Sams DS-4 Instruction manual

DS-4
SDI switcher 4x1
Copyright © 1999 - 2014 Sams elektronik d.o.o.
Published: 15. january 2006.
Updated: 29. october 2014.
Z10-3 edition 1
Code: 002.100
ENGLISH
Sams elektronik d.o.o.
48 Zivka Davidovica st.
11050 Belgrade
Serbia
Tel/Fax: +381 11 3806 253
+381 11 2402 212
www.sams.rs
USER MANUAL FOR USE AND MAINTENANCE
Read the instructions before using the device.
Keep this manual for periodic usage.

DS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
2
Dear User,
Thank you very much for purchasing our product.
Your purchase is a wise investment. The equipment you have purchased is manufactured with great care from
high-quality parts and materials. It is designed to fully meet the needs according to specications, if properly
installed, used and maintained according to the enclosed instructions.
Any technical failure or deciency that occurs during the warranty period specied on the invoice of the
purchased equipment will be inspected and serviced by Sams elektronik doo or an authorized service center of
the manufacturer, with the conditions set out in the warranty statement.
THIS DEVICE IS INTENDED FOR PROFESSIONAL USE.
WARRANTY STATEMENT
1. Product has declared characteristics. Within the warranty period, manufacturer ensures the removal of
technical failures, product defects or replacement of products if declared characteristics of the product are
changed.
2. If the goods are not delivered as specied with the contract, the consumer has the right to request from the
manufacturer / service provider to eliminate the lack of conformity, without charge, repair or replacement,
or to request an appropriate price reduction or terminate the contract.
3. Any repair or replacement must be made within a reasonable time without signicant inconvenience to
the consumer, taking into account the nature and the purpose for which the consumer has purchased the
product.
4. The consumer has the right to terminate the contract, if he can realize the right to repair or replacement,
or if the manufacturer / servicer has not completed repair or replacement within a reasonable time or if
the manufacturer / servicer did not perform repair or replacement without signicant inconvenience to the
consumer.
5. The consumer may not terminate the contract if the lack of conformity of the product is negligible.
6. The product will function properly when used in accordance with the user manual.
7. Period of servicing the product is 6 years from the launch on the market.
The product purchased outside the territory of Serbia does not fall under the terms of this warranty, only to 1
year factory warranty from date of purchase.
TERMS OF WARRANTY
1. The warranty period begins on the date of sale referred in the invoice.
2. The buyer loses the right to warranty if the defect cause failure from not following the user manual
instructions, improper installation, comes to mechanical damage during use, repairs and modications by
unauthorized persons, installation of non-genuine spare parts, and if the buyer does not comply with all
warnings listed in the user manual.
3. The warranty is voided if the device is damaged during the disturbances from the environment, natural
disasters (oods, hail, etc.), suffered an electric shock or lightning strike.
IMPORTANT NOTES
1. Be sure to thoroughly read the user manual.
If you have any doubts about the instructions, contact the technical support of the manufacturer.
2. Before contacting for technical help, please make sure that are provided with all necessary conditions for
normal operation.
3. If the malfunction or defect in the device does not eliminate within a reasonable time from the date of
failure, the warranty period shall be extended for as many days as the unit is in service.
4. For all maintenance interventions shall solely be authorized services listed in this Warranty Certicate.
WARRANTY

elektronik
3
IMPORTANT SAFEY
WARNING
TO AVOID RISK OF FIRE OR ELECTRIC SHOCK
DO NOT EXPOSE THE UNIT TO MOISTURE OR RAIN
The symbol “lightning in a triangle” is to alert the user to the presence of
high voltage. In poor conditions the user may be exposed to shock.
The symbol “exclamation mark in a triangle” is to alert the user to comply by
the terms of use in user’s manual, which is supplied with the device.
SAFETY WARNINGS
ELECTRICAL SHOCK HAZARD
DO N OT O PEN
CAUTION
RIZIK OD S TRUJNOG UDARA
NE O TVARATI
DOK JE P OD N APONOM
UPOZORENJE
CLASS I DEVICE
Grounding is connected to the chassis of the device.
The power supply is protected with fuse against overload.

