Sams DAS-10 Instruction manual

DAS-10
AES/EBU switcher 10x1
Copyright © 1999 - 2014 Sams elektronik d.o.o.
Published: 20. november 2009.
Updated: 28. october 2014.
Z10-3 edition 1
Code: 002.205
ENGLISH
Sams elektronik d.o.o.
48 Zivka Davidovica st.
11050 Belgrade
Serbia
Tel/Fax: [phone]
[phone]
[email protected]
www.sams.rs
USER MANUAL FOR USE AND MAINTENANCE
Read the instructions before using the device.
Keep this manual for periodic usage.

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
2
Dear User,
Thank you very much for purchasing our product.
Your purchase is a wise investment. The equipment you have purchased is manufactured with great care from
high-quality parts and materials. It is designed to fully meet the needs according to specications, if properly
installed, used and maintained according to the enclosed instructions.
Any technical failure or deciency that occurs during the warranty period specied on the invoice of the
purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of
the manufacturer, with the conditions set out in the warranty statement.
THIS DEVICE IS INTENDED FOR PROFESSIONAL USE.
WARRANTY STATEMENT
1. Product has declared characteristics. Within the warranty period, manufacturer ensures the removal of
technical failures, product defects or replacement of products if declared characteristics of the product are
changed.
2. If the goods are not delivered as specied with the contract, the consumer has the right to request from the
manufacturer / service provider to eliminate the lack of conformity, without charge, repair or replacement,
or to request an appropriate price reduction or terminate the contract.
3. Any repair or replacement must be made within a reasonable time without signicant inconvenience to
the consumer, taking into account the nature and the purpose for which the consumer has purchased the
product.
4. The consumer has the right to terminate the contract, if he can realize the right to repair or replacement,
or if the manufacturer / servicer has not completed repair or replacement within a reasonable time or if
the manufacturer / servicer did not perform repair or replacement without signicant inconvenience to the
consumer.
5. The consumer may not terminate the contract if the lack of conformity of the product is negligible.
6. The product will function properly when used in accordance with the user manual.
7. Period of servicing the product is 6 years from the launch on the market.
The product purchased outside the territory of Serbia does not fall under the terms of this warranty, only to 1
year factory warranty from date of purchase.
TERMS OF WARRANTY
1. The warranty period begins on the date of sale referred in the invoice.
2. The buyer loses the right to warranty if the defect cause failure from not following the user manual
instructions, improper installation, comes to mechanical damage during use, repairs and modications by
unauthorized persons, installation of non-genuine spare parts, and if the buyer does not comply with all
warnings listed in the user manual.
3. The warranty is voided if the device is damaged during the disturbances from the environment, natural
disasters (oods, hail, etc.), suffered an electric shock or lightning strike.
IMPORTANT NOTES
1. Be sure to thoroughly read the user manual.
If you have any doubts about the instructions, contact the technical support of the manufacturer.
2. Before contacting for technical help, please make sure that are provided with all necessary conditions for
normal operation.
3. If the malfunction or defect in the device does not eliminate within a reasonable time from the date of
failure, the warranty period shall be extended for as many days as the unit is in service.
4. For all maintenance interventions shall solely be authorized services listed in this Warranty Certicate.
WARRANTY

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
3
IMPORTANT SAFEY
WARNING
TO AVOID RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THE UNIT TO MOISTURE OR RAIN
The symbol “lightning in a triangle” is to alert the user to the presence of
high voltage. In poor conditions the user may be exposed to shock.
The symbol “exclamation mark in a triangle” is to alert the user to comply by
the terms of use in user’s manual, which is supplied with the device.
SAFETY WARNINGS
ELECTRICAL SHOCK HAZARD
DO N OT O PEN
CAUTION
RIZIK OD S TRUJNOG UDARA
NE O TVARATI
DOK JE P OD N APONOM
UPOZORENJE
CLASS I DEVICE
Grounding is connected to the chassis of the device.
The power supply is protected with fuse against overload.

