Samson Meteorite User manual

USB Condenser Microphone
Quick Start Guide

2
Congratulations on your purchase
of the Samson Meteorite USB
studio condenser microphone.
The Meteorite represents the
culmination of Samson’s history of
building world-class microphones,
and is a product of Samson’s
position on the leading edge of
digital microphone technology.
The Meteorite is a professional
studio microphone with a large
studio condenser microphone
capsule, housed in a uniquely
designed case with a magnetic base
that allows the microphone to be easily directed at the sound source.
The microphone features high-quality on-board digital converters for
crystal clear recordings. With the Meteorite, you get everything you
need to start recording on your computer - just plug in the connected
USB cable, launch your favorite audio software, and begin recording.
With its extended frequency and fast transient
response, the Meteorite reproduces any
performance with incredible accuracy and
clarity. It is also great for VoIP, chatting and
webcasting.
Whether you’re recording your latest song
idea, a podcast, or your band’s next big
hit, the Meteorite is the simplest and most
comprehensive solution for high-quality
recording on a Mac or PC. Just plug it in and
start creating!
INTRODUCTION
Copyright 2014, v1.3

3
MICROPHONE CALL OUTS
Status Light
Two-color LED illuminates
blue to indicate power
and flashes red when the
input signal is clipping.
Capsule
Large 14mm studio
quality microphone
capsule with Cardioid
polar pickup pattern.
Windscreen
Dual stage grille
protects the capsule
and helps reduce wind
noise and p-popping.
USB Cable
USB cable for interfacing with your
PC or Mac.
Magnetic Base
Microphone mounts
to the magnetic base
providing a full range of
motion and optimal posi-
tioning for any recording
application.

4
Follow this example as a typical setup to begin recording vocals:
Place the Meteorite microphone
into the desktop base. You will
feel the microphone snap into
place as a result of the
magnetic connection.
Position the
microphone so it is
facing the sound source
by rotating and tilting the
microphone on the base.
Plug the USB cable into
an available port on your
computer.
Quick Start

5
Launch your audio software.
Select the Meteorite as the
input audio device and create
a mono track in your software
for the vocal track.
Press RECORD and start capturing your performance!
Turn the Monitor output ON to hear
the input of the microphone to the
track’s input. If using speakers, you
may want to turn the Monitor output
OFF in order to avoid feedback. Set the level of the Meteorite by
slowly raising the level of the microphone while singing or talking
into the microphone at the performance level. If you see the
peak indicator illuminate red, your
signal will be distorted. Turn the
microphone level control down until
it no longer flashes red.
Quick Start
L R
No Effects
Tracks
Mono 1
Samson Meteorite Mic
My instrument is connected with:
L R
No Effects
Tracks
Input Source:
Recording Level:
Monitor:
Mono 1 (Samson Meteorite Mic)
On

6
Installing the Meteorite is a simple procedure that takes just a few
minutes. Simply connect the included USB cable and begin record-
ing. The following sections of this manual provide detailed instruc-
tions on setting up your Meteorite in Windows or MAC OS.
Windows
1. The first time you plug the Meteorite into a USB port, Windows
will install the universal USB drivers for that port.
2. To set the Meteorite as your default input/recording device, or to
change its settings, open the Control Panel, Hardware & Sound
settings, then click SOUND. Under Recording tab, you can se-
lect the Samson Meteorite from the list of devices and press the
Set Default button to set it as the default audio input device.
3. To set the gain of the microphone, click the Properties button,
and then select the Levels tab. Slide the control until the de-
sired level is reached. If you Find that the microphone red clip
LED is lighting frequently, turn this control down until the LED
no longer flashes red.
Apple MAC OSX
1. To start using the Samson Meteorite, simply plug it in. The LED
will illuminate to indicate it is receiving USB power. The MAC
will recognize the USB audio device and automatically install a
universal driver.
2. To select the Meteorite as the computer’s audio input, open
System Preferences from the dock or the main Apple Menu.
3. Next, open the Sound preferences, choose the Input tab and
select Meteorite. To set the gain of the microphone, adjust the
Input volume slider at the bottom of the Sound dialog box. The
Input Level meter will show the recording level.
Computer Setup

7
Polar Pattern. . . . . . . . . . Cardioid
Capsule . . . . . . . . . . . . 14mm condenser capsule
Frequency Response . . . . . . 20Hz - 20kHz
Max SPL. . . . . . . . . . . . 120dB
Sample Rate . . . . . . . . . . 44.1/48kHz
Bit Rate . . . . . . . . . . . . 16bit
Power Requirements . . . . . . 5V 50mA
Dimensions . . . . . . . . . . 1.96” x 2.63” (50mm x 67mm)
Weight. . . . . . . . . . . . . 0.26lb (118g)
Specications
At Samson, we are continually improving our products, therefore
specifications and images are subject to change without notice.

Samson Technologies Corp.
45 Gilpin Avenue
Hauppauge, New York 11788-8816
Phone: 1-800-3-SAMSON (1-800-372-6766)
Fax: [phone]
samsontech.com
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES
CLASS B. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS:
(1) THIS DEVICE MUST NOT CAUSE HARMFUL
INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION. SUITABLE FOR HOME OR OFFICE
USE.
If you want to dispose this product, do not mix it with gen-
eral household waste. There is a separate collection system
for used electronic products in accordance with legislation
that requires proper treatment, recovery and recycling.
Private household in the 28 member states of the EU, in
Switzerland and Norway may return their used electronic products
free of charge to designated collection facilities or to a retailer (if you
purchase a similar new one).
For Countries not mentioned above, please contact your local authori-
ties for a correct method of disposal.
By doing so you will ensure that your disposed product undergoes the
necessary treatment, recovery and recycling and thus prevent poten-
tial negative effects on the environment and human health.
