Samsung AF**FSSDA Series Guide

QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
U.A.E 800-SAMSUNG (726-7864) www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
OMAN 800-SAMSUNG(726-7864) www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
KUWAIT 183-2255 (183-CALL) www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
BAHRAIN 8000-4726 www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
QATAR 800-2255 (800-CALL) www.samsung.com/ae/support (English)
www.samsung.com/ae_ar/support (Arabic)
EGYPT 08000-726786
16580 www.samsung.com/eg/support
ALGERIA 021 36 11 00 www.samsung.com/n_africa/support
PAKISTAN 0800-Samsung (72678) www.samsung.com/pk/support
TUNISIA 80-1000-12 www.samsung.com/n_africa/support
JORDAN 0800-22273
06 5777444 www.samsung.com/Levant/support (English)
SYRIA 18252273 www.samsung.com/Levant/support (English)
MOROCCO 080 100 2255 www.samsung.com/n_africa/support
SAUDI ARABIA 920021230 www.samsung.com/sa/support
www.samsung.com/sa_en/support (English)
TURKEY 444 77 11 www.samsung.com/tr/support
INDIA
1800 3000 8282 - Toll Free
1800 266 8282 - Toll Free
30308282 - Non Toll Free
www.samsung.com/in/support
SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/support
CHILE 800-SAMSUNG(726-7864) www.samsung.com/cl/support
This product is RoHS compliant
This product is not manufactured for Iran. SVC Warraty will not be
applicable and the user will be responsible for service
expenses when the product is used in Iran.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 54 2014-03-12 오전 9:33:18

AFFSSDA Series
AFFSZDA Series
Air Conditioner
user & installation manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DB68-03892A(5)
EN ES FR AR
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 55 2014-03-12 오전 9:33:19

2
Features of your new air conditioner
Samsung Air Solution! Cool, Clean and refreshing feeling at once
Cool Air : Your air conditioner uses air flow direction control which provide direct air flow in hot days and indirect air flow
when you are cooled down.
Refreshing Air : Auto mode will provide refreshing air by selecting the operation mode automatically from Cool, Dry, Purity
depending on the indoor air environment.
4 seasons of effective cleaning
Purity mode
 Purity mode can be selected solely to save energy.
 When the air conditioner operates, Zero filter and the Virus Doctor eliminates harmful contaminants to provide us with
the cleanest air.
Smart sensor
Camera on the top of the indoor unit will detect the movement within the indoor and when there is no movement for a
certain time, air conditioner will adjust the indoor temperature or turn off power automatically to save the energy.
 Applicable to AFFSSD only
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
(For India only)
For more information on safe disposal and recycling visit our website
www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 2 2014-03-12 오전 9:32:56

3
ENGLISH
Contents
Safety precautions ....................................................................................................... 4
Checking before use .................................................................................................... 11
Checking the name of the parts ........................................................................................ 14
Checking the remote controller ......................................................................................... 17
Basic operation ......................................................................................................... 19
Turbo operation ........................................................................................................ 21
Air flow direction ....................................................................................................... 21
good'sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the On/Off timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Smart sensor operation ................................................................................................. 26
Lighting function ....................................................................................................... 26
Quiet operation ......................................................................................................... 27
Auto clean operation ................................................................................................... 27
Cleaning the air conditioner ............................................................................................. 28
Troubleshooting ........................................................................................................ 31
Open Source Announcement ........................................................................................... 34
Safety precautions ...................................................................................................... 35
Required tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Choosing the installation location ....................................................................................... 37
Indoor/outdoor unit installation diagram ............................................................................... 38
Accessories ............................................................................................................. 41
Drilling a hole and fixing the indoor unit ................................................................................ 42
Connecting pipes ....................................................................................................... 42
Connecting drain hose .................................................................................................. 45
Electrical work .......................................................................................................... 46
Vacuum pump .......................................................................................................... 50
Performing leak test .................................................................................................... 51
Installing the earth wire ................................................................................................. 52
Charging refrigerant .................................................................................................... 52
Check and test operation ............................................................................................... 53
Pump down procedure (When removing the product) .................................................................. 53
USING PARTS
INSTALLATION PARTS
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 3 2014-03-12 오전 9:32:56

4
Safety precautions
Before using your new air conditioner, please read this manual thoroughly to ensure that
you know how to safely and efficiently operate the extensive features and functions of
your new appliance.
If you have any questions, call your nearest contact center or find help and information
online at www.samsung.com.
Important safety symbols and precautions:
WARNING Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION Hazards or unsafe practices that may result in minor personal
injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut the power at the circuit breaker.
Do NOT disassemble.
FOR INSTALLATION WARNING
Use the power line with the power specifications of the product or higher and use
the power line for this appliance only. In addition, do not use an extension line.
 Extending the power line may result in electric shock or fire.
 Do not use an electric transformer. It may result in electric shock or fire.
 If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician or
service company.
 Failing to do so may result in electric shock, fire, explosion, problems with the
product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
 Failing to do so may result in electric shock or fire.
USING PARTS
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 4 2014-03-12 오전 9:32:56

