccessory (WR* product only)
1
Flat screw driver 0.4 x 2.0
1
Quick Installation Guide
1
WEEE notice
Indoor & Weather Resistant (WR) Checklist
*WR : Weather Resistant
Step one : overview
Electronic documentation is provided in Adobe® Acrobat® format (PDF). Adobe® Acrobat® Reader is available at http://www.adobe.com.
Product packaging checklist:
Micro SD card must be installed in the
terminal at start up (storage area for internal
database and terminal logs)
Micro SD card replacement:
Class 10 or higher, 1GB min, 32GB max
Formatted by the terminal. Windows® PC
may damage the content of the card and
make it inoperative.
Use only Brand Name cards. No name
card may have lower performances or
lower life time.
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
4
MorphoAccess® SIGMA Series
Step one : overview
Product
designation Biometrics
(Fingerprint)
iCLASS
®MIFARE®
DESFire®
NFC Prox®Water
Resistant (*)
MA SIGMA

MA SIGMA WR
 
MA SIGMA
iCLASS  
MA SIGMA
iClass WR   
MA SIGMA Multi
 
MA SIGMA Multi WR
  
MA SIGMA Prox
 
MA SIGMA Prox WR
  
The MorphoAccess® SIGMA Series contains the following product variants:
Contactless Smart
card reader
MA stands for MorphoAccess®and WR stands for Water Resistant
(*) WR units must be installed according to installation guidelines on Quick Installation Guide
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
5
MorphoAccess® SIGMA terminal implementation
ACCESS CONTROL
SYSTEM
(*) OR EQUIVALENT
NON SECURED
AREA
ACCESS
CONTROLLER
TCP/IP, Wiegand, Dataclock, RS485 or RS422
ELECTRIC
LATCH (*)
SECURED
AREA
Dry Contact
MorphoAccess®
Sigma Terminal
Dry Contact
ALARM
Step one : overview
The MorphoAccess®SIGMA Series terminal
Its role is to process the access request from the user. It performs access
right checks using one-to-many biometric identification or one-to-one
biometric verification, and/or RF card authentication, and/or PIN check.
A Door Electric Latch or equivalent such Deadbolt, Door Strike or Magnetic Lock (3rd party product)
The Access Controller sends a command to activate the latch if the access is granted (i.e. if the individual's User ID is listed in the
Controller White List). Control of the latch is made through a dry contact..
An Alarm (3rd party product)
The MorphoAccess®terminal sends a message to the Access Controller, to
activate the Alarm as soon as a malicious activity such as tamper or pulling, is
detected.
To secure an access, Morpho recommends installing the MorphoAccess®SIGMA Series terminal as a part of a typical Access Control
system, this consists of the components described below.
An Access Controller (3rd party product)
The MorphoAccess®terminal interfaces with an Access Controller
(using TCP/IP, Wiegand, Data Clock or RS485 protocol):
After user’s access rights checks, the MorphoAccess®terminal
sends the result to the Access Controller (this message contains
at least the User ID)
The Access Controller performs additional checks, and returns the
final decision (access granted/denied) to the MorphoAccess®
terminal (which displays the result to the user), and to the door
controller which opens the door (if the access has been granted).
A
A
B
B
D
D
C
C
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
6
MorphoAccess® SIGMA Access Control Modes
Step one : overview
(1) or the user enter their Identifier on the keypad, or a Wiegand frame is received from an external device
(2) stored on the contactless card or in the user record in the terminal’s local database
(3) There is no fingerprint image stored in the terminal, but only points of interest (minutiae) of each fingerprint
Identification
Authentication
Multifactor
Proxy
Access
control
a
pplication
Application that runs
on the terminal when
it starts.
Application that runs
on the terminal when
it starts.
Application that runs
on the terminal when
it starts.
Remote application
that controls the
terminal through
network commands
Access
control
triggering
event
A
user places a
finger on the
biometric sensor.
A user places
a
contactless
card in
front of
the reader (1)
Both
Identification
and Authentication
triggers are enabled.
Triggering events are
selected
by the
remote application
Biometric
check (if
enabled)
The user’s captured
fingerprint template