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
4
TECHNICAL SUPPORT AND SERVICE
Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In
the event that problems that occur can not be resolved, or if you have any questions regarding this
equipment or information about other products produced from Sams elektronik, contact your local sales
representative or call Sams elektronik directly through one of the ways listed below:
Sales: [phone]
Technical support: [phone]
Service: [phone]
Email:
Sales - [email protected]
Technical support and service - [email protected]
Web site: www.sams.rs
Address:
SAMS ELEKTRONIK d.o.o.
48 Zivka Davidovica st
11050 Belgrade
Serbia
WARNING
TO AVOID ELECTRIC SHOCK, DO NOT OPEN COVER.
DEVICE MAINTENANCE REQUIRES PROFESSIONAL PERSON AUTHORIZED BY THE MANUFACTURER.
1. Read all safety and operating instructions before using the device.
2. Keep all safety and operating instructions.
3. Follow the instructions from the user manual.
4. Do not upgrade device, except in the case advised by the manufacturer.
5. Do not use the device in the presence of water and / or moisture.
6. Do not pour water or moisten the device with any type of liquid.
7. Openings on device are provided for ventilation.
8. Do not block air ow through the ventilation openings.
9. This product is powered by AC ~ 230V ± 10%, 50Hz.
10. This product is equipped with a three-wire cord with grounding.
11. This device is equipped with a protective fuse in the power outlet. Do not bypass fuse.
12. Do not replace the fuse. Replacement can be made by a person authorized by the manufacturer.
13. Do not bend the power cord so that it can be damaged.
14. Connect connectors as in the enclosed instructions. Deviations from the allowed values predicted
for the inputs and outputs of the device can cause severe damage and warranty void.
15. Do not use the device in an environment that contains ammable or explosive materials in any
physical state.
16. Turn off the power corde before cleaning. Do not use liquid, aerosol or ammable cleaners. Use
only a dry cloth.
17. Servicing is performed by a qualied person. Removing the cover user is exposed to high
voltages.
18. Never use the device when the cover is open and the device is powered on.
19. Do not expose to extreme high or low temperatures.
20. Do not expose to sudden temperature changes.
21. Call service in the following cases:
- The power cord or plug is damaged
- Liquid or foreign objects is inside the device
- The machine is exposed to water and moisture
- The device does not function according to specication
- The unit has been dropped or damaged
- The characteristics are signicantly changed
22. Use only specied replacement parts.
23. Professional person authorized by the manufacturer must check the device after completion of
service.
24. Allow a free rack unit (1RU) above and below the device for ventilation or put rack fan under the
device.
Pictures and drawings listed in this user manual are for information purposes only and may differ
from the actual device. Design and specications of the device may change without prior notice.

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
5
UNPACKING AND INSTALLATION....................................................................................6
MAINTENANCE..............................................................................................................6
REMOVAL AND STORAGE...............................................................................................6
DESCRIPTION...............................................................................................................7
INSTALLATION..............................................................................................................8
CABLE CONNECTION BETWEEN SWITCHER AND REMOTE ...............................................8
REMOTE CONTROL NSCU-10 .........................................................................................9
REMOTE CONTROL SCU-10............................................................................................10
IMPEDANCE ADJUSTMENT.............................................................................................11
SETTING THE DEVICE GROUNDING ...............................................................................12
CONFIGURATION AND CONNECTION, GRAPHIC EXAMPLE ...............................................12
NETWORK SETUP..........................................................................................................13
NETWORK ACCESS AND DEVICE CONTROL.....................................................................13
PROBLEMS AND SOLUTIONS IN A NETWORK ENVIRONMENT ..........................................15
SOFTWARE SUPPORT ....................................................................................................17
NOTES .........................................................................................................................18
PageDescription
TABLE OF CONTENTS