DS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
4
TECHNICAL SUPPORT AND SERVICE
Sams elektronik has made every effort to ensure that the equipment works in perfect condition. In
the event that problems that occur can not be resolved, or if you have any questions regarding this
equipment or information about other products produced from Sams elektronik, contact your local sales
representative or call Sams elektronik directly through one of the ways listed below:
Sales: +381 11 3806 254
Technical support: +381 11 2402 212
Service: +381 11 4056 051
Email:
Web site: www.sams.rs
Address:
SAMS ELEKTRONIK d.o.o.
48 Zivka Davidovica st
11050 Belgrade
Serbia
WARNING
TO AVOID ELECTRIC SHOCK, DO NOT OPEN COVER.
DEVICE MAINTENANCE REQUIRES PROFESSIONAL PERSON AUTHORIZED BY THE MANUFACTURER.
1. Read all safety and operating instructions before using the device.
2. Keep all safety and operating instructions.
3. Follow the instructions from the user manual.
4. Do not upgrade device, except in the case advised by the manufacturer.
5. Do not use the device in the presence of water and / or moisture.
6. Do not pour water or moisten the device with any type of liquid.
7. Openings on device are provided for ventilation.
8. Do not block air ow through the ventilation openings.
9. This product is powered by AC ~ 230V ± 10%, 50Hz.
10. This product is equipped with a three-wire cord with grounding.
11. This device is equipped with a protective fuse in the power outlet. Do not bypass fuse.
12. Do not replace the fuse. Replacement can be made by a person authorized by the manufacturer.
13. Do not bend the power cord so that it can be damaged.
14. Connect connectors as in the enclosed instructions. Deviations from the allowed values predicted
for the inputs and outputs of the device can cause severe damage and warranty void.
15. Do not use the device in an environment that contains ammable or explosive materials in any
physical state.
16. Turn off the power corde before cleaning. Do not use liquid, aerosol or ammable cleaners. Use
only a dry cloth.
17. Servicing is performed by a qualied person. Removing the cover user is exposed to high
voltages.
18. Never use the device when the cover is open and the device is powered on.
19. Do not expose to extreme high or low temperatures.
20. Do not expose to sudden temperature changes.
21. Call service in the following cases:
- The power cord or plug is damaged
- Liquid or foreign objects is inside the device
- The machine is exposed to water and moisture
- The device does not function according to specication
- The unit has been dropped or damaged
- The characteristics are signicantly changed
22. Use only specied replacement parts.
23. Professional person authorized by the manufacturer must check the device after completion of
service.
24. Allow a free rack unit (1RU) above and below the device for ventilation or put rack fan under the
device.
Pictures and drawings listed in this user manual are for information purposes only and may differ
from the actual device. Design and specications of the device may change without prior notice.

elektronik
5
UNPACKING AND INSTALLATION....................................................................................6
MAINTENANCE..............................................................................................................6
REMOVAL AND STORAGE...............................................................................................6
DESCRIPTION...............................................................................................................7
INSTALLATION..............................................................................................................8
CABLE CONNECTION BETWEEN SWITCHER AND REMOTE ...............................................8
REMOTE CONTROL SCU-4 .............................................................................................9
NOTES .........................................................................................................................10
PageDescription
TABLE OF CONTENTS

DS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
6
UNPACKING AND INSTALLATION
REMOVAL AND STORAGE
MAINTENANCE
The box contains:
- Device
- Power corde
- Remote control (optional)
- Connection cable (optional)
- User manual (optional)
Before use, check the contents of the box. For any deciency report to the seller or the manufacturer
of the product.
DEVICE IS INSULATED BY PROTECTIVE WRAP AND PACKED IN A CARDBOARD BOX.
DEVICE IS SENSITIVE TO SHAKES AND DROPS. HANDLE WITH CARE DURING TRANSPORT
AND ASSEMBLY.
Check if the product is damaged during transport.
1. Before dismantling the device, switch off the power, remove
the power cord and remove all other connectors.
2. Remove the four screws for fastening.
3. Remove the device from rack cabinet.
4. Wrap the machine in the foil to protect it from dust. Package
it in a box.
5. The device must be stored in a room without moisture.
The system maintains only person authorized by Sams elektronik
doo.
Any voluntarily opening device, upgrading or servicing is strictly
prohibited and is subject to warranty void, and the possibility of
injury.
Places for fastening
PROCEDURES FOR SAFE USE OF THE DEVICE:
1. - Remove the protective wrap from the chassis.
- For devices that are AC 230V / 50Hz powered, the device is supplied with power cord.
- Use only power corde that comes with the device.
2. Device is mounted in a 19“ special-purpose rack cabinets designed for this type of device. Screw
device with four screws. Screws for fastening are not supplied with the device.
3. The device must be connected to ground. A device that is not connected to the grounding does
not function properly according to factory declarations and can cause adverse effects on users and
other equipment.
4. Strictly comply to all steps for proper connection of devices in the system.
Illustration - mounted device

