Sakai PC600 Installation and operation manual

No.3498-35860-0
No.50101~
OPERATING & MAINTENANCE INSTRUCTIONS
PLATE COMPACTOR
Be sure to operate, inspect, and maintain the products after you
have read this manual carefully to understand the contents.

Forward
Forward
This manual has been prepared as a guide to operate SAKAI PLATE COMPACTOR, PC
600.
It is hoped that the manual is useful for experienced operators to refresh the knowledge and
the experiences as well as for inexperienced operators.
You are requested to use this product after you have fully understood the contents of this
manual. Furthermore, keep this manual at a suitable place for your easy access.
Refer to a separate Engine Operation Manual for operation and maintenance of the engine.
If you lend or let other person to operate the machine, thoroughly explain how to operate
it and guide him to read this manual in advance before operation. In addition, if you trans-
fer the product to someone, provide him with the Engine Operation Manual as well as this
instruction manual.
Please note that the purchased product may be somewhat different in the the contents of the
manual due to our constant efforts to improve its design.

Contents
When you order parts or get instructions for trouble correction ........... 1
Safety precautions .................................................................................. 2
1. Basic safety precautions ................................................................ 4
2. Sticking position of warning notice (Label) .................................. 6
3. Inspection before operation ........................................................... 8
4. Starting-up ..................................................................................... 10
5. Operation ....................................................................................... 13
6. Shutting down ................................................................................ 16
7. Inspection and Maintenance .......................................................... 17
8. Fuel and Lubricant ......................................................................... 21
9. For a long-term storage .................................................................. 21
10. Overall View .................................................................................. 22
Contents

ー1ー
When you order parts or get instructions for trouble correction
When you order parts or get instructions for trouble correction
Be sure to inform us of the MODEL and its CHASSIS NUMBER when you are ordering
parts or getting instructions for trouble correction. The PRODUCT MODEL and BODY
NUMBER (Serial No.) are indicated on the body name plate.
The name plate is located on the rear side of the body for model PC600.
MODEL CHASSIS NUMBER
PC600 〇〇〇〇〇
Location of the name plates
MODEL
CHASSIS NUMBER
MODEL
CHASSIS No.
SAKAI HEAVY INDUSTRIES, LTD.

ー2ー
Safety precautions
Safety precautions
In order to use this product safely, correct operation and periodical maintenance are
absolutely essential. Do not operate and/or carry out maintenance of the product until you
read the manual carefully to understand the safety precautions.
The operation and safety precautions illustrated in this manual are only limited for what it
is to be used as a plate compactor. If the product is to be used for works other than what the
manual covers, every safety consideration must be made on your responsibility.
In this manual, precautions. if they are failed to be observed, which may lead to an accident
resulting in injury or death, are marked as " DANGER" or " WANING".
Precautions, if they are failed to be observed, which may lead to injury or to serious damage
to the machine, are marked as " CAUTION", and for precautions which may result in
damage to the machine or shortening its service life are marked as "IMPORTANT".
In addition, labels indicating precautions in carrying out safety operation and maintenance
service are stuck on the compactor as follows:
DANGER Indicates extremely high risk of an accident resulting in
serious injury or death if it is failed to be observed.
(This is marked in red.)
WANING Indicates a possibility to an accident resulting in
serious injury or death if it is failed to be observed.
(This is marked in orange.)
CAUTION Indicates a possibility resulting in injury or damage to
the machine if it is failed to be observed.
(This is marked in yellow.)

ー3ー
Safety precautions
Do not operate the machine until the
operator has understood the contents
by reading this manual carefully.
Wrong operation may invite an acci-
dent resulting in injury or death.
Safety operation of the machine is on
operator's responsibility.
WANING
☆Cautions to be taken when making an alteration of the machine:
Making an alteration without our recommendation is a matter of question in terms of
safety.
Contact our local sales agent or office in advance for alteration.
We will not bear any responsibility for injury or breakdown of machine resulted from
alteration without approval from our side.
☆Basic safety precautions to be taken in operating the machine are illustrated on the next
page on.
In order to avoid an accident, you are requested to pay close attention to the safety other than
the precautions indicated in this manual and/or on the labels during machine operation, as
they could not cover all the precautions by foreseeing any possible danger.

