Samsung AC TN4L Series User manual

Airconditioner
Installationmanual
AC***TN4F**,AC***TN4L**
࡙Thankyou forpurchasing this Samsung airconditioner.
࡙Before operating this unit, please readthis manual carefullyand retain itforfuture
reference.
DB68-08576A-03

2English
Contents
SafetyInformation 3
InstallationProcedure 5
Step1 Checking and preparing accessories 5
Step 2 Choosing the installation location 5
Step 3 Optional: Insulating the body ofthe indoorunit 8
Step 4 Installing the indoorunit 8
Step 5 Purging inert gas fromthe indoorunit 10
Step 6 Cutting and flaring the pipes 10
Step 7 Connecting the assemblypipes to the refrigerant pipes 11
Step 8 Performing the gas leaktest 12
Step 9 Insulating the refrigerant pipes 12
Step10 Installing the drain hose and drain pipe 13
Step11 Performing the drainage test 15
Step12 Optional: Forthe installation of the circularpanel 16
Step13 Connectingthe powerand communication cables 16
Step14 Optional: Extending the powercable 18
Step15 Setting the indoorunit addresses andthe installation options 20
Appendix 37
Troubleshooting 37
Packing and unpacking guide 38
Product specification 41

3
English
SafetyInformation
WARNING
࡙ Hazards orunsafe practices that mayresult in severe
personal injuryordeath.
CAUTION
࡙ Hazards orunsafe practices that mayresult in minor
personal injuryorproperty damage.
࡙ Carefully follow the precautions listed below because they
are essentialto guarantee the safetyof the equipment.
WARNING
࡙ Always disconnect the airconditionerfromthe power
supplybefore servicing it oraccessing its internal
components.
࡙ Verifythat installation and testing operations are
performed byqualified personnel.
࡙ Verifythat the airconditioneris not installed in an
easilyaccessible area.
Generalinformation
WARNING
࡙ Carefullyread the content of this manual before installing
the airconditionerand store the manual in a safe place in
orderto be able to use it as reference afterinstallation.
࡙ Formaximum safety, installers should always carefullyread
the followingwarnings.
࡙ Store the operation and installation manual in a safe
location and rememberto hand it overto the newownerif
the airconditioneris sold ortransferred.
࡙ This manual explains howto install an indoorunit with a
split systemwith two SAMSUNG units. The use of other
types of unitswith different control systems maydamage
the units and invalidate thewarranty. The manufacturer
shall not be responsible fordamages arising from the use of
non compliant units.
࡙ The manufacturershall not be responsible fordamage
originating from unauthorized changes orthe improper
connection of electric and requirements set forth in the
“Operating limits” table, included inthe manual, shall
immediately invalidate thewarranty.
࡙ The airconditionershould be used onlyforthe applications
forwhich it has been designed: the indoorunit is not
suitable to be installed in areas used forlaundry.
࡙ Do not use the units if damaged. If problems occur, switch
the unit off and disconnect it from the powersupply.
࡙ In orderto prevent electric shocks,fires orinjuries, always
stop the unit, disablethe protection switch and contact
SAMSUNG’s technical support if the unit produces smoke, if
the powercable is hot ordamaged orif the unit isvery noisy.
࡙ Always rememberto inspect the unit, electric connections,
refrigerant tubes and protections regularly. These
operations should be performed byqualified personnel only.
࡙ The unit contains moving parts,which should always be
kept out of the reach of children.
࡙ Do not attemptto repair, move, alterorreinstall the unit. If
performed byunauthorized personnel, these operations may
cause electric shocks orfires.
࡙
Do not place containerswith liquids orotherobjects on the unit.
࡙ All the materials usedforthe manufacture and packaging of
the airconditionerare recyclable.
࡙ The packing material and exhaust batteries of the remote
controller(optional) must be disposed of in accordancewith
current laws.
࡙ The airconditionercontains a refrigerantthat has to be
disposed of as specialwaste. Atthe end of its life cycle, the
airconditionermust be disposed of in authorised centres
orreturnedto the retailerso that it can be disposed of
correctlyand safely.
࡙ Wearprotective equipment (such as safetygloves, goggles,
and headgear) during installation and maintenanceworks.
Installation/repairtechnicians maybe injured if protective
equipment is not properlyequipped.
࡙ Do not use means to acceleratethe defrost operation or
to clean, otherthan those recommended bySamsung.
࡙ Do not pierce orburn.
࡙ Be aware that refrigerants maynot contain an odour.
Installingtheunit
WARNING
IMPORTANT:When installing theunit, always rememberto
connectfirst the refrigeranttubes, thenthe electricallines.
࡙ Always disassemble the electric lines before the
refrigerant tubes.
࡙ Upon receipt, inspect the product toverifythat
it has not been damaged during transport. If the
product appears damaged, DO NOTINSTALLit and
immediatelyreport the damage to the carrieror
retailer(if the installerorthe authorized technician has
collected the material from the retailer.)
࡙ Aftercompletingthe installation, always carryout a
functional test and providethe instructions on howto
operatethe airconditionerto the user.
SafetyInformation

