Jolly
Electric piston pump
on trolley with accessories
K 56500
on frame with accessories
K 56501
EN
OPERATING AND MAINTENANCE MANUAL

Due to a constant product improvement programme, the factory reserves the right to modify
technical details mentioned in this manual without prior notice.
This manual is to be considered as an English language translation of the original manual in Italian.
The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to
the incorrect translation of the instructions contained within the original manual in Italian.

JOLLY
www.larius.com
1
REV. 01 - 09/2020 - Cod. 150165
Jolly
Electric piston pump
A
C
D
B
E
H
G
F
I
M
N
J
K
L
O
P
Q
R
S
T
U
V
W
X
Y
Z
WE ADVISE THE USE OF THIS EQUIPMENT ONLY BY PROFESSIONAL OPERATORS.
ONLY USE THIS MACHINE FOR USAGE SPECIFICALLY MENTIONED IN THIS MANUAL.
Thank you for choosing a LARIUS S.R.L. product.
As well as the product purchased, you will receive a range of support services
enabling you to achieve the results desired, quickly and professionally.
INDEX
WARNINGS ..................................................................................................................................................................2
WORKING PRINCIPLE .................................................................................................................................................3
TECHNICAL DATA ........................................................................................................................................................4
DESCRIPTION OF THE EQUIPMENT ..........................................................................................................................5
TRANSPORT AND UNPACKING ..................................................................................................................................7
CONDITIONS OF GUARANTEE ...................................................................................................................................7
SAFETY RULES............................................................................................................................................................7
PIPE CONNECTION .....................................................................................................................................................9
OPERATION................................................................................................................................................................12
CLEANING AT THE END OF THE WORK...................................................................................................................14
GENERAL MAINTENANCE ........................................................................................................................................15
ROUTINE MAINTENANCE .........................................................................................................................................15
WARNING PLATES.....................................................................................................................................................16
CORRECT PROCEDURE OF DECOMPRESSION ..................................................................................................17
REPLACEMENT OF THE PUMPING GROUP’S GASKETS........................................................................................18
TROUBLESHOOTING ................................................................................................................................................27
SPARE PARTS
RECIRCULATING-SAFETY VALVE GROUP ...............................................................................................................30
FRAME .......................................................................................................................................................................31
COMPLETE ELECTRO-MECHANICAL ......................................................................................................................32
TROLLEY....................................................................................................................................................................34
COMPLETE HYDRAULIC GROUP .............................................................................................................................36
COMPLETE ELECTRO-HYDRAULIC DRIVING GROUP ............................................................................................38
SUCTION AND RECIRCULATION KIT ON FRAME ....................................................................................................41
SUCTION AND RECIRCULATION GROUP ON TROLLEY .........................................................................................42
ELECTRIC MOTOR ....................................................................................................................................................43
ACCESSORIES...........................................................................................................................................................45
CE DECLARATION OF CONFORMITY.......................................................................................................................49

JOLLY
www.larius.com
2
REV. 01 - 09/2020 - Cod. 150165
A
The table below provides the meaning of the symbols used in this manual in relation to using, earthing, operating, maintaining, and
repairing of this equipment.
WARNINGS
A










FIRE AND EXPLOSION HAZARD

To help prevent fire and explosion:
- Use equipment ONLY in well ventilated area.
- Eliminate all ignition sources, such as pilot lights, cigarettes and plastic drop cloths (potential static arc).

- Use only grounded hoses.
               
pressurized aluminium equipment. Such use can cause serious chemical reaction and equipment rupture, and result in death,


must be stopped immediately.







-




It indicates important recommendations about disposal and recycling process of products in accordance with the environmental
regulations.




To help prevent injection, always:
- (IF PROVIDED) Engage trigger lock when not spraying.

- (IF PROVIDED) Do not point gun at anyone or at any part of the body.
- (IF PROVIDED) Never spray without tip guard.
- Do pressure relief if you stop spraying or being servicing sprayer and before any maintenance operations.