ー4ー
1. Basic safety precautions
1. Basic safety precautions
■Read the instruction manual carefully.
●Understand functions of operation control equipment and
familiarize yourself with where it is and how to control it.
Also, have a proper understanding of how to operate and
meaning of each symbol.
■Observe the rules in work site.
●Observe the established rules such as prohibitions in the work site, cautions, and work
procedures.
■Wear clothes suitable for the work, and protective means.
●Wear clothes suitable for the work, safety shoes, and safety cap.
●Do not wear clothes which are likely to be caught in a projection of the machine, and/or
an ornament. Also, do not wear a clothe stained with oil as it may catch fire easily.
●Never forget to wear protective goggles and a mask when required in the work.
■Handle with care when hot members are at high temperature.
●Take care not to be burned as the engine as a whole is very hot
during operation or immediately after it has been stopped.
●Do not allow your hand, body and clothe to be touched to
the muffler as it is very hot while the engine is running or
immediately after it has been stopped.
●Take care, while the engine is still hot, not to be burned from oil
spray when draining or filling oil.
Be sure to observe the safety precau-
tions to secure safety.
Failure to observe the precautions will
invite accidents or machine troubles.
WANING

ー5ー
1. Basic safety precautions
■Pay attention to fire.
●Bringing a open flame close to fuel and oil may invite a fire.
In particular, fuel can catch fire very easily and it is dangerous.
●Do not bring a fire such as of cigarette or of match close to the
flammable materials.
●Supply fuel with the engine stopped after no fire has been
confirmed around the compactor.
●Tighten the caps such as for fuel and for oil securely.
■Pay attention to ventilation.
●Exhaust gas is harmful for your health. If the engine has to be
run in a room or in a poorly ventilated area, ventilate the area by
opening windows and/or entrances.
■Check the machine body before operation.
●Check to see if each part of the machine functions properly at a safe place. If it is found
anything wrong, be sure to take corrective measures to start operating the machine.
●Check the machine for unusual noise, unnatural vibration, heat and smell. If it is found
something wrong, stop the machine at a safe place immediately and check and locate the
cause to repair it.
■Be careful not to be caught in the machine.
●Do not stand close to the machine while operating the machine
because your hand, body, or clothe is likely to be caught in the
rotating members which may result in an injury.
Be sure to stop the engine before performing inspections and
maintenance for rotating members such as V-belt, PTO pulley
and its vicinity.
●Never try operating the machine with any of covers removed
from the rotating members.
■Cautions to be taken when loading and unloading the machine.
●Load and unload the machine in/from a transporting vehicle with two persons in order to
avoid an accidental drop of the machine.
●Drain fuel from the fuel tank, the carburetor, and the fuel strainer before transporting it on
a long distance or on a rough road.

ー6ー
2. Sticking Position of Warning Notice (Label)
1
3
2
For safety's sake, warning notice (label) is
sticked to below mentioned position of our
products.
Keep the label clean and free of breakage.
If it is broken or missed, replace it with a
new one. When ordering labels, be sure to
mention the relative part number printed at
the bottom right corner of it.
2. Sticking Position of Warning Notice (Label)

ー7ー
2. Sticking Position of Warning Notice (Label)
Detail of Warning Notice (Label)
① 3998-06140-0
② 3998-16491-2
③ 3998-16490-0
Noise and vibration value of this machine are as follows:
Noise
(a) Operating conditions and measuring method
Place the machine on the soil and raise its rpm up to full throttle(3,800 rpm) and measure
the noise using microphones set up at the position 1.5 m above ground and 7 m apart
from the front, rear, left and right ends of the machine.
(b) Measured value
Equivalent continuous A weighted sound pressure level......81 dB(A)
Vibration
(a) Operating conditions and measuring method
Place the machine on the soil and raise its rpm up to full throttle (3,800 rpm) and measure
the vertical vibration acceleration at the hand grip portion of the handle.
(b) Measured value
Root mean square value......32.0 m/sec2
• Read the operator's manual thoroughly before operating
the machine.
• Incorrect operation can cause severe injury or death.
• It is your responsibility to operate the machine safely.
3998-16491-2
WARNING
3998-16490-0
• Do not approach, or allow objects to
touch, the rotating parts.
• Body parts contacting rotating mechanism
will be severed.
DANGER

ー8ー
3. Inspection before operation
3.1. Engine
Refer to a separate Engine Operation
Manual for the engine.
3.2. Checking engine oil
①Remove the oil gauge and wipe off oil
stuck on the gauge with a rag.
②Push the oil gauge against the oil fill port
without screwing it in to check oil level.
③Refill oil until it comes to the upper limit
mark when the level is insufficient.
3. Inspection before operation
Oil gauge
Fill port
Drain plug
Maximum oil level
Minimum oil level
(Refill is required)
Be sure to check and refill oil with the engine held level.
Check the oil level again at approx. 3 minutes after it has been refilled.
Do not supply oil more than the specified since over-supply of oil may
result in blowing out of oil and poor output of the engine.
Shortage of oil may cause seizure of the engine.
If an oil other than the specified is used, service life of engine is likely to
be shortened.
•
•
•
•
IMPORTANT
Screw in the oil gauge
securely after oil level has
been checked and refilled.
•
CAUTION
3.3. Checking oil in the vibrator
Remove the plug out of the fill-drain port
in the vibrator with the machine body held
level and check that the oil is filled up to the
mouth of oil fill-drain port.
If it is found insufficient, supply oil to the
extent that it comes full to mouth of the
port.
Fill drain plug