elektronik
7
DESCRIPTION
II
4
SDI SWITCHERS
• Sams elektronik d.o.o. • 48 Zivka Davidovica st. • 11050 Belgrade • Serbia •
The DS-4 is a 4x1 serial digital video routing switcher for component or composite digital signal, with auto input
equalization and reclocking with EDH processing. This routing switcher is available as a standalone frame 1RU rack
size which may be ordered with or with out a local push button control panel. Control can be front the front panel or
from module mount local push button control SCU-4.
TECHNICAL SPECIFICATIONS
GENERAL INFORMATION
- Code: ....................................................................002.100
- Weight: ................................................................... 1.5 Kg
- Type: .........................................................1RU rack frame
- Dimensions: ........................................ 1RU x 19” x 100mm
- Required: .......................................... remote control SCU-4
- Delivery includes: ............. device, power corde, user manual
INPUT
- Number: ..........................................................................4
- Signal type: .......................................... SDI per SMPTE 259
- EQ: ..................Automatic to 100m with Belden 1694A cable
- Impedance: .................................................................75Ω
- Connectors: ................................................................ BNC
OUTPUT
- Number: ..................................................................1, dual
- Connectors: ................................................................ BNC
- Impedance: .................................................................75Ω
- Output level: ............................................... 800mV ± 10%
- Jitter: ........................................................< 0.2UI at 10Hz
- Delay: ............................................................. 15μs typical
BLOCK DIAGRAM
ORDERING INFORMATION
Code Name Description
002.100 DS-4 SDI switcher 4x1
002.501 SCU-4L Remote control 4x1
Specications and designs are subject to change without notice
DS-4
SDI switcher 4x1
- 4x1 SDI switcher
- Digital component or composite video
- Local or remote control
- All inputs are equalized
- Two outputs
- Reclocked outputs
- EDH processing
- Power down memory recovery
- Vertical interval switching per SMPTE RP 168-1993
- 540, 360, 270, 177, 143 Mb/s
SDI IN #1
(143-540Mbps)
SDI IN #2
(143-540Mbps)
SDI IN #3
(143-540Mbps)
SDI IN #4
(143-540Mbps)
SDI OUT #1
SDI OUT #2
AUTO
EQ
AUTO
EQ
AUTO
EQ
AUTO
EQ
RECLOCK
LOCAL OR REMOTE
CONTROL PANEL
VERTICAL INTERVAL
SWITCH PROC.
front side
rear side
POWER
- Voltage: ................................................. ~230V AC ± 10%
- Power: .......................................................................30W
- Frequency: ................................................................ 50Hz
- Overload protection: .............. front Mounted Circuit Breaker
TEMPERATURE
- Performance: .......................................................... 5-40°C
- Operating: .............................................................. 0-50°C

DS
Switchers
elektronik
Sams elektronik d.o.o. • [email protected] • www.sams.rs
8
1
23
Power
Lock
FUSE: 500mA
AC ~230V/50Hz
POWER
REMOTE
www.sams.rs
Made in Serbia
DS-4
SN:
SDI INPUT
3 421
SDI OUTPUT
21
USE ONLY WITH A 250V FUSE
SDI switcher 4x1 DS-4
www.sams.rs
Power Lock
Remote control panel 4x1
SCU-4
www.sams.rs
1 2 3 4
RED - power is present. If does not light, check the power supply.
RED - video input. If does not light, check the video input.
Connect the power cord.
The device works only on AC ~ 230 V / 50 Hz.
Connect all necessary connectors
before the unit is turned on.
Turn on the device by pressing
power switch.
video inputs video output
connection
with
remote
control
DS-4, rear side
Buttons to select an input
Remote control - SCU-4, front side
DS-4, front side
12345
6789
P1A
P1A
P1A
P2B
P2B
P2B
GND
GND
-V
-V
13
31 579
2468x
muski SUB D9P
1
5
96
2
3
4
7
8
Ozicenje et kabla u kutiji
Raspored pinova u kablu za komunikaciju sa daljinsklom komandom SCU-4
J6
1 1
55
99
66
A0
GV-
A1 A0
A1
GV-
female male
2
3
4
7
8
2 3 4
78
INSTALLATION
CABLE CONNECTION BETWEEN SWITCHER AND REMOTE

elektronik
9
REMOTE CONTROL SCU-4
The connection to
the switcher
This manual suits for next models
1
Table of contents
Other Sams Switch manuals
Popular Switch manuals by other brands

Black Box
Black Box ServSwitch KV5004MN-R2 manual

Green Brook
Green Brook T41D-C Installation & operating instructions

Wyrestorm
Wyrestorm SW-0402-MV-HDBT installation guide

Black Box
Black Box DKM FX Interface manual

Cisco
Cisco Nexus 93400LD-H1 Hardware installation guide

NETGEAR
NETGEAR ProSafe GS700TS user guide