is matched against
all fingerprint
templates in the
terminal database (3)
The user’s captured
fingerprint templated
is
matched against
his reference
fingerprint templates
(2)
As per Identification
or Authentication,
depending on the
triggering event
Selected
by the
remote application
Decision
to
display
result
signal to user
By Identification
standalone
application
By Authentication
standalone
application
By
running
s
tandalone
application
By remote
application
The terminal can be configured in one of the modes described in the table below
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
7
Deployment Environments
Step one : overview
General precautions
Do not expose the terminal to extreme temperatures.
When the environment is very dry, avoid synthetic carpeting near the MorphoAccess® SIGMA terminal, to
reduce the risk of unwanted electrostatic discharge.
Areas containing combustibles
Do not install the terminal in the vicinity of gas stations or any other installation containing flammable or
combustible gases or materials. The terminal is not designed to be intrinsically safe.
The terminal should be installed in controlled lighting conditions
Avoid biometric sensor exposure to a blinking light
Avoid direct exposure of the biometric sensor to sunlight or to UV lights.
Operating temperature
-
20°to + 60 °C (- 4°to 140°F)
Operating
humidity
10 % < RH < 80 % (non condensing)
Storage
temperature
-
25°to + 70 °C (-13°to 158°F)
Storage
humidity
5% < RH < 95 %
IP code
IP65 rated for WR(*) products (once wall
-mounted)
(*) WR units must be installed according to installation guidelines on Quick Installation Guide
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
8
C
Wiring Overview
Step two : wiring
All connections of the terminal are of SELV (Safety Electrical Low Voltage) type.
Power supply from electrical source shall be switched off before starting the installation.
Before proceeding, make sure that the person in charge of installation and connections, is
properly connected to earth, in order to prevent Electrostatic Discharges (ESD).
1
6
2
5
4
3
Power Supply +12V
Power Ground
Tamper switch 2
Tamper switch 1
Digital Ground
Digital Ground
1
6
2
5
4
3
Wiegand IN 0
Wiegand IN 1
Wiegand OUT 0
Wiegand OUT 1
Wiegand LED 1
Wiegand LED 2
1
6
2
5
4
3
Digital Input 0
Digital Input 1
Digital Input 2
Digital Output 0
Digital Output 1
Digital Output 2
1
6
2
5
4
3
Relay_NO
RS422 RX-
RS422/485 TX+
RS422/485 TX-
Battery
Reset button
A
A
B
B
C
RJ-45
USB
µSD D
D
Relay_COM
RS422 RX+
Connection: Insert cable in the round hole of the block connector.
Disconnection: Insert flat screw driver (0.4x2.0max) in rectangular hole and pull the wire.
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
9
Power Wiring
Step two : wiring
External Power Supply: 12-24 Volts (regulated and filtered) 1 Amp min @12V,
CEE/EEC EN60950 standard compliant. A12 Volts power supply compliant with SIA's
Wiegand standard will also be suitable. If sharing power between devices, each unit
must receive 1A (e.g. two units would require a 12vDC, 2Asupply)
WARNING: Under powering may cause memory and data corruption; over
powering may cause hardware damage. Both of these situations will void the
warranty
A battery backup or uninterrupted power supply (UPS) with built-in surge protection is
recommended.
1
A
2
3
Power Supply +12V
Power Ground
Inversion of +12V and GND will damage the product.
B C D
Gauge
AWG
Diameter
(mm)
Maximum drop voltage (V)
at 1m at 5m at 10m
20 0.81 0.03 0.17 0.33
22 0.64 0.05 0.26 0.53
24 0.51 0.08 0.42 0.84
Morpho recommends using a gaugeAWG20 for 12V power supply.
The voltage measured on the product block connector of the terminal must be equal
to 12V-24V (-15% / +10%).
The table below, shows the maximum voltage drop between the power source and the
terminal, depending on the length of the cable.
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
10
Power Over Ethernet & Battery
Step two : wiring
USB
1
2
6
Power Over Ethernet (POE): power can be provided through RJ-45 connector using a
PSE (Power Sourcing Equipment) IEEE 802.3af or IEEE802.3at type 1 compliant.
This feature requires a specific electronic card plugged at the rear of the product.