4
SafetyInformation
English
SafetyInformation
࡙ Do not use the airconditionerin environmentswith
hazardous substances orclose to equipment that
release free flames to avoid the occurrence of fires,
explosions orinjuries.
࡙ Do not install the product in a placewhere
thermohygrostat is needed (such as serverroom,
machineryroom, computerroom, etc.) Those places do
not provide guaranteed operation condition ofthe product
therefore performance can be poorin these places.
࡙ Do not install the product in a ship oravehicle (such
as a campervan). Salt,vibration orotherenvironmental
factormaycause the product malfunction, electric
shock orfire.
࡙
Ourunits should be installed in compliance withthe
spaces shown in the installation manual,to ensure
accessibilityfrom both sides and allowrepairs or
maintenance operations to be carried out. The unit’s
components should be accessible and easyto disassemble
without endangering people and objects.
Forthis reason,when provisions of the installation manual
are not compliedwith, the cost required to access and
repairthe units (in SAFETY CONDITIONS, as set out in
prevailing regulations)with harnesses,ladders, scaffolding
oranyotherelevation systemwill NOTbe considered part
of thewarrantyandwill be charged to the end customer.
Donotinstalltheairconditionerinfollowingplaces.
࡙ Placewhere there is mineral oil orarsenic acid. Resin
parts flame and the accessories maydrop orwater
mayleak. The capacityof the heat exchangermay
reduce orthe airconditionermay be out of order.
࡙ The placewhere corrosive gas such as sulphuric acid
gas generatesfrom thevent pipe orairoutlet.
࡙ The copperpipe orconnection pipe maycorrode and
refrigerant mayleak.
࡙ The placewhere there is a machine that generates
electromagneticwaves. The airconditionermaynot
operate normallydue to control system.
࡙ The placewhere there is a dangerof existing
combustible gas, carbon fibre orflammable dust.
࡙ The placewhere thinnerorgasoline is handled. Gas
mayleak and it maycause fire.
࡙ The placewhere animals mayurinate on the product.
Ammonia maybe generated.
࡙ The placewhere is close to heat sources.
࡙ Do not use the indoorunit forpreservation of food
items, plants, equipment, and artworks. This may
cause deterioration of theirquality.
࡙ Do not install the indoorunit if it has any drainage
problem.
Powersupplyline,fuseorcircuitbreaker
WARNING
࡙ Always make sure thatthe powersupplyis compliantwith
current safetystandards. Always install the airconditioner
in compliancewith current local safetystandards.
࡙ Alwaysverifythata suitablegroundingconnection is available.
࡙ Verifythat thevoltage and frequencyof the powersupply
complywith the specifications andthat the installed
poweris sufficient to ensurethe operation of anyother
domestic appliance connected tothe same electric lines.
࡙ Alwaysverifythat the cut-off and protection switches
are suitablydimensioned.
࡙ Verifythat the airconditioneris connectedto the power
supplyin accordancewith the instructions provided in
thewiring diagram included in the manual.
࡙ Alwaysverifythat electricconnections (cableentry,section
ofleads,protections…)arecompliantwith theelectric
specificationsandwith theinstructions providedin thewiring
scheme.Alwaysverifythatallconnectionscomplywiththe
standardsapplicabletotheinstallation of airconditioners.
࡙ Devices disconnected from the powersupplyshould
be completely disconnected inthe condition of
overvoltage category.
࡙ Be sure notto perform powercable modification,
extensionwiring, and multiplewire connection.
– It maycause electric shock orfire due to poor
connection, poorinsulation, orcurrent limit override.
– When extensionwiring is required due to power
line damage, referto "Step14 Optional: Extending
thepowercable" in the installation manual.
CAUTION
Makesurethatyouearththe cables.
࡙ Do not connect the earthwire to the gas pipe,water
pipe, lighting rod ortelephonewire. If earthing is not
complete, electric shock orfire mayoccur.
Installthecircuitbreaker.
࡙ If the circuit breakeris not installed, electric shock or
fire mayoccur.
Make surethat the condensedwaterdripping fromthe
drainhose runsout properlyandsafely.
Installthe powercableandcommunicationcableofthe indoor
and outdoorunit atleast1m awayfrom theelectricappliance.
Install the indoorunit away from lighting apparatus
usingtheballast.
࡙ If you use the wireless remote control, reception error
mayoccurdue to the ballast of the lighting apparatus.

