Samsung AR BXEA Series User manual

Air conditioner
Quick Guide
AR**BXEA**** / AR**BXFC****
•Thank you for purchasing this Samsung air conditioner.
•Before operating this unit, please read this manual carefully and retain it for future reference.

2
English
Preparation
Connecting SmartThings
1 Launch a QR code reader app and scan the QR code image on the product.
2 Try connecting the SmartThings app to the product.
Registering the product / Reading the manual / Connecting to Services
1 Launch a QR code reader app and scan the QR code image on the product.
2 Choose the desired menu from the Product Registration, Manual, Customer Support.
If you choose 'Manual' you can read the manual of the product you purchased.
NOTE
•We provide online manuals that can be accessed via your smartphone or our website to contribute
in reducing the usage of manuals in paper format, as part of efforts to save the Earth.

3
English
01
02
03
04
09
05
06
08
07
01 Air intake
02 Air filter
03 Tri-care filter (For AR**BXEA**** models)
04 WindFree panel
05 Airflow blade (up and down)
06 Airflow blade (left and right)
07 Power button/Remote control receiver
08 Room temperature sensor
09 Display
NOTE
•The product ships with two Tri-care filters and the
manual included.
Display
01
02 03 04
01 Temperature indicator (numeric)
Filter reset indicator ( )
Electricity consumption indicator (numeric /
For the multi system, usage time indicator)
Auto clean indicator ( )
Defrost indicator ( )
02 AI Auto indicator
03 Timer indicator
good’sleep indicator
04 Wi-Fi indicator
NOTE
•When the Wi-Fi is turned on, the indicator blinks
three times and then turns on.
The appearance of the actual product may differ slightly from the image below.
Indoor Unit Overview

4
English
Operating the Air Conditioner
02
01
Functions and Buttons
Function Button and Selection Display
Power On/Off
WindFree
Cooling In Cool/Dry/Fan mode ▶
AI Auto ▶ ▶ Select Auto.
Auto ▶ ▶ Select Auto.
Cool ▶ ▶ Select Cool.
Dry ▶ ▶ Select Dry.
Fan ▶ ▶ Select Fan.
Heat ▶ ▶ Select Heat.
Fast In Cool or Heat mode ▶
Eco In Cool or Heat mode ▶ ▶
▶ Select Eco. ▶
Quiet In Cool or Heat mode ▶ ▶
▶ Select Quiet. ▶
Electricity
consumption
check
In operation ▶ ▶ ▶
Select Usage. ▶
Usage time
check
In operation ▶ ▶ ▶
Select Usage. ▶
Beep ▶ ▶ Select Beep. ▶
01 Display
02 Button
NOTE
•Although Purify, Direct, Indirect
is displayed on the remote control
display, it is not available on this
model.
•Features may differ depending on
models.

5
English
Function Button and Selection Display
Display lighting ▶ ▶ Select Display. ▶
Wi-Fi
(SmartThings)
▶ Press and hold for 5 or more
seconds.
Wi-Fi (On/Off)
and ▶ Press and hold for
5 or more seconds.
Timed on/off
▶ Select On or Off ▶
(Set the duration.) ▶
good'sleep
In Cool or Heat mode ▶
(Select .) ▶
(Set the duration.) ▶

6
English
Cleaning
Auto clean function
Use the Auto clean function if the indoor unit produces odors.
Activating Auto clean
To activate Auto clean, press the (Options) button for at least 3 seconds.
The indoor unit display shows:
Canceling Auto clean
To cancel Auto clean while it is running, follow the procedure below:
▶Press and hold for 3 or more seconds.
Deactivating Auto clean
To deactivate Auto clean, follow the procedure below while the air conditioner is in operation or turned off:
▶ ▶ Select Clean. ▶
Cleaning the filter
Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit
display. The time between cleanings may vary, depending on the usage and environmental conditions.
Vacuum cleaner
Soft brush 30 minutes
Mild detergent

7
English
1 Slide the filter off of the unit.
2 Use a soft brush or vacuum cleaner to remove any dust or debris on the filter.
3 Soak the filter in a solution of water and mild detergent for 30 minutes.
4 Rinse the filter and let it air dry in a well-ventilated area that is out of direct sunlight.
5 Reinstall the filter.
6 Reset the filter-cleaning reminder:
In operation ▶▶ ▶ Select Filter Reset. ▶
Replacing the Tri-care filter (ForAR**BXEA**** models)
Slide a new Tri-care filter in the direction of arrow 2.
Replace Tri-care filters once every three years. Replacement cycle may differ depending on the environment
and usage time.
Tri-care filter
CAUTION
•Do not clean the Tri-care filterwith water. Failing to do so may result in damage to the filter.
NOTE
•To replace a Tri-care filter, purchase a new one at a service centre.
•To use the Tri-care filter for a long time in an environment where fish cooking and smoking cause odour,
ventilate the place by opening a window.

COUNTRY CALL OR VISIT US ONLINE AT
UK 0333 000 0333 www.samsung.com/uk/support
IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support
GERMANY 06196 77 555 77 www.samsung.com/de/support
FRANCE 01 48 63 00 00 www.samsung.com/fr/support
ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support
SPAIN 91 175 00 15 www.samsung.com/es/support
PORTUGAL 808 207 267 www.samsung.com/pt/support
LUXEMBURG 261 03 710 www.samsung.com/be_fr/support
NETHERLANDS 088 90 90 100 www.samsung.com/nl/support
BELGIUM 02-201-24-18 www.samsung.com/be/support (Dutch)
www.samsung.com/be_fr/support (French)
NORWAY 21629099 www.samsung.com/no/support
DENMARK 707 019 70 www.samsung.com/dk/support
FINLAND 030-6227 515 www.samsung.com/fi/support
SWEDEN 0771-400 300 www.samsung.com/se/support
POLAND 801-172-678* lub [phone]*
* (opłata według taryfy operatora) http://www.samsung.com/pl/support/
HUNGARY 0680SAMSUNG (0680-726-7864) www.samsung.com/hu/support
AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support
SWITZERLAND 0800 726 786 www.samsung.com/ch/support (German)
www.samsung.com/ch_fr/support (French)
CZECH 800 - SAMSUNG (800-726786) www.samsung.com/cz/support
SLOVAKIA 0800 - SAMSUNG (0800-726 786) www.samsung.com/sk/support
CROATIA 072 726 786 www.samsung.com/hr/support
BOSNIA 055 233 999 www.samsung.com/ba/support
North Macedonia 023 207 777 www.samsung.com/mk/support
MONTENEGRO 020 405 888 www.samsung.com/support
SLOVENIA 080 697 267 (brezplačna številka) www.samsung.com/si/support
SERBIA 011 321 6899 www.samsung.com/rs/support
ALBANIA 045 620 202 www.samsung.com/al/support
BULGARIA
0800 111 31 - Безплатен за всички оператори
*3000 - Цена на един градски разговор или според
тарифата на мобилният оператор
09:00 до 18:00 - Понеделник до Петък
www.samsung.com/bg/support
ROMANIA 0800872678 - Apel gratuit
*8000 - Apel tarifat în reţea www.samsung.com/ro/support
CYPRUS 8009 4000 only from landline, toll free
www.samsung.com/gr/support
GREECE 80111-SAMSUNG (80111 726 7864) only from land line
([phone] from mobile and land line
LITHUANIA 8-800-77777 www.samsung.com/lt/support
LATVIA 8000-7267 www.samsung.com/lv/support
ESTONIA 800-7267 www.samsung.com/ee/support
QUESTIONS OR COMMENTS?
This appliance is
filled with R-32.