- Never allow children to use this unit
- (IF PROVIDED) Brace yourself; gun may recoil when triggered.
If high pressure fluid pierces your skin, the injury might look like “just a cut”, but it is a serious wound!
Get immediate medical attention.




equipment during the work, inspection, or maintenance cycles.

JOLLY
www.larius.com
3
REV. 01 - 09/2020 - Cod. 150165
WORKING PRINCIPLE
B
The LARIUS JOLLY
An electric piston pump is used for high pressure painting without
air (from this process derives the term ”airless”).
The pump is controlled by an electric motor coupled with a
reduction gear.
A cam shaft and a connecting rod allow to obtain the reciprocating


The product is sucked, pushed towards the pump outlet and then



out of the pump.
When the pump reaches the set value, the motor stops and starts
again when the value decreases.
A safety valve avoiding overpressure, guarantees the total relia-
bility of the equipment.
INDICATIONS OF USE
To ensure correct operation of the airless electric piston equipment

of power that is less than that indicated may compromise the
integrity and the correct operation of the equipment.
The use of electric cables with a diameter of at least 2.5mm2 is
recommended; ensure system grounding on the motor generator.
 JOLLY minimum 4,0 kW single-phase
 JOLLY Top Finish mist-less minimum 4,0 kW single-phase
 NEW EXCALIBUR minimum 4,0 kW single-phase
 ZEUS minimum 5,0 kW single-phase
 DRAGON minimum 5,0 kW single-phase
 THOR minimum 6,0 kW single-phase
PAINT
Use special paint for airless applications
NOZZLE
Pair the nozzle with the type of work to be carried out in order to


number indicates the diameter of the mouth while the second
number indicates the spraying angle.
Fields of application Applications materials
Indoor Lacquer Paints
Outdoor Waterborne Emulsions
Industrial buildings Acrylic Impregnants
Industrial constructions Primer Antirust
Redeveloping Enamels Primer
Roofing Fixative
Fig. 1B
Version on TROLLEY
Fig. 2B
Version on FRAME

JOLLY
www.larius.com
4
REV. 01 - 09/2020 - Cod. 150165
JOLLY Versione su TELAIO Versione su CARRELLO
SUPPLY (single-phase)* 230Vac - 50Hz 230Vac - 50Hz
Motordrive supply minimo 4Kw asincrono minimo 4Kw asincrono
Motor power 0,65 Kw 0,65 kW
Max working pressure 210 bar 210 bar
Max. delivery 1,8 L/min 1,8 L/min
Material outlet M16 x 1,5 (M) M16 x 1,5 (M)
Ma. dimension of the gun nozzle 0,019” 0,019”
Weight 15 Kg 16 Kg
Sound pressure level ≤ 80dB(A) ≤ 80dB(A)
Length (A) 450 mm (A) 580 mm
Width (B) 460 mm (B) 540 mm
Height (C) 550 mm (C) 995 mm
TECHNICAL DATA
C
*Available on request with special voltages
PARTS OF THE PUMP IN CONTACT WITH THE MATERIAL Stainless Steel AISI 420B, PTFE, Aluminium
Fig. 1C
Version on FRAME
Fig. 2C
Version on TROLLEY
A
B
C
C
A
B

JOLLY
www.larius.com
5
REV. 01 - 09/2020 - Cod. 150165
D
Version on FRAME
DESCRIPTION OF THE EQUIPMENT
Pos. Description
1 Recirculation tube
2 Output product recirculation
3 Safety-recirculation valve
4 Suction filter
5 Plug filter
6 Pumping group
7 ON/OFF switch
8 Potentiometer for adjusting the operating pressure
Pos. Description
9 Suction product pipe
10 Coupling for product delivery
11 Alarms indicator light
12 Airless manual gun
13 Trigger safety clamp
14 Reduction box
15 Handle/Handgrip
16 Frame
Fig. 1D
4 16 10 5 6
2
3
1 1523 14
22 9
7
8
23
13
12
8
11
7
5
10
3