5
InstallationProcedure
English
InstallationProcedure
Step1 Checkingandpreparing
accessories
The following accessories are suppliedwith the indoor
unit. The type and quantitymay differ, depending on the
specifications.
Installationtemplate(1) Dimension gauge(1)
Drainhose(1) Clamp (1)
Insulationpipe
(Liquidside (1), gas side(1)) Insulationdrainhose (1)
Cable-tie(6) Installation manual (1)
Usermanual(1)
Step2 Choosingtheinstallation
location
Installationlocationrequirements
࡙ There must be no obstacles nearthe airinlet and
outlet.
࡙ Install the indoorunit on a ceiling that can support its
weight.
࡙ Maintain sufficient clearance aroundthe indoorunit.
࡙ Before installing the indoorunit, be sureto check
whetherthe chosen location iswell-drained.
࡙ The indoorunit must be installed such that it is beyond
public access and is not touchable byusers.
࡙ Rigidwallwithoutvibration.
࡙ Where it is not exposed to direct sunshine.
࡙ Wherethe airfiltercan be removed and cleaned easily.
CAUTION
࡙ As a rule,the unit cannot be installed at a height of
less that 2.5m.
࡙ Ifyou install the cassette orduct type indoorunit on
the ceiling with humidityover80%, you must apply
extra10mm of polyethylene foam orotherinsulation
with similarmaterial on the bodyof the indoorunit.

6
InstallationProcedure
InstallationProcedure
English
Indoorunitdimensions
(Unit: mm)
Category Squarepanel Circularpanel
Front
1000 358
Ceiling opening dimension
960 (950 - 960)
Ceiling opening dimension
960 (950 - 960) 116
1050
883
Large+,
Large
385
166
66
357
404
128
181
190
317
Drain hose
connector Refrigerant
pipe
Wire insert
hole
100 153 162 289
138
94
Small
385
166
66
357
404
128
181
190
233
Drain hose
connector Refrigerant
pipe
Wire insert
hole
100
153
162 205
138
94
Common
646
646
942
787
80 ø100
H1
H1 Large+, Large:180, Small:150
H2 Large+, Large:152, Small:122
H2
Squarepanel Circularpanel

7
InstallationProcedure
English
Spacingrequirements
A :1500 mm ormore
A
A
A
A
'C'
Indoorunit
2500 mm ormore
Obstruction
20 mm
1500 mm or
more
10 mm
(Unit: mm)
Model AC018TN4FCC AC018TN4FCH
AC018TN4LCC
AC024TN4FCC
AC024TN4FCH
AC024TN4LCC
AC036TN4FCC
AC036TN4FCH
AC036TN4LCC
AC048TN4FCC
AC048TN4FCH/SU
AC048TN4FHH
AC048TN4LCC
AC048TN4LHC
C261 345 345 345
Model AC018TN4FCC AC018TN4FCH
AC018TN4LCC
AC024TN4FCC
AC024TN4FCH
AC024TN4LCC
AC036TN4FCC
AC036TN4FCH
AC036TN4LCC
AC048TN4FCC
AC048TN4FCH/SU
AC048TN4FHH
AC048TN4LCC
AC048TN4LHC
Chassis Small LRG LRG+ LRG+
Netdimension (WxH x D) mm 947 x 281 x 947 947 x 365 x 947 947 x 365 x 947 947 x 365 x 947
Netweight kg 20.0 23.3 25.3 25.8
Liquidpipe connection mm 6.35 6.35 9.52 9.52
Gaspipe connection mm 12.7 15.88 15.88 19.05
Drainhoseconnection mm Outerdiameter: Ø32, Innerdiameter: Ø26.5
࡙ The circularpanel is by default available in exposed
installation.
࡙ Make inspection holes onthe ceiling foreasier
installation and maintenance, as shown in the
following table. (The size of an inspection hole must be
at least 450 mm x 450 mm.)
࡙ A suspended ceiling structure can substituteforthe
inspection holes.
Category
Inspectionhole
Recessedinstallation Exposed
installation
Integrated suspended
Squarepanel 1 ea -
Circularpanel 2 ea
࡙ Forthe recessed installation of the circularpanel
Refrigerant
pipe
Connection part of the
drain hose
Indoorunit
display
Inspection hole 1050
(Unit: mm)
883
ø1010 to1020
Ceiling opening
diameter
ø1010 to1020
Inspection hole
NOTE
The clearance between the panel andthe inspection hole
is15 to 20 mm on a side.