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
6
UNPACKING AND INSTALLATION
REMOVAL AND STORAGE
MAINTENANCE
The box contains:
- Device
- Power corde
- User manual (optional)
Before use, check the contents of the box. For any deciency report to the seller or the manufacturer
of the product.
DEVICE IS INSULATED BY PROTECTIVE WRAP AND PACKED IN A CARDBOARD BOX.
DEVICE IS SENSITIVE TO SHAKES AND DROPS. HANDLE WITH CARE DURING TRANSPORT
AND ASSEMBLY.
Check if the product is damaged during transport.
1. Before dismantling the device, switch off the power, remove
the power cord and remove all other connectors.
2. Remove the four screws for fastening.
3. Remove the device from rack cabinet.
4. Wrap the machine in the foil to protect it from dust. Package
it in a box.
5. The device must be stored in a room without moisture.
The system maintains only person authorized by Sams elektronik
doo.
Any voluntarily opening device, upgrading or servicing is strictly
prohibited and is subject to warranty void, and the possibility of
injury.
Places for fastening
PROCEDURES FOR SAFE USE OF THE DEVICE:
1. - Remove the protective wrap from the chassis.
- For devices that are AC 230V / 50Hz powered, the device is supplied with power cord.
- Use only power corde that comes with the device.
2. Device is mounted in a 19“ special-purpose rack cabinets designed for this type of device. Screw
device with four screws. Screws for fastening are not supplied with the device.
3. The device must be connected to ground. A device that is not connected to the grounding does
not function properly according to factory declarations and can cause adverse effects on users and
other equipment.
4. Strictly comply to all steps for proper connection of devices in the system.
Illustration - mounted device

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
7
DESCRIPTION
II
5
AES/EBU SWITCHERS
• Sams elektronik d.o.o. • 48 Zivka Davidovica st. • 11050 Belgrade • Serbia • • [phone]; [phone] • [email protected] • www.sams.rs •
DAS-10 is a 10x1 AES / EBU digital audio switcher. Input and output level has been mixed 75/110Ω and allows the
signal to be converted from balanced to unbalanced format without amplitude and phase distortion as it is achieved
by using transformers. High signal quality is achieved through the development in the SMD technology. Switcher
has automatic signals equalization. It is designed to meet the most demanding requirements for switching signals
in televisions and digital studios. Available in 1RU 19 “chassis. Control may be the front panel or by remote control
SCU-10. Also, the device can be controlled from a computer through a TCP-IP network. Can function independently
or be associated with related switcher for audio-follow-video control.
TECHNICAL SPECIFICATIONS
GENERAL INFORMATION
- Code: ....................................................................002.205
- Weight: ................................................................... 1.5 Kg
- Type: .........................................................1RU rack frame
- Dimensions: ........................................ 1RU x 19” x 100mm
- Required: ........................................ remote control SCU-10
- Delivery includes: ............. device, power corde, user manual
AES3 110Ω INPUT
- Connector: ......................................... 3-pin terminal switch
- Impedance: ...............................................................110Ω
- Max level: ................................................................7V p-p
- Min level: ............................................................. 0.2V p-p
AES3 110Ω OUTPUT
- Connector: ......................................... 3-pin terminal switch
- Impedance: ...............................................................110Ω
- Nominal level: ............................................3.1V p-p ± 10%
- Rising time: ......................................................4ηs to 31ηs
- Symmetry: .......................................< -30dB (DC at 6MHz)
- Jitter: ........................................ < 0.005UI at 700Hz/10KHz
ORDERING INFORMATION
Code Name Description
002.205 DAS-10 AES/EBU switcher 10x1
002.503 SCU-10L Remote control 10x1
Specications and designs are subject to change without notice
DAS-10
AES/EBU switcher 10x1
- 10x1 AES/EBU switcher
- 110Ω / 75Ω balanced / unbalanced inputs and
outputs
- 24bit / 32-96KHz sempling and processing
- Can function independently or be linked with other
10x1 switchers
- Return to the previous state due to power failure
- Local or remote control
- PC control
front side
rear side
EXTERNAL REFERENCE
- Number: ..................................................................1, BNC
- Word clock: ............................................................. 48KHz
TCP-IP
- Number: ................................................................1, RJ-45
POWER
- Voltage: ................................................. ~230V AC ± 10%
- Power: .......................................................................30W
- Frequency: ................................................................ 50Hz
- Overload protection: .............. front Mounted Circuit Breaker
TEMPERATURE
- Performance: .......................................................... 5-40°C
- Operating: .............................................................. 0-50°C