Warning : after use, the temperature of the POE module may be high: after power cut off,
wait 5mn before working on connectors area.
POE
RJ-45
Battery
Battery
•Installation : the engraved side, the positive side (+), must face upwards.
•protects the date and time in case of power failure or switch off
•lifetime is limited : at least 350 hours at 25°C, when power is off:
•must be changed after a long power cut or after several shorter power cuts.
•Remove and store the battery if the terminal will be unpowered for a long period of time
PoE Injector Specs
Output Voltage: -48VDC
Output Current: 0.32A
Power: 15.36W
Reset Button : performs a hardware reset of the terminal (one power down, power up
cycle). No data is lost and the settings are kept if the battery is installed and has charge.
Reset
Button
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
11
RS-485 Communication
Step three : communications
1D
2
4
3
A maximum of 31 devices may be installed on the same line.
The maximum total cable length is 4000 ft. (1200m).
The cable must be dedicated to this installation and not used for any other purpose
Choose a RS-232 to RS-485 converter that supports Sense Data to
switch from Send to Receive mode.
RS-232
from the
Com Port
RS-232 to
RS-485
converter RS-485 to
1200m (4000ft)
RS485 TX+
RS485 TX-
For RS-485 installations, the cable should be run in a daisy-chain
configuration (i.e. converter > position 1 > position 2 > position 3, etc.).
Use CAT-5 UTP (or better) cable (shielded recommended) with a
impedance of 120 . AWG 24 should be the minimum wire gauge used.
Choose one twisted pair of conductors to use for RS-485 TDA/TX+ (D-5
wire) and RS-485 TDB/TX- (D-6 wire). Another conductor should be
used for Signal Ground (A-5 or A-6 wires) .
1
6
2
5
4
3GND
GND
A B C
6
5
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
12
RS-422 Communication
Step three : communications
1D
2
4
3
RS422 TX+
RS422 TX-
1
6
2
5
4
3GND
GND
A B C
6
5
RS422 RX-
RS422 RX+
The maximum total cable length is 4000 ft. (1200m).
The cable must be dedicated to this installation and not used for any other purpose
For RS-422 installations, the cable should be run in a point to point configuration
(i.e. PC > converter > terminal)
Use CAT-5 UTP (or better) cable (shielded recommended) with a
impedance of 120 . AWG 24 should be the minimum wire gauge used.
Choose one twisted pair of conductors to use for RS-422 TDA/TX+ (D-
5 wire) and RS-422 TDB/TX- (D-6 wire).
Choose one twisted pair of conductors to use for RS-422 RDA/RX- (D-
3 wire) and RS-422 RDB/TX+ (D-4 wire).
Another conductor should be used for Signal Ground (A-5 or A-6 wires).
RS-232
from the
Com Port
RS-232 to RS-
422 converter RS-422 to
1200m (4000ft)
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
13
Ethernet and Wireless LAN
RJ-45 Ethernet connection (recommended)
Ethernet connection to the terminal is made through a
standard RJ-45 connector on the back of the terminal.
Use a category 5 shielding cable (120 Ohms) or better. It is
strongly recommended to insert a repeater unit every 90m.
By default, MorphoAccess® SIGMA Series terminal is
configured in Static IP mode.
Terminal Block Ethernet connection
Extreme care must be taken while connecting Ethernet
wire to the block board since low quality connection may
strongly impact Ethernet signal sensibility.
Connect Rx+ and Rx- with the same twisted-pair wire (and to
do the same with Tx+/Tx- and the other twisted-pair wire).
Step three : communications
Management
station
Wireless
WLAN option
This option is available only with Wi-Fi™ dongle (and adaptation cable) delivered by Morpho (kit
reference 293658530), and requires the terminal be powered by an externalAC/DC 12V to 24V
power supply (the POE feature doesn’t provide enough power for the terminal and the dongle).
Morpho Wi-Fi™ dongle supports 802.11b and 802.11g standards, WEP Open, WPA and WPA2.
The Wi-Fi™ dongle shall not be exposed to temperatures exceeding 50°C (thermal dissipation).
The Wi-Fi™ dongle shall be installed outside the product (separate area shall be reserved in the
wall).
2014_0000000530-V6
LAN Ethernet
IP address
Mode Parameter Factory value
Static
Terminal IP address 192.168.1.10
Gateway IP address 192.168.1.254
Sub network mask 255.255.254.0
Host name MAsigma