JOLLY
www.larius.com
6
REV. 01 - 09/2020 - Cod. 150165
Press here to
unlock
Pos. Description
17 Trolley
18 Suction tube
19 Recirculation hose
20 Wheel
Pos. Description
21 Product delivery tube coupling
22
Unlocking manual device
23 Electric motor
24 Product delivery tube
Fig. 2D
Version on TROLLEY
21
19
17
24
18
20
18
19
22

JOLLY
www.larius.com
7
REV. 01 - 09/2020 - Cod. 150165
E G
Read carefully and entirely the following instruc-
tions before using the product. Please save these
instructions in a safe place.
The unauthorised tampering/replacement of one
or more parts composing the machine, the use
of accessories, tools, expendable materials other
than those recommended by the manufacturer
can be a danger of accident.
The manufacturer will be relieved from tort and
criminal liability.
F
          
symbols and markings on the outside of the packing.
 
used is large enough for such purposes, is properly lit and

 
   

 
trained personnel (truck and crane operators, etc.) and also
suitable hoisting equipment for the weight of the installation
or its parts.
Follow carefully all the safety rules.
The personnel must be equipped with the necessary safety
clothing.
 
operations and transport to the workplace of the machine.
 
Unpack the machine and verify if there has been any damage
due to transportation.
In case of damage, call immediately LARIUS and the Shipping
Agent. All the notices about possible damage or anomalies
must arrive timely within 8 days at least from the date of
receipt of the plant through Registered Letter to the Shipping
Agent and to LARIUS.
 
ALL THOSE RISKS STEMMING FROM ACCIDENTS, ABOUT
THE USE OF SAFETY DEVICES FOR THEIR OWN SAFE-
TY AND ABOUT THE GENERAL RULES FOR ACCIDENT
PREVENTION IN COMPLIANCE WITH INTERNATIONAL
REGULATIONS AND WITH THE LAWS OF THE COUNTRY
WHERE THE PLANT IS USED.
 
COMPLY WITH THE ACCIDENT PREVENTION AND ALSO
ENVIRONMENTAL REGULATIONS IN FORCE IN THE
COUNTRY WHERE THE PLANT IS INSTALLED AND USED.
 
WHERE YOU ARE WORKING CREATES A POTENTIAL RISK
OF ACCIDENTS.
 
STANCE.
        
DAMAGED PARTS AND THE MACHINE CAN WORK PRO-
PERLY.
 
AND THE REGULATIONS IN FORCE.
        
EQUIPMENT OUT OF THE WORK AREA.
      
INDICATED.
        
AT OTHER PEOPLE. THE CONTACT WITH THE CASTING
CAN CAUSE SERIOUS INJURIES. IN CASE OF INJURIES
CAUSED BY THE GUN CASTING, SEEK IMMEDIATE ME-
DICAL ADVICE SPECIFYING THE TYPE OF THE PRODUCT
INJECTED. NEVER UNDERVALUE A WOUND CAUSED BY
THE INJECTION OF A FLUID.
      
THE PRESSURE IN THE CIRCUIT BEFORE PERFOR-
MING ANY CHECK OR PART REPLACEMENT OF THE
EQUIPMENT.
 
REGULARLY THE COMPONENTS OF THE SYSTEM. RE-
PLACE THE PARTS DAMAGED OR WORN.
TRANSPORT
AND UNPACKING
SAFETY RULES
The conditions of guarantee do not apply in the
following situations:
- improper washing and cleaning of components
causing malfunction, wear or damage to the
equipment or any of its parts;
- improper use of the equipment;
- use that does not conform with applicable
national legislation;
- incorrect or faulty installation;
- modifications, interventions and maintenance
that have not been authorised by the manufacturer;
- use of non-original spare parts or parts that do
not correspond to the specific model;
- total or partial non-compliance with the
instructions provided.
CONDITIONS OF GUARANTEE
The disposal of packaging materials is a custo-
mer’s competence and must be performed in
accordance with the regulations in force in the
country where the plant is installed and used.
It is nevertheless sound practice to recycle
packaging materials in an environment-friendly
manner as much as possible.