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
8
FUSE: 500mA
AC ~230V/50Hz
NETWORK
TCP/IP
OUTPUT
AES/EBU
AES/EBU INPUT
101 2 3 4 5 6 7 8 9
WORD
CLOCK
POWER
www.sams.rs
Made in Serbia
DAS-10
CODE: 002.205
SN:
+ – GG – +G – +G – +G – +G – +G – +G – +G – +G – +G – +
75Ω
110Ω110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
110Ω
75Ω
48KHz
REMOTE IN
REMOTE LOOP
MAC ADDRESS:
USE ONLY WITH A 250V FUSE
1
23
audio inputs
Buttons to select an input Panel lock
audio output
REMOTE / WORD CLOCK STATUS
GREEN - remote is ON / reference is ON
NOTE: WORD CLOCK (REFERENCE) is 48KHz audio signal
RED - remote is OFF / reference is ON
GREEN BLINK - remote is ON / reference is OFF
RED BLINK - remote is OFF / reference is OFF
4
NSCU-10sg
www.sams.rs
1 2 3 4 5 6 7 8 9 10 PAN. LOCK
Remote panel 10x1 with GPI
AES/EBU Digital audio switcher 10x1 (110Ω / 75Ω)
DAS-10
www.sams.rs
REMOTE / WORD CLOCK STATUS
GREEN - remote on / word clock on
RED - remote off / word clock on
GREEN BLINK - remote on / word clock off
RED BLINK - remote off / word clock off
Connect the power cord.
The device works only on AC ~ 230 V / 50 Hz.
external
reference TCP-IP
DAS-10, rear side
DAS-10, front side
Remote control - NSCU-10, front side
connection
with
remote
control
Connect all necessary connectors
before the unit is turned on.
Turn on the device by pressing
power switch.
Status is represented by LEDs on the front side
CABLE CONNECTION BETWEEN SWITCHER AND REMOTE
1 1
55
99
66
A0
GV-
A1
A0
A2
A3 A1
A2
A3
GV-
female male
2
3
4
7
8
2 3 4
78
Connector for Control Panel
SCU-10 (male/female) SUB D9 pin
NOTE: If the switcher is connected to the network, changes in inputs that are made in this way
remote control does not detect.
INSTALLATION

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
9
REMOTE CONTROL NSCU-10
The connection to
the switcher
NOTE: If the remote control is connected to the network, changes in inputs that are made in this
way are detected by remote control.
GPI
Ethernet
GPI connector
GPI
1 - GPI 1
2 - GPI 2
3 - GPI 3
4 - GPI 4
5 - GPI 5
6 - GPI 6
7 - GPI 7
8 - GPI 8
9 - GPI 9
10 - GPI 10
11-25 - GND
GPI PINOUT
www.sams.rs
SN:
MODEL:
REMOTE
NO USER - SERVICEABLE PARTS INSIDE!
REFER SERVICING TO QUALIFIED PERSONNEL!
NETWORK
TCP/IP
MAC ADDRESS:
To find this device through network
use Sams NETFINDER software.
Download software only from
www.sams.rs

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
10
REMOTE CONTROL SCU-10
The connection to
the switcher

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
11
IMPEDANCE ADJUSTMENT
In order to perform impedance changes, it is necessary
to open the device.
To change the input impedance to 75Ω, set jumper. Each
input can be independently configured. Jumpers are
marked with the name IJMP1.
Place the jumper at the input.
Place the jumper on the output.
110Ω
75Ω
The factory setting 110Ω
75Ω
75Ω110Ω
JMP1
JMP1
110R
110R
75R
75R
The output is factory set to 110Ω.
To change to 75Ω switch jumper as shown below.
Wiring inputs
Wiring output
G
+ +
G
-
-
+
G G
+

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
12
CONFIGURATION AND CONNECTION, GRAPHIC EXAMPLE
SETTING THE DEVICE GROUNDING
PC
Remote control
AES/EBU switcher
SDI switcher
In systems where it is required GROUND LIFT, this option is enabled by setting jumper OJ1.
The factory is not set.