5
ENGLISH
Fix the outdoor unit firmly so that the electric part of the outdoor unit is not
exposed.
 Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material. Do not install
this appliance in a humid, oily or dusty location, in a location exposed to direct
sunlight and water (rain drops). Do not install this appliance in a location where
gas may leak.
 This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where
it could fall.
 If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas
pipe, plastic water pipe, or telephone line.
 Failure to do so may result in electric shock, fire, an explosion, or other problems
with the product.
 Make sure to use a socket-outlet with ground.
FOR INSTALLATION CAUTION
Install your appliance on a level and hard floor that can support its weight.
 Failing to do so may result in abnormal vibrations, noise, or problems with the
product.
Confirm that the indoor unit fixing device has been installed by confirming this at
an installation engineer.
 If the indoor unit fixing device is not installed, the indoor unit may vibrate and fall
and this may result in injury.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 5 2014-03-12 오전 9:32:56

6
Safety precautions
FOR INSTALLATION CAUTION
Install the draining hose properly so that water is drained correctly.
 Failing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining hose so that
draining is performed correctly.
 The water generated during the heating operation, by the outdoor unit, may
overflow and result in property damage. Especially in winter time, when water
freezes and if a block of ice falls, it may result in injury, death or property damage.
FOR POWER SUPPLY WARNING
When the circuit breaker is damaged, contact your nearest service center.
Do not pull or excessively bend the power line. Do not twist or tie the power
line. Do not hook the power line over a metal object, place a heavy object on the
power line, insert the power line between objects, or push the power line into the
space behind the appliance.
 This may result in electric shock or fire.
FOR POWER SUPPLY CAUTION
When not using the air conditioner for a long period of time or during a thunder/
lightning storm, cut the power at the circuit breaker.
 Failing to do so may result in electric shock or fire.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 6 2014-03-12 오전 9:32:57

7
ENGLISH
FOR USING WARNING
If the appliance is flooded, please contact your nearest service center.
 Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, cut-off the
power supply immediately and contact the nearest service center.
 Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line. Do not touch the appliance or
power line.
 Do not use a ventilating fan.
 A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service center.
 Failing to do so may result in problems with the product, water leakage, electric
shock, or fire.
 A delivery service for the product is not provided. If you reinstall the product in
another location, additional construction expenses and an installation fee will be
charged.
 Especially, when you wish to install the product in an unusual location such as
in an industrial area or near the seaside where it is exposed to the salt in the air,
please contact your nearest service center.
Do not operate the appliance with wet hands.
 This may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
 This may result in fire, injury, or problems with the product.
 Importantly, if the support bracket is excessively impacted, it may become
damaged.
Do not place an object near the outdoor unit that allows children to climb onto
the machine.
 This may result in children seriously injuring themselves.
Do not turn the air conditioner off with the circuit breaker while it is operating.
 Turning the air conditioner off and then on again with the circuit breaker may
cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the
reach of children, as packaging materials can be dangerous to children.
 If a child places a bag over its head, it may result in suffocation.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 7 2014-03-12 오전 9:32:57

8
Safety precautions
FOR USING WARNING
Do not insert your fingers or foreign substances into the outlet when the air
conditioner is operating or the front panel is closing.
 Take special care that children do not injure themselves by inserting their fingers
into the product.
Do not insert your fingers or foreign substances into the air inlet/outlet of the air
conditioner.
 Take special care that children do not injure themselves by inserting their fingers
into the product.
Do not touch the air flow blade with your hands during the heating operation.
Especially, do not put your finger into the air conditioner.
 This may result in electric shock or burns.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near infirm people.
 Since this may be dangerous due to a lack of oxygen, open a window at least once
an hour.
If any foreign substance such as water has entered the appliance, cut-off the
power supply and contact the nearest service center.
 Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
 Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
 Failing to do so may result in electric shock, fire, problems with the product, or
injury.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 8 2014-03-12 오전 9:32:57

9
ENGLISH
FOR USING CAUTION
Do not place objects or devices under the indoor unit.
 Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least once a
year.
 Failing to do so may result in injury, death or property damage.
Do not stand on top of the appliance or place objects (such as laundry, lighted
candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the
appliance.
 This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
 This may result in electric shock.
Do not forcefully open the front panel while air conditioner is operating.
 This may cause damage to the product.
Do not spray volatile material such as insecticide onto the surface of the
appliance.
 As well as being harmful to humans, it may also result in electric shock, fire or
problems with the product.
Do not drink the water from the air conditioner.
 The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not disassemble
the remote controller.
Do not touch the pipes connected with the product.
 This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food, animals,
plants or cosmetics, or for any other unusual purposes.
 This may result in property damage.
Avoid directly exposing humans, animals or plants from the air flow from the air
conditioner for long periods of time.
 This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy efficiency.
칠레향 FAC MEMORY 냉난방_IBIM_EN_03892A(5).indd 9 2014-03-12 오전 9:32:57