JOLLY
www.larius.com
8
REV. 01 - 09/2020 - Cod. 150165
Thehigh speedof theproductin thehose cancreate
static electricity through discharges and sparks.
It is suggested to earth the equipment.
The pump is earthed through the earth cable of
the supply.
The gun is earthed through the high pressure
flexible hose.
All the conductors near the work area must be
earthed.
Always check the product is compatible with
the materials composing the equipment (pump,
spray gun, flexible hose and accessories) with
which it can come into contact. Never use paints
or solvents containing halogen hydrocarbons (as
the methylene chloride).
If these products come into contact with alu-
minium parts can provoke dangerous chemical
reactions with risk of corrosion and explosion.
If the product to be used is toxic, avoid inhalation
and contact by using protection gloves, goggles
and proper face shields.
Take proper safety measures for the protection
of hearing in case of work near the plant.
Never attempt to tamper with the calibre of
instruments.
Electrical safety precautions
 
the cable to the mains .
 Never carry a plugged-in equipment.
 Disconnect the equipment before storing it and before perfor-
ming any maintenance operation or replacing of accessories.
 Do not carry the equipment neither unplug it by pulling the
electric cable.
 Protect the cable from heat, oil and sharp edges.
 Take care when the pumping rod is moving.
Stop the machine whenever someone is within its vicinity.
 Repairs of the electrical equipment should only be carried
out by skilled personnel, otherwise considerabledanger to
the user may result.
 -
TION BETWEEN PUMP, FLEXIBLE HOSE AND SPRAY GUN
BEFORE USING THE EQUIPMENT.
 -
DARD KIT. THE USE OF ANY ACCESSORIES OR TOOLING
OTHER THAN THOSE RECOMMENDED IN THIS MANUAL,
MAY CAUSE DAMAGE OR INJURE THE OPERATOR.
 
VERY DANGEROUS. HANDLE THE FLEXIBLE HOSE CARE-
FULLY. DO NOT PULL THE FLEXIBLE HOSE TO MOVE THE
EQUIPMENT. NEVER USE A DAMAGED OR A REPAIRED
FLEXIBLE HOSE.

JOLLY
www.larius.com
9
REV. 01 - 09/2020 - Cod. 150165
H
Make sure that the electrical system is earthed
and complies with regulations.
Should anyone use an extension cable between
the unit and the socket, it must have the same
characteristics as the cable supplied (minimum
diameter of the wire 2.5 mm2)with a maximum
length of 50 mt. Higher lengths and lower dia-
meters can cause excessive voltage falls and a
bad operation of the equipment.
•Check the mains voltage corresponds to 230 Vac - 50Hz.
•The supply electric cable (H4) of the equipment is provided
without the plug. Use a plug which guarantees the plant
earthing. Only a technician or a skilled person should perform
the connection of the plug to the electric cable.
Check on power supply
PIPE CONNECTION
Connecting the flexible hose to the gun
 H1) to the pump
(H2) and to the gun (H3
use of two wrenches is suggested).
 
It is ADVISED to mount a high pressure manometer at the

pressure.
 
kit (ref. 18036).
 
H4
Fig. 1H
Fig. 2H
Fig. 3H
H1
H2
H3

JOLLY
www.larius.com
10
REV. 01 - 09/2020 - Cod. 150165
Connecting the equipment to the power supply
 Check that the switch (H5) is on the OFF(0) position before
connecting the cable to the mains.
 Place the pressure control knob (H6) on theMINposition
(turn counterclockwise).
 
washing liquid.