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
14
Wiegand Communication
Step three : communications
Three-conductor wire (shielded recommended) is required for Data 0, Data 1, and WGND.
Use 18-22AWG cable in a homerun configuration from each unit to the Access Control Panel (ACP).
Connect WIEGAND_OUT0 (B-3 Wire) to ACP Data 0,
Connect WIEGAND_OUT1 (B-4 Wire) to ACP Data 1,
Connect WIEGAND_GND (A-5 or A-6 Wire) to ACP reader common (0vDC).
For 18 AWG, the maximum cable distance is 500 ft. (150m); for 20AWG, the maximum is 300 ft. (90m); for
22AWG, the maximum is 200 ft. (60m).
Electrical interface conforms to the Security Industry Association's Wiegand standard March 1995, and it is
5V TTL compatible.
1
6
2
5
4
3
Wiegand IN 0
Wiegand IN 1
Wiegand OUT 0
Wiegand OUT 1
Wiegand LED 1
Wiegand LED 2
1
6
2
5
4
3GND
GND
A B
Wiegand Out
Wiegand In
LED Out
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
15
Wiegand Communication (continued)
Step three : communications
Example Format Information
Type: Standard 26-bit
Alt Site Code and Fail Site Code Range: 0-255
Template ID Number Range: 1-65535
Extended ID Number Range: N/A
ID Start Bit: 9
Length of ID: 16
Site Code Start bit: 1
Length of Site Code: 8
Start Bit length : 0
Important
By default, the Wiegand output format is not enabled.
Wiegand output must be configured before connecting
to theACP.
Note
On installation, the system administrator will be
prompted to select either a pre-existing Wiegand frame
format or create a custom format, and upload it to the
unit before the first use.
Data Clock
The Wiegand port also supports the Clock & Data
protocol. The wiring is described below.
1
6
2
5
4
3
Wiegand IN 0 –Data IN
Wiegand IN 1 –Clock IN
Wiegand OUT 0 –Data OUT
Wiegand OUT 1 –Clock OUT
Wiegand LED 1
Wiegand LED 2
1
6
2
5
4
3GND
GND
A B
Data Clock Out
Data Clock In
LED
Out
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
16
SINGLE DOOR ACCESS CONTROL (SDAC)
Step four:ACP or SDAC
1
6
1
6
1
6
1
6
AB C D
GPI1
GPO0
GPI0
GPO1
Relay_NO
Relay_Com Deadbolt / Door strike
Power
supply
Single Door Access Control (SDAC) wiring sample : with Push Button
Door contact
2
Power
supply
5
Push Button
4
2
Warning
•Please check next page for important information about internal relay rating
•If door contact is not used, GPI1 (C-2) and GPO1 (C-5) shall be connected together
•Power supply from electrical source shall be switched off before starting the installation.
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
17
Internal Relay Wiring (Normally open)
Inductive load management requires a parallel diode for a better contact lifetime.
Warning
The internal relay is limited to a maximum current of 2A @ 30V. If the deadbolt / door strike draws
more than 2A, damage to the device may occur. If the deadbolt / door strike load exceeds 2A, an
external relay must be used.
The internal relay is designed for 100.000 cycles. If more cycles are needed, an external relay
driven by GPO must be used.
Power supply
VCC < 30V
Imax < 2A
Deadbolt / Door strike
Push Button
on other side
of the door
Snubber Diode
1D
2
Relay_NO
Relay_Com
A B C (Sample)
Warning
This applies only for small
or stand-alone applications
where access control
panels are not available.
In this mode it is strongly
recommended to monitor
the Tamper Detection of
the device
Step four:ACP or SDAC
Relay mode can be
changed to “normally
close” instead of
“normally closed” (default)
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
18
Local Administration - First Boot Assistant
The First Boot Assistant (FBA) helps the administrator to
configure all the devices fundamental settings.
It is automatically launched at first terminal startup, but
can also be launched on demand, though administration
menu (i.e. to reinitialize terminal main settings)
Main settings managed by FBA
Date & Time Configuration: date & time, time zone
Language Configuration: user interface language
selection,
Trigger Event: select event(s) to be processed as an
access request by a user
Network Configuration: LAN or WLAN parameters
Recognition Mode: identification mode activation.
Protocol Configuration: select communication
protocol : Bioscrypt 4G terminals, MA 500 and J
Series (MA2G), or MorphoAccess SIGMA (MA5G)
Password Configuration: terminal administration
password modification
First Boot Configuration Storage Type: select
either temporary (i.e. for a short duration test, reboot
will restore previous values) or permanent storage
(applies to normal operation, new settings remains
after reboot) of the setting modified by FBA.
The battery must be installed to prevent real time
clock loss on power off or power failure
Step five: Administration
2014_0000000530-V6

This document and the information therein are the property of
Morpho, They must not be copied or communicated to a third party
without the prior written authorization of Morpho.
19
Frequently used icons
Local Administration –Using Touch Screen Menu
+ password (default: 12345) For security reasons, it is highly recommended to change the
devices default password to a custom password.
Exit or Go
Home Validation or
confirmation
Cancel or
refuse
Back (and
Cancel)
User
management
Security
Multimedia
management Communication
settings
Information
about terminal
Terminal
settings
Restart USB key
management
Start/Stop
Step five: Administration
2014_0000000530-V6
