Samson Go Mic User manual

Go Mic Mobile
Professional Wireless System for Mobile Filmmaking
Quick Start Guide

Go Mic Mobile
Important Safety Information
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
This lightning flash with arrowhead
symbol within an equilateral
triangle is intended to alert the user
to the presence of non-insulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance instructions in the literature
accompanying the appliance.
ATTENTION
RISQUE D’ÉLECTROCUTION !
NE PAS OUVRIR !
WARNING
TO PREVENT FIRE OR SHOCK HAZARD. DO
NOT USE THIS PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
TO PREVENT FIRE OR SHOCK HAZARD. DO
NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE. TO PREVENT ELECTRICAL
SHOCK, MATCH WIDE BLADE PLUG TO
WIDE SLOT AND FULLY INSERT.
Copyright 2017, Samson Technologies Corp. v1.1
Samson Technologies Corp.
278-B Duffy Ave
Hicksville, NY 11801
www.samsontech.com
If you want to dispose this product,
do not mix it with general household
waste. There is a separate collection
system for used electronic products
in accordance with legislation that
requires proper treatment, recovery
and recycling.
Private households in the 28 member states
of the EU, in Switzerland and Norway may
return their used electronic products free of
charge to designated collection facilities or to
a retailer (if you purchase a similar new one).
For Countries not mentioned above, please
contact your local authorities for a correct
method of disposal.
By doing so you will ensure that your disposed
product undergoes the necessary treatment,
recovery and recycling and thus prevent
potential negative effects on the environment
and human health.

Owner’s Manual
3
Important Safety Information
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at the plugs,
convenience receptacles, and at the
point where they exit from the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug the apparatus during lightning
storms, or when unused for long periods
of time.
14. Refer all servicing to qualified personnel.
Service is required when the apparatus
has been damaged in any way, such as
power supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the apparatus, has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
15. This appliance shall not be exposed to
dripping or splashing water and no object
filled with liquid such as vases shall be
placed on the apparatus.
16. Caution-to prevent electrical shock,
match wide blade plug wide slot fully
insert.
17. Please keep a good ventilation
environment around the entire unit.
18. The direct plug-in adapter is used as
disconnect device, the disconnect device
shall remain readily operable.
19. Batteries (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine, fire or
the like.

Go Mic Mobile
4
Important Safety Information
FCC Notice
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Warning Statement
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction.
This device complies with IC radiation exposure of RSS-102 limits set forth for an uncontrolled
environment. The device can be used in portable exposure condition without restriction.
WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive
heat such as sunshine, fire or the like.
Hereby, Samson Technologies Corp., declares that this Go Mic Mobile Wireless System is in
compliance with the essential requirements and other relevant provisions of Directive 2014/53/
EU. The declaration of conformity may be consulted at:
http://www.samsontech.com/site_media/support/manuals/GMM_DOC.pdf

Owner’s Manual
5
Introduction
Congratulations on purchasing the Samson Go Mic Mobile Wireless System. The Go
Mic Mobile is a dual wireless system designed to deliver professional quality audio
for mobile video. Pair and mix two transmitters to the GMM and turn your mobile
device into a complete video production studio. It is the ideal solution for mobile
journalists, filmmakers, videographers or anyone looking to add wireless audio to
their video projects.
The Go Mic Mobile includes all the cables needed to connect the Go Mic Mobile
Receiver (GMM) to a smartphone or digital camera (with an audio input). The Go
Mic Mobile will work with iOS, Android, Mac OS and Windows devices. The locking
mount arms enable the Go Mic Mobile receiver to mount directly onto the rear of a
smartphone out of the way of the phone’s lens. The arms can be removed to attach
the receiver to a tablet (using the included hook-and-loop strips) or affix to a camera
using the included shoe mount adapter.
In these pages, you’ll find a detailed description of the features of the Go Mic
Mobile wireless system, instructions for its setup and use, and specifications. If your
wireless system was purchased in the United States, you’ll also find a registration
card enclosed—don’t forget to follow the instructions so that you can receive
technical support and so that we can send you updated information about this and
other Samson products in the future. Also, be sure to check out our website (www.
samsontech.com) for complete information about our full product line.
We recommend you keep the following records for reference, as well as a copy of your
sales receipt.
Transmitter & Receiver Serial number: _________________________________
Date of purchase: ___________________________________________________
If you have any questions or comments regarding the Go Mic Mobile Wireless
Microphone System or any other products from Samson, do not hesitate to contact us
at [email protected].
With proper care and maintenance, your Go Mic Mobile Wireless System will operate trouble-
free for many years. Should your Go Mic Mobile Wireless System ever require servicing, a
Return Authorization (RA) number must be obtained before shipping your unit to Samson.
Without this number, the unit will not be accepted. Please visit www.samsontech.com/ra for
an RA number prior to shipping your unit. Please retain the original packing materials and,
if possible, return the unit in its original carton. If your Go Mic Mobile Wireless System was
purchased outside of the United States, contact your local distributor for warranty details
and service information.