Press the equipment main switch (H5) on pos. “ON” (I).
 Open the recirculation-safety valve (H7).
Washing of the new equipment
 
light mineral oil left inside the pumping group as protection.
Therefore, wash with diluent before sucking the product.
 H3) is without nozzle.
OFF
ON
OPEN
It re-circulates back into
the tank without spraying
CLOSED
It sprays out of
the spray gun
Fig. 4H
Fig. 5H
Fig. 6H
Fig. 7H
Fig. 8H
H7
H5 H6
H5 H6
H3
H7 H7

JOLLY
www.larius.com
11
REV. 01 - 09/2020 - Cod. 150165
Never spray solvents indoor. In addition, it is re-
commended to keep far from the pump in order
to avoid the contact between the solvent fumes
and the electric motor.
Make sure the product to be used is compatible
with the materials employed for manufacturing
the equipment (stainless steel and aluminium).
For further information, please contact the supplier
of the product.
 Visually check that the washing liquid starts to re-circulate
within the tank (H8).
  (H6) counterclockwise
to stop the pump.
 Close the recirculating-safety valve (H7).
Turn the pressure regulating knob (H6) clockwise to the
see drops) so
that the machine idles.
 Remove the suction pipe (H9) and take away the solvent
tank (H8).
 Point the gun into the solvent tank (H8) and press the trigger
so as to recover the residual solvent.
 As the pump idles, press theOFF” (0) switch to stop the
unit.
 Point the gun (H3) into a collecting tank (H8) keeping the
trigger pressed (so as to drain the oil inside) till a clean solvent
comes out. Now, release the trigger.
 Now the machine is ready. Should you use water paints,
beside washing with the solvent, it is suggested to wash
with soap and and clean water.
 .
Recirculation
and
washing
Recirculation
and
washing
PREPARATION OF THE PAINT
 Make sure the product is suitable to be used with a spray
gun.
 
CLOSE-MESH (ref. 214) and LARGE-MESH (ref.215) LARIUS
METEX braids.
Never use products containing halogen hydrocarbons (as methyle-
ne chloride). If these products come into contact with aluminium
parts of the equipment, they can cause dangerous chemical

 Turn pressure regulating knob (H6) slightly clockwise so that
the machine idles.
Fig. 9H
H6
H8
Fig. 10H
Fig. 11H
H6
H6
Fig. 12H
H3 H8
Fig. 13H
H9

JOLLY
www.larius.com
12
REV. 01 - 09/2020 - Cod. 150165
 Open the recirculating-safety valve (I2) (turn clockwise so as
the pin slides on the cam track).
 Press the switch “ON” (I) of the equipment and turn slightly
the pressure control knob clockwise (I3), so as the machine
works at the idle speed.
 Make sure the product recycles from the recirculation tube (I4).
Version on TROLLEY
Version on FRAME
OPERATION
I
START OF THE PAINTING OPERATIONS
 Use the equipment only after performing all the SETTING
UP operations described above.
 Dip the suction pipe (I1) into the product tank.
Fig. 1I
I1
I1
Fig. 2I
Fig. 3I
I2
OPEN
It re-circulates back into
the tank without spraying
CLOSED
It sprays out of
the spray gun
Fig. I4
I2 I2
I3
Fig. I5
I4
Fig. I6

JOLLY
www.larius.com
13
REV. 01 - 09/2020 - Cod. 150165
Recirculating-safety valve: when working at the
maximum pressure available, releasing the gun
trigger can cause sudden increases of pressure.
In this case, the recirculating-safety valve opens
automatically discharging part of the product from
the recirculating tube.
Then it closes so as to go back to the previous
working conditions.
Never point the spray gun towards yourselves or
other people. The contact with the casting can
cause serious injuries.
In case of injuries caused by the gun casting, seek
immediate medical advice specifying the type of
the product injected.
For all alarms, the machine shuts down and signals
the type of abnormality by means of a series of
flashes.
As for alarm No. 6, light signalling through a se-
ries of uninterrupted flashes is provided without
machine shut-down. The operator must, however,
immediately connect the unit to an adequate
grounding system.
LARIUS assumes no responsibility for failure to
comply with this requirement.
 Close the recirculating-safety valve (I2) (turn clockwise to
release the valve).
 
hose is full up to the set pressure.
Then it will automatically stop.
 (I3).
SPRAY ADJUSTMENT
 Slowly turn clockwise the pressure control knob to reach the
pressure value in order to ensure a good atomization of the
product.
 An irregular and marked spray on the sides indicates a low
working pressure. On the contrary, a too high pressure
causes a high fog (“overspray”) and waste of product.
 In order to avoid overthickness of paint, let the gun advance
sideways (right-left) when spraying.
 Always paint with regular parallel bands coats.
 Keep a safety and constant distance between the gun and
the support to be painted and also keep yourselves perpen-
dicular to it.
PROCEDURE TO UNLOCK THE SUCTION GROUP BALL
Should the ball of the suction group be blocked, the unit does
not suck the product anymore.

