Sage Kitchen Wizz Peel & Dice SFP820 User manual

the Kitchen Wizz®Peel & Dice
SFP820
EN QUICK GUIDE DE KURZANLEITUNG
FR GUIDE RAPIDE IT GUIDA RAPIDA
NL SNELSTARTGIDS

2 3
EN
SAGE®
RECOMMENDS
SAFETY FIRST
At Sage®we are very safety
conscious.We design and
manufacture consumer
products with the safety of
you, our valued customer,
foremost in mind. In
addition, we ask that you
exercise a degree of care
when using any electrical
appliance and adhere to the
following precautions.
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE
FOR FUTURE REFERENCE
• A downloadable version of
this document is also available
at sageappliances.com
• Before using for the rst
time ensure your electricity
supply is the same as
shown on the label on the
underside of the appliance.
• Remove and safely discard
any packaging materials
before rst use.
• To eliminate a choking hazard
for young children, safely
discard the protective cover
tted to the power plug.
• This appliance is for household
use only. Do not use the
appliance for anything other
than its intended use. Do not
use in moving vehicles or
boats.Do not use outdoors.
Misuse may cause injury.
• Fully unwind the power
cord before operating.
• Position the appliance on a
stable, heat resistant, level,
dry surface away from the
edge and do not operate on
or near a heat source such as
a hot plate, oven or gas hob.
• Vibration during operation may
cause the appliance to move.
• Do not let the power cord
hang over the edge of a
bench or table, touch hot
surfaces or become knotted.
• This appliance shall not
be used by children.
• Always disconnect the
appliance from the supply
if it is left unattended
and before assembling,
disassembling or cleaning.
• Children should not play
with the appliance.
• Cleaning of the appliance
and user maintenance should
not be carried out by children
unless they are 8 years or
older and supervised.
• Keep the appliance and its
cord out of reach of children.
• The appliance can be used by
persons with reduced physical
or mental capabilities or a lack of
experience and knowledge, only if
they have been given supervision
or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
• Do not use the appliance
if the power cord, plug, or
appliance becomes damaged
in any way. If damaged and
maintenance other than
cleaning is required, please
contact Sage Customer Service
or go to sageappliances.com
• Any maintenance other
than cleaning should be
performed by an authorised
Sage®service centre.
• The installation of a residual
current safety switch is
recommended to provide
additional safety when using all
electrical appliances. Safety
switches with a rated operating
current not more than 30mA
are recommended.Consult an
electrician for professional advice.
• Always ensure the appliance
is properly assembled as
per instructed before use.
Use the appliance without
properly assembled may cause
product malfunction, product
damage or pose safety risk
including personal injury.
• Do not use the food processor
on slippery, unstable or
uneven surfaces such
as a sink drain board.
• Keep hands, ngers, hair,
clothing as well as spatulas
and other utensils away
from moving or rotating
parts during operation.
• Do not use the appliance for
anything other than food and/
or beverage preparation.
• In order to avoid the possible
hazard of the appliance
starting by itself due to
inadvertent resetting of the
overload protection, do not
attach an external switching
device (such as a timer) or
connect the appliance to a
circuit that can regularly switch
the appliance on and o.
• Keep the appliance clean.
Follow the cleaning instructions
provided in this book.
• This appliance is for household
use only. Do not use this
appliance for anything other
than its intended use. Do not
use in moving vehicles or
boats.Do not use outdoors.
Misuse may cause injury.
• Never use attachments or
accessories that are not
supplied with this product or
authorised by Sage®to be used
on this product. Failing to follow
this instruction may cause
product malfunction, product
damage or even pose safety risk.
• For optional accessories
authorised by Sage®to
be used on this product,
please read all instructions
supplied with the accessory in
conjunction with the instructions
contained in this booklet.
2Sage®Recommends Safety First
6Components
9Assembly
12 Functions
16 Food Processing Guide
18 Care & Cleaning
20 Troubleshooting
Contents