8
InstallationProcedure
InstallationProcedure
English
CAUTION
࡙ Complywith the length and height limits described in the
figure above.
࡙ The indoorunit must be installed according to the
specified distances in orderto permit accessibility
from each side, to guarantee correct operation,
maintenance, and repairof the unit.
The components of the indoorunit must be reachable and
removable undersafe conditions forpeople and the unit.
࡙ Do not holdthe dischargewhile carrying the indoor
unit to avoid the possibility of breakage.
࡙ You must holdthe hangerplate on the cornerand
carrythe indoorunit.
Step3 Optional:Insulatingthebodyof
theindoorunit
Ifyou install a cassette type indoorunit on the ceiling
when temperature is over27°C and humidityis over
80%,you must applyan extra10 mm thick polyethylene
insulation ora similartype of insulationto the bodyof the
indoorunit.
Cut awaythe part where pipes are pulled out forthe
insulatingwork.
A
Insulate the end ofthe pipe and some curved area by
using separate insulator.
NOTE
࡙ A: Reference forthe outercircumference of the unit
(When insulating the bodyof the indoorunit, use Aas
the reference for its outer circumference.)
(Unit: mm)
Indoorunittypeand models Dimensions
360 cassettetype <S>
(947*947*281) AC018TN4FCC
AC018TN4FCH
AC018TN4LCC 2610*130
360 cassettetype <L>
(947*947*365) AC024TN4FCC
AC024TN4FCH
AC024TN4LCC 2610*215
360 cassettetype <L+>
(947*947*365)
AC036TN4FCC
AC036TN4FCH
AC036TN4LCC
AC048TN4FCC
AC048TN4FCH/SU
AC048TN4FHH
AC048TN4LCC
AC048TN4LHC
2610*215
Step4 Installingtheindoorunit
When deciding on the location of the airconditionerthe
following restrictions must be taken into account.
1 Determinethe positions of the pipe and the drain hose
hole as shown inthe pattern sheet, and drill the hole
with an innerdiameterof14 mm.
NOTE
࡙ Since the diagram is made of paper, it may shrink
orstretch slightlydue to temperature orhumidity.
Forthis reason, before drilling the holes, be sure
to maintain the correct dimensions between the
markings.

9
InstallationProcedure
English
2 Performthe following steps to install inspection holes
in accordance with the panel type.
a Forthe recessed installation of the square panel.
࡙ Install an inspection hole to the direction of
connection parts of the refrigerant pipe and the
drain hose. (1 point)
Indoorunit
display
Refrigerant pipe
Inspection hole
b Forrecessed installation of the circularpanel
࡙ Install inspection holes to both directions ofthe
connection part of the refrigerant pipe and the
drain hose and of the indoorunit display.
(2 points)
Inspection hole
Indoorunit display
Refrigerant pipe
Inspection hole
3 Insert bolt anchors, use existing ceiling supports or
construct a suitable support as shown infigure.
Concrete
Hole in anchor
Hole in plug
ƊЇϑΧʪϑͱɵͱϩ࣑đߣߢ࣒ࣛѣʪʒϑЇΧΧц
Insert
4 Install the suspension bolts, depending on the ceiling
type.
Ceiling support
CAUTION
࡙ Make sure that the ceiling is strong enough to support
theweight of the indoorunit. Before hanging the unit,
test the strength of each attached suspension bolt.
࡙ If the length ofthe suspension bolt is morethan1.5 m,
you are required to preventvibration.
5 Screweight pairs of nuts and washers tothe
suspension bolts, making space forhanging the indoor
unit.
CAUTION
࡙ You must install all of the suspension rods.
࡙ It is important to leave sufficient space in thefalse
ceiling to allowaccess formaintenance orrepairs to
the drainage pipe connection,the refrigerant pipe
connection, orto removethe unit if necessary.
6 Hang the indoorunit to the suspension bolts between
two nuts. Cut a pad stopperand place it on the
suspension bolts to hold thewashers. Remove the
stopperand screwthe nuts to fixthe unit.
1
2
2
Pad stopper
Bracket

10
InstallationProcedure
InstallationProcedure
English
7 Adjust the unitto the appropriate position,taking into
account the installation area forthe front panel.
࡙ Place the pattern sheet onthe indoorunit.
࡙ Adjust the space between the ceiling and the
indoorunit byusing a dimension gauge.
࡙ Fix the indoorunit securelyafteradjusting the level
of the unit byusing a leveller.
࡙ Removethe pattern sheet, connect the other
cables. and installthe front panel.
Forthe recessed installation
of the square panel:11.5 mm
Forthe recessed installation
of the circularpanel: 41.5 mm
Indoorunit Ceiling
Gauge of
dimensions
Step5 Purginginertgasfromthe
indoorunit
The indoorunit comeswith nitrogen gas (inert gas)
charged atthe factory. Therefore, all inert gas must be
purged before connecting the assemblypiping.
Unscrewthe pinchpipe at the endof each refrigerant
pipe.
Liquid
side
Gas side
Insulator
NOTE
࡙ To prevent dirt orforeign objects from getting intothe
pipes during installation, do not remove the pinch pipe
completelyuntil you are ready to connect the piping.
Step6 Cuttingandflaringthepipes
1 Make sure thatyou havethe required tools available:
pipe cutter, reamer, flaring tool, and pipe holder.
2 Ifyou wishto shorten the pipes, cutthemwith a pipe
cutter, ensuring that the cut edge remains at a 90°
angle to the side of the pipe. Referto the illustrations
belowforexamples of edges cut correctlyand
incorrectly.
Pipe cutter
Pipe Oblique Rough Burr
3 To prevent anygas from leaking out, remove all burrs
at the cut edge of the pipe, using a reamer.
4 Slide a flare nut on to the pipe and modifythe flare.
Pipe Flare Flare
D
D
AR 0.4to 0.8 mm
L
90° ±2°
45° ±2°
OuterDiameter(D) Depth(A) Flaredimension(L)
Ø6.35 mm 1.3 mm 8.7 to 9.1 mm
Ø9.52 mm 1.8 mm 12.8 to13.2 mm
Ø12.70 mm 2.0 mm 16.2 to16.6 mm
Ø15.88 mm 2.2 mm 19.3 to19.7 mm
Ø19.05 mm 2.2 mm 23.6 to 24.0 mm