 I5).
PRESS
ALARMS
 I6
Fig. 7I
I2
I5
Fig. 8I
Fig. 9I
I6

JOLLY
www.larius.com
14
REV. 01 - 09/2020 - Cod. 150165
LED ALLARMI - ALARMS
WARNMELDUNGEN - ALARME
1
CORRENTE MASSIMA SUPERATA
MAXIMUM CURRENT EXCEEDED
MAX. STROM ÜBERSCHRITTEN
MAXIMUM COURANT DÉPASSÉE
2
SURRISCALDAMENTO HEAD CONTROL
OVERHEATING HEAD CONTROL
ÜBERHITZUNG HEAD CONTROL
SURCHAUFFAGE HEAD CONTROL
3
MOTORE IN CORTO CIRCUITO
MOTOR SHORT CIRCUIT
MOTOR IN KURZSCHLUSS
MOTEUR COURT-CIRCUITÉ
4
TENSIONE DI ALIMENTAZIONE ALTA
HIGH VOLTAGE FEEDING CURRENT
HOHE VERSORGUNGSSPANNUNG
TENSION D’ALIMENTATION À L’ENTRÉE TROP ÉLEVÉE
5
TENSIONE DI ALIMENTAZIONE BASSA
LOW VOLTAGE FEEDING CURRENT
NIEDRIGE VERSORGUNGSSPANNUNG
TENSION D’ALIMENTATION À L’ENTRÉE TROP FAIBLE
6
MANCANZA CONNESSIONE A TERRA
NO EARTHING
KEINE ERDUNG
PAS DE MISE À TERRE
7
SENSORE DI PRESSIONE GUASTO
PRESSURE SENSOR FAULT
DRUCKKNOPFANSCHLUSS DEFEKT
CAPTEUR DE PRESSION EN PANNE
8
BLOCCO RICIRCOLO (DOPO 15 MIN.)
RECYCLING STOP (AFTER 15 MIN.)
ABSCHALTUNG DES RUCKLAUFS (NACH 15 MIN.)
ARRET RECYCLAGE (APRÈS 15 MIN.)
Continuous flashing indicates
a lack of grounding connection
while the machine continues
to work.
The operator must, however,
immediately connect the unit
to an adequate grounding
system.
LARIUS assumes no responsi-
bility for failure to comply with
this requirement.
Reduce pressure to the minimum (turn counterclockwise the
pressure control knob) (J1).
Press the switch (J2) 
to stop the equipment.
 
of the gun and pointing it into a container.
 Open the recirculating-safety valve (J3) to release the pressure
in the circuit.
 Lift the suction pipe and replace the product container with
the solvent tank (ensure it is compatible with the product
being used).
 Unscrew the gun nozzle (remember to clean it with solvent).
Press the switch (J2) ON and slightly turn the pressure
control knob (J1) clockwise so as the machine works till
the motor starts.
 Make sure the solvent recycles the washing liquid from the
recirculation tube.
 Close the recirculating-safety valve (J3).
 Point the gun (J4) into the product container (J5) and, keeping
the trigger pressed, release the remaining product till a clean
solvent comes out. Now, release the trigger.
CLEANING AT THE END OF
THE WORK
J
Fig. 1J
J1
J2
J3
Fig. 2J