4 5
EN
• Care should be taken when
removing the food from the
processing bowl by ensuring
the motor, Quad™blade,
dough blade or disc, have
completely stopped before
disassembling. Ensure
the OFF button has been
pressed to switch the motor
o; the appliance is switched
o at the power outlet and
unplugged, before removing
the lid from the bowl.The
processing bowl should then
be unlocked from the motor
body and the Quad™blade,
dough blade or discs carefully
removed before attempting to
remove the processed food.
• Do not process hot or boiling
liquids - allow liquids to
cool before placing into the
processing bowl. Hot liquid
can be ejected to cause injury
due to sudden steaming.
• Ensure the OFF button
has been pressed, and the
food processor is switched
o at the power outlet and
unplugged before attaching
the Quad™blade, dough
blade, disc or processing lid.
• To avoid possible malfunction of
the processing bowl’s auto switch,
do not place the processing
lid in the locked position when
the appliance is not in use
• Do not place hands or ngers in
the bowl of the food processor
unless the motor, Quad™blade,
dough blade or discs have
come to a complete stop. SAVE THESE INSTRUCTIONS
• The processing blades and
discs are extremely sharp,
handle with care at all times.
Avoid contact with moving
parts during operation. Keep
hands, hair, clothing, spatulas
and other utensils out of
food processor feed chute
to prevent personal injury or
damage to the mixer. Always
use the food pusher to push
the food down the feed chute.
• Handle the food processor
and attachments with care –
remember the blades and discs
are razor-sharp and should be
kept out of reach of children.
• Care should be taken when
handling the sharp cutting
blades, emptying the bowl
and during cleaning.
• Do not ll bowl above
marked liquid levels or
15 cups dry level (shredding).
Always add drier or thicker
ingredients to the processing
bowl prior to adding uids.
• Never remove the lid while
the processor is operating.
Always use the POWER/OFF
button to stop the machine
before removing the lid.
• Do not place the food processor
near the edge of a bench or
table during operation. Ensure
the surface is level, clean
and free of water, our, etc.
• Do not place any part
of the food processor in
the microwave oven.
• Do not leave the food processor
unattended when in use.
• Do not move the food
processor whilst in operation.
• Do not use attachments
other than those provided
with the food processor.
• Do not attempt to operate
the food processor by any
method other than those
described in this booklet.
• Do not push food into the
feed chute with your ngers
or other utensils.Always use
the food pusher provided.
• Always operate the food
processor with the processing
lid securely in position.
• Always secure the processing
bowl onto the motor base
before attaching the Quad™
blade, dough blade or discs.
• Please do not crush ice in the
large or small processing bowls.
This will cause damage to the
blades (Quad™or mini blade).
We recommend that you use
a blender for ice crushing.
• When mixing yeast dough,
the operating time of the
food processor should not
longer than 30 seconds.
Allow the appliance to cool
down before next use.
• Some sti mixtures, such
as dough, may cause the
processing blade to rotate
more slowly than normal. If
this happens, do not process
for longer than 30 seconds.
• Do not use your ngers or
a knife to clean the dicing
grid. Please use the cleaning
tool or brush provided to
clean the dicing grid.
• Do not use your ngers or
a knife to clean the dicing
blade. Please use the cleaning
tool or brush provided to
clean the dicing blade.
• Do not attempt to use the Dicing
Kit in any other manner than
described in this user manual.
• Do not attempt to use the
Dicing Kit with any other
food processor than the
models specied on the
Dicing Kit packaging.
The symbol shown
indicates that this
appliance should
not be disposed of
in normal household waste.
It should be taken to a local
authority waste collection centre
designated for this purpose or
to a dealer providing this
service. For more information,
please contact your local
council oce.
To protect against electric
shock, do not immerse the
power plug, cord or
appliance in water or any liquid.

6 7
EN
Q
T
S
R
U
V
W
X
Y
Z
Q. Dough blade
R. Mini processing blade
S. Quad®processing blade
T. Quad®blade safety cover
U. Whisk/emulsifying disc
V. Adjustable slicer
W. French fries cutter
X. Julienne disc
Y. Reversible shredder
Z. Disc spindle
Use with the reversible shredder, julienne,
chip cutting, whisk, potato peeler and
adjustable slicing discs in position.
Rating Information
220–240V~50Hz 2000W
Components
A
B
C
D
E
F
G
H
J
K
L
I
O
P
M
N
A. Small food pusher
B. Medium pusher
C. Large food pusher
The food processor will not start unless
the large pusher is correctly in place.
D. Extra wide 14cm chute
E. Feed chute safety system
Preventsthemotorfromoperatingunlessthe
bowl and lid are correctly locked in position,
and large feed pusher is inserted.
F. Processing lid
G. Silicone seal
H. Mini bowl
For better control when processing
small quantities.
I. Processing bowl with handle
15 cup bowl for dry ingredients and
10 cups for diced and liquid (thick,
wet ingredients e.g. soups).
J. LCD display
K. Count up & count down timer
L. POWER / OFF button
M. START / PAUSE button
N. PULSE button
O. Direct drive motor base
P. Non-skid rubber feet

8 9
EN
BEFORE FIRST USE
• Before using your food processor for the rst
time, remove any packaging material and
promotional labels.Ensure the POWER button
is OFF and the food processor is unplugged.
• Be careful when handling the blades and discs
as they are extremely sharp.
• Wash the processing bowl, processing lid and
all attachments in warm soapy water with a soft
cloth. Rinse and dry thoroughly. All attachments
except the geared spindle and large food pusher
may be washed in the dishwasher.
• When rst using your food processor, you
may notice an odour coming from the motor.
This is normal and will dissipate with use.
• Always use the food processor on a dry,
level work surface.
ASSEMBLY
Motor Base and Bowl
1. Position the processing bowl onto the motor
base with the handle in line with the ALIGN
HANDLE graphic on the motor base.
2. Turn the bowl clockwise until the handle locks
to the front.The processing bowl should now
be securely locked into position.The food
processor will not operate unless the bowl
is locked into position correctly.
Assembly
AA. Peeler disc
AB. Dicing disc
AC. Dicing grid
AD. Dicing Distributor
AE. Cleaning cap
AF. Geared spindle
Use with the dicing kit.
AG. Plastic spatula
AH. Cleaning brush
AI. Storage box
AA
AB
AC
AD
AE
AF AG AH
AI