11
InstallationProcedure
English
5 Check that the flaring is correct, referring to the
illustrations belowforexamples of incorrect flaring.
Correct Inclined Damaged
Surface Cracked Uneven
Thickness
Step7 Connectingtheassemblypipes
totherefrigerantpipes
Therearetwo refrigerantpipes ofdifferentdiameters :
࡙ A smallerone forthe liquid refrigerant.
࡙ A largerone forthe gas refrigerant. The inside of
copperpipe must be clean and has no dust.
1 Removethe pinch pipe on the pipes and connect the
assemblypipes to each pipe, tightening the nuts, first
manuallyand thenwith a torquewrench, a spanner
applying the following torque.
2
3
3
1
Torque
wrench
Flare nut
Spanner
Union
OuterDiameter(mm) ƟͱθαЇʪ࣍Ę࡙࣎
Ø6.35 14 to18
Ø9.52 34 to 42
Ø12.70 49 to 61
Ø15.88 68 to 82
Ø19.05 100 to120
࣍ߢĘ࡙ߢߡ˝˙࡙ʀ࣎
NOTE
࡙ If the pipes must be shortened, see Step6 Cutting
andflaringthe pipes on page 10.
2 Be sure to use an insulatorthick enough to coverthe
refrigerant tube to protect the condensatewateron
the outside of the pipe falling onto the floorand to
improve the efficiencyof the unit.
3 Cut off anyexcessfoam insulation.
4 Make sure that there are no cracks orwaves on the
bent area.
5 Itwould be necessaryto double the insulation
thickness (10 mm ormore) to prevent condensation
even onthe insulatorwhen if the installed area is
warm and humid.
CAUTION
࡙ Connectthe indoorand outdoorunits using pipeswith
flared connections (not supplied). Forthe lines, use
insulated, unwelded, degreased and deoxidized copper
pipe (Cu DHPtype to ISO1337 orUNI EN12735-1),
ϑЇϩɇɵʪ˙ͱθͱΧʪθɇϩ˝ΧθʪϑϑЇθʪϑͱ˙ɇϩʪɇϑϩߥࢋߣđťɇ
ɇʒ˙ͱθɇɵЇθϑϩΧθʪϑϑЇθʪͱ˙ɇϩʪɇϑϩߣߡࢋߨđťɇࢋAͱΧΧʪθ
pipe forhydro-sanitaryapplications is completely
unsuitable.
࡙ Forsizing and limits (height difference, line length,
max. bends, refrigerant charge, etc.) seethe outdoor
unit installation manual.
࡙ All refrigerant connection must be accessible, in order
to permit eitherunit maintenance orremoving it
completely.
࡙ If the pipes require brazing, make sure that oxygen
free nitrogen (OFN) is flowing through the system.
࡙ Nitrogen blowing pressure range is 0.02to 0.05 MPa.

