Saje AROMA HAVEN JILLIAN HARRIS EDITION User manual

ultrasonic diuser
diuseur ultrasonique
Please read and save this manual
AROMA HAVEN
jillian harris edition

Live healthier by improving
the quality of the air you breathe
ultrasonic diuser
diuseur ultrasonique
AROMA HAVEN
jillian harris edition

TABLE OF CONTENTS
   1
    2
  3
 4
   6
  7
  9
 11
   13
s15

BENEFITS OF DIFFUSING
Ultrasonic diffusers support healthy indoor air quality.
Ultrasonic technology, combined with water and a
diffuser blend, produces negative ions and aromas
that elevate your well being.
Diffusing helps to reduce dust, pet dander and other
airborne allergens (like dust mite matter) from the air
you breathe. When used with your favourite Saje diffuser
blend, the ultrasonic diffuser's refreshing mist brings
the benefits of nature into your space while supporting
balance and harmony.
Transform your surroundings with clean air that's
reminiscent of mist from a waterfall. Add the Saje
diffuser blend of your choice and enjoy fresh, inviting
aromas in your space.
1

RECOMMENDED SAJE DIFFUSER BLENDS
Soothing and relaxing:
 | ® |  
Cough, cold and allergy relief:
 |  ®
Fresh, clear air:
 |  |  
Spa-like experience:
  |  ® |   
Energizing and uplifting:
 |  
use only saje diffuser blends; using other oils may result
in malfunction.
2

PRODUCT FEATURES
 Uses an ultrasonic, heat-free system to disperse
essential oil molecules into the air.
 May also be used as an air purifier or humidifier.
 Whisper-quiet operation and auto shut-off.
 Continuous and intermittent mist output settings.
3

SPECIFICATIONS
product name Aroma Haven
input voltage AC100-240V
output voltage DC24V +/- 5%
rating power 12W max.
water tank capacity 200 ml (6.8 fl oz)
misting duration
approx. 7 hours continuous;
approx. 14 hours intermittent
(30 sec on/30 sec off)
mist output
approx. 30 ml (1  oz) per hour on
continuous; approx. 15 ml (3 tsp)
per hour for intermittent
settings continuous mist or intermittent
mist; Off
coverage area approx. 550 sq ft
4

dimensions approx. (D) 114 mm x (H) 140 mm
or (D) 4.5" x (H) 5.5"
net weight 970 g (34 oz)
main materials outer cover: terrazzo; base: ABS;
water tank: PP; o-ring: silicone
5

DIAGRAM OF PARTS
.  
.  
. 
.    
.  
.  
.  
.   
.  
.  
.  
w
a
t
e
r
l
e
v
e
l
d
c
k
g
b
a
i
j
f
h
e
6

OPERATING INSTRUCTIONS
1. Connect power adapter to DC power jack
on bottom of unit.
2. Remove the terrazzo cover from the base,
then remove the water tank cover from
the water tank.
3. Fill water tank with room temperature tap
water to no higher than max. water level line
(200 ml/6.8 fl oz). Tilting the unit can cause
water to run into the diffuser's ventilation
system and out the bottom - to ensure correct
usage, always bring water to your ultrasonic
diffuser and not the other way around.
4. Add 10-15 drops (depending on prefe-
rence) of your favourite Saje diffuser
blend to the water.
5. Replace the water tank cover and then the
terrazzo cover; ensure that the terrazzo cover
is pressed down over the silicone o-ring.
6. Plug power adapter into electrical outlet.
water level
water level
water level
7

7. Press the on/off button and select the mist setting.
8. Unit will shut off automatically after 7 hours (continuous
setting) and 14 hours (intermittent setting). Note that the
water level remaining in the tank after shut-off will vary.
For next use, fill up water level to the max. water level line
with new water supply.
9. Use only Saje diffuser blends; using other oils may
result in malfunction
please note: run times and amount of water left in the tank
after auto shut-off will vary due to climate, environment
and other factors.
press once:
Mist emits continuously, automatically
turns o after 7 hours of operation
press a second time:
Mist emits at intervals of 30 seconds,
automatically turns o after 14 hours
of operation
press a third time: Mist off.
button indicators:
2
off
1
8