ー9ー
3.4. Checking fuel
3. Inspection before operation
Remove the cap on the fuel tank to check remaining oil visually. Refill fuel if it is found
insufficient.
Fuel to be employed: Regular gasoline for automobile
Fuel tank capacity: 2.5 liters
Wipe off fuel thoroughly when it has been spilled out.
Be sure to stop the engine when filling fuel.
Tighten the cap on the fuel tank securely after fuel has been
filled up.
•
•
•
WARNING
In order to prevent fuel from being blocked. Be sure to fill up
fuel through a filter.
•
CAUTION
Be sure to check if it is the right fuel before refilling fuel.•
WARNING
3.5. Checking bolts and nuts for their tightness
Bolts and nuts are likely to become loose due to vibration of the machine body.
If it is operated with the bolts and/or nuts loosened, lowering in function and damage to the
machine may result. Inspect the machine body to re-tighten any loosened bolts and nuts.
Oil leaks out of the bleeder in the vibrator if the machine is
left for a long period of time with the machine fallen down to
the right or to the left. Do not block the bleeder except when
it is necessary such as in carrying out a repair.
•
CAUTION

ー10ー
4. Starting-up
4. Starting-up
(1) Open fuel cock full.
(2) Move speed control lever to half-open
position.
(3) Turn carburetor choke lever to fully
closed position to facilitate ignition.
(Turn lever to haft-open position if
engine is warm or when starting in warm
weather.)
Fuel cock
Open
Speed control lever
Fully open
Slow
Close
Choke lever
Open

ー11ー
4. Starting-up
(4) Turn the engine switch ON.
(5) Pull the starting knob forcibly.
Start the engine after looking around to confirm the safety of
its surroundings .
Hold the handle securely with your left hand to fix the
machine body and pull the starter knob forcibly with your
right hand to start the engine.
When pulling up the starter knob, pull it from immediately
behind the handle to prevent your hand from hitting the han-
dle.
•
•
•
WARNING
ON
Engine switch
Do not pull out the rope up to its extreme. And when return-
ing the rope, return it slowly as an abrupt release of the rope
will cause damage to the cover with a shock.
•
CAUTION

ー12ー
4. Starting-up
Warm-up the engine at an idling speed for 1 to 3 minutes
after the engine has been started.
If the engine fails to start, check the spark plug and the fuel
system for blockage.
•
•
CAUTION
(6) Shift the choke lever to Fully open posi-
tion after the engine has been started.

ー13ー
5. Operation
5. Operation
(1) Shift the speed control lever to Full throttle after the warm-up operation has been com-
pleted.
(2) The compactor moves forward while
vibrating.
Do not operate the engine with an intermediate speed as the
centrifugal clutch repeats ON and OFF in this speed which
may result in seizure of the engine.
•
CAUTION
Do not apply vibration to an hard surface such as the con-
crete board.
Do not get your hands off the handle while operating.
When operating the compactor on a slope, operate it within
a gradient of 1/4 (approx. 14 degrees).
When operating the compactor on a rugged surface or on
a surface with a sharp level difference, the compactor may
easily tumble over or slip. Take care that you will not be
injured in your wrist.
Be sure to stop the engine before leaving the compactor
unattended.
•
•
•
•
•
CAUTION

ー14ー
(3) If the compactor is slow in its speed,
check if soil or other surface materials
are stuck to the tamping plate.
Scrape them off the plate if they are.
[Advice] When operating the compactor
on a steep slope, hitch a towing
rope to the compactor to pro-
vide some assistant pull for an
effective works.
5. Operation
(4) Turn the sprinkling faucet to “OPEN”
position to sprinkle water.
Close
Open
How to remove the sprinkling tank
①Close the faucet of sprinkling tank.
②Depress the socket button to remove the
plug.
③Raise the sprinkling tank with your both
hands.
Socket button
Close
Plug

ー15ー
Check the sprinkling tank for
water quantity before starting
sprinkling water. Supply the
tank with water if it is found
insufficient.
Be sure to use only clean water
for sprinkling.
•
•
IMPORTANT
When in cold season,
drain the water remained
in the sprinkling tank and
in the hoses completely
after completion of the
work to prevent the water
from being frozen up.
CAUTION
5. Operation

ー16ー
6. Shutting down
(2) Turn the engine switch OFF.
6. Shutting down
(1) Return speed control lever to the lowest speed position and allow the engine to run for 1
to 2 minutes for cooling.
Do not stop engine immediately after high-speed operation,
otherwise oil deteriorates or motion members are stuck fast
since the engine temperature rises suddenly.
•
CAUTION
OFF
Engine switch