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
13
NETWORK ACCESS AND DEVICE CONTROL
The device can be congured through the web browser. First, the device must be found in the local
network. To do this, start the Sams Netnder software double clicking on the icon. The software rst
scans for devices.
Sams Netnder: scan for devices
When the search is completed, a new window will open showing found devices.
NETWORK SETUP
To change the settings, consult your network administrator.
The default IP address is 192.168.0.200. If there is a DHCP server, the device will be assigned a new
address.
If there is a problem with connecting the device, check the rewall and allow UDP port 3040.
Sams Netnder: found devices
Click on the desired device and press the “Web Browser” located on the left side of the software.
Browser will display the conguration options.
NOTE:
The device will be found from across the network only if the device was connected to a network cable
before turning on.
If the program NETFINDER does not nd the device on the network, try the following:
- Connect the inserter directly to the computer;
- The computer set with xed IP address, as follows:
IP ADDRESS 192.168.0.15
SUBMASK IP 255.255.255.0
IP GATEWAY left blank;
- Set REPAIR network card, in order to fully accept the new settings (alternatively RELEASE / RENEW
scenario);
- Try NETFINDER;
- The device must be seen;
- Write down the MAC ADDRESS and consult with the network administrator.
NOTE:
Do not use simultaneously with multiple places control over the network!
Just enter the correct value in the permitted range.
The manufacturer does not guarantee the validity of the results of irresponsible use of the device.

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
14
After a few seconds, the page will open.
Web browser
WORD CLOCK status: f it is green, everything is OK. If it is red, check cable or source of reference.
Each number represents the buttons of incoming signal. Pressing the button connects the selected input
to the output.

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
15
If the software NETFINDER is not able to locate the device in the network try the following:
1. Right click on Local Area Connection
2. Select option “Change Windows Firewall settings”
3. When a window “Windows Firewall” opens select tab “Exceptions”
4. Click on button “Add program”
PROBLEMS AND SOLUTIONS IN A NETWORK ENVIRONMENT

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
16
5. Click button “Browse”.
6. Select application NETFINDER.
8. Click “Open”, and “OK”. “OK” and “OK”
If the above solution does not help, try the following:
1. Download from address “http://www.softcab.com/dhcp-server/index.php” Tiny DHCP server*.
2. Before installation, note down the MAC address of the device.
3. Turn off the UTP cable, and if your computer has another network access, BT, WiFi etc. - disable
them.
4. Network card on your computer set to a xed address 192.168.0.1, subnet mask 255.255.255.0,
default gateway and DNS leave blank.
5. Turn off all kinds of rewalls completely.
6. Install Tiny DHCP server.
7. In Tray icon will appear in the form of two shaking hands.
8. Click on that icon.
9. In the opened window, click the button “Add new”.
10. Enter the MAC address of the device (MAC address is entered without dashes, dots and spaces) and
press OK.
11. If the eld is not marked with the MAC address of the device, click on it.
12. In the right part of the window in the drop down menu instead of “Ask me” choose “Automaticallz
process the request”.
13. In the IP Address eld enter 192.168.0.200 (can be some other IP)
14. Connect the UTP cable to the computer and the other side to the device.
15. Turn on device.
16. Wait the computer to show “10mb connected...”

DAS
Switchers
Sams elektronik d.o.o. • [email protected] • www.sams.rs
elektronik
17
The device supports the development of specic software for customer needs, for remote conguration
of software for playout systems, sending specic commands to the device IP address.
Commands are sent in the format:
http://ip_address/get_data?cmd=value
LIST OF COMMANDS:
src - input selection. Enter in the form src=n (n - value from 0-9 representing inputs from 1-10)
ref - send feedback about status of word clock. Enter in form ref=. Feedback is 0 - no reference, 1 -
reference present
EXAMPLE:
http://[ip_adresa]/get_data?src=0
This means: rst input selected
NOTE:
- If you use a web browser for programming, we recommend that it be Mozilla Firefox®, with desabled
options to cache the page.
17. If the “tray” icon of DHCP server has not changed its color when you turn the device, turn the unit off, wait
for a while and turn it on again.
18. Start application NETFINDER.
* Tiny DHCP server is free software, which is owned by the publisher SoftCab, Inc.
SOFTWARE SUPPORT
PC
Building 1
TCP IP TCP IP
Inserter
Building 2
INTERNET

DAS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
18
NOTES