12
InstallationProcedure
InstallationProcedure
English
Step8 Performingthegasleaktest
To identifypotential gas leaks onthe indoorunit, inspect
the connection area of each refrigerant pipe using a leak
detectorforR-410A.
Before recreating thevacuum and recirculating the
refrigerant gas, pressurize thewhole systemwith
nitrogen (using a cylinderwith a pressure reducer) at
a pressure above 4 MPa in orderto immediatelydetect
leaks on the refrigerantfittings.
Madevacuum for15 minutes and pressurizing systemwith nitrogen.
Liquid
side
Gas side
Insulator
Step9 Insulatingtherefrigerantpipes
Onceyou have checkedthat there are no leaks in the
system,you can insulate the piping and hose.
1 To avoid condensation problems, placeAcrylonitrile Butadien
Rubberseparatelyaround each refrigerant pipe.
No gap
NBR
NOTE
࡙ Always makethe seam of pipes face upwards.
2 Wind insulating tape around the pipes and drain hose
avoiding compressing the insulation too much.
Indoorunit
Insulation coverpipe
Insulation pipe
Be sure to overlap the insulation.
CAUTION
࡙ Be sure towrap insulation tightlywithout anygaps.
3 Finishwrapping insulating tape aroundthe rest ofthe
pipes leading to the outdoorunit.
4 The pipes and electrical cables connectingthe indoor
unit with the outdoorunit must be fixed to thewall
with suitable ducts.
CAUTION
࡙ Make sure that all refrigerant connection must be
accessibleforeasymaintenance and detachment.
࡙ Install the insulation not to getwiderand use the
adhesives on the connection part of it to prevent
moisture from entering.
࡙ Wind the refrigerant pipewith insulation tape if it is
exposed to outside sunlight.
࡙ Install the refrigerant pipe respecting that the
insulation does not get thinneron the bent part or
hangerof pipe.
࡙ Add the additional insulation ifthe insulation plate
gets thinner.
Refrigerant pipe insulation
a x 3
Hanger
Additional insulation
a
5 Selectthe insulation of the refrigerant pipe.
࡙ Insulate the gas side and liquid side pipe, noting the
insulation thickness that must differaccording to
the pipe size.
࡙ Standard: Less than an indoortemperature of 30°C,
with humidityat 85%. If installing in a high humidity
environment, use one grade thickerinsulatorby
referring to the table below. If installing in an
unfavourable environment, use thickerone.
࡙ The heat-resistancetemperature of the insulator
must be morethan120°C.

13
InstallationProcedure
English
Pipe Pipe size
(mm)
Insulationtype(heating/cooling)
Remarks
Standard
(Lessthan30°C,85%) Highhumidity (Over30°C,85%)
EPDM,NBR(mm)
Liquid pipe Ø6.35 to Ø9.52 9t 9t
The internal
temperature is
higherthan120°C.
Ø12.7 to Ø19.05 13t 13t
Gas pipe
Ø6.35 13t 19t
Ø9.52
19t 25t
Ø12.70
Ø15.88
Ø19.05
࡙ When installing insulation in the places and
conditions below, use the same insulation that is
used forhigh humidity conditions.
<Geologicalcondition>
High humiditylocations such as shorelines, hot
springs, lake orriversides, and ridges (when part of
the building is covered byearth and sand)
<Operationpurposecondition>
Restaurant ceiling, sauna, swimming pool etc.
<Buildingconstructioncondition>
Ceilings frequently exposed to moisture and cooling
are not covered. Forexample, pipes installed at a
corridorof a dormitory and studio ornearan exit that
opens and closes frequently.
Places (where the pipes are installed) that are highly
humid due to a lack ofventilation.
Step10 Installingthedrainhoseand
drainpipe
1 Push the supplied drain hose as faras possible over
the drain socket.
2 Tighten the metal clamp as shown in the picture.
3 Wrapthe supplied large sealing pad overthe metal
clamp and drain hose to insulate and fix itwith clamps.
4 Insulate the complete drain piping inside the building
(field supply).
If the drain hose cannot be sufficientlyset on a slope,
fit the hosewith drain raising piping (field supply).

14
InstallationProcedure
InstallationProcedure
English
5 Push the drain hose upto insulation when connecting
the drain hose to drain socket.
Metal clamp Drain socket
Drain hose
Large seailng pad Be sure to bond the drain
hose and the main pipe.
Drain pipe
Drain hose PVC Tube Joint
+ VP25 (OD: 32 mm, ID: 25 mm)
Drain pipe
CAUTION
Checkthatthe indoorunitis levelwiththe ceilingby
usingtheleveller.
࡙ Install airventilation to drain condensation smoothly.
Airventilation
Ceiling
࡙ If it is necessaryto increase the height ofthe drain
pipe, install the drain pipe straightwithin 300 mm
fromthe drain hose port. If it is raised higherthan 550
mm, there maybe waterleaks.
Band joint
300 mm
orless 20 mm ormore
Drain hose
Ceiling
550 mm orless
࡙ Do not givethe hose an upward gradient beyond
the connection port. Thiswill cause waterto flow
backwardswhen the unit is stopped, resulting inwater
leaks.
Undergradient
Ceiling
࡙ Do not applyforce tothe piping on the unit side when
connecting the drain hose. The hose should not be
allowed to hang loose from its connection to the unit.
Fasten the hose to a wall, frame orothersupport as
close to the unit as possible.
Support pieces
1 to1.5 m
1/100 ormore
Ceiling
࡙ Install horizontally.
Indoorunit
Be horizontal
Flexible hose
࡙ Max. allowable axis gap.
Indoorunit
Max. 20 mm