JOLLY
www.larius.com
15
REV. 01 - 09/2020 - Cod. 150165
Follow the washing procedure before using again
the equipment.
Before performing any maintenance operation,
discharge the pressure in the pumping unit (open
the drain valve).
ALWAYS DISCONNECT THE POWER SUPPLY
AND RELEASE THE PRESSURE IN THE PUMPING
GROUP (open the drain valve) BEFORE TIGHTE-
NING THE PACKING NUT.
 Lift again the suction pipe and remove the solvent tank.
 Now point the gun into the solvent tank and press the trigger
so as to recover the residual solvent.
As the pump starts idling, press the switch OFF (0) to
stop the equipment.
 In case of long storage, we recommend you to suck and
to leave light mineral oil inside the pumping group and the
.
DAILY
 
 
 
PERIODICALLY
 (if the product draws,
replace the gaskets);
 (spray guns,
etc.);
 
GENERAL MAINTENANCE
K
CHECK ON THE PACKING NUT
Daily check the packing nut is tight in order to avoid wastes but
not excessively to prevent the piston from seizing and the
gaskets from wearing.
 For tightening, use the wrench supplied (ref. 11503).
Rif. 11503
Adjusting
wrench
Oil ring
ROUTINE MAINTENANCE
L
 Use the lubricant supplied (ref. 16340) to allow an easy sliding
of the piston inside the gasket group.
Daily top up the packing nut.
OIL
Rif. 16340
J4 J5
Fig. 3J
Fig. 1L
Fig. 2L

JOLLY
www.larius.com
16
REV. 01 - 09/2020 - Cod. 150165
M
MODELLO
MATRICOLA
ANNO DI
COSTRUZIONE
MADE IN ITALY
WWW.LARIUS.EU
WARNING PLATES
Art. 16801
Art. 16858
Art. 16859
Art. 16854
Art. 16852
Art. 56524
Art. 8079
Art. 18677

JOLLY
www.larius.com
17
REV. 01 - 09/2020 - Cod. 150165
N
 Insert the gun clamp (N1).
 Move the switch (N2) to the OFF position to stop the
equipment.
Reduce pressure to the minimum (turn counterclockwise the
pressure control knob (N3)).
CORRECT PROCEDURE
OF DECOMPRESSION
 Disconnect the power supply cable (N4).
 Release the gun clamp (N1), point the gun into the tank of
the product and press the trigger to release pressure. At the
end of the operation, insert the gun clamp.
 Open clockwise the recirculating-safety valve (N5) to release
the residual pressure.
WARNING :
If the equipment is still under pressure after
performing the operations above described be-
cause of the nozzle or the flexible hose clogged,
proceed as follows:
• Loosen very slowly the gun nozzle.
• Release the clamp.
• Point the gun into the container of the product
and press the trigger to release pressure.
• Loosen very slowly the fitting of connection
from the flexible hose to the gun .
• Clean or replace the flexible hose and the
nozzle.
Clamp released
Clamp inserted
OFF
N1
Fig. 1N
Fig. 2N
N3
N2
Fig. 3N
N5
Fig. 2J
N4

JOLLY
www.larius.com
18
REV. 01 - 09/2020 - Cod. 150165
O
Always disconnect the power supply and di-
scharge pressure before performing the following
operations (follow the “correct procedure of
decompression”).
 Release the plastic covering (O2).
 Use a 19 mm spanner to unscrew the ring nut (O1) on the
feeding pipe in order to make the operation easier.
 Remove the locking pin (O5) using pliers (O6).
 Use a screwdriver (O3) to turn the motor(O4) until the piston
stem is at the bottom of its stroke and then move the rod
accordingly to remove it.
REPLACEMENT OF THE PUMPING GROUP’S GASKETS
       operation after having
cleaned the equipment.
    (O7), to the end of the thread
using a 45 mm spanner.
 Unscrew the suction casing using a 32 mm spanner as illu-
strated. If necessary, remove the suction pipe (O8) by means
of a 19 mm spanner before performing other operations.
O1
Fig. 1O
O2
Fig. 2O
Fig. 3O
O6
O5
Fig. 4O
Fig. 5O
O7
O8
Fig. 6O