CARE & MAINTENANCE
 If the unit is knocked over while in operation, water
could leak into the internal mechanism of the unit; if
this occurs, unplug from power, empty water and let unit
dry out in well-ventilated area for at least three days.
 Turn o unit and unplug from the power adapter prior
to cleaning.
 Remove cover and empty water from the water tank,
carefully avoiding the air outlet side.
 If required, use a clean, soft, damp cloth to wipe down
exterior of unit.
 Frequency of cleaning is dependent upon usage and
types of diuser blends used (i.e. how thick the essential
oils are in the diuser blend).
 To clean inside water tank, pour a few drops of rubbing
alcohol into tank and wipe with a clean, soft cloth.
 To clean ceramic disc at bottom of water tank, pour a
few drops of rubbing alcohol onto a clean cotton swab
and wipe clean.
9

 The ceramic disc should be kept clean of mineral
deposits and other debris for optimal misting. Never use
any sharp objects to clean the ceramic disc as this will
damage the disc permanently.
 For optimum results, clean the water tank before
changing diuser blends.
 Do not disassemble or attempt to repair unit; in the
event of a problem, please contact 1-877-ASK-SAJE.
10

CAUTIONS
 Only use the power adapter supplied with the device.
 Never operate the device if the power adapter is damaged.
 Never operate the device if the power adapter is damaged.
 To reduce the risk of electric shock, do not attempt to
service the device in any way other than as described in
the “Care & Maintenance” section of this manual.
 When moving the device, hold securely by the base.
 Do not touch the highly sensitive ceramic disc with bare
fingers when the ultrasonic diffuser is in use or plugged in.
 Always place the unit on a stable, level surface.
 Do not fill water tank directly from tap as water could
spill into the internal mechanism and cause damage.
 Ensure that no essential oils or water leak into the air
outlets on either side of the water tank.
 Do not plug the unit into the wall socket with wet hands.
 To prevent damage to the ceramic disc, only use tap
water at room temperature.
11

 Do not pour water or other liquid into the air outlet.
 Do not tilt, move or attempt to empty or rell unit while
in operation.
 To prevent clogging and damage to the ceramic disc,
always use clean water.
 Remove any liquid left in the water tank after each use.
 Always turn o and unplug the device during maintenance
or when not in use.
 Ensure that the power adapter is not covered or blocked when
plugged in; it must be able to dissipate the heat properly.
 Use only Saje diuser blends; other oils may contain fragran-
ces, base oils or synthetics that could result in malfunction.
Some single note essential oils are also too thick or heavy for
use in the ultrasonic diuser. See FAQs for more information.
 In case of smoke, unusual aroma, undue noise or other
malfunction, unplug the unit immediately and discontinue
use. Further use may result in re or electrical shock.
 Do not overfill or immerse the unit in water.
 Always keep unit out of reach of small children and pets.
12

FCC & IC STATEMENTS
This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio commu-
nications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
13

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Changes or modifications not expressly approved by Saje
Natural Wellness Canada could void the user’s authority to
operate this equipment.
This device complies with Part 18 of the FCC Rules and ICES 001.
Although this product is tested and complies with FCC, it
may interfere with other devices. If this product is found to
interfere with another device, separate the other device and
this product. Conduct only the user maintenance found in
this instruction manual. Other maintenance and servicing
may cause harmful interference and can void the required
FCC compliance.
14

FAQs
q: what if my unit does not turn on?
Power adapter may not be properly plugged in; ensure that
the power adapter is properly plugged into the DC power
jack and the electrical source.
q: what if my unit does not mist or there is almost no mist?
There may not be enough water in the water tank; ensure
that the water tank is lled to the maximum water level line.
The water level may be too high (higher than the maximum
water level line); pour out excess water and try again.
The ceramic disc may require cleaning. Please see "Care &
Maintenance" instructions.
15

q: what type of water should go into my ultrasonic diffuser?
To prevent damage to the unit, it's recommended to use
room temperature tap water. To prevent clogging and
damage to the ceramic disc, always use clean water.
q: what can i put in my ultrasonic diffuser?
Use only 100% natural Saje diuser blends; other blends
and oils may contain fragrances, base oils or synthetics that
could result in malfunction.
Many single note essential oils should not be used in the
ultrasonic diuser. Single note essential oils may have
a thick or heavy consistency that can clog the ultrasonic
diuser and cause it to stop working.
Saje diuser blends have been carefully blended to be
eective for you, and are safe and easy to use in your
ultrasonic diuser.
16

Imported by / Importé par :
saje natural wellness
vancouver, bc canada v5t 1g8
saje.com | 1-877-ask-saje | @sajewellness
i'm made from recycled paper. please recycle me