15
InstallationProcedure
English
࡙ Max. allowable bending angle.
Indoorunit
đɇу࢏ߥߢઘ
NOTE
࡙ If a concentrated drain pipe is installed, referto the
figure below.
Centralized horizontal drain pipe
(more than1/100 slope)
Main drain pipe
Full thread bolt hanger 1000 to1500 mm
300 to
550 mm
200 mm
ormore
Individual air
vent Main airvent
(must be installed)
Step11 Performingthedrainagetest
1 Do a leaktest at the connection part of the flexible
hose and the drian pipe:
a Connect a general hose tothe connection part of
the flexible hose of the indoorunit, and pourin
somewater.
Hose
Flexible hose
Waterleakage
check part
b Afterpouring somewater, reassemble the rubber
cap on the connection part of a flexible hose of
the indoorunit and firmlytighten itwith a band to
prevent leakage.
c Check the leaktest at the partwhere the adhesive
forthe flexible hose and the drian pipe is used.
CAUTION
࡙ The leak test must be performedforat least 24 hours.
2 Check the condensed waterdrainage:
a Pourabout 2 liters ofwaterinto the indoorunit
drain pan as shown inthe picture.
b When the electric cable connection is completed
࡙ Turn on the indoorunit and outdoorunit.
࡙ Operate in the Cool mode.
CAUTION
࡙ Onlyin the Cool mode,you can check the correct
operation of the drain pump.
When the electric cable connection has not been completed
࡙ Removethe control box coverof the indoorunit.
࡙ Connectthe powersupply(230V, 60Hz) tothe Land
N terminals.
࡙ Reassemble the control box coverand turn on the
indoorunit.
CAUTION
࡙ Whenthefloat switchis notdetectedduetoinsufficient
wateronthedrainpan,thedrainpumpwillnotwork.
࡙ If the powersupplyis directlyconnected to the L
and N terminals, communication errormessage
might appear.
࡙ Aftercompleting the drainage check, turn the unit
off and disconnect the powersupply.
࡙ Reassemble the control box cover.
c Checkwhetherthe drain pumpworks correctly.
d Checkwhetherthe drainage is performing
correctlyat the end of the drain pipe.
e Check forleakage atthe drain pipe and drain pipe
connection part.

16
InstallationProcedure
InstallationProcedure
English
f When leakage occurs, checkwhetherthe indoorunit
is level and check the drain hose connection part,
drainpipe connection part and drain pump connection.
g When the drainage check is completed and
the condensedwaterremains onthe drain pan,
remove thewater.
Step12 Optional:Fortheinstallation
ofthecircularpanel
Makingacircularopening onthe ceiling
Use a papercompass printed onthe indoorunit package.
(attached inside to the upperpart)
1
Usea boltorapintofix pivotpoint ofthe papercompass on
centeroftheceiling. (inthe middle of locationforinstallation)
2 ťЇϩɇΧʪʀɇϩϩ˵ʪͱΧΧͱϑϩʪϑʒʪͱ˙ϩ˵ʪΧЭͱϩΧͱϩ
fixed in place.
3 Rotate the papercompass on its pivot point to drawa
line on the ceiling.
4 Rotate the papercompass diametricallyto drawa
circle on the ceiling.
Forthe paintingof the panel
࡙ Make sure to onlyapplypaints and varnishes forresins
(ABS, HIPS) orpaint thinners.
࡙ Ifyou applylacquers forgeneral use on the panel, it
maylead to discoloration orerosion on the surface of
the panel.
Step13 Connectingthepowerand
communicationcables
CAUTION
࡙ Always rememberto connectthe refrigerant pipes
before performing the electric connections.
When disconnecting the system, always disconnect
the electric cables before disconnectingthe
refrigerant pipes.

17
InstallationProcedure
English
CAUTION
࡙ Always rememberto connect the airconditionerto the
grounding system before performing the electric connections.
Use a crimp ring terminal atthe end of each wire.
The indoorunit is powered through the outdoorunit by
means of a H05 RN-F orH07 RN-F connection cable (ora
more powermodel),with insulation in synthetic rubber
and a jacket in polychloroprene (neoprene), in accordance
with the requirements specified inthe standard EN
60335-2-40.
1 Removethe screwon the electrical component box
and remove the coverplate.
2 Route the connection cordthrough the side of the
indoorunit and connect the cable tothe terminals
referto the figure below.
3 Route the otherend of the cable to the outdoorunit
throughthe ceiling & the hole on thewall.
4 Reassemble the electrical component box cover,
carefullytightening the screw.
Wiringterminals)1phase(AC018/024TN4*C*)
F1 F2
LN
IndoorUnit
1(L) 2(N) L N F1 F2
Cable
tie
Main power
cable
Cable clamp
Indoorpower Communication
cable
OutdoorUnit
Wiring terminals)1 phase (AC036/048TN4*C*,
AC048TN4FCH/SU)
1(L) 2(N) L N F1 F2
LN
Indoorpower Main powercable Communication
cable
Indoorunit
Outdoorunit
F1 F2
Wiring terminals) 3 phase(AC048TN4FCC,AC048TN4FHH,
AC048TN4LHC)
1(L) 2(N) L1(R) L2(S) L3(T) N F1 F2
F1 F2
LN
Indoorpower Main powercable Communication
cable
Indoorunit
Outdoorunit