Go Mic Mobile
6
Charging the Go Mic Mobile Receiver Battery
Getting the most out of the rechargeable battery:
• Completely charge the batteries before first use
• Fully charge the battery before it will be used.
• After the battery is charged, unplug the adapter from
the outlet.
• The optimal temperature range for using and
storing the battery is 50°F - 86°F (10°C - 30°C).
The battery performance and operation may
decrease in temperatures below 50°F (10°C).
• To extend the battery life, power off the Go Mic Mobile
receiver when not in use.
The Go Mic Mobile Receiver has an internal lithium-ion rechargeable battery. The
receiver is charged via the Mini USB jack located on the side of the receiver.
To charge the receiver, use the included USB charging cable and AC adapter.
Charging may also be done with 3rd party AC 5V adapters, or by connecting the units
to a standard computer USB port.
The total full charge time is 3 hours if you use a fast charger or a fast-charging
USB port (with a lightning symbol next to it), but if connected to a “standard
computer USB port” it will take 10 hours. The max run time from a full battery is
approximately 7–13 hours.
Note: The Go Mic Mobile receiver does not recharge from the Micro USB port, so
the battery level will decrease if plugged into a computer. If you want to power the
receiver while it is connected to a device, you will also need to connect the Mini USB
port to the computer or AC adapter.

Owner’s Manual
7
1. Power/Pair Switch - Press less
than 5 seconds to turn the unit
on or off. Press and hold for
more than 5 seconds to enter
pairing mode.
2. Analog Output Select Switch - Sets
the wiring of the analog output.
The OUT 1 & 2 positions are for
connecting to a smartphone’s
TRRS headset input. The
Headphone/Line output is for
connecting the receiver to a
camera, mixer or headphones.
3. VOL Control - This slider sets the
level of the audio signal sent to
the receiver’s digital and analog
outputs.
4. MIX / 2 CH Switch - Sets the receiver audio output to either mixed mono or split
left and right.
5. CH 1 & CH 2 Indicators - When lit white, the LEDs indicate the receiver is paired
with a transmitter. When the transmitter input or the receiver output is clipped,
the LEDs flash red.
6. Battery Level Indicator - This indicator lights green when the battery is charged,
lights red when the battery is low, and orange when the battery is charging.
7. Power Indicator - This indicator lights green when the Go Mic Mobile Receiver is
powered on.
8. USB AUDIO Output - Use this output when connecting to a digital audio input.
9. OUT Jack - Use this 3.5mm jack when connecting to an analog input or
headphones.
10. USB CHARGE Port - Use this Mini USB jack to connect the Go Mic Mobile
Receiver to the included AC adapter to charge the receiver’s internal battery.
11. Lock Screw - Turn left to loosen the screw and adjust the mounting arm. Turn
right to lock the mounting arm in place.
Go Mic Mobile Receiver (GMM) Callouts
10
1
3
4
2
56
9
8
11
7

Go Mic Mobile
8
14
15
Go Mic Mobile Receiver (GMM) Callouts
12. Adjustable Mounting
Arm - This mounting arm
is adjustable to affix
the GMM Receiver to a
smartphone. To adjust,
loosen the Lock Screw
on the top of the GMM
Receiver. To fix the arm
in place, tighten the Lock
Screw. The Adjustable
Mounting Arm can be
removed by loosening the
Lock Screw completely
and sliding the Mounting
Arm out of the GMM
Receiver.
13. Fixed Mounting Arm - This fixed mounting arm is used to mount the GMM
Receiver to a smartphone. A 1/4”-20 adapter is included to mount the GMM to
a standard camera tripod. To remove the fixed mounting arm, unscrew the two
Phillips screws.
14. Cold Shoe Adapter - This removable shoe
mount adapter is used to affix the GMM
Receiver to a camera or mobile filming
case.
15. Hook and Loop Area - Use the included
self adhesive hook and loop pieces
to affix the GMM to a tablet. Before
attaching the GMM to a tablet, remove
the standard mounting arms and/or cold
shoe adapter.
12
13

Owner’s Manual
9
HXD2 Handheld Transmitter Callouts
1. Status Indicator - This LED displays the
operation mode.
2. Power/Pair Switch - Press <5 seconds to turn
the unit on or off. Press >5 seconds to enter
pairing mode.
3. Battery Cover - Unscrew the battery cover
and slide down to open the Go Mic Mobile
Handheld battery compartment.
4. Battery Holder - Open the battery holder by
pressing the tab and lifting the cover. Insert
two standard AA (LR6) batteries here, being
sure to observe the plus and minus polarity
markings shown.
WARNING: Do not insert the batteries
backwards; doing so can cause severe damage
to the transmitter and will void your warranty.
5. Input GAIN Control - This control adjusts
the transmitter input sensitivity. This input
sensitivity control has been factory preset
to provide optimum level for the particular
microphone capsule provided with the Go Mic
Mobile system and so we recommend that
this not be adjusted manually. If necessary,
however, you can use the supplied plastic
screwdriver to raise or lower the input level.
6. Plastic Screwdriver - Used to adjust the input
GAIN control.

Go Mic Mobile
10
1. Input Connector - Connect the input device
via the mini-XLR connector. The PXD2 is
supplied with a lavalier microphone.
2. Status Indicator - This LED displays the
operation mode
3. Power/Pair Switch - Press <5 seconds to turn
the unit on or off. Press >5 seconds to enter
pairing mode.
4. Input GAIN Control - This control adjusts the
transmitter input sensitivity.
5. Battery Holder - Insert two standard AA (LR6)
batteries here, being sure to observe the plus
and minus polarity markings shown.
WARNING: Do not insert the batteries
backwards; doing so can cause severe
damage to the PXD2 and will void your
warranty.
6. Plastic Screwdriver - Used to adjust the input
GAIN control.
PXD2 Belt Pack Transmitter Callouts
12 3
4
5
6