18
InstallationProcedure
InstallationProcedure
English
NOTE
࡙ Insert the powerand the communication cablesto the
cable insert hole, then arrange and connect the cables,
as shown in thefigure:
Cable
insert hole
Powercable Communication cable
Indoorpowersupply
Powersupply Max/Min(V) Indoorpowercable
ߢעࡡߣߤߡǤࡡߧߡ²і ±10% ߡࢋߨߦࠟࡡߤиθʪϑ
Communicationcable
ߡࢋߨߦࠟࡡߣиθʪϑ
AC power: M4 screw Communication: M3.5 screw
11 13 7.5 9.0
(Unit: mm)
18
13.8
Ɵ˝˵ϩʪ˝ϩͱθαЇʪ࣍˝˙࡙ʀ࣎
M3.5 8.0 to12.0
M4 12.0 to18.0
࡙ ߢĘࡔߢߡ˝˙ࡔʀ
࡙ Powersupplycords of parts of appliances foroutdoor
use shall not be lighterthan polychloroprene sheathed
flexible cord.
– Code designation
(1-phase) IEC: 60245 IEC 57 / CENELEC: H05RN-F
grade ormore
(3-phase) IEC: 60245 IEC 66 / CENELEC: H07RN-F
grade ormore
࡙ Since it has the external powersupply, refertothe
outdoorunit installation manual forMAIN POWER.
CAUTION
࡙ When installing the indoorunit in a computer
room ornetwork room, use the double shielded
communication cable (tape aluminum / polyester
braid + copper) of FROHH2R type.
Step14 Optional:Extendingthepower
cable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulation tape Width19
mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
2 As shown in the figure, peel off the shields from the
rubberand wire of the powercable.
࡙ Peel off 20 mm of cable shields from the pre-
installed tube.

19
InstallationProcedure
English
CAUTION
࡙ Forinformation about the powercable
specifications forindoorand outdoorunits, referto
the installation manual.
࡙ Afterpeeling off cablewires from the pre-installed
tube, insert a contractiontube.
࡙ If cablewires are connectedwithout using
connecting sleeves, theircontact area becomes
reduced, orcorrosion develops onthe outer
surfaces ofthe wires (copperwires) overa long
time. This maycause an increase of resistance
(reduction of passing current) and consequently
mayresult in a fire.
Powercable (Unit: mm)
20 20 20
60
120
180
Pre-installed tube
for the power cable
202020 60 120 180
3 Insert both sides of corewire of the powercable into
the connection sleeve.
࡙ Method1: Push the corewire into the sleeve from
both sides.
࡙ Method2: Twist thewire cores togetherand push it
into the sleeve.
Connection sleeve
Method1
Connection sleeve
Method 2
4 Using a crimping tool, compress the two points and
flip it overand compress anothertwo points in the
same location.
࡙ The compression dimension should be 8.0.
Compression
dimension
࡙ Aftercompressing it, pull both sides of thewire to
make sure it is firmlypressed.
Compress it 4times.
5 mm
Method1
Compress it 4times.
5 mm
Method 2
5 Wrap itwith the insulation tapetwice ormore and
positionyourcontraction tube in the middle of the
insulation tape.
Method 2
Method1 Insulation tape
40 mm
Insulation tape
35 mm

20
InstallationProcedure
InstallationProcedure
English
6 Apply heat to the contraction tube to contract it.
Method 2
Method1 Contraction tube Contraction tube
7 Aftertube contractionwork is completed,wrap itwith
the insulation tape to finish.
Three ormore layers of insulation are required.
Method 2
Method1 Insulation tape Insulation tape
CAUTION
࡙ Make sure that the connection parts are not exposed
to outside.
࡙ Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials that
havethe same level ofwithstand voltagewith the power
cable. (Complywith the local regulations on extensions.)
WARNING
࡙ In case of extending the electricwire, please DO NOT
use a round-shaped Pressing socket.
– Incompletewire connections can cause electric
shock ora fire.
Step15 Settingtheindoorunit
addressesandtheinstallationoptions
You cannot set both ofthe indoorunit addresses and
the installation options in a batch: set both of them
respectively.
Commonstepsforsettingtheaddressesand
options
AR-KH00E/AR-KH03E remotecontrol (for360 cassette
only)
Temperature
button
Timerbutton
Wheel
Mode button
Settingthe
optionvalues
Enteringthe
modeforsetting
theoptions
NOTE
࡙ The remote control displaymayvarydepending on the
model.
1 Enterthe mode forsetting the options:
a Remove the batteries from the remote control.
b While holding down the (Temp) and
(Timer) buttons simultaneously, insert the
batteries into the remote control.
c Make sure thatyou are enteredto the modefor
setting the options:
